QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satisfac-
tion through our Customer
Service Department.
Please CALL:
0345-089009
Or WRITE:
ICON Fitness Lifestyle Ltd.
Greenwich House
223 North Street
Sheepscar
West Yorkshire
Leeds LS7 2AA
Model No. PFEVEX34080
Serial No.
Write the serial number in the
space above for future reference.
Class H C Fitness Product
Serial
Number
Decal

2
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
HOW TO USE THE PROFORM®870E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
MAINTENANCE AND TROUBLE-SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
HOW TO ORDER REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
®

47
1
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
20
21
22
22
24
23
25
25
26
26
28
27
29
30
38
37
40
42
43
65
65
45
46
46
48
53
54
54
55
55
55
44
44
44
56
57
58
56
61 61
33
34
35
35
35
2
35
35
35
35
41
41
44
44
62
60 52
51
61
50
59
59
31
39
37
36
36
32
49
46
49
56
34
64
63
66
EXPLODED DRAWING—Model No. PFEVEX34080 R0798A
15

14
PART LIST—Model No. PFEVEX34080 R0798A
Key No. Qty. Description
1 1 49” Drive Belt
2 3 M4 x 38mm Screw
3 1 Seat Knob w/Pin
4 1 Reed Switch w/Wire
5 1 Console
6 1 Resistance Knob w/Cable
7 4 M4 x 16mm Screw
8 1 Seat
9 1 Seat Post
10 1 Seat Collar
11 1 Seat Tube Spacer
12 1 Spring
13 1 Frame
14 1 Flywheel
15 2 Round Endcap
16 1 Rear Stabiliser
17 2 Foam Grip
18 1Handlebar
19 1Handlebar Post
20 1 Left Pedal w/Strap
21 1Right Pedal w/Strap
22 1Crank
23 1 Right Side Shield
24 1Left Side Shield
25 2 Adjustable Endcap
26 2 Wheel
27 1Front Stabiliser
28 1 “J” Bolt
29 1Idler Arm
30 1Flywheel Axle
31 1 Flywheel Cover
32 1 M4 x 25mm Screw
33 1 Magnet
34 1 Crank Bearing Assembly
Key No. Qty. Description
35 11 M4 x 16mm Washer Head Screw
36 2 608 Bearing
37 2 Idler Pulley Washer
38 1 Flywheel Spacer
39 2 M6 Nut
40 1 “C” Magnet
41 2 M10 x 45mm Button Head Bolt
42 1 Idler Pulley
43 2 5/16” Push Nut
44 6 M10 Nylon Locknut
45 3 3/8” Locknut
46 3 M10 Washer
47 2 Handlebar Endcap
48 1 12” Pulley
49 2 M6 x 16mm Self-tapping Screw
50 1 Pulse Monitor
51 1 Resistance Hook
52 1Clamp Nut
53 2Hex Jam Nut
54 4 M10 x 75mm Carriage Bolt
55 5M10 x 22mm Button Head Bolt
56 4M8 Nylon Locknut
57 1 M8 x 43mm Hex Head Bolt
58 1M6 x 64mm Hex Head Bolt
59 3 M8 Lock Washer
60 4 #8 Flat Washer
61 5M10 Lock Washer
62 1 Clamp Bolt
63 1Left Pedal Strap
64 1Right Pedal Strap
# 1 User’s Manual
# 1 Caution Decal Sheet
# 1 Warning Decal Sheet
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of this manual for information about ordering replacement parts.

3
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following important precautions before
using the PROFORM®870E exercise cycle.
1. Read all instructions in this manual before
using the exercise cycle. Use the exercise
cycle only as described.
2. It is the responsibility of the owner to ensure
that all users of the exercise cycle are ade-
quately informed of all precautions.
3. Use the exercise cycle indoors, away from
moisture and dust. Place the exercise cycle
on a level surface, with a mat beneath it to
protect the floor or carpet from damage.
4. Inspect and tighten all parts regularly.
Replace any worn parts immediately.
5. Keep children under the age of 12 and pets
away from the exercise cycle at all times.
6. The exercise cycle should not be used by
persons weighing more than 250 pounds.
7. Wear appropriate clothing when exercising;
do not wear loose clothing that could become
caught on the exercise cycle. Always wear
athletic shoes for foot protection.
8. The pulse monitor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse monitor is intended only
as an exercise aid in determining heart rate
trends in general.
9. Always keep your back straight when using
the exercise cycle. Do not arch your back.
10. If you feel pain or dizziness at any time
whilst exercising, stop immediately and
begin cooling down.
11. The exercise cycle is intended for in-home
use only. Do not use the exercise cycle in a
commercial, rental or institutional setting.
12. The decal shown below has been placed on
the exercise cycle. If the decal is missing, or
if it is not legible, please call our Customer
Service Department at 0345-089009 to order
a free replacement decal. Apply the decal in
the location shown.
WARNING: Before beginning this or any exercise program, consult your physician. This is espe-
cially important for persons over the age of 35 or persons with pre-existing health problems. Read
all instructions before using. ICON assumes no responsibility for personal injury or property dam-
age sustained by or through the use of this product.

4
BEFORE YOU BEGIN
Thank you for selecting the innovative PROFORM®
870E exercise cycle. Cycling is one of the most popu-
lar and effective exercises for improving cardiovascu-
lar fitness and toning the body. The PROFORM®870E
blends advanced engineering with contemporary
styling to let you enjoy the benefits of this exercise in
the convenience and privacy of your home.
Please read this manual carefully before you use
the PROFORM®870E. If you have additional ques-
tions, please call our Customer Service Department at
0345-089009. To help us assist you, please mention
the product model number and serial number when
calling. The model number is PFEVEX34080. The ser-
ial number can be found on a decal attached to the
PROFORM®870E (see the front cover of this manual
for the location of the decal).
Before reading further, please familiarise yourself with
the parts that are labeled in the drawing below.
a
a
a
a
a
a
a
a
a
a
a
a aaa
a
a
a
a
a
a
a
a
a
a
a
aa
a
a
a
a
a
a
a
a
a
a
aa
a
a
a
a
a
a
a
a
a
a
a
a
aaa
a
a
a
a
a
a
a
a
a
a
a
aa
a
a
a
a
a
a
a
a
a
a
aa
a
a
a
a
a
a
a
a
Handlebars
Resistance Knob
FRONT
BACK RIGHT SIDE
Seat Knob
Seat
Seat Post
Pedal
Console
Front Wheels
Side Shield
Leveling Cap
Pulse Monitor w/Clothes Clip

Next, locate the Reed Switch (4). Turn the arms of the
Crank (22) until the Magnet (33) is aligned with the
Reed Switch. Loosen but do not remove the indicated
Screw (35). Slide the Reed Switch slightly closer to or
away from the Magnet. Retighten the Screw. Turn the
Crank for a moment. Repeat until the console displays
correct feedback. When the Reed Switch is correctly
adjusted, reattach the left side shield, flywheel cover
and left pedal.
HOW TO ADJUST THE DRIVE BELT
The exercise cycle features a Drive Belt (1) that must
be kept properly adjusted. If the Drive Belt slips as you
pedal, it should be adjusted. To do this, the left side
shield and the flywheel cover must be removed. Refer
to the instructions on page 12 and remove these parts.
Next, locate the Drive Belt (1). To tighten the Drive
Belt, turn the 3/8” Locknut (47) slightly; be careful not
to overtighten the Drive Belt. When the Drive Belt is
properly adjusted, reattach the left side shield, flywheel
cover and left pedal.
13
1
1
45
4
22
35
33
View from the Front View from the Back

12
Inspect and tighten all parts of the exercise cycle
regularly. Replace any worn parts immediately.
The exercise cycle can be cleaned with a soft, damp
cloth. Avoid spilling liquid on the console. Keep the
console out of direct sunlight or the display may be
damaged. Remove the batteries when storing the
exercise cycle.
PULSE MONITOR TROUBLE-SHOOTING
If the pulse monitor does not function properly, try the
following measures:
• make sure that the pulse monitor is plugged fully into
the left side of the console.
• rub your left ear lobe and reposition the pulse monitor.
• Make sure to attach the clothes clip to your collar to
prevent excessive movement of the wire.
• It may also be helpful to stop pedaling whilst you
measure your pulse.
• Replace the batteries.
If the pulse monitor still does not function properly, it
may need to be cleaned. Press the monitor open, and
find the two small plastic “bubbles” inside. Wipe the
bubbles using a cotton swab and water.
BATTERY REPLACEMENT
If the console does not function properly, replace the
batteries (see assembly step 5 on page 6).
HOW TO LEVEL THE EXERCISE CYCLE
If the exercise
cycle does not sit
flat on the floor,
try turning one or
both of the
Adjustable
Endcaps (25) at
the front of the
exercise cycle
until the exercise
cycle is level.
HOW TO TIGHTEN THE CRANK
If the arms of the
Crank (22)
become loose,
they should be
tightened in order
to prevent exces-
sive wear. Loosen
the two Hex Jam
Nuts (53) on the
left arm of the
Crank. Place the
end of a standard
screwdriver in one of the slots in the outer bearing
nut. Tap the screwdriver with a hammer to turn the
Outer Bearing Nut counterclockwise until the arms are
no longer loose. Do not overtighten the Outer
Bearing Nut. When the Outer Bearing Nut is properly
tightened, retighten the Hex Jam Nut.
HOW TO ADJUST THE REED SWITCH
If the console does not display correct feedback, the
reed switch should be adjusted. To adjust the reed
switch, the Left Side Shield (24) and the Flywheel
Cover (31) must be removed. Using an adjustable
wrench, turn the Left Pedal (20) clockwise and
remove it. Next, remove the indicated Screws (2, 32,
35, 49). Turn the left arm of the Crank (22) to the
position shown and slide off the Left Side Shield and
the Flywheel Cover.
MAINTENANCE AND TROUBLE-SHOOTING
Outer
Bearing Nut
53
22
24
20
2
35
49
22
31
25
32

Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the
packing materials until assembly is completed.
Assembly requires the included allen wrench , a phillips screwdriver and two adjustable
spanners .
5
1. Make sure that there are Adjustable Endcaps (25)
on the ends of the Front Stabiliser (27).
Attach the Front Stabiliser (27) to the saddle on the
front of the Frame (13) with two M10 x 75mm
Carriage Bolts (54) and two M10 Nylon Locknuts
(44).
2. Make sure that there are Round Endcaps (15) on
the ends of the Rear Stabiliser (16).
Hold the Rear Stabiliser (16) against the saddle on
the rear of the Frame (13), with the square holes
facing away from the saddle. Attach the Rear
Stabiliser with two M10 x 75mm Carriage Bolts (54)
and two M10 Nylon Locknuts (44).
ASSEMBLY
56
1
27
25
25
44
13
13
54
54
44
15
16
Square
Holes
15
2
13
9
56 56
59 59
10
8
3
3
3. Turn the Seat Knob (3) counterclockwise several
turns to loosen it. Next, pull back the Seat Knob and
insert the Seat Post (9) into the Frame (13). Slide
the Seat Post to the desired height and release the
Seat Knob. Move the Seat Post up or down
slightly until it locks into place. Turn the Seat
Knob clockwise to tighten it.
Press the Seat Collar (10) into the Frame (13).
Next, attach the Seat (8) to the Seat Post (9) with
the three M8 Nylon Locknuts (56) and M8 Lock
Washers (59). Note: The M8 Nylon Locknuts and
M8 Lock Washers may be pre-attached to the bot-
tom of the Seat.

6
5. Hold the Handlebar Post (19) near the Frame (13)
as shown. Feed the Resistance Cable (6) and the
Reed Switch Wire (4) into the Frame, and then slide
the Handlebar Post into the Frame. Be careful not
to pinch the Resistance Cable or the Reed
Switch Wire. Attach the Handlebar Post with three
M10 x 22mm Button Head Bolts (55) and three M10
Lock Washers (61).
The Console (5) requires two 1.5V batteries (not
included). Alkaline batteries are recommended.
Refer to the inset drawing. Locate the battery door
on the back of the Console. Slide the battery door to
the left and open it as shown. Press two batteries
into the battery clip, with the negative (–) ends of the
batteries touching the springs. Close the battery
door and slide it to the right.
61 61
55
55
55
5
13
4
6
19
5
Batteries
Battery Clip
Battery
Door
5
20
22
4
4. Identify the Left Pedal (20); there is an “L” on the
Left Pedal for identification. Using an adjustable
wrench, tighten the Left Pedal counterclockwise into
the left arm of the Crank (22).
Tighten the Right Pedal (not shown) clockwise into
the right arm of the Crank (22).
19
61
55
18
6. Attach the Handlebar (18) to the Handlebar Post
(19) with two M10 x 22mm Button Head Bolts (55)
and two M10 Lock Washers (61).
6
