Prexiso P30M User manual

P30M
®
LASER DISTANCE MEASURE
IMPORTANT: Read before Using
2WARRANTY
LIMITED
YEARS
UNITS
CLEAR
OFF
ON
P30M

1
EN
Prexiso P30M
Table of Contents
Instrument Set-up ------------------------------ 2
Overview---------------------------------------------
Display---------------------------------------------------
Insert batteries ----------------------------------------
2
2
2
Operations ---------------------------------------- 3
Switching ON/OFF -----------------------------------
Unitsetting Change ----------------------------------
Change Measurement Reference ---------------
3
3
3
Measuring Functions ------------------------- 4
Measuring single distance------------------------
Continuous measuring------------------------------
Area------------------------------------------------------
Volume--------------------------------------------------
Pythagoras(2-point)----------------------------------
Pythagoras(3-point)----------------------------------
Clear-----------------------------------------------------
Addition/Subtraction ---------------------------------
4
4
4
5
5
6
6
6
Technical Data -----------------------------------
Message Codes ---------------------------------
Care -------------------------------------------------
Disposal -------------------------------------------
Warranty ------------------------------------------
7
7
7
7
7
Safety Instructions ----------------------------
Symbols used -----------------------------------------
Permitted use -----------------------------------------
Prohibited use ----------------------------------------
Hazards in use ---------------------------------------
Limits of use ------------------------------------------
Areas of responsibility -----------------------------
Electromagnetic Compatibility (EMC) ----------
FCC statement (applicable in U.S.) -------------
Laser classification ----------------------------------
Labelling ------------------------------------------------
8
8
8
8
8
8
9
9
9
10
10

P30M
Prexiso P30M
Display
Insert batteries
Battery
Units
Main line
Info
i
Measuring
Reference
Pythagoras
Area / Volume/
Pythagoras
(2-Point/3-Point)
Clear / Off
Display
On/ Measure /
Continuous
measuring
Units /
Measuring
Reference
Add/Sub
Instrument Set-up
Overview
The safety instructions and the user manual should be
read through carefully before the product is used for the
first time.
The person responsible for the product must ensure that
all users understand these directions and adhere to them.
Change
batteries when
battery symbol
is empty.
2
EN
+
-
Area /
Volume

Prexiso P30M
i
0.000 m
0' ''00 1/16
0 1/16 in
0.00 ft
Change the measurement reference
The system
default
measurements
start at the
bottom as a
reference point.
Press button
to change the
reference to
top for
measurement.
The measurement
and the system
recover to initial
setting.
Device is turned
OFF.
If the info icon appears with a number, observe the
instructions in section "Message Codes".
Example:
Switch between
the following units:
Operations
Switching ON / OFF
If no key is
pressed for
120 sec, the
device
switches off
automatically.
3
EN
Unit setting
OFF
3 sec
3 sec
1 2 3
ON

Aim active laser at target.
i
Stops continuous
measuring.
i
Measuring Functions
Measuring single distance
Target surfaces: Measuring errors can occur
when measuring to colourless liquids, glass,
styrofoam or semipermeable surfaces or when
aiming at high gloss surfaces. Against dark
surfaces the measuring time increases.
Continuous measuring
Area
The result is shown in the
main line and the measured
distance above.
The last value measured
is displayed.
Aim laser at first
target point.
Aim laser at
second target
point.
Aim active laser at target.
Prexiso P30M
4
EN
UNITS
1 2
m
29.99
3
3 sec
1
29.99
m
2 3
1x
1 2 3 4
24.352 m
2
5

i
Aim laser at
first target
point.
Aim laser at
second target
point.
The result is
shown in the
main line and
the measured
distance
above.
Measuring Functions
Volume
The result is shown in the main
line and the measured distance
above.
Pythagoras(2-point)
Aim laser at
first target
point.
Aim laser at
second target
point.
Aim laser at
third target
point.
78.694 m
3
7
2x
1 2 3 4 5 6
90° 90°
1 2 3 4
3x
25.286 m
Prexiso P30M 5
EN

Pythagoras(3-point)
Aim laser
at first
target
point.
Aim laser at
second target
point(Perpen-
dicular to the
measuring
surface).
Aim
laser at
third
target
point.
The result is
shown in the
main line and
the measured
distance
above.
The result is
shown in the
main line and
the measured
distance
above.
Measure
the first
data.
Then
measure
the
second
data.
Clear
Addition/subtraction
Press the “+”or “-”
button to
add/subtract next
measurement from
the previous data.
Press button to
undo last action.
1
4
9.999
—20.000
m
m
49.999
+20.000
m
1
29.999 m
3
20.000
m
2
or
m
90° 90°
1 2 3
90°
4 5
4x
26.868
m
Prexiso P30M
6
EN

*
Technical Data
The typical measurement uncertainty of ± 3 mm
is valid for measurements on white, diffusive,
reflective targets up to 5 m at low ambient light
and moderate temperatures. For distances
greater than 5 m, the measurement uncertainty
could increase additionally by 0.1 mm/m. In
unfavourable conditions (such as bright sunlight,
targets with poor reflectivity, or high or low
temperatures) the measurement uncertainty
could further increase up to ± 4 mm for distances
below 5 m and additionally by roughly 0.15
mm/m for distances greater than 5 m.
Troubleshooting Care
• Clean the device with a damp, soft cloth.
• Never immerse the device in water.
• Never use aggressive cleaning agents or
solvents.
Disposal
CAUTION
Flat batteries must not be disposed
of with household waste. Care for
the environment and take them to
the collection points provided in
accordance with national or local
regulations. The product must not
be disposed with household waste.
Dispose of the product
appropriately in accordance with
the national regulations in force in
your country. Adhere to the national
and country specific regulations.
Product specific treatment and
waste management can be
downloaded from our homepage.
Warranty
The Prexiso P30M has two-years
warranty.
For further information on this, contact
your dealer.Subject to change (drawings,
descriptions and technical data).
General
Range 0.3-30m
0.98-100ft
Measuring accuracy* ± 3 mm
± 1/8 in
Smallest unit displayed 1 mm
1/16 in
Laser class
Laser type
Autom. power switch-off
Continuous measuring
Area / Volume
Dimension (H x D x W)
2
635 nm, < 1 mW
after 120 s
yes
yes
Battery durability (2 x AAA) up to 3000
measurements
Weight
(without batteries)
Temperature range:
- Storage
- Operation
-10 to 60 °C
14 to 140 °F
0 to 40 °C
32 to 104 °F
110 x 45 x 24 mm
4.33 x 1.77 x 0.94 in
70 g / 0.15 lb
Prexiso P30M 7
EN
Potential issue table
ISSUE CAUSE ACTION
Hardware protection
after shocking Take out batteries
and insert again
Low battery Replace with
new batteries
Failure to
switch on
Trigonometric
function
calculation error
Measure correctlyCode 204
warning
All dashes shows
on display
Insufficient
On/Measure/Units
button press
Press the
On/Measure/Units
button firmly
Received signal
too weak/
Measuring time too long
Change target surface
(e.g. white paper)
Received signal
too strong
(target is too reflective)
Change target surface
Ambient light
is too strong Shadow target area
(e.g. white paper)
The object is out
of rated range Measure within rated range
Beam is moved too fast Move the measuring
tool slowly

Safety Instructions
The person responsible for the instrument
must ensure that all users understand
these directions and adhere to them.
Symbols used
The symbols used have the following
meanings:
WARNING
Indicates a potentially hazardous situation
or an unintended use which, if not avoided,
will result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation
or an unintended use which, if not avoided,
may result in minor injury and/or
appreciable material, financial and
environmental damage.
Important paragraphs which must be
adhered to in practice as they enable
the product to be used in a technically
correct and efficient manner.
Permitted use
• Measuring distances
Prohibited use
• Using the product without instruction
• Using outside the stated limits
• Deactivation of safety systems and
removal of explanatory and hazard
labels
• Opening of the equipment by using tools
(screwdrivers, etc.)
• Carrying out modification or conversion
of the product
• Use of accessories from other
manufacturers without express approval
• Deliberate dazzling of third parties; also
in the dark
• Inadequate safeguards at the surveying
site (e.g. when measuring on roads,
construction sites, etc.)
• Deliberate or irresponsible behaviour on
scaffolding, when using ladders, when
measuring near machines which are
running or near parts of machines or
installations which are unprotected
• Aiming directly in the sun
Hazards in use
WARNING
Watch out for erroneous measurements if
the instrument is defective or if it has been
dropped or has been misused or modified.
Carry out periodic test measurements.
Particularly after the instrument has been
subject to abnormal use, and before,
during and after important measurements.
CAUTION
Never attempt to repair the product
yourself. In case of damage, contact a
local dealer.
WARNING
Changes or modifications not expressly
approved could void the user’s authority
to operate the equipment.
Limits of use
Refer to section "Technical data".
The device is designed for use in areas
permanently habitable by humans. Do not
use the product in explosion hazardous
areas or in aggressive environments.
i
i
Prexiso P30M
8
EN

Safety Instructions
Areas of responsibility
Responsibilities of the person in
charge of the instrument:
• To understand the safety instructions on
the product and the instructions in the
User Manual.
• To be familiar with local safety regulations
relating to accident prevention.
• Always prevent access to the product by
unauthorised personnel.
Electromagnetic Compatibility
(EMC)
WARNING
The device conforms to the most
stringent requirements of the relevant
standards and regulations. However,
the possibility of causing interference
in other devices cannot be totally
excluded.
FCC statement (applicable in U.S.)
This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation.This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Responsibilities of the manufacturer
of the original equipment:
Prexiso AG
Fabrikstrasse 1
CH-8586 Erlen / Switzerland
Internet: www.prexiso-eu.com
The company above is responsible for
supplying the product, including the User
Manual in a completely safe condition.
The company above is not responsible for
third party accessories.
Prexiso P30M 9
EN

The device produces visible laser beams, which are emitted from the
instrument: It is a Class 2 laser product in accordance with:
Do not stare into the laser beam or direct it towards other people
unnecessarily. Eye protection is normally afforded by aversion
responses including the blink reflex.
Laser Class 2 products:
IEC60825-1 : 2014“Radiation safety of
laser products”
WARNING
Looking directly into the beam with optical aids
(e.g. binoculars, telescopes) can be hazardous.
CAUTION
Looking into the laser beam may be hazardous to
the eyes.
Wavelength
620 - 690 nm
Maximum radiant output power for classification
< 1 mW
Pulse duration
> 400 ps
Pulse repetition frequency
320 MHz
Beam divergence
0.16 x 0.6 mrad
Labelling
Subject to change (drawings, descriptions and
technical data) without prior notice.
Safety Instructions
Laser classification
Prexiso P30M
10
EN
Complies with 21 CFR 1040.10
and 1040.11 except for
conformance with IEC 60825-1
Ed. 3., as described in Laser
Notice No. 56, dated May 8,
2019
<1.0mW @ 620-690nm IEC/EN 60825-1: 2014
Prexiso AG
Fabrikstrasse 1
CH-8586 Erlen / Switzerland
P30M
Batteries: 2 x AAA GS-ADL
