Premium PWC147MB User manual

WINE COOLER
REFRIGERADOR DE VINO
PWC147MBModel/Modelo:
This product is for domestic use only
Use & care manual
Important safeguards

Do not use extension cords.
Risk of child entrapment. Before you throw away your old wine cooler or freezer:
Take off the door.
Leave the shelves in place so that children may not easily climb inside.
--- Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear
of obstruction.
--- Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
--- Do not use electrical appliances inside the food storage compartments of the appliance,
unless they are of the type recommended by the manufacturer.
--- Do not damage the refrigerant circuit. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
--- Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
--- Use two or more people to move wine cooler.
--- The appliance is not intended for use by young children or infirm persons without supervision.
--- Young children should be supervised to ensure that they do not play with the appliance
--- If the supply cord or other components damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
Safety Warnings
Prohibition symbols
The symbol indicates prohibited matters, and behaviors that
are forbidden. Non-compliance with the instructions may
result in product damages or endangerment to the personal
safety of users.
Warning symbols
The symbol indicates matters that must be followed, and
behaviors that must be strictly executed in line with the
operation requirements. Non-compliance with the
instructions may result in product damages or endangerment
to the personal safety of users.
Note symbols
The symbol indicates matters to pay attention to, and
behaviors that shall be specially noted. Due precautions
are needed or minor or moderate injuries or damages of
the product will be caused.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
This chapter describes the important security matters to prevent
users from injury or property damage. Please understand fully the
following text (logo, icon) and comply with the safety warnings.
1

Safety warnings
Electricity related warnings
This chapter describes the important security matters to prevent
users from injury or property damage. Please understand fully the
following text (logo, icon) and comply with the safety warnings.
Do not pull the power cord when unplugging the wine cooler.
Please firmly grasp the plug and pull out it from the socket
directly.
Do not damage the power cord under any condition so as to
ensure safety use, do not use when the power cord is damaged
or the plug is worn.
Worn or damaged power cords shall be replaced in manufacturer-
authorized maintenance locations.
The power cord should be firmly contacted with the socket or else
fires might be caused. Please ensure that the grounding electrode
of the power socket is equipped with a reliable grounding line.
Please use a dedicated three-hole power socket which is 15A
or more and never share the power socket with any other
electrical appliances.
The wine cooler adopts 115V/60Hz AC power; voltage fluctuations
over the range of 115±10%V will cause malfunction or even damage.
Please turn off the valve of the leaking gas and then open the doors
and windows in case of leakage of gas and other flammable gases.
Do not unplug the wine cooler or other electrical appliances considering
that spark may cause a fire.
To ensure safety, it is not recommended to place regulators,
rice cookers, microwave ovens or other appliances at the top of the wine
cooler, those recommended by the manufacture are not included. Do not
use electrical appliances in the food pantry.
2
15A

Safety warnings
Use related warnings
Authorized demolition or renovation of the wine cooler is not prohibited.
It is forbidden to damage the refrigerant lines. The repair and
maintenance of the wine cooler must be carried out by professionals.
Damaged power cords must be replaced by the manufacturer, its
maintenance department or related professionals in order to avoid
danger.
The surrounding of the appliance or the embedded structure shall not
be obstructed while good ventilation shall be maintained.
The gaps between wine cooler doors and between doors and
wine cooler body are small. Never put your hand in these areas to
prevent squeezing the fingers. Please be gentle when closing or
opening the wine cooler door to avoid falling articles.
Do not pick foods or containers in the freezing chamber when the
wine cooler is running, especially metal containers in order to avoid
frostbite.
Do not allow children to enter or climb the wine cooler to prevent
children from being trapped inside the wine cooler or injured by falling
from the wine cooler.
Do not spray or wash the wine cooler; do not put the wine cooler in
moist places, or in places where it can easily be splashed with water so
as not to affect the electrical insulation properties of the wine cooler.
Do not place heavy objects on top of the wine cooler considering that
objectsmay fall when opening the door, and accidental injuries might
be caused.
Please pull off the plug in case of power failure or cleaning. Do not
connect the wine cooler to power supply within five minutes to prevent
damages to the compressor due to successive starts.
This chapter describes the important security matters to prevent users
from injury or property damage. Please understand fully the following
text (logo, icon) and comply with the safety warnings.
3

Safety warnings
Warnings related to placing items
Warnings related to disposal
The wine cooler's refrigerant and cyclopentane foam materials are combustible materials
and discarded wine coolers should be isolated from fire sources and can not be burned.
Please transfer the wine cooler to qualified professional recycling companies for processing to
avoid damages to the environment or other hazards.
Please remove the door of the wine cooler and shelves which shall be properly
placed to avoid accidents of children entering and playing in the wine cooler.
Corros ives
E x p lo sive s
Flammable
Blood
M e d i
c in e
biol
og ic a ls
Dry i
ce
D ry i
ce
This chapter describes the important security matters to prevent
users from injury or property damage. Please understand fully the
following text (logo, icon) and comply with the safety warnings.
4
Do not put flammable, explosive, volatile or highly corrosive items
in the wine cooler to prevent damages to the product or fire accidents.
Do not place flammable items near the wine cooler to avoid fires.
This product is for household refrigeration uses, mainly to be used for wine
storage, not for other purposes, such as storage of blood, drugs or biological
products.
Do not store or place dry ice in the wine cooler.
Any liquor with high alcohol content can only be stored and sealed upright.
Avoid plastic parts and cooler door seal being contaminated by oil. Otherwise
small holes will appear between plastic parts and cooler door seal.
Do not cover or close ventilation and exhaust holes.

Before using the wine cooler, remove all packaging materials including bottom
cushions and foam pads and tapes inside the wine cooler, tear off the
protective film on the door and the wine cooler body.
Installation Instructions
Placement
Install the wine cooler in a well-ventilated indoor place; the ground shall
be flat, and sturdy (rotate left or right to adjust the wheel for leveling if
unstable).
Keep away from heat and avoid direct sunlight. Do not place the wine cooler
in moist or watery places to prevent rust or reduction of the insulating effect.
The hot air from the side walls of the cooler shall be exhausted without restrictions, or
the compressor's power will increase and further increase power consumption. Thus
the distance between cooler and walls or neighboring furniture shall not be less than
4cm Wipe the wine cooler inside and outside with a warm moist rag (add a small
amount of detergent in the warm water and wipe clean with clean water at the end).
Please leave enough space to ensure easy opening .
Dimensions shown are for reference only.
The wine cooler shall stay still for half an hour before connecting 115V/60Hz
power when it is started for the first time.
The wine cooler shall run 2 to 3 hours before loading wine; the wine cooler
shall run for more than 4 hours in summer in advance considering that the
environmental temperature is high.
5
18.9inch
15.4inch 32.9inch
28.7inch

Lock key
Lighting mode key
Display area
Temperature-rise key Temperature-drop key
Temperature Control
Operations panel
6
Display Control
When connecting for the first time, the display screen will be on full display for 3 seconds, and the start-up tone will
ring, and then enter into the display of normal operation;
When in the lock state, the display screen will be cut-off if no key is touched for 30 seconds; the display screen will
recover the normal display if any key is pushed.
This cooler has a touch control on the glass door. Touch slightly when pressing the keys. Avoid touching or scratching the
area of the display panel with sharp things and keep it away from high magnetic fields and high humidity. Otherwise the
cooler may not operate normally.
Locking and unlocking
Except the lighting function, the following functions will be carried out under the unlock state.
Under the lock state, press the Lock key ( ) continuously for 3 seconds, the locking will be relieved; the
display area will flicker;
Under the unlock state, press the "Lock key ( )" continuously for 3 seconds to enter into the lock state;
" "
Switching between Fahrenheit temperature and Celsius temperature
Press the Temperature-rise key ( ) and the Temperature-drop key ( ) to finish the switch of the Celsius
temperature and Fahrenheit temperature; the display area will show the setting Fahrenheit temperature or
Celsius temperature under the current mode.
" " " "
Temperature setting
Press the Temperature-rise key ( ) , the temperature will increase 1℃ (or ). After locking, the cooler will
operate according to the setting value;
Press the "Temperature-drop key ( )" , the temperature will decrease 1℃ (or ℉). After locking, the cooler will
operate according to the setting value.
" " ℉
Setting range of the Celsius temperature: 5℃~18℃; setting range of the
Fahrenheit temperature: 41 ℉~65℉.
Memory function
The cooler has a power off memory function. After the power is on again, the cooler will work according to the setting
mode before the power-off.
Fault indication
If any fault code of the following table is displayed on the display area, it means the cooler has a fault.
Fault code
Description
E1 E4
Temperature sensor of the
refrigerator failure
Defrosting sensor of the
refrigerator failure
When the above faults are displayed on the screen, please do not disassemble to
check by yourself. Please contact the special maintenance personnel of the local after-
sales service company for maintenance.
Lighting mode
Press the Lighting mode key ( ) to turn on or turn off the light." "

Wine Cooler Features
Names of Components
7
entirely consistent with the picture, please refer to the actual object.
On the Wine Cooler you buy some of the features and accessories may not be
Temperature control display
Wine Shelf
Wine Basket
Adjustable feet

Proper use of the Wine Cooler
Bottles arrangement
Pay attention when arranging:
Do not let the bottlestouch the cabinet liner’s back in order to maintain good air circulation in the cooler.
The actual bottles distances may be different for bottles with different shape and size.
The bottle storage capacity in the wine cabinet is based on the following marked bottle size. Oversized bottlesmay
have an impact on the number of bottlesstored in the wine cabinet.
Φ30mm
Φ75mm 215mm
300mm
Useof temperature zones in the cooler
Due to different temperature zones generated due to air circulation in the cooler，the upper area's
temperature is the highest while the lower area has the lowest temperature.
Arrangement of beverages
Different beveragescan be stored from top to bottom as follows:
Strong red wine
Rose and mild red wine
White wine
Champagne and spritzer
We suggest to pour wine in temperaturesbelow serving temp, as the wine would warm up quickly when
pouring into a tumbler.
Practical skills for wine storage
Do not store bottled wine by box or case in the refrigerator.
The cork of the bottle shall always be moistened when putting into the cooler. Air space is not allowed between wine and cork.
The open-type bottle shelf is helpful, as it does not cut off air circulation. The air moisture that condensed on the bottle can be dried out swiftly.
The wine shall be allowed to rest before drinking: Place rose or red wine onto the table 2-5 hours before drinking and red wine 4-5 hours, so they can reach
suitable serving temp. White wine, on the contrary, can be served right on the table. Champagne shall always be stored in cooler and taken out only before
drinking.
Please notice that wine's temperature is always lower than ideal serving temp, as the temperature will immediately rise 1 to2 oC when pouring into a
tumbler.
8

Proper use of the Wine Cooler
Serving temperatures
The wine taste depends on the right pouring temperature; therefore it determines its flavor. We suggest the wineshave
reached the following temperatures when pouring:
Wine Kinds Serving Temp
18℃
17℃
16℃
15℃
14℃
12℃
11℃
10℃
9℃
8℃
7℃
Bordeaux red
Barolo Louis Family dry red wine/Barolo
Burgundy red/Bordeaux red
Port
Young Burgundy red
Young red wine
Young Beaujolais/all white wines with little residual sugar
Old white wines/Chardonnay
Sherry
Young white wines from late vintage
White wines Loire/Entre-deux-Mers
Pay attention to room temperature and ventilation
T
The cooler cannot operate normally in room temperature below +16℃.
If this happens, the temperature inside the refrigerator will become too low and cause
damage to the items that are sensitive to temperature.
When room temperature is higher than +32℃and humidity reaches 75%RH, it will cause
frost to condense on the cooler’s glazed door.
he Cooler shall be placed in qdry and ventilated room. The cooler cannot be put under direct sunlight or
next to a heat source (Such as radiator, stove, etc.), and a suitable insulation board shall be applied if
necessary.
Try to shorten opening times of the cooler's door.
Put beverage into the cooler after it has cooled down.
Energy Conservation
9

Notes
Do not use detergents or solvents with sand or acid.
The drain hole shall be cleaned regularly to ensure water can be drained. Clean the drain hole with
a thin stick or something similar.
Wine Cooler Maintenance
Disconnect the cooler
Unplug the power plug to disconnect the cooler.
Stop using the cooler
If the cooler is going to be left unused for a long time, please:
1.Unplug the cooler;
2.Clean the cooler;
3.Keep the cooler door open.
Clean the cooler
Dust behind the cooler and on the ground shall be timely cleaned to improve the cooling effect and
energy saving. The interior of the cooler should be cleaned regularly to avoid odor. Cleaning procedure
is below:
1.Unplug power plug or disconnect cutoff；
2.Clean the door seal with only clear water and give it a thorough wipe；
3.Use slightly warm water and a little dish soap to clean the cooler. Do not let water spill onto
operation control elements and panel on glazed door；
4.Reconnect and power cooler when cleaning is completed.
Do not use hard brushes, clean steel sponges, wire brushes, abrasives such
as toothpastes, organic solvents (such as alcohol, acetone, banana oil, etc.),
hot water, acid or alkaline items to clean the cooler considering that this may
damage the cooler surface and interior.
Do not rinse with water so as not to affect the electrical insulation properties.
10

Frequently asked questions
The following simple issues can be handled by the user. Please call the after-sale service
department if the issues are not settled.
Tips:
◆The wine cooler enclosure may emit heat during operation specially in summer;this is caused
by the radiation of the condenser, and it is a normal phenomenon.
◆Condensation: condensation phenomenon will be detected on the exterior surface and door
seals of the cooler when the ambient humidity is high; this is a normal phenomenon, and the
condensation can be wiped away with a dry towel.
◆Airflow sound: Refrigerants circulating in the refrigerant lines will produce eruption of sound and
grunts which is normal and does not affect the cooling effect.
◆Buzz: Buzz will be generated by a running compressor specially when starting up or shutting
down.
◆Clatter: The solenoid valve or electric switch valve will clatter which is a normal phenomenon
and does not affect the operation.
◆The refrigerating chamber will periodically frost and defrost (water drops will be generated on the
backside of the refrigerating chamber when defrosting) which are normal.
Inoperation
Odor
Foods in the refrigerating
chamber are frozen
Long-term operation
of compressor
The wine cooler door
can not be properly
closed.
Loud noises
Whether the cooler is plugged and connected to power;
Low voltage;
Failure power or tripping circuit
Odorous foods should be closely wrapped;
Whether foods are rotten;
Whether the interior shall be cleaned.
Whether the thermostat is over adjusted; Whether
food containing water is put inside the glass
partition.
It is normal that wine cooler operates for longer times
in summer when the ambient temperature is higher;
Frequent opening of wine cooler door.
Thick frost layer (defrost is needed)
The door is stuck by food packages;
Too much food;
Tilt wine cooler.
Whether the bottles are leveled, whether the wine
cooler is balanced;
Whether the wine cooler parts are properly placed.
11

Manual de uso y cuidado
Precauciones importantes
Éste producto es para uso doméstico únicamente
