Pro-Elec PELL0012 User manual

6 LED MOTION SENSOR LIGHT
PELL0012
Please read these instructions carefully before use and retain for future reference.
• Avoid locations of high temperature or humidity.
• If the light output becomes less bright or ashes, replace the batteries.
• Always remove the batteries if the light is not to be used for long periods.
• Never mix new and old batteries or mix different battery types.
• Slide the shield down the body and unscrew the lens unit from the main body and
insert the batteries into the holder noting the correct polarity.
• The light will illuminate initially for 30 seconds before resuming it’s motion detection in
low light normal function.
• Replace the lens unit and turn clockwise to lock into place.
• Ret the shield.
IMPORTANT SAFETY INFORMATION
INSTALLATION

OPERATION
MAINTENANCE
SPECIFICATION
• The motion sensor will turn on the light when movement is detected only in low light
environments.
• After motion ceases to be detected, the light will
extinguish after 25 seconds.
• Clean the unit only with a soft dry cloth. Do not use any chemicals, abrasives or
solvents that could damage the casing or lens.
Power supply: 4×AA batteries (NOT included)
Material: ABS, PS
Light Source: 6×F5 High Brightness LEDs
Output power: 50 lumen
Ambient light: <10LUX
Sensor distance: 0-5m
Sensor angle: 120°
Time delay: 25±2 sec (Auto-delay function)
Product weight: 208g
Product size H x W x D: 190×88×110mm
IP rating IP44
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF
ELECTRICAL & ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China. PR2 9PP
Man Rev 1.0
• Drill 2 holes the wall 55mm apart vertically in the required location with regard to any
concealed wiring or pipework, use wall plugs if required and screw in two dome head
screws leaving the heads 4mm proud of the surface.
• Locate the keyhole slots in the base of the light unit over the screw heads and ensure
the light is securely xed.
• Adjust the angle of the dummy camera head unit as required.
