Owner’s Manual

SAFETY GUIDELINES
Copyright©2006
PrideMobilityProductsCorp.
INFMANU2429/RevC/March06
Thesymbolsbeloware usedthroughout thisowner's manualand onthe powerchair toidentify warningsand important
information.Itis veryimportantforyou toreadthem andunderstandthem completely.
WARNING! Failure to follow designated procedures can cause either personal injury, component
damage, or malfunction (black symbol on yellow triangle with black border).
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause injury to personnel and/or damage to equipment (white symbol on blue dot
with white border).
PROHIBITED! These actions are prohibited. These actions should not be performed at any time
or in any circumstances. Performing a prohibited action can cause injury to personnel and/or
damage to equipment (black symbol with red circle and red slash).
SAFETY GUIDELINES
www.pridemobility.com Jazzy 1103 Ultra

Jazzy 1103 Ultra www.pridemobility.com 3
I. INTRODUCTION....................................................................................................................................4
II. SAFETY....................................................................................................................................................6
III. YOUR POWER CHAIR.......................................................................................................................16
IV. ASSEMBLY............................................................................................................................................21
V. COMFORT ADJUSTMENTS...........................................................................................................23
VI. BATTERIES AND CHARGING .......................................................................................................31
VII. OPERATION..........................................................................................................................................35
VIII.CARE AND MAINTENANCE ...........................................................................................................47
IX. WARRANTY...........................................................................................................................................53
CONTENTS
Thisowner’smanualiscompiledfromthelatestspecificationsandproductinformationavailableatthetimeofpublication.
Wereservetherighttomakechangesas theybecomenecessary.Anychangestoour productsmaycause slightvariations
betweentheillustrationsandexplanationsinthis manualandtheproductyouhavepurchased.

4 www.pridemobility.com Jazzy 1103 Ultra
I. INTRODUCTION
SAFETY
WELCOMEtoPrideMobilityProductsCorporation(Pride).Thepowerchairyouhavepurchasedcombinesstate-of-the-
artcomponentswithsafety,comfort,andstylinginmind.Weareconfidentthatthesedesignfeatureswillprovideyouwith
the conveniencesyou expectduring yourdaily activities.Once youunderstand howto safelyoperate andcarefor your
powerchair,itshould giveyou yearsof troublefree operationandservice.
Readandfollow allinstructions,warnings,andnotesinthismanual beforeattemptingtooperateyourpowerchair forthe
firsttime.In addition, yoursafetydepends upon you,as well as your provider, caretaker,orhealthcareprofessional in
usinggoodjudgement.
Ifthereis anyinformation inthismanual whichyou donotunderstand, orif yourequireadditional assistanceforsetupor
operation, pleasecontact yourauthorized PrideProvider. Failuretofollowtheinstructions inthismanualandthose
locatedonyourpowerchaircanleadto personalinjuryand/ordamagetothepowerchair,includingvoidingthe
warranty.
PURCHASER’S AGREEMENT
Byaccepting delivery of thisproduct, you promisethat you will notchange, alter, or modifythis product or removeor
renderinoperableorunsafeanyguards, shields,orothersafetyfeaturesofthisproduct;fail,refuse,orneglectto installany
retrofitkits fromtime totimeprovided byPride toenhance orpreserve the safeuse ofthis product.
INFORMATION EXCHANGE
Wewanttohearyourquestions,comments,andsuggestionsaboutthismanual.Wewould alsoliketohearaboutthesafety
andreliabilityof yournew powerchair,andabout theservice youreceivedfrom yourauthorized PrideProvider.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
products,and newoptions thatcan increaseyour abilitytouse andenjoy yourpower chair.Pleasefeel freetocontact us
atthe address below:
PrideMobilityProducts Corporation
Attn:CustomerCare Department
182SusquehannaAvenue
Exeter, PA18643-2694
[e-mail]
800-424-8205
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.

Jazzy 1103 Ultra www.pridemobility.com 5
I. INTRODUCTION
PRIDE OWNERS CLUB
Asan ownerof aPride product,you areinvitedto registeryour product'swarranty andenroll inthe PrideOwnersClub.
You may do so by filling out and returning your enclosed product registration card or by visiting Pride’s web site at
www.pridemobility.com.Asaregistered member, eachtimeyouvisitour site,youwillhaveaccess tothemostinteractive
andhonesteducationalvenueavailable todayforpeoplewithmobilityneeds,theirfamilies,andfriends.
Fromourhome page,select “OwnersClub”toentera pagededicated tocurrentand potentialPride productowners.You
willgainaccess tointerviews,stories, recreationideas,dailylivingtips,productand fundinginformation,and interactive
messageboards.These messageboardsinviteyouto communicatewithother Pridecustomersaswellas Priderepresen-
tativeswhoareavailableto assistyou withany questionsorconcerns youmay have.
MyAuthorizedPrideProvider:
Name:_______________________________________________________________________________
Address:_______________________________________________________________________________
Phone Number:_________________________________________________________________________
Purchase Date:__________________________________________________________________________

6 www.pridemobility.com Jazzy 1103 Ultra
II. SAFETY
PRODUCT SAFETY SYMBOLS
Thesymbolsbeloware usedonthepowerchairtoidentifywarnings,mandatoryactions,and prohibitedactions.Itis very
importantforyou toread andunderstandthem completely.
Corrosive chemicals contained in battery. Use only AGM or Gel-Cell batteries to reduce
the risk of leakage or explosive conditions.
This product has been tested and passed at an immunity level of 20 V/m.
Read and follow the information in the owner’s manual.
Maximum seating weight.
Locked and in drive mode.
Place unit on level ground and stand behind or to one side when changing from drive
mode to freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Battery Configuration:
TT
TT
T = Terminal Post
Connect Red wire to TT
TT
T with ++
++
+
Connect Black wire to TT
TT
T with ––
––
–

Jazzy 1103 Ultra www.pridemobility.com 7
II. SAFETY
Prevent personal injury and equipment damage. Do not connect an extension cord to the
AC/DC converter or the battery charger.
Do not remove anti-tip wheels.
Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while operating.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possible. Maintain and
store in a clean and dry condition.
Removal of grounding prong can create electrical hazard. If necessary, properly install an
approved 3-pronged adapter to an electrical outlet having 2-pronged plug access. Failure
to heed could result in personal injury and/or property damage.

8 www.pridemobility.com Jazzy 1103 Ultra
II. SAFETY
SAFETY
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairisastate-of-the-art life-enhancementdevicedesignedto increasemobility. Prideprovidesanextensive
varietyofproducts to best fit the individual needs ofthepower chair user. Please be aware that thefinal selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableofmaking sucha decision,andhis/her healthcareprofessional(i.e.,medicaldoctor,physicaltherapist, etc.).
Thecontentsof thismanual arebasedon theexpectationthatamobility deviceexperthas properlyfitted thepowerchair
totheuser andhasassisted theprescribinghealthcareprofessionaland/or theauthorizedPride Providerinthe instruction
processfor the use of theproduct.
Therearecertainsituations,includingsomemedicalconditions,wherethepowerchairuserwillneedto practiceoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusingyourpowerchairduringdailyactivities,youwillprobablyencounter situationsinwhichyouwillneed
somepractice.Simplytakeyourtimeandyouwillsoonbeinfullandconfidentcontrolasyoumaneuverthroughdoorways,
onand off ofelevators, up anddown ramps, andover moderate terrain.
Belowaresome precautions,tips,andother safetyconsiderationsthat willhelptheuserbecomeaccustomedto operating
thepowerchair safely.
Modifications
Pridehasdesignedandengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessories
isavailable from yourauthorized Pride Providerto further customizeyour power chairto better suityour needs and/or
preferences.However,underno circumstancesshould youmodify,add, remove,ordisable anyfeature, part,or function
ofyour powerchair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Unauthorized
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Getto knowthefeel ofyour powerchairand itscapabilities. Pride recommendsthat youperform a safetycheck before
eachuse tomakesure yourpower chair operatessmoothly and safely. SeeVIII. “Care andMaintenance.”
Performthefollowinginspections priortousingyourpower chair:
!Checkforpropertireinflation.Maintainbutdonotexceed35psi(2.4bar)ineachtire(ifequippedwithpneumatictires).
!Checkall electricalconnections. Makesure theyaretight andnot corroded.
!Checkall controller connectionsto the powerpod. Make surethey are securedproperly.
!Checkthe brakes. See VIII.“Care and Maintenance.”
!Checkbattery charge.See VI.“Batteries andCharging.”
NOTE: If you discover a problem, contact your authorized Pride Provider for assistance.

Jazzy 1103 Ultra www.pridemobility.com 9
II. SAFETY
Weight Limitations
Yourpowerchairisrated foramaximum weightcapacity.Pleaserefer tothespecifications tableforthis limit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not be held responsible for injuries and/or property
damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tire Inflation
Ifyourpower chairisequipped withpneumatictires,youshouldcheckor havetheair pressurecheckedregularly.Proper
inflationpressureswill prolongthelife ofyourtiresandhelpensurethe smoothoperationof yourpowerchair.
WARNING! It is important that 35 psi (2.4 bar) tire pressure be maintained in pneumatic tires at all
times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may burst. Failure to maintain 35 psi (2.4 bar) tire pressure in pneumatic tires at
all times may result in tire and/or wheel failure, causing serious personal injury and/or damage to
your power chair.
WARNING! Inflate your power chair drive tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in a
burst tire and/or personal injury.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesofinclination,designedforeasyandsafeaccess.Someramps
mayhaveturningswitchbacks(180-degree turns)that requireyouto havegood corneringskills onyourpower chair.
!Proceedwith extremecaution asyouapproach thedowngrade ofa ramp orother incline.
!Takewideswings withyourpowerchair’sfrontwheelsaroundanytight corners.Ifyoudo that,thepowerchair’srear
wheelswill followawidearc,not cutthe cornershort, andnot bumpinto orget hungup onanyrailingcorners.
!When driving down a ramp, keep the power chair’s speed adjustment set to the slowest speed setting to ensure a
safelycontrolleddescent.SeeVII. “Operation.”
!Avoid sudden stopsand starts.
Whenclimbinganincline,trytokeepyourpowerchairmoving.Ifyoumuststop, startupagainslowlyandthenaccelerate
cautiously.Whendriving downan incline,set yourpowerchair tothe slowestsetting anddrivein theforward direction
only. If your power chair starts to move down the incline faster than you anticipated or desired, allow it to come to a
completestopby releasingthe joystick,thenpush thejoystick forwardslightlyto ensurea safelycontrolleddescent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.
WARNING! Never travel down an incline backwards. This may result in personal injury.

10 www.pridemobility.com Jazzy 1103 Ultra
II. SAFETY
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated
in figure 1, do not, under any circumstances, exceed the incline guidelines or any other
specifications presented in this manual. Doing so could cause instability in your power chair,
resulting in personal injury and/or damage to your power chair.
Incompliance withtheAmericanswithDisabilitiesActof1990, allhandicap publicaccess rampsare requiredto havea
maximumslope of5° (8.7%).Therefore, Priderecommendsthatthemaximumslopeof anincline youattempt tosafely
ascend or descend on your power chair does not exceed 5° (8.7%). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 5°(8.7%) may put your power
chair in an unstable position and cause it to tip, resulting in personal injury
Yourpowerchairis equippedwith twopowerfulbrakesystems:
1. Regenerative— useselectricityto rapidlyslow thevehiclewhen thejoystickreturns tothecenter/stopposition.
2. DiscPark Brake—activatesmechanicallyafter regenerativebrakingslowsthevehicletonearstop,or whenpoweris
removedfromthesystemfor anyreason.
Cornering Information
Whileyour power chairis equipped withcaster wheelsandanti-tip wheels,excessively high corneringspeeds can still
createthe possibilityoftipping. Factorswhich affect thepossibility oftippinginclude, butare not limitedto: cornering
speed,steering angle(howsharplyyouare turning),uneven roadsurfaces, inclinedroad surfaces,riding froman areaof
low traction to an area of high traction (such as passing from a grassy area to a paved area – especially at high speed
whileturning),and abruptdirectionalchanges.Highcornering speedsarenot recommended.Ifyou feelthat youmaytip
over in a corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your power
chairfromtipping.
WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibility of a
tip or fall. To avoid personal injury and/or property damage, always exercise common sense when
cornering.
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with extreme
caution.
Freewheel Mode
Yourpowerchairisequippedwithtwomanualfreewheelleverstoallowformanualmaneuverabilitybyatrainedattendant.
Formoreinformationabouthow toplaceyourpowerchairinto andoutoffreewheelmode,seeIII.“YourPower Chair.”
Figure 1. Maximum Safe Slope (Ascending and Descending)
5 (8.7%)
Braking Information

Jazzy 1103 Ultra www.pridemobility.com 11
II. SAFETY
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. The chair could
roll uncontrollably on its own, causing personal injury.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktop,orasphalt.However,Priderecognizesthattherewillbetimeswhenyou willencounterothersurface
types.For thisreason, your powerchair isdesigned to performadmirably onpackedsoil, grass,and gravel.Feelfree to
useyour powerchairsafely onlawns andinpark areas.
!Reduceyour powerchair’sspeed whendriving onuneventerrainand/orsoft surfaces.
!Avoidtallgrassthatcanentangletherunninggear.
!Avoidlooselypacked graveland sand.
!Ifyoufeel unsureabouta drivingsurface,avoid thatsurface.
Stationary Obstacles (Steps, Curbs, etc.)
Proceedwith extreme cautionwhen driving near raisedsurfaces, unprotected ledgesand/or drop-offs (curbs,porches,
stairs,etc.). Thecorrectmethodforapproaching acurb isillustrated infigure 2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than two inches unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backward down any step, curb, or
other obstacle. This may cause the power chair to tip and cause personal injury.
Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach
Stairs and Escalators
Powerchairs are notdesigned to travelupor down stairsor escalators. Always usean elevator.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.

12 www.pridemobility.com Jazzy 1103 Ultra
II. SAFETY
Transfers
Transferring onto and off of your power chair requires a good
sense of balance.Always have an attendant or healthcare pro-
fessionalpresentwhilelearningtoproperlytransferyourself.
Toeliminatethepossibilityofinjury,Priderecommendsthatyouor
atrainedattendantperformthefollowingtasksbeforeattemptinga
transfer:
!Turnoffthepowertothecontroller.SeeVII.“Operation.”
!Ensure your power chair is not in freewheel mode. See III.
“YourPowerChair.”
!Turnbothcasterwheels towardthetransfer destinationtoim-
provepowerchairstabilityduring transfer.
Figure 4.IdealTransfer Position
!Makesurebotharmrests areflippedupor removedfromyour
powerchair.
!Flipup thefoot platformormove theleg restsaside; thiswill
helpto keepyour feetfrom gettingcaught onthe footrigging
duringthetransfer.
!Reduce thedistance betweenyourpower chairand theobject
youaretransferringonto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause the power
chair to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the foot rigging. Such use may cause the power
chair to tip and cause personal injury.
Motor Vehicle Transport
Priderecommendsthat youdonot remainseatedin yourpowerchairwhiletravelinginamotor vehicle.Thepower chair
shouldbe stowed in thetrunk of a caror in the backof a truck orvan with batteries removedand properly secured.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your power chair.
Doors
!Determineif thedoor openstoward or awayfrom you.
!Driveyourpowerchairgently andslowlyforwardtopush thedooropen.Ordriveyourpowerchairgentlyandslowly
backwardto pull the door open.

Jazzy 1103 Ultra www.pridemobility.com 13
II. SAFETY
Elevators
Modernelevators havea door edgesafety mechanismthat, when pushed,reopens theelevator door(s).
!Ifyou are in thedoorway of an elevatorwhen the door(s) beginto close, push onthe rubber door edgeor allow the
rubberdoor edge to contact thepower chair and the doorwill reopen.
!Usecarethat pocketbooks, packages, or powerchair accessories do not become caughtin elevator doors.
Lift/Elevation Products
Ifyouwillbe travelingwithyourpowerchair,you mayfinditnecessary tousealift/elevationproducttoaidintransporta-
tion.Pride recommends thatyou closely reviewthe instructions, specifications,and safety informationset forth bythe
manufacturerofthelift/elevationproduct beforeusingthatproduct.
Inclement Weather Precautions
Exposureofyour powerchairto inclementweatherconditionsshouldbe avoidedwheneverpossible. Ifsuddenlycaught
up in rain, snow, severe cold, or heat while operating your power chair proceed to shelter at the earliest opportunity.
Thoroughlydryyour powerchairbefore storing,charging,oroperatingyour powerchair.
WARNING! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery surfaces can
cause personal injury and/or damage to the power chair and electrical system. Maintain and
store your power chair in a dry and clean condition.
Positioning Belts
Yourauthorized PrideProvider,therapist(s),and otherhealthcare professionalsare responsiblefor determiningyour re-
quirementforapositioningbelt inorder tooperate yourpowerchair safely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.
Reaching and Bending
Neverreach,lean,or bendwhiledrivingyourpowerchair.Ifitis absolutelynecessarytoreach, lean,orbendwhile seated
onyour power chair, itis important to maintainastable center of gravityand keep the powerchairfrom tipping. Pride
recommendsthat the powerchairuser determine his/herpersonal limitations and practicebending and reachingin the
presenceofaqualified healthcareprofessional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by
reaching down between your knees. Movements such as these may change your center of gravity
and the weight distribution of the power chair. This may cause your power chair to tip, possibly
resulting in personal injury.
WARNING! Prevent personal injury! Keep your hands away from the tires when driving. Be aware
that loose fitting clothing can become caught in drive tires.

14 www.pridemobility.com Jazzy 1103 Ultra
II. SAFETY
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationaboutyour powerchair’sbatteries,seeVI.“Batteriesand Charging.”
WARNING! Power chair batteries are heavy. See specifications table. If you are unable to lift that
much weight, be sure to get help. Lifting beyond your capacity can result in personal injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging
a frozen battery may result in personal injury and/or damage to the battery.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts. Personal
injury and/or damage to the power chair may result.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.
Failure to do so may result in personal injury.
Prescription Drugs/Physical Limitations
Usersmustexercisecareand commonsensewhenoperatingapower chair.Thisincludesawarenessofsafetyissueswhen
takingprescribedor over-the-counterdrugsor whentheuser hasspecificphysical limitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol
Thepowerchairuser mustexercisecareand commonsensewhenoperating his/herpowerchair.Thisincludesawareness
ofsafetyissueswhileundertheinfluenceofalcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.

Jazzy 1103 Ultra www.pridemobility.com 15
II. SAFETY
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
ElectromagneticandRadio Frequency Interference can come from sources suchascellular phones, mobile two-way
radios(such aswalkie-talkies), radiostations, TVstations, amateurradio (HAM)transmitters, wirelesscomputer links,
microwavesignals, paging transmitters,and medium-range mobiletransceiversused by emergencyvehicles. In some
cases,thesewavescancauseunintendedmovementordamagetothecontrolsystem.Every electrically-poweredmobility
vehiclehasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.This
producthas beentested and haspassed atan immunitylevelof 20V/m.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Center on www.pridemobility.com. If
unintended motion or brake release occurs, turn the power chair off as soon as it is safe to do so. Call Pride
at 800-424-8205 to report the incident.

16 www.pridemobility.com Jazzy 1103 Ultra
III. YOUR POWER CHAIR
YOUR POWER CHAIR
The Jazzy 1103 Ultra has two main assemblies: the seat and the power base. See figures 5 and 6. Typically, the seat
assemblyincludesthe armrests,seatback,andseatbase.Thepower baseassemblyincludes twomotor/brakeassemblies,
twodrive wheels,two anti-tipwheels, twocaster wheels,two batteries,and theelectrical components.
SEATBACK
CONTROLLER
(VSI SHOWN)
REAR
SHROUD
ANTI-TIP WHEEL
DRIVEWHEEL
CASTER WHEEL
Figure 5.The Jazzy 1103 Ultra
JOYSTICK
FOOT PLATFORM
SEATBASE
ARMRESTS
FRICTION LOCK LEVER
SEATBACK
RELEASELEVER
SEAT ASSEMBLY
POWERBASE
ASSEMBLY

Jazzy 1103 Ultra www.pridemobility.com 17
III. YOUR POWER CHAIR
JAZZY1103ULTRASPECIFICATIONS
Suspension: ActiveTrac
DriveWheels: 10in.pneumatic,(10in.solidareoptional)
CasterWheels: 8in.solid,rear-mounted
Anti-tipWheels: 5in.solid,front-mounted
MaximumSpeed:¹ Upto4 mph
Brakes: “IntelligentBraking”electronicregenerative,discparkbrake
GroundClearance:² 2.5in.
TurningRadius:² 20.75in.
OverallSize:² Length:39in.(withfootplatform)
Width: 23 in.
SeatingOptions: PowerElevatingSeatSystem (standard)
Medium-BackSeat(optional)
LimitedReclineHigh-BackSeat(optional)
SynergySeatingSystems(optional)
TRU-BalancePowerPositioningSystems(optional)
SolidSeatPan(optional)
SpecialitySeat(optional)
Drivetrain: Twomotor, mid-wheeldrive
Batteries:³ Two12-volt,U-1batteries
Range:¹ Up to 25 miles
BatteryCharger: 4-amp,onboard (standard)
Off-board (optional)
Electronics: 50-ampPGDrivesVSIController(standard)
70-ampPGDrivesRemotePlus(optional)
70-ampPGDrivesMicrodrive(optional)
WeightCapacity: 300lbs. (standard)
200lbs.withTRU-BalancePowerPositioningSystems
160lbs.withSynergyManualTilt
ComponentWeights: Base: 97 lbs.
Medium-BackSeat:37lbs.(44lbs.withUniversalFrictionLockSeatPlate)
Batteries:24.5lbs.each
¹Varieswithuserweight,terrain type,batteryamp hourrating(AH), batterycharge,batterycondition,andtire condition.
²Due to manufacturing tolerances and continued product improvement, this specification can be subject to variance
of (+ or – ) 3%.
³AGMor Gel-Celltype recommended.
NOTE: All specifications subject to change without notice.

18 www.pridemobility.com Jazzy 1103 Ultra
III. YOUR POWER CHAIR
Figure 6. The Jazzy 1103 Ultra Power Base
MOTOR/BRAKEASSEMBLY
ARTICULATINGBEAM
POWER SEAT ACTUATOR
REARSHROUDFASTENERS
YELLOWFASTENER (LOCATED
UNDERFRONT SHROUD)
ELECTRICAL COMPONENTS
The electrical components are located on the power base. The ammeter and the charger power cord receptacle are
located on the right side of the power base. The main circuit breaker is located on the front of the battery tray. The
controllerconnector and the motorconnectors are locatedon the power pod,inside the powerbase.See figure 7.
Ammeter:Theammeter displaysthe charger’scurrent outputinamps. SeeVI.“Batteriesand Charging.”
ChargerPowerCordReceptacle:This iswherethe chargerpowercordplugs intotheonboard batterycharger. SeeVI.
“BatteriesandCharging.”

Jazzy 1103 Ultra www.pridemobility.com 19
III. YOUR POWER CHAIR
MainCircuitBreaker:Themaincircuitbreaker isasafetyfeaturebuilt intoyourpowerchair.Whenthebatteriesandthe
motorsareheavilystrained(e.g., fromexcessiveloads),themain circuitbreakertripstoprevent damagetothemotorsand
theelectronics.Ifthe circuittrips,allowyour powerchairto“rest” forapproximatelyoneminute.Next,pushinthecircuit
breakerbutton,turnonthe controller, andcontinue normaloperation.If themain circuitbreaker continuestotriprepeat-
edly,contactyourauthorizedPrideProvider.
MotorConnectors:This iswhere thecontrollerconnects tothe motors.Themotorconnectorsare color-codedwith red
andyellow labels.Thelabel coloron themotorconnector correspondswith the labelcolor onthe power pod.
BatteryConnector: This iswhere the controllerconnects tothe batteries.
PowerSeat Connector: This is where the powerseat actuator is connected tothe power pod.
ChargerInhibitConnector: Thechargerinhibit enablestheonboardchargerto disablethe controllerduring charging.
SeeVII. “Operation.”
BATTERY CONNECTOR
MOTOR CONNECTOR
CHARGERINHIBIT
CONNECTOR
AMMETER
CHARGER POWER
CORDRECEPTACLE
ONBOARD BATTERY CHARGER
CHARGERCIRCUIT FUSE(ATO)
Figure 7. Jazzy 1103 Ultra Electrical Components
MOTOR CONNECTOR
POWER POD
POWER SEAT CONNECTOR
CIRCUITBREAKER

20 www.pridemobility.com Jazzy 1103 Ultra
MANUAL FREEWHEEL LEVERS
Yourpowerchairhasamanualfreewheelleveroneachmotor.Manual freewheelleversenableyoutodisengagethedrive
motorsfromthegearboxes andmaneuverthechairmanually.
WARNING! Do not use the power chair while the drive motors are disengaged! Do not disengage
the drive motors when the power chair is on an incline, as the unit could roll on its own, causing
injury!
To engage or disengage the drive motors:
1. Locatethe lever on topof each motor.
2. Pushthe twolevers inwardto engagethe drivemotors.See figure8.
3. Pullthe twolevers outwardto disengagethe drivemotors. Seefigure 9.
Ifalever isdifficultto moveineither direction,slightlyrockthepowerchair backandforth. Thelevershould thenmove
tothe desiredposition.
WARNING! It is important to remember that when your power chair is in freewheel mode, the
braking system is disengaged.
III. YOUR POWER CHAIR
Figure 9. Freewheel Mode (Drive Disengaged)Figure 8. Drive Mode (Drive Engaged)
MANUALFREEWHEELLEVER
MANUALFREEWHEELLEVER
