PROAIM CINEMA P-CTST-01 User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Assembly Manua l
Cam Tower Stand w/ Counterbalance
Accessory Tray
Plaorm Secon-2 with Locking Pivot Wheels
Plaorm Secon -1 with
Locking Pivot Wheel
Camera Support Plaorm
Cam Tower Stand w Counterbalance
(P-CTST-01)
2 x Screws 1x Spanner (Size:-17mm) 2x Allen Keys T-Type
(Size:-3/16”& 4mm)

2
• Loose all the screws of platform selection-1
as shown in image.
Cam Tower Stand Setup
• Now all screw has been removed as you can
see in the image.
• Use removed screw to secure the platforms
together and tighten it by spanner.
• Now attach platform selection-with platform
selection-1.
Plaorm Secon-2 with Locking Pivot Wheels
Plaorm Secon -1 with Locking Pivot Wheel
• Now stand the platform on its wheel.

3
• Now mount tower stand on platform rod.
Cam Tower Stand w Counterbalance
• Secure the tower stand with the help of
provided Allen key (Size:3/16”).
• Aach supporter plaorm to counter
balanced column of cam tower stand.
• Screw it with the help of Allen key (Size:4mm).
• Remove screws from the boom of counter
balanced column.
Camera Support Plaorm

4
• Now place Accessory Tray with counter
balanced column as shown in image.
• Add screws to Accessory tray by the help of
Allen key (Size:4mm) to secure.
• The tray is properly aached.
Feature: It features a horizontal geared column
equipped with a camera head at one end & is
counterbalanced by weights on the other end; it
can easily be adjusted in height and reach to
achieve a desired shoong posion.
• Attach camera (Not included) to supporter
platform and secure it by rotating knob.
• Now open the crank lever from supporter
platform.
• You can rotate crank to the rod of supporter
platform.
Accessory Tray
Camera Support Plaorm

5
• Open the knob of counter balanced knob to
adjust height of supporter plaorm and
secure it by closing knob back again.
YOUR PROAIM CAM TOWER STAND W COUNTERBALANCE
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our utmost
support and care unl you use our product.
