Prexiso P20 User manual

P20
IMPORTANT: Read before Using
Questions, problems, missing parts?
Before returning to your retailer, call our customer service department
For English Version See Page 1.
P20

1
EN
Table of Contents
Instrument Set-up - - - - - - - - - - - - - - - - - - -2
Important Safety Instructions - - - - - - - - 1
Overview - - - - - - - - - - - - - - - - - - - - - - - - - -2
Display - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2
Insert batteries - - - - - - - - - - - - - - - - - - - - - - 2
Operations - - - - - - - - - - - - - - - - - - - - - - - - -3
Switching ON/OFF- - - - - - - - - - - - - - - - - - - -3
Message Codes - - - - - - - - - - - - - - - - - - - - - 3
Unit setting - - - - - - - - - - - - - - - - - - - - - - - - -3
Measuring Functions - - - - - - - - - - - - - - - - 4
Measuring single distance - - - - - - - - - - - - - -4
Permanent measuring - - - - - - - - - - - - - - - - -4
Area- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4
Volume- - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
T
echnical Data - - - - - - - - - - - - - - - - - - - - - -6
Message Codes - - - - - - - - - - - - - - - - - - - - -6
Care - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -6
Disposal - - - - - - - - - - - - - - - - - - - - - - - - - - -6
Warranty - - - - - - - - - - - - - - - - - - - - - - - - - - -6
S
afety Instructions - - - - - - - - - - - - - - - - - - 7
Symbols used - - - - - - - - - - - - - - - - - - - - - - -7
Permitted use - - - - - - - - - - - - - - - - - - - - - - - 7
Prohibited use- - - - - - - - - - - - - - - - - - - - - - -7
Hazards in use - - - - - - - - - - - - - - - - - - - - - -7
Limits of use - - - - - - - - - - - - - - - - - - - - - - - - 7
Areas of responsibility - - - - - - - - - - - - - - - - -8
Electromagnetic Compatibility (EMC) - - - - - 8
FCC statement (applicable in U.S.) - - - - - - - - 8
Laser classification - - - - - - - - - - - - - - - - - - - 9
Labelling- - - - - - - - - - - - - - - - - - - - - - - - - -9
Important Safety
Instructions
Do not use the product before you
have studied the Safety instructions
and the User Manual on the
enclosed CD or on our Homepage.
If you have no such manual, or it is in the wrong
language, please ask your agency for an appropriate
copy.
The product is permitted to use for skilled persons
only.
WARNING:
• It is a Class 2 laser product in accordance with
IEC 60825-1:2014
• Do not stare into the laser beam or direct it
towards other people unnecessarily.
LASER
2
• Don't dazzle other individuals.
• Looking directly into the beam
with optical aids can be
hazardous.
• Do not operate the product in
explosion hazardous areas or in
aggressive environments.
• Only use chargers recommended
by the manu-facturer to charge
the batteries.
• Keep extremities in a safe
distance from the moving parts.
• Watch out for erroneous
measurements if the product is
defective or if it has been
dropped or has been misused or
modified.
• Carry out periodic test measure-
ments. Particularly before, during
and after important measure-
ments.
• The product and batteries must
not be disposed of with
household waste.
Prexiso P20

2
EN
Instrument Set-up
Overview
The safety instructions and the user manual should be
read through carefully before the product is used for the
first time.
The person responsible for the product must ensure that
all users understand these directions and adhere to them.
Display
Insert batteries
Battery
Units
Main line
Info
+
+
-
-
i
Change batteries
when battery
symbol is
flashing.
Prexiso P20
P20
On / Measure /
Units
Display

3
EN
Operations
sedoCegasseMFFO/NOgnihctiwS
ON OFF
Device is turned
OFF.
4 sec
i
If no key is
pressed for
120 sec, the
device
switches off
automatically.
OFF
Device is turned
OFF.
4 sec
i
If the info icon appears with a number, observe
the
instructions in section "Message Codes".
Example:
Unit setting
4 sec
ON
Prexiso P20
ON
i
Switch
between the
following
units:
i
Make sure
the device is
off, if not,
press the
ON button 4
seconds to
turn it off.
Hold button
seconds, device will
be turned on with
Unit setting ready.
0.000 m
0‘00‘‘ 1/16
0 1/16 in
0.00 ft
0.000 m
0‘00‘‘ 1/16
0 1/16 in
0.00 ft

EN
Measuring Functions
Continuous Measuring
1
Aim active laser at target.
2
19.99 m
3
i
Target surfaces: Measuring errors can occur
when measuring to colourless liquids, glass,
styrofoam or semi-permeable surfaces or when
aiming at hight gloss surfaces. Against dark
surfaces the measuring time increases.
4
Prexiso P20

5
EN
Technical Data Message Codes
If the message Error does not disappear
after switching on the device repeatedly,
contact the dealer.
If the message InFo appears with a
number, press the Clear button and
observe the following instructions:
Care
•Clean the device with a damp, soft cloth.
•Never immerse the device in water.
•Never use aggressive cleaning agents
or solvents.
Disposal
CAUTION
Flat batteries must not be disposed of with
household waste. Care for the environ-
ment and take them to the collection points
provided in accordance with national or
local regulations.
The product must not be disposed with
household waste.
Dispose of the product appropri-
ately in accordance with the
national regulations in force in your
country.
Adhere to the national and country specific
regulations.
Product specific treatment and waste
management can be downloaded from our
homepage.
Warranty
The Prexiso P20 has a two-year warranty.
For further information on this, contact
your dealer.
Subject to change (drawings, descriptions
and technical data).
No. Cause Correction
252 Temperature too high Let device cool
down.
253 Temperature too low Warm device up.
255 Received signal too
weak, measuring time
too long
Change target
surface (e.g. white
paper).
Error Measurement outside
of measuring range
Correct range.
260 Laser beam inter-
rupted
Repeat measure-
ment.
Prexiso P20
* The typical measurement uncertainty of ± 3 mm is
valid for measurements on white, diffusive, reflective
targets up to 5 m at low ambient light and moderate
temperatures. For distances greater than 5 m, the
measurement uncertainty could increase additionally
by 0.1 mm/m. In unfavourable conditions (such as
bright sunlight, targets with poor reflectivity, or high or
low temperatures) the measurement uncertainty
could further increase up to ± 4 mm for distances
below 5 m and additionally by roughly 0.15 mm/m for
distances greater than 5 m.
General
Range 21 cm - 20 m
8’’ - 135’
Measuring accuracy* ± 3 mm
± 1/8’’
Smallest unit displayed 1 mm
1/16 in
Laser class 2
Laser type 635 nm, < 1 mW
Autom. power switch-off after 120 s
Continuous measuring yes
Dimension (H x D x W)
Battery durability (2 x AAA) up to 3000 measure-
ments
Weight
(without batteries)
Temperature range:
- Storage
- Operation
-25 to 70 °C
-13 to 158 °F
0 to 40 °C
32 to 104 °F
115 x 43.5 x 24.7 mm
4.52 x 1.71 x 0.97 IN
80.5 g / 2.84 oz

6
EN
Safety Instructions
The person responsible for the instrument
must ensure that all users understand
these directions and adhere to them.
Symbols used
The symbols used have the following
meanings:
WARNING
Indicates a potentially hazardous situation
or an unintended use which, if not avoided,
will result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation
or an unintended use which, if not avoided,
may result in minor injury and/or appre-
ciable material, financial and environ-
mental damage.
Important paragraphs which must be
adhered to in practice as they enable
the product to be used in a technically
correct and efficient manner.
Permitted use
•Measuring distances
Prohibited use
•Using the product without instruction
•Using outside the stated limits
•Deactivation of safety systems and
removal of explanatory and hazard
labels
•Opening of the equipment by using tools
(screwdrivers, etc.)
•Carrying out modification or conversion
of the product
•Use of accessories from other manufac-
turers without express approval
•Deliberate dazzling of third parties; also
in the dark
•Inadequate safeguards at the surveying
site (e.g. when measuring on roads,
construction sites, etc.)
•Deliberate or irresponsible behaviour on
scaffolding, when using ladders, when
measuring near machines which are
running or near parts of machines or
installations which are unprotected
•Aiming directly in the sun
Hazards in use
WARNING
Watch out for erroneous measurements if
the instrument is defective or if it has been
dropped or has been misused or modified.
Carry out periodic test measurements.
Particularly after the instrument has been
subject to abnormal use, and before,
during and after important measurements.
CAUTION
Never attempt to repair the product your-
self. In case of damage, contact a local
dealer.
WARNING
Changes or modifications not expressly
approved could void the user’s authority to
operate the equipment.
Limits of use
Refer to section "Technical data".
The device is designed for use in areas
permanently habitable by humans. Do not
use the product in explosion hazardous
areas or in aggressive environments.
i
i
Prexiso P20

Safety Instructions
7
EN
Areas of responsibility
Responsibilities of the person in
charge of the instrument:
•To understand the safety instructions on
the product and the instructions in the
User Manual.
•To be familiar with local safety regula-
tions relating to accident prevention.
•Always prevent access to the product by
unauthorised personnel.
Electromagnetic Compatibility
(EMC)
WARNING
The device conforms to the most stringent
requirements of the relevant standards
and regulations.
However, the possibility of causing inter-
ference in other devices cannot be totally
excluded.
FCC statement (applicable in U.S.)
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential instal-
lation.This equipment generates, uses and
can radiate radio frequency energy and, if
not installed and used in accordance with
the instructions, may cause harmful inter-
ference to radio communications.
However, there is no guarantee that inter-
ference will not occur in a particular instal-
lation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the interfer-
ence by one or more of the following
measures:
•Reorient or relocate the receiving
antenna.
•Increase the separation between the
equipment and receiver.
•Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced
radio/TV technician for help.
Prexiso P20

Safety Instructions
8
EN
Laser classification
The device produces visible laser
beams, which are emitted from the
instrument:
It is a Class 2 laser product in accor-
dance with:
• IEC60825-1 : 2007 „Radiation safety of
laser products“
Laser Class 2 products:
Do not stare into the laser beam or direct it
towards other people unnecessarily. Eye
protection is normally afforded by aversion
responses including the blink reflex.
WARNING
Looking directly into the beam with optical
aids (e.g. binoculars, telescopes) can be
hazardous.
CAUTION
Looking into the laser beam may be
hazardous to the eyes.
Labelling
Attach the laser sticker (a) of your country
language.
Laser Radiation
Do not stare into the beam
Laser class 2
acc. IEC 60825-1:2007
Maximum radiant power *: <1mW
Emitted wavelength: 620-690nm
Beam divergence: 0.16 x 0.6 mrad
Impulse duration: 0.2 x 10
-9
s - 0.8 x 10
-9
s
Prexiso P20
2
IEC 60825-1:2014
a
