SAFETY GUIDELINES
Copyright©2006
PrideMobility Products Corp
INFMANU2882/RevB/Feb06
Thesymbolsbelow areusedthroughoutthis owner'smanualandonthe powerchair toidentify warnings andimportant
information.Itisveryimportantfor you toreadthemandunderstand them completely.
WARNING! Failure to follow designated procedures can cause either personal injury, component
damage, or malfunction (black symbol on yellow triangle with black border).
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause injury to personnel and/or damage to equipment (white symbol on blue dot).
PROHIBITED! These actions should be prohibited. These actions should not be performed at any
time or in any circumstances. Performing a prohibited action can cause injury to personnel and/
or damage to equipment (black symbol with red circle and red slash).

Quantum 1107 www.quantumrehab.com 3
I. INTRODUCTION..................................................................................................................................... 4
II. SAFETY..................................................................................................................................................... 6
III. YOUR POWER CHAIR........................................................................................................................16
IV. ASSEMBLY/DISASSEMBLY............................................................................................................21
V. COMFORT ADJUSTMENTS............................................................................................................25
VI. BATTERIES AND CHARGING ........................................................................................................31
VII. OPERATION........................................................................................................................................... 35
VIII.CARE AND MAINTENANCE ............................................................................................................50
IX. WARRANTY............................................................................................................................................55
CONTENTS
Thisowner’smanualiscompiledfromthelatestspecificationsandproductinformationavailableatthetimeofpublication.
Wereservetherighttomake changes astheybecomenecessary.Anychangestoourproducts maycauseslightvariations
betweentheillustrationsandexplanationsinthis manual andtheproductyouhavepurchased.

4 www.quantumrehab.com Quantum 1107
I. INTRODUCTION
SAFETY
WELCOMEto QuantumRehab, adivision ofPride Mobility Products Corporation (Pride).The powerchair youhave
purchasedcombines state-of-the-artcomponents withsafety,comfort,and stylingin mind.Weare confidentthat these
designfeatureswillprovideyouwiththeconveniencesyouexpectduringyourdaily activities. Once youunderstandhow
to safelyoperateand care for your powerchair, itshould give you years oftrouble free operationand service.
Readandfollowallinstructions, warnings, and notesinthismanualbeforeattemptingtooperateyourpowerchairfor the
first time. Inaddition, your safetydepends upon you, as well as yourprovider,caretaker, or healthcare professional in
usinggoodjudgement.
Ifthereisanyinformation inthismanualwhich you donotunderstand,or if yourequireadditionalassistance for setupor
operation,pleasecontactyour QuantumRehabSpecialist. Failuretofollowtheinstructionsinthismanualandthose
locatedonyourpowerchaircanleadtopersonalinjuryand/ordamagetothepowerchair,including voidingthe
warranty.
PURCHASER’S AGREEMENT
Byaccepting delivery ofthis product, youpromise that youwill not change,alter,or modifythis product orremove or
renderinoperableorunsafeanyguards,shields,or other safety features of this product; fail,refuse,orneglecttoinstallany
retrofitkits from time to time provided byPride toenhance orpreserve thesafe useof thisproduct.
INFORMATION EXCHANGE
Wewanttohearyourquestions,comments,andsuggestionsaboutthis manual.Wewouldalsoliketohearaboutthesafety
andreliabilityofyour newpowerchair,and about theserviceyou received fromyourQuantum Rehab Specialist.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
products,and new optionsthat canincrease yourability touse and enjoyyour powerchair.Please feel freeto contactus
atthe addressbelow:
PrideMobilityProductsCorporation
Attn:CustomerCareDepartment
182SusquehannaAvenue
Exeter, PA18643-2694
[e-mail]
800-424-8205
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.

Quantum 1107 www.quantumrehab.com 5
I. INTRODUCTION
PRIDE OWNERS CLUB
Asan owner ofa Prideproduct, youare invitedto register yourproduct's warrantyand enrollin thePride OwnersClub.
You may do so by filling out and returning your enclosed product registration card or by visiting Pride's web site at
www.pridemobility.com.Asaregisteredmember,eachtimeyouvisitoursite,youwillhaveaccesstothemostinteractive
andhonesteducationalvenueavailabletodayforpeoplewithmobilityneeds,theirfamilies,andfriends.
Fromourhomepage, select“OwnersClub” toentera page dedicatedtocurrent andpotentialPride product owners.You
willgainaccesstointerviews, stories, recreationideas,dailylivingtips, product andfundinginformation,and interactive
messageboards.Thesemessage boards inviteyouto communicate withotherPride customers aswellas Pride represen-
tativeswhoare available toassist you withanyquestions orconcernsyou mayhave.
MyQuantum Rehab Specialist:
Name:_____________________________________________________________________________________
Address:___________________________________________________________________________________
Phone Number:______________________________________________________________________________
PurchaseDate:_______________________________________________________________________________

6 www.quantumrehab.com Quantum 1107
II. SAFETY
Corrosive chemicals contained in battery. Use only AGM or Gel-Cell batteries to
reduce the risk of leakage or explosive conditions.
This product has been tested and passed at an immunity level of 20 V/m.
Read and follow the information in the owner’s manual.
Maximum seating weight.
Locked and in drive mode.
Place unit on level ground and stand behind or to one side when changing from
drive mode to freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Battery Configuration:
TT
TT
T = Terminal Post
Connect Red wire to TT
TT
T with ++
++
+
Connect Black wire to TT
TT
T with ––
––
–
PRODUCT SAFETY SYMBOLS
Thesymbolsbelowareusedonthepower chair toidentifywarnings,mandatoryactions,andprohibitedactions. It isvery
importantforyouto readandunderstand them completely.

Quantum 1107 www.quantumrehab.com 7
II. SAFETY
Do not remove anti-tip wheels.
Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while
operating.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possible.
Maintain and store in a clean and dry condition.
Removal of grounding prong can create electrical hazard. If necessary, properly
install an approved 3-pronged adapter to an electrical outlet having 2-pronged
plug access. Failure to heed could result in personal injury and/or property
damage.
Prevent personal injury and equipment damage. Do not connect an extension
cord to the AC/DC converter or the battery charger.

8 www.quantumrehab.com Quantum 1107
II. SAFETY
SAFETY
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairisa state-of-the-art life-enhancementdevicedesignedtoincreasemobility.Prideprovidesanextensive
varietyof products to best fit the individual needs of the power chair user. Please be aware that the final selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableofmakingsuch adecision,andhis/her healthcareprofessional(i.e.,medical doctor,physical therapist,etc.).
Thecontentsofthis manualarebasedon theexpectationthata mobilitydeviceexpert has properlyfittedthe power chair
totheuserandhasassistedtheprescribinghealthcareprofessionaland/ortheQuantum Rehab Specialist intheinstruction
processfor the use ofthe product.
Therearecertain situations,includingsomemedicalconditions,wherethepowerchairuserwillneedtopracticeoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusing your power chairduringdailyactivities,youwillprobablyencountersituationsinwhichyouwillneed
somepractice.Simplytakeyourtimeandyouwillsoonbeinfullandconfidentcontrolasyoumaneuverthroughdoorways,
onand offof elevators, upand downramps, and over moderate terrain.
Belowaresomeprecautions,tips,and other safetyconsiderationsthatwillhelpthe userbecomeaccustomedtooperating
thepowerchairsafely.
Modifications
Pridehasdesigned andengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessories
isavailable from yourQuantum RehabSpecialist tofurther customizeyour power chairto bettersuit yourneeds and/or
preferences.However,undernocircumstances shouldyoumodify,add, remove,ordisable anyfeature,part, orfunction
ofyourpower chair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Unauthorized
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Getto knowthe feelof yourpower chairand itscapabilities. Pride recommends that you perform asafety checkbefore
eachuse tomake sureyour powerchair operatessmoothly andsafely.
Performthefollowinginspectionspriortousing your power chair:
!Checkforpropertireinflation.Maintainbutdonotexceed35psi(2.4bar)ineachtireifequippedwithpneumatictires.
!Checkall electrical connections.Make surethey aretight andnot corroded.
!Checkall controllerconnections to thepower base. Make sure theyare secured properly.
!Checkthe brakes. SeeVIII. “Care and Maintenance.”
!Checkbattery charge. SeeVI. “Batteriesand Charging.”
NOTE: If you discover a problem, contact your Quantum Rehab Specialist for assistance.

Quantum 1107 www.quantumrehab.com 9
II. SAFETY
Weight Limitations
Yourpowerchair is ratedforamaximum weight capacity.Pleasereferto the specificationstableforthislimit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not be held responsible for injuries and/or property
damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tire Inflation
Ifyourpowerchairis equipped withpneumatictires,youshould check orhavetheair pressure checkedregularly.Proper
inflationpressureswillprolongthe life ofyourtiresandhelp ensure thesmoothoperationof your powerchair.
WARNING! It is important that 35 psi (2.4 bar) tire pressure be maintained in pneumatic tires at all
times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may burst. Failure to maintain 35 psi (2.4 bar) tire pressure in pneumatic tires at
all times may result in tire and/or wheel failure, causing serious personal injury and/or damage to
your power chair.
WARNING! Inflate your power chair drive tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in a
burst tire and/or personal injury.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesofinclination,designedforeasyand safeaccess.Someramps
mayhaveturning switchbacks (180-degreeturns)that requireyouto havegoodcornering skillsonyour power chair.
!Proceedwith extreme caution as you approach the downgrade of a ramp or otherincline.
!Takewideswingswithyour power chair’s front wheelsaroundanytightcorners.Ifyoudothat,thepowerchair’srear
wheelswillfollow awidearc, notcut the cornershort, and notbump intoorget hungupon anyrailing corners.
!Whendriving down a ramp, keepthe power chair’s speedadjustment set to the slowestspeed setting toensure a
safelycontrolleddescent. See VII.“Operation.”
!Avoid sudden stopsand starts.
Whenclimbinganincline, trytokeepyourpowerchairmoving.Ifyoumuststop,startupagainslowlyandthenaccelerate
cautiously. When driving down an incline, set your power chair to the slowest speed setting and drive in the forward
directiononly.Ifyour power chairstartsto move downtheincline faster thanyouanticipated or desired,allowit to come
toacomplete stop byreleasing the joystick,then push thejoystick forward slightlytoensure asafelycontrolled descent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.
WARNING! Never travel down an incline backward. This may result in personal injury.

10 www.quantumrehab.com Quantum 1107
II. SAFETY
5 (8.7%)
Figure 1. Maximum Safe Slope (Ascending and Descending)
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated in
figure 1, do not, under any circumstances, exceed the incline guidelines or any other specifications pre-
sented inthis manual. Doingso couldcause instability inyourpowerchair, resulting inpersonalinjury and/
or damage to your power chair.
Incompliancewith theAmericans with DisabilitiesAct of1990,all handicappublic access rampsare requiredtohave a
maximumslopeof 5°(8.7%). Therefore, Priderecommends thatthemaximum slopeof an inclineyou attempttosafely
ascend or descend on your power chair does not exceed 5° (8.7%). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 5° (8.7%) may put your power
chair in an unstable position and cause it to tip, resulting in personal injury.
Braking Information
Yourpower chair isequippedwith twopowerfulbrake systems:
!Regenerative—useselectricity to rapidlyslowthe vehicle whenthejoystickreturns tothecenter/stopposition.
!DiscParkBrake—activatesmechanicallyafter regenerative brakingslowsthevehicletonear stop, orwhenpoweris
removedfromthe system foranyreason.
Cornering Information
Whileyour powerchair is equipped with casterwheels andanti-tip wheels, excessively high corneringspeeds canstill
createthe possibilityof tipping.Factors whichaffect the possibility of tippinginclude, butare notlimited to:cornering
speed,steeringangle (howsharplyyou areturning),uneven roadsurfaces, inclined roadsurfaces, riding froman areaof
lowtractiontoanareaof high traction(suchaspassingfrom a grassyareatoapaved area –especiallyathighspeedwhile
turning),andabruptdirectionalchanges.Highcorneringspeedsarenotrecommended.Ifyoufeelthatyoumaytipover in
a corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your power chair
fromtipping.
WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibility of a
tip or fall. To avoid personal injury and/or property damage, always exercise common sense when
cornering.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktop,or asphalt. However,Priderecognizesthattherewillbetimeswhenyouwillencounterothersurface
types.For thisreason, yourpower chairis designedto performadmirably onpacked soil,grass, and gravel. Feel free to
useyour powerchair safelyon lawnsand inpark areas.
!Reduceyourpower chair’sspeedwhen drivingonuneven terrainand/orsoft surfaces.
!Avoidtallgrassthatcanentangletherunninggear.
!Avoidlooselypacked graveland sand.
!Ifyoufeelunsureabout adrivingsurface,avoid that surface.

Quantum 1107 www.quantumrehab.com 11
II. SAFETY
Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach
Freewheel Mode
Yourpowerchairisequippedwitha manualfreewheelsystemtoallowformanualmaneuverabilitybyatrainedattendant.For
moreinformationabouthowtoplace your power chairintoandoutoffreewheelmode,seeIII.“YourPowerChair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. The chair could
roll uncontrollably on its own, causing personal injury.
Stationary Obstacles (Steps, Curbs, etc.)
Proceedwith extreme caution when drivingnear raised surfaces,unprotected ledges and/ordrop-offs (curbs, porches,
stairs,etc.).The correctmethodfor approachingacurb isillustratedin figure2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than two inches unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backward down any step, curb, or
other obstacle. This may cause the power chair to tip and cause personal injury.
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware that it
may be difficult for traffic to see you when you are seated on your power chair. Obey all local pedestrian
traffic rules. Wait until your path is clear of traffic, and then proceed with extreme caution.
Stairs and Escalators
Powerchairs arenot designed totravel upor down stairsor escalators.Alwaysusean elevator.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.
CURB CURB

12 www.quantumrehab.com Quantum 1107
II. SAFETY
Transfers
Transferringontoandoffofyourpowerchairrequiresagoodsense
ofbalance.Alwayshavean attendant orhealthcare professional
presentwhilelearningtoproperlytransferyourself.
To eliminate the possibilityofinjury,Priderecommendsthatyou
oratrained attendantperformthefollowingtasksbeforeattempt-
ingatransfer:
!Turnoffpowerto thecontroller.SeeVII.“Operation.”
!Ensureyour power chairis notin freewheelmode. SeeIII.
“YourPowerChair.”
!Turnbothcasterwheelstowardthetransferdestinationtoim-
powerchairstabilityduringtransfer.
!Make sure both armrests are flipped up or removed from
your power chair.
!Flipupthefootplatformormove the legrestsaside;thiswill
helptokeepyourfeetfromgettingcaughtonthefootrigging
duringthetransfer.
!Reduce thedistance between yourpower chair and the ob-
jectyouaretransferring onto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause the
power chair to tip and cause personal injury.
Figure 4.IdealTransfer Position
WARNING! Avoid putting all of your weight on the foot riggings. Such use may cause the power
chair to tip and cause personal injury.
Motor Vehicle Transport
Priderecommendsthatyou donotremain seatedinyour power chairwhiletraveling inamotor vehicle. Thepower
chairshould be stowed in the trunk of a car or in the back ofa truck orvan with thebatteries removed andproperly
secured.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your power chair.
Doors
!Determineif the door opens towardor awayfrom you.
!Driveyourpowerchairgentlyandslowlyforward to pushthedooropen.Ordriveyourpower chair gentlyandslowly
backwardto pull the dooropen.

Quantum 1107 www.quantumrehab.com 13
II. SAFETY
Elevators
Modernelevators havea dooredge safetymechanism that,when pushed,reopens theelevator door(s).
!Ifyou are inthe doorway ofan elevator when the door(s) begin to close, push on the rubber door edge or allow the
rubberdoor edge to contact the power chair and the door will reopen.
!Usecare that pocketbooks, packages, or power chair accessories do not become caught in elevator doors.
Lift/Elevation Products
Ifyouwillbetravelingwithyourpowerchair,youmayfinditnecessarytouse a lift/elevationproducttoaidintransporta-
tion.Pride recommendsthat you closely review theinstructions, specifications, and safety informationset forth by the
manufacturerofthelift/elevationproductbeforeusingthatproduct.
Positioning Belts
YourQuantum RehabSpecialist, therapist(s), andother healthcare professionals are responsible for determining your
requirementfora positioning beltin order tooperateyour powerchairsafely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.
Inclement Weather Precautions
Exposureofyourpower chair toinclementweatherconditions shouldbeavoidedwhenever possible.Ifsuddenlycaught
up in rain, snow, severe cold, or heat while operating your power chair proceed to shelter at the earliest opportunity.
Thoroughlydryyourpower chair beforestoring,charging,or operatingyourpower chair.
WARNING! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery surfaces can
cause personal injury and/or damage to the power chair and electrical system. Maintain and
store your power chair in a dry and clean condition.
Reaching and Bending
Neverreach,lean,orbendwhiledrivingyour power chair.If it isabsolutelynecessarytoreach,lean,orbend while seated
onyour power chair, it is important tomaintain a stable centerof gravity and keepthe power chair from tipping. Pride
recommendsthat the power chair user determine his/her personal limitations and practice bending and reaching in the
presenceofaqualifiedhealthcareprofessional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by
reaching down between your knees. Movements such as these may change your center of gravity
and the weight distribution of the power chair. This may cause your power chair to tip, possibly
resulting in personal injury.
WARNING! Prevent personal injury! Keep your hands away from the tires when driving. Be aware
that loose fitting clothing can become caught in drive tires.

14 www.quantumrehab.com Quantum 1107
II. SAFETY
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.
Failure to do so may result in personal injury.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts. Personal
injury and/or damage to the power chair may result.
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationaboutyourpower chair’sbatteries,seeVI.“Batteriesand Charging.”
WARNING! Power chair batteries are heavy. See specifications table. If you are unable to lift that
much weight, be sure to get help. Lifting beyond your capacity can result in personal injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging
a frozen battery may result in personal injury and/or damage to the battery.
Prescription Drugs/Physical Limitations
Usersmustexercisecareandcommonsensewhenoperatingapowerchair.This includes awareness ofsafetyissueswhen
takingprescribedorover-the-counterdrugs orwhentheuser has specificphysicallimitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations.Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol
Thepowerchairusermustexercisecareandcommon sense when operatinghis/herpowerchair.Thisincludesawareness
ofsafetyissues whileundertheinfluenceofalcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.

Quantum 1107 www.quantumrehab.com 15
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
Electromagneticand Radio Frequency Interference can come from sources such as cellular phones, mobile two-way
radios(suchas walkie-talkies),radio stations,TV stations, amateurradio (HAM)transmitters, wireless computerlinks,
microwavesignals, paging transmitters, and medium-rangemobile transceivers usedby emergency vehicles. In some
cases,thesewavescan cause unintended movementordamagetothecontrolsystem.Everyelectrically-poweredmobility
vehiclehasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.This
producthas beentested andhas passedat animmunity levelof 20V/m.
WARNING! Be aware that cell phones, two-way radios, laptops, and other sources of radio
transmitters may cause unintended movement of your electrically powered mobility vehicle due
to EMI. Exercise caution when using any of these items while operating your mobility vehicle and
avoid coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, visit the Resource Center on www.pridemobility.com. If unintended motion or
brake release occurs, turn your power chair off as soon as it is safe to do so. Call Pride at 800-424-8205 to report the incident.
II. SAFETY

16 www.quantumrehab.com Quantum 1107
III. YOUR POWER CHAIR
THE QUANTUM 1107
TheQuantum1107hastwomainassemblies:theseat assemblyandthepowerbaseassembly. Seefigure5.Typically,the
seatassemblyincludesthearmrests, seatback, andseatbase.The power baseassemblyincludestwo motor/brake assem-
blies,twodrive wheels,two anti-tip wheels,two casterwheels,two batteryboxes, and wiringharnesses. Seefigure5, 6,
and 7.
Figure 5.The Quantum 1107
SEAT ASSEMBLY
POWERBASE
ASSEMBLY
ARMRESTS
FOOT PLATFORM
ANTI-TIP WHEELS
DRIVE WHEEL
CASTER WHEEL
SEATBACK
CONTROLLER
SEATBASE

Quantum 1107 www.quantumrehab.com 17
III. YOUR POWER CHAIR
QUANTUM1107SPECIFICATIONS
Suspension: Active-Trac
DriveWheels: 10in.,pneumatic,(10in.,solidareoptional)
CasterWheels: 6in.,solid,rear-mounted
Anti-tipWheels: 5in.,solid,front-mounted
MaximumSpeed:¹ Up to4.5mph
Brakes: “IntelligentBraking”electronicregenerative,discparkbrake
GroundClearance:² 2.5in.
MaximumSafeSlope: 5°(8.7%)
TurningRadius:² 20.5in.(withoutfootriggings)
OverallSize:² Length:36.625in.(withoutfootriggings)
Width: 23 in.
SeatingOptions: SpecialtySeat
LimitedReclineHigh-BackSeat
FullReclineHigh-BackSeat
SynergySeatingSystems(ManualTiltisoptional)
SynergyTRU-BalancePowerPositioningSystems
Drivetrain: Twomotor, mid-wheeldrive
Batteries: Two12-volt,U-1batteries(AGMorGel-Celltyperecommended)
Range:¹ Up to 25 miles
BatteryCharger: 5-amp,off-boardpowercube
Electronics: 75-ampPrideFLIGHTController
70-ampPGDrivesVSIController
70-ampPGDrivesRemotePlusController
70-ampMicrodriveController
WeightCapacity: 300lbs.
160lbs.withSynergyManualTilt
ComponentWeights: Base: 112 lbs. (right section 43 lbs.; left section 43 lbs.; center section 17 lbs.; battery boxes 4.5 lbs. each)
Specialty Seat: 37 lbs.
Batteries:29lbs.each
¹Varieswithuserweight,terrain type,batteryamphourrating (AH), batterycharge,batterycondition, and tirecondition.
²Dueto manufacturing tolerances andcontinued product improvement, thisspecification can be subjectto a variance
of (+ or – ) 3%.
NOTE: All specifications subject to change without notice.

18 www.quantumrehab.com Quantum 1107
Figure 6.The Quantum 1107 Power Base
SIDEFRAMEHANDLES
BATTERY BOXES
FRONT TRAPEZE BAR
MANUAL
FREEWHEELLEVER
MOTOR/BRAKEASSEMBLY
CONTROLLERCABLE
CONNECTOR
III. YOUR POWER CHAIR

Quantum 1107 www.quantumrehab.com 19
III. YOUR POWER CHAIR
Electrical Components
Theelectrical components consist of the controller assembly,the batteries, and themotors.Thebatteries, motors, and
controller power module (if equipped)are located on the power base assembly. See figures 6 and 7. The controller is
locatedon theseat assembly.Connectivity betweenthe controller and the motors,the batteries,and the battery charger
isprovided by one or more wiring harnesses.
ControllerCable Connector: The controller cable connector is wherethe controller plugs into the power base.Each
controllerusesadifferenttype of harness.Ifthecontrollerhas a powermoduleinthepower base, theconnectorisasmall
communications-typeconnector.Ifthecontrollerisintegrated,thenthe harness has alarge9-pinconnector.Regardlessof
whichtypeofcontrollerisused,theharnessmustbesecuredtotheseatassemblyand not allowed todragonthefloor.
BatteryHarnessConnector: This is where thecontroller connects tothe battery boxes.
Figure 7. Quantum 1107 Electrical Components
BATTERY HARNESS
CONNECTOR
CONTROLLERCABLECONNECTOR
MOTOR
CONNECTOR
MOTOR CONNECTOR
CONTROLLERPOWERMODULE

20 www.quantumrehab.com Quantum 1107
MainCircuitBreaker(locatedonrearbatterybox):The maincircuitbreakeris a safetyfeaturebuiltinto yourpower
chair.Whenthebatteries and themotorsareheavilystrained (e.g.,fromexcessiveloads),the maincircuitbreakertripsto
preventdamageto themotors and theelectronics. Ifthe circuit trips,allow yourpower chair to“rest” forapproximately
oneminute. Next, pushin the circuitbreaker button, turnon the controller, and continuenormal operation. Ifthe main
circuitbreakercontinuesto triprepeatedly,contact your QuantumRehabSpecialist.
ControllerPowerModule:The controllerpower module enablesthe controllertocommunicate withthe batteries and
themotors.
MotorConnectors:This iswhere themotors connectto thecontroller powermodule.
Manual Freewheel Levers
Your power chair has a manual freewheel lever on each motor. See figure 6. Manual freewheel levers enable you to
disengagethedrivemotorsfromthegearboxesandmaneuver the chair manually.
WARNING! Do not use the power chair while the drive motors are disengaged! Do not disengage
the drive motors when the power chair is on an incline, as the unit could roll on its own, causing
injury!
To engage or disengage the drive motors:
1. Locatethe lever ontop of eachmotor.
2. Pullthe two leversupward toengage thedrive motors.See figure 8.
3. Pushthe two leversdownward todisengage thedrive motors.See figure9.
Ifaleverisdifficult to moveineitherdirection, slightly rockthepowerchair back and forth.Thelevershould then move
tothedesired position.
WARNING! It is important to remember that when your power chair is in freewheel mode, the
braking system is disengaged.
III. YOUR POWER CHAIR
Figure 8. Drive Mode (Drive Engaged) Figure 9. Freewheel Mode (Drive Disengaged)
MANUALFREEWHEELLEVER
MANUALFREEWHEELLEVER
