Prepac SS-4824 User manual

Shoe Cubbie
Required Tools
Screwdrivers
Flat Head
Using a power screwdriver
will speed up assembly.
Caution
Do not over tighten any screw.
The last few turns of each screw
should be done very slowly or by hand.
Phillips Head
Optional Tools
DATE STAMP
Prepac Manufacturing Ltd.
6705 Dennett Place
Delta, BC V4G 1N4
LB-0670
2015-01-13
Model #
SS-4824
Assembly Instructions
CALL US FIRST
1-877-PREPAC1
1-877-773-7221
Mon - Fri 7am - 4pm PST
10am - 7pm EST
•For help with assembly
•If you have received a damaged or defective part or
are missing hardware.
We will process replacement parts
UPS Ground or mail.
Before you call please:
2) Note the
3) Review the contents of your shipment to determine
what you are missing.
in 2 business days or
less. Parts are shipped via
1) Record the following information from the shipping
label on the outside of the box. You will need it for
warranty purposes:
•Ship To Name
•Sales Order Number
product model number.
Hammer
This product is shipped in
1 carton
1 of 1
Online Option:
Fill out the Replacement Parts Order form in the Product
Support section of our website: www.prepacmfg.com

Profiled Top (1)
TP-0712 Black
TP-0762 Espresso
TP-0702 White
C1
Left Side (1)
SL-4141 Black
SL-4641 Espresso
SL-4041 White
C3
Front Stabilizer (1)
Black
KR-4641 Espresso
KR- 4041 White
KR- 4141
C6
Unfinished
ST-4541
Rear
Stabilizer (1)
C7
Right Side (1)
SR-4141 Black
SR-4641 Espresso
SR-4041 White
C4
Side Molding (2)
TR-4141 Black
TR-4641 Espresso
TR-4041 White
C8
C5
Bottom (1)
BT-4141 Black
White
BT-4641 Espresso
BT-4041
Cabinet Parts
C1
C2
C6
C4
C5
C8 C7
C8
C9 C10
C11
C2
Top Molding (1)
TR-0714 Black
TR-0764 Espresso
TR-0704 White
Backer (1)
BB-4141 Black
BB-4641 Espresso
BB-4041 White
C9
Vertical Divider (5)
DV-4141 Black
DV-4641 Espresso
DV-4041 White
C10
Horizontal Divider (2)
DV-4142 Black
DV-4642 Espresso
DV-4042 White
C11
C3
Page 2 of 12

Cabinet Hardware
Hardware Identification
2" Confirmat Screws
(6)
RM-0001
15mm Zinc Cam (8)
RM-0103
¾” Nail (18)
RM-0022
Screw Cover Caps (6)
RM-0226 Black
RM-0228 Espresso
RM-0008 White
Green Twister Dowel (8)
RM-0501
STEP 1 Estimated Time: 5 minutes
Insert cams into holes on left (C3) and right (C4) sides and
the unfinished side of the bottom (C5)
Make sure arrow on
cam faces hole for
connecting bolt
Plastic Dowels (10)
RM-0072
Screw green twister dowels into Left (C3) and Right (C4) Sides
C5
C3 C4
1a.
1b.
Page 3 of 12

STEP 2 Estimated Time: 5 minutes
Unlocked Locked
Turn 210°
C5
FRONT
2a.
2b.
Attach the LEFT SIDE (C3) to the bottom (C5) and tighten
cams using a FLAT HEAD screwdriver.
Repeat for the RIGHT SIDE (C4).
ONLINE
HELP
To see a video showing how to use cams and
connectors, visit Product Support on our website:
www.prepacmfg.com/support/assemblyvideos.html
C3
C4
Page 4 of 12

STEP 3 Estimated Time: 10 minutes
Attach front stabilizer (C6) to left and right sides (C3 & C4) with
Confirmat screws and add screw cover caps.
Attach unfinished rear stabilizer (C7) to bottom (C5) with Confirmat
screws and insert screw cover caps
3a.
3b.
C5
C6
C7
C3
C4
Page 5 of 12

STEP 4 Estimated Time: 5 minutes
Attach top to sides and lock cams
using a flat head screwdriver
Screw green twister dowels into the unfinished
side of the top (C1) where shown
4a.
4b.
C1
Unlocked Locked
Turn 210°
Page 6 of 12

STEP 5 Estimated Time: 10 minutes
Hammer plastic dowels halfway into side and top moldings
Attach top & side moldings.
Using your hands, apply even
pressure to moldings and press firmly
Do not use a
hammer
It may damage
the molding
5a.
5b.
NOTE:
The remaining holes on the top
will not be used.
Page 7 of 12

STEP 6 Estimated Time: 2 minutes
Assemble the shoe cubbies by interlocking the vertical and horizontal dividers as shown below.
FRONT
Finished
Edge
Finished
Edge
Page 8 of 12

STEP 7 Estimated Time: 5 minutes
Slide the assembled dividers into the cubbie bench from the back.
Make sure the finished edges are facing the front
FRONT
Finished
Edges
Page 9 of 12

STEP 8 Estimated Time: 2 minutes
Nail backer as indicated. You may have more nails than
are necessary
Page 10 of 12

This page intentiionally left blank
Page 11 of 12

CALL US
1-877-PREPAC1 (1-877-773-7221)
Mon - Fri 7am - 4pm PST
10am - 7pm EST
Email Us: [email protected]
Q. How do I clean your products?
A. We recommend that you simply wipe your products with a clean, damp cloth and then dry immediately with
another clean cloth to maximize the life span and look of your unit
Q. Can I paint or varnish your products?
A. Our products are made from durable composite woods with a laminate finish and therefore should not be
painted or varnished.
Q. Are they waterproof?
A. NO. If liquid is spilled and quickly wiped up, no damage will be done to your product. However, continuous
exposure to liquids or high humidity may cause damage to the board.
Give Us Your Feedback
Furniture Care Q&A
Thanks!
Page 12 of 12
