PROAIM QR-UD15 User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
15mm Universal Quick Release Camera
Baseplate with Dovetail (QR-UD15)
Assembly Manua l
Core Unit with 15mm
Rod Mounng
Lower Quick Dovetail
Tripod Plate
Universal Dovetail
Camera Plate

2
 Loosen the knob to remove the uid head
plate (Not Included). Then, aach the uid
head plate to the boom of the universal base
plate.
Note: Universal Baseplate includes the Core
Unit, a Lower Quick Dovetail tripod plate on the
boom, and a Universal Dovetail Camera Plate.
 Secure both the plates together using a
screwdriver (Not Included). Then, slide and
mount it on the uid head.
 Tighten the knob to secure the universal base
plate on the uid head. Next, loosen the quick
release knob on the universal base plate to
remove the dovetail camera plate.`
 Take out the dovetail camera plate and align
its threads to that of the camera
(Not Included)
Note: The dovetail camera plate has 1/4"-20
threaded holes on the boom for aaching to
other compable Cameras.
Universal Camera Base plate Setup
 Secure the dovetail camera plate to the
camera properly using a screwdriver
(Not Included). Then slide and mount the
camera setup onto the universal base plate
and secure it properly.
 Insert 2 rods of 15mm each (Not Included) in
the universal base plate holes, as shown in the
image.

3
 Tighten the corner knobs provided on both
sides of the plate.
 Then, loosen the center knob to remove the
core unit along with the dovetail camera plate
plate & camera setup.
Note: You can remove the Dovetail Camera
Plate only and leave the Core Unit with your rod
pair behind, or you can remove the Core Unit
from the Lower Quick Dovetail, in which case
you'll have a dovetail on the boom of the Core
Unit that's compable with any Arri Standard
Dovetail, or Shoulder Rig.
Universal Base Plate Mount on Discovery Shoulder Rig
 Slide in and mount the camera setup
(Not Included) onto the Discovery Shoulder
Rig (Not Included).
Note: The Shoulder Rig is based on ARRI
standard dovetail and rosees. The Rig is
extremely Easy to assemble/disassemble for
quick setup and convenient storage.
 Tighten the center knob to secure the camera
(Not Included) properly on the rig
(Not Included).
Note: The Lower Quick Dovetail Tripod Plate has
1/4"-20 and 3/8"-16 threaded holes for
aaching to Proaim 15mm Baseplate, Proaim
19mm Baseplate or 19-15mm Baseplate. It
allows quick and easy switching between
dierent camera setups.
Universal Dovetail
Camera Plate
Universal Base
Plate
Lower Quick
Dovetail Tripod
Plate
Center Knob for Releasing
Dovetail Camera plate with
Base plate direct

4
YOUR PROAIM UNIVERSAL QUICK RELEASE CAMERA BASEPLATE WITH DOVETAIL
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
