Preface
I
Preface
TabletNote Computer
T200C/T210C
T200V/T210V
Service Manual

Preface
II
Preface
Notice
The company reserves the right to revise this publication or to change its contents without notice. Information contained
herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven-
dor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are
they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or
reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publica-
tion, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of
their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement
of that product or its manufacturer.
Version 1.0
November 2003
Trademarks
Intel®and Pentium®are registered trademarks of Intel Corporation.
Windows®is a registered trademark of Microsoft Corporation.
Other brand and product names are trademarks and/or registered trademarks of their respective companies.

Preface
III
Preface
About this Manual
This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and
inspection of personal computers.
It is organized to allow you to look up basic information for servicing and/or upgrading components of the computer.
The following information is included:
Chapter 1, Introduction, provides general information about the location of system elements and their specifications.
Chapter 2, Disassembly, provides step-by-step instructions for disassembling parts and subsystems and how to upgrade
elements of the system.
Appendix A, Part Lists
Appendix B, T2X0C Schematic Diagrams
Appendix C, T2X0V Schematic Diagrams

Preface
IV
Preface
Related Documents
You may also need to consult the following manual for additional information:
User’s Manual on CD
This describes the computer’s features and the procedures for operating the computer and its ROM-based setup program.
It also describes the installation and operation of the utility programs provided with the computer.

Preface
V
Preface
Contents
Introduction ..............................................1-1
Overview .........................................................................................1-1
Model Differences ...........................................................................1-2
System Specifications T200C/T210C ............................................1-3
System Specifications T200D/T210D ............................................1-5
System Specifications T200V/T210V ............................................1-7
System Specifications T200H/T210H ............................................1-9
External Locator - Top View with LCD Open ..............................1-11
Rotating the LCD Swivel Screen ..................................................1-12
External Location - Front & Rear Views ......................................1-14
External Locator - Left & Right Views .........................................1-15
External Locator - Bottom View ...................................................1-16
T2X0C/T2X0D Mainboard Overview - Top ................................1-17
T2X0C/T2X0D Mainboard Overview - Bottom ...........................1-18
T2X0C/T2X0D Mainboard Overview - Top ................................1-19
T2X0C/T2X0D Mainboard Overview - Bottom ...........................1-20
T2X0V/T2X0H Mainboard Overview - Top ................................1-21
T2X0V/T2X0H Mainboard Overview - Bottom ...........................1-22
T2X0V/T2X0H Mainboard Overview - Top ................................1-23
T2X0V/T2X0H Mainboard Overview - Bottom ...........................1-24
Disassembly ...............................................2-1
Overview .........................................................................................2-1
Disassembly Steps ...........................................................................2-4
Removing the Battery ......................................................................2-5
Removing the Hard Disk .................................................................2-6
Removing the System Memory (RAM) ..........................................2-7
Removing the Intel WLAN Module (T2X0C/T2X0D Only) ..........2-8
Removing the Processor (T2X0C/T2X0D Only) ............................2-9
Part Lists ..................................................A-1
Part List Illustration Location ........................................................ A-1
Top (T200C) .................................................................................. A-2
Bottom (T200C) ............................................................................. A-3
14.1" LCD (T200C) ....................................................................... A-4
Hard Disk Drive (T200C) .............................................................. A-5
Top (T210C) .................................................................................. A-6
Bottom (T210C) ............................................................................. A-7
14.1" LCD (T210C) ....................................................................... A-8
Hard Disk Drive (T210C) .............................................................. A-9
Top (T200V) ................................................................................ A-10
Bottom (T200V) .......................................................................... A-11
14.1" LCD (T200V) ..................................................................... A-12
Hard Disk Drive (T200V) ............................................................ A-13
Top (T210V) ................................................................................ A-14
Bottom (T210V) .......................................................................... A-15
14.1" LCD (T210V) ..................................................................... A-16
Hard Disk Drive (T210V) ............................................................ A-17
T200C/T210C Schematic Diagrams ......B-1
System Block Diagram ...................................................................B-2
Pentium-M-1 ...................................................................................B-3
Pentium-M-2 ...................................................................................B-4
855GM-1 .........................................................................................B-5
855GM-2 .........................................................................................B-6
855GM-3 .........................................................................................B-7
DDR SODIMM ..............................................................................B-8
DDR Termination ...........................................................................B-9
LVDS, CRT ..................................................................................B-10

Preface
VI
Preface
Clock Generator ........................................................................... B-11
ICH4-1 .......................................................................................... B-12
ICH4-2 .......................................................................................... B-13
ICH4-3, HDD ............................................................................... B-14
USB2.0 Port ................................................................................. B-15
MDC, Mini PCI ............................................................................ B-16
LAN RTL8100BL ........................................................................ B-17
PCMCIA ENE CB710 ................................................................ B-18
PCM Socket, 4 IN 1 Socket ........................................................ B-19
SIO, BIOS .................................................................................... B-20
Touch Panel .................................................................................. B-21
Hitachi H8S .................................................................................. B-22
LED B’d, HOT KEY B’d, FAN, K/B .......................................... B-23
CODEC, AMP .............................................................................. B-24
+3VS, +5VS ................................................................................. B-25
+2.5V, +1.25V, 1.5V .................................................................... B-26
V_CORE/ +VCCP/ +1.2VS ......................................................... B-27
5V, 3.3V, +1.2, 1.5V .................................................................... B-28
Charger ......................................................................................... B-29
Hot Key ........................................................................................ B-30
Inverter ......................................................................................... B-31
LCD LED Board .......................................................................... B-32
T200V/T210V Schematic Diagrams ..... C-1
System Block Diagram ...................................................................C-2
VIA C3 (1 of 2) ..............................................................................C-3
VIA C3 (2 of 2) ..............................................................................C-4
VT8623 (1 of 3) ..............................................................................C-5
VT8623 (2 of 3) ..............................................................................C-6
VT8623 (3 of 3) ..............................................................................C-7
DDR SO-DIMM .............................................................................C-8
DDR Termination ...........................................................................C-9
LVDS Transmitter, Panel I/F ....................................................... C-10
Clock (W311 + W256) ................................................................ C-11
VT2835 (1 of 3) ........................................................................... C-12
VT2835 (2 of 3) ........................................................................... C-13
VT2835 (3 of 3) ........................................................................... C-14
All USB 2.0 Port .......................................................................... C-15
HDD, MDC, BT, Indicator, WLAN ............................................ C-16
LAN PHY VT6103 ...................................................................... C-17
PCMCIA ENE CB710 ................................................................. C-18
PCM Socket, 4 In 1 Socket .......................................................... C-19
SIO, BIOS, FIR ............................................................................ C-20
H8S / 2104LPC ............................................................................ C-21
Fan, CRT, Inverter, DC, Power_GD ........................................... C-22
Audio Codec VT1616 .................................................................. C-23
Touch Panel Controller ................................................................ C-24
System Power 1 ........................................................................... C-25
System Power 2 ........................................................................... C-26
System Power 3 ........................................................................... C-27
CPU VCORE ............................................................................... C-28
Charger ........................................................................................ C-29

Introduction
Overview 1 - 1
1.Introduction
1: Introduction
Overview
This manual covers the information you need to service or upgrade the T200C/T210C/T200D/T210D/T200V/T210V/
T200H/T210H TabletNote computer. Information about operating the computer (e.g. getting started, and the Setup util-
ity) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual
is shipped with the computer.
Operating systems (e.g. DOS, Windows 9x, Windows NT 4.0, Windows 2000, Windows XP, OS/2 Warp, UNIX, etc.) have
their own manuals as do application software (e.g. word processing and database programs). If you have questions about
those programs, you should consult those manuals.
The T200C/T210C/T200D/T210D/T200V/T210V/T200H/T210H TabletNote computer is designed to be upgradeable.
See “Disassembly” on page 2 - 1 for a detailed description of the upgrade procedures for each specific component.
Please note the warning and safety information indicated by the “” symbol.
The balance of this chapter reviews the computer’s technical specifications and features.

Introduction
1 - 2 Model Differences
1.Introduction
Model Differences
The differences between the model types are indicated in the table and pictures below.
Specifications
Designs
Feature/Model T200C
T210C
T200D
T210D
T200V
T210V
T200H
T210H
Processor Type Intel Pentium® M Intel Pentium® M VIA Antaur VIA Antaur
Touch Panel
Functionality
Supported
Yes No Yes No
Table 1 - 1
Model
Specifications
Figure 1 - 1
Design Differences
T200 Series T210 Series

Introduction
System Specifications T200C/T210C 1 - 3
1.Introduction
System Specifications T200C/T210C
Feature Specification T200C & T210C
Processor Types Intel Pentium® M Processor (478-pin) Micro-FCPGA
Package
(µ0.13) 0.13 Micron Process Technology, 1MB On-Die L2
Cache & 400MHz Front Side Bus - 1.3/ 1.4/ 1.5/ 1.6/ 1.7
GHz
Core Logic Intel® 855 GM + Intel 82801DBM (ICH4-M)
Security Security (Kensington® Type) Lock Slot BIOS Password
Memory Two 200 Pin DDR SODIMM Sockets
Supporting DDR 266 MHz Modules
Supporting 256/512MB DDR RAM Modules
Expandable up to 1024 MB
BIOS ACPI 4MB Flash ROM Insyde BIOS
LCD Flat Panel TFT - 14.1" XGA LCD with Built-in Touch Panel and Stylus Pen
Supporting 1024 * 768 dot resolution
LCD Swivel Hinge (allows conversion between Notebook and Tablet Modes)
Display Intel Chipset 855GM Integrated Graphics
Shared Video Memory Architecture Supporting up to 32MB (Default Setting 32MB)
Storage Easy Changeable 2.5" 9.5 mm (h) IDE HDD
Supporting Ultra DMA 66/100
Built-in 4-in-1 Card Reader for the following formats:
SD (Secure Digital)
MMC (Multi Media Card)
MS (Memory Stick)
SM (Smart Media Card)
Audio Integrated Direct Sound Audio Compliant with AC’97 2.2
2 Built-In Speakers
Keyboard,
Pointing Device &
Buttons
Winkey Keyboard
Built-In TouchPad
4 Hardware Buttons:
“Q” for screen rotation/power
Tab
Escape
Scroll Up/Scroll Down/Enter
Indicators 7 LED Indicators (Power/Suspend, Battery, HDD, Caps Lock, Scroll Lock, Num Lock, Wireless LAN)
Table 1 - 2
T200C/T210C
System
Specifications

Introduction
1 - 4 System Specifications T200C/T210C
1.Introduction
Interface &
Communication
Two USB 2.0/1.1 Ports
One Type-II PCMCIA 3.3V/5V Socket
One Stereo Headphone-Out Jack
One Monaural Microphone-In Jack
One RJ-11 (V.90 K56flex™) Jack for Fax/Modem
MDC Modem Module Supporting Wake On Ring
One RJ-45 Jack for 100M (Max) Fast Ethernet
Intel Pro 2100 (802.11b) Mini PCI Wireless LAN Module
One External (VGA) Monitor Port
One DC-in Jack
One Infrared FIR, IrDA 1.1 Transceiver
One Type II PCMCIA 3.3V/5V Socket Supporting
CardBus
Power
Management
Supports ACPI v1.0b
Supports Hibernate Mode
Supports Standby Mode
Supports Battery Low Sleep
Supports Resume From Modem Ring
Supports Resume From LAN
Close Cover Switch
Power Full Range AC adapter
AC Input 100~240V, 50~60Hz
DC Output 20V, 3.25A, 65W
One Primary Smart Lithium-Ion (1800mAH x 6 cells)
Battery Pack with Gas Gauge
Environmental
Spec
Temperature
Operating: 5°C ~ 35°C
Non-Operating: -20°C ~ 60°C
Relative Humidity
Operating: 20% ~ 80%
Non-Operating: 10% ~ 90%
Physical
Dimensions &
Weight
313 (w) x 265 (d) x 26.5/29.5(h) mm 2.3 Kg Without Battery
Optional PC Camera (factory option)
Smart Lithium-Ion Battery Pack)
Standard - 1800mAH x 6 cells (40W)
Optional - 1800mAH x 8 cells (53W)
Handwriting Recognition Utility
Car Adapter
MDC Module (factory option)
Intel Pro 2100 (802.11b) Mini PCI Wireless LAN Module
External FDD with USB Interface
External Slim Optical Drive with One of the Following
Options:
CD-ROM
DVD-ROM
CD-RW
Combo
DVD-RW
DVD+RW
Feature Specification T200C & T210C

Introduction
System Specifications T200D/T210D 1 - 5
1.Introduction
System Specifications T200D/T210D
Feature Specification T200D & T210D
Processor Types Intel Pentium® M Processor (478-pin) Micro-FCPGA
Package
(µ0.13) 0.13 Micron Process Technology, 1MB On-Die L2
Cache & 400MHz Front Side Bus - 1.3/ 1.4/ 1.5/ 1.6/ 1.7
GHz
Core Logic Intel® 855 GM + Intel 82801DBM (ICH4-M)
Security Security (Kensington® Type) Lock Slot BIOS Password
Memory Two 200 Pin DDR SODIMM Sockets
Supporting DDR 266 MHz Modules
Supporting 256/512MB DDR RAM Modules
Expandable up to 1024 MB
BIOS ACPI 4MB Flash ROM Insyde BIOS
LCD Flat Panel TFT - 14.1" XGA LCD
Supporting 1024 * 768 dot resolution
LCD Swivel Hinge (allows conversion between Notebook and Tablet Modes)
Display Intel Chipset 855GM Integrated Graphics
Shared Video Memory Architecture Supporting up to 32MB (Default Setting 32MB)
Storage Easy Changeable 2.5" 9.5 mm (h) IDE HDD
Supporting Ultra DMA 66/100
Built-in 4-in-1 Card Reader for the following formats:
SD (Secure Digital)
MMC (Multi Media Card)
MS (Memory Stick)
SM (Smart Media Card)
Audio Integrated Direct Sound Audio Compliant with AC’97 2.2
2 Built-In Speakers
Keyboard,
Pointing Device &
Buttons
Winkey Keyboard
Built-In TouchPad
4 Hardware Buttons:
“Q” for screen rotation/power
Tab
Escape
Scroll Up/Scroll Down/Enter
Indicators 7 LED Indicators (Power/Suspend, Battery, HDD, Caps Lock, Scroll Lock, Num Lock, Wireless LAN)
Table 1 - 3
T200D/T210D
System
Specifications

Introduction
1 - 6 System Specifications T200D/T210D
1.Introduction
Interface &
Communication
Two USB 2.0/1.1 Ports
One Type-II PCMCIA 3.3V/5V Socket
One Stereo Headphone-Out Jack
One Monaural Microphone-In Jack
One RJ-11 (V.90 K56flex™) Jack for Fax/Modem
MDC Modem Module Supporting Wake On Ring
One RJ-45 Jack for 100M (Max) Fast Ethernet
Intel Pro 2100 (802.11b) Mini PCI Wireless LAN Module
One External (VGA) Monitor Port
One DC-in Jack
One Infrared FIR, IrDA 1.1 Transceiver
One Type II PCMCIA 3.3V/5V Socket Supporting
CardBus
Power
Management
Supports ACPI v1.0b
Supports Hibernate Mode
Supports Standby Mode
Supports Battery Low Sleep
Supports Resume From Modem Ring
Supports Resume From LAN
Close Cover Switch
Power Full Range AC adapter
AC Input 100~240V, 50~60Hz
DC Output 20V, 3.25A, 65W
One Primary Smart Lithium-Ion (1800mAH x 6 cells)
Battery Pack with Gas Gauge
Environmental
Spec
Temperature
Operating: 5°C ~ 35°C
Non-Operating: -20°C ~ 60°C
Relative Humidity
Operating: 20% ~ 80%
Non-Operating: 10% ~ 90%
Physical
Dimensions &
Weight
313 (w) x 265 (d) x 26.5/29.5(h) mm 2.3 Kg Without Battery
Optional PC Camera (factory option)
Smart Lithium-Ion Battery Pack)
Standard - 1800mAH x 6 cells (40W)
Optional - 1800mAH x 8 cells (53W)
Handwriting Recognition Utility
Car Adapter
MDC Module (factory option)
Intel Pro 2100 (802.11b) Mini PCI Wireless LAN Module
External FDD with USB Interface
External Slim Optical Drive with One of the Following
Options:
CD-ROM
DVD-ROM
CD-RW
Combo
DVD-RW
DVD+RW
Feature Specification T200D & T210D

Introduction
System Specifications T200V/T210V 1 - 7
1.Introduction
System Specifications T200V/T210V
Feature Specification T200V & T210V
Processor Types VIA Antaur 1.0 GHz
Core Logic CLE266CE
Security Security (Kensington® Type) Lock Slot BIOS Password
Memory Two 200 Pin DDR SODIMM Sockets
Supporting DDR 266 MHz Modules
Supporting 256/512MB DDR RAM Modules
Expandable up to 1024 MB
BIOS ACPI 4MB Flash ROM Insyde BIOS
LCD Flat Panel TFT - 14.1" XGA LCD with Built-in Touch Panel and Stylus Pen
Supporting 1024 * 768 dot resolution
LCD Swivel Hinge (allows conversion between Notebook and Tablet Modes)
Storage Easy Changeable 2.5" 9.5 mm (h) IDE HDD
Supporting ATA-33/66/100
Built-in 4-in-1 Card Reader for the following formats:
SD (Secure Digital)
MMC (Multi Media Card)
MS (Memory Stick)
SM (Smart Media Card)
Audio AC’97 2.1 Compliant
2 Built-In Speakers
Keyboard,
Pointing Device &
Buttons
Winkey Keyboard
Built-In TouchPad
4 Hardware Buttons:
“Q” for screen rotation/power
Tab
Escape
Scroll Up/Scroll Down/Enter
Indicators 7 LED Indicators (Power/Suspend, Battery, HDD, Caps Lock, Scroll Lock, Num Lock, Wireless LAN)
Interface &
Communication
Two USB 2.0/1.1 Ports
One Type-II PCMCIA 3.3V/5V Socket
One Stereo Headphone-Out Jack
One Monaural Microphone-In Jack
One RJ-11 (V.90 K56flex™) Jack for Fax/Modem
MDC Modem Module Supporting Wake On Ring
One RJ-45 Jack for 100M (Max) Fast Ethernet
One External (VGA) Monitor Port
One DC-in Jack
One Infrared FIR, IrDA 1.1 Transceiver
One Type II PCMCIA 3.3V/5V Socket Supporting
CardBus
Table 1 - 4
T200V/T210V
System
Specifications

Introduction
1 - 8 System Specifications T200V/T210V
1.Introduction
Power
Management
Supports ACPI v1.0b
Supports Hibernate Mode
Supports Standby Mode
Supports Battery Low Sleep
Supports Resume From Modem Ring
Supports Resume From LAN
Close Cover Switch
Power Full Range AC adapter
AC Input 100~240V, 50~60Hz
DC Output 20V, 2.5A, 50W
One Primary Smart Lithium-Ion (1800mAH x 6 cells)
Battery Pack with Gas Gauge
Environmental
Spec
Temperature
Operating: 5°C ~ 35°C
Non-Operating: -20°C ~ 60°C
Relative Humidity
Operating: 20% ~ 80%
Non-Operating: 10% ~ 90%
Physical
Dimensions &
Weight
313 (w) x 265 (d) x 26.5/29.5(h) mm Min 2.2 Kg Without Battery Pack
Optional PC Camera (factory option)
Smart Lithium-Ion Battery Pack)
Standard - 1800mAH x 6 cells
Optional - 1800mAH x 8 cells
Handwriting Recognition Utility
Car Adapter
MDC Module (factory option)
802.11b Wireless LAN Module with USB Interface
External FDD with USB Interface
External Slim Optical Drive with One of the Following
Options:
CD-ROM
DVD-ROM
CD-RW
Combo
Feature Specification T200V & T210V

Introduction
System Specifications T200H/T210H 1 - 9
1.Introduction
System Specifications T200H/T210H
Feature Specification T200H & T210H
Processor Types VIA Antaur 1.0 GHz
Core Logic CLE266CE
Security Security (Kensington® Type) Lock Slot BIOS Password
Memory Two 200 Pin DDR SODIMM Sockets
Supporting DDR 266 MHz Modules
Supporting 256/512MB DDR RAM Modules
Expandable up to 1024 MB
BIOS ACPI 4MB Flash ROM Insyde BIOS
LCD Flat Panel TFT - 14.1" XGA LCD
Supporting 1024 * 768 dot resolution
LCD Swivel Hinge (allows conversion between Notebook and Tablet Modes)
Storage Easy Changeable 2.5" 9.5 mm (h) IDE HDD
Supporting ATA-33/66/100
Built-in 4-in-1 Card Reader for the following formats:
SD (Secure Digital)
MMC (Multi Media Card)
MS (Memory Stick)
SM (Smart Media Card)
Audio AC’97 2.1 Compliant
2 Built-In Speakers
Keyboard,
Pointing Device &
Buttons
Winkey Keyboard
Built-In TouchPad
4 Hardware Buttons:
“Q” for screen rotation/power
Tab
Escape
Scroll Up/Scroll Down/Enter
Indicators 7 LED Indicators (Power/Suspend, Battery, HDD, Caps Lock, Scroll Lock, Num Lock, Wireless LAN)
Interface &
Communication
Two USB 2.0/1.1 Ports
One Type-II PCMCIA 3.3V/5V Socket
One Stereo Headphone-Out Jack
One Monaural Microphone-In Jack
One RJ-11 (V.90 K56flex™) Jack for Fax/Modem
MDC Modem Module Supporting Wake On Ring
One RJ-45 Jack for 100M (Max) Fast Ethernet
One External (VGA) Monitor Port
One DC-in Jack
One Infrared FIR, IrDA 1.1 Transceiver
One Type II PCMCIA 3.3V/5V Socket Supporting
CardBus
Table 1 - 5
T200H/T210H
System
Specifications

Introduction
1 - 10 System Specifications T200H/T210H
1.Introduction
Power
Management
Supports ACPI v1.0b
Supports Hibernate Mode
Supports Standby Mode
Supports Battery Low Sleep
Supports Resume From Modem Ring
Supports Resume From LAN
Close Cover Switch
Power Full Range AC adapter
AC Input 100~240V, 50~60Hz
DC Output 20V, 2.5A, 50W
One Primary Smart Lithium-Ion (1800mAH x 6 cells)
Battery Pack with Gas Gauge
Environmental
Spec
Temperature
Operating: 5°C ~ 35°C
Non-Operating: -20°C ~ 60°C
Relative Humidity
Operating: 20% ~ 80%
Non-Operating: 10% ~ 90%
Physical
Dimensions &
Weight
313 (w) x 265 (d) x 26.5/29.5(h) mm Min 2.2 Kg Without Battery Pack
Optional PC Camera (factory option)
Smart Lithium-Ion Battery Pack)
Standard - 1800mAH x 6 cells
Optional - 1800mAH x 8 cells
Handwriting Recognition Utility
Car Adapter
MDC Module (factory option)
802.11b Wireless LAN Module with USB Interface
External FDD with USB Interface
External Slim Optical Drive with One of the Following
Options:
CD-ROM
DVD-ROM
CD-RW
Combo
Feature Specification T200H & T210H

Introduction
External Locator - Top View with LCD Open 1 - 11
1.Introduction
External Locator - Top View with LCD Open
2
6
3
4
1
9
7
10
58
11
6
8
T200C/T200V T210C/T210V
2
6
3
4
1
9
10
58
11
6
8
T200D/T200H T210D/T210H
7
Figure 1 - 2
Top View with LCD
Panel Open
1. Built-In PC Camera
(Optional)
2. LCD Swivel Screen
3. LED Power
Indicators
4. Cover Sensors
5. LCD Swivel Hinge
6. LCD Side Hinges
7. Power Button
8. Speakers
9. Keyboard
10. TouchPad and
Buttons
11. Built-In Microphone

Introduction
1 - 12 Rotating the LCD Swivel Screen
1.Introduction
Rotating the LCD Swivel Screen
1. Unlock the LCD side hinges & by moving them in the direction of the arrows.
2. Carefully rotate the LCD fully in the direction indicated by the arrow , then lock the side hinges & .
3. Move latches & in and to the left (if they are not already in this position), then push the LCD down to lock it in position.
Figure 1 - 3
Rotating the LCD
Swivel Screen
12
3
4 5

Lid Button
It is recommended
that the lid (left LCD
cover sensor) power
button to should be
set to “Do nothing” in
the Power Options
control panel.
This will prevent acci-
dentally triggering a
power saving mode
when you rotate the
LCD swivel screen.
1 2
3 1 2
4 5
