PROAIM P-21-J User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Jib Secons Supporng
Accesssories
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Alphabet 21 Crane (P-21-J)
As se m bl y M a n u a l
Secon 1
Secon 2
Secon 3
Secon 4
Secon 5
Secon 6
8mm Male Female Knob Set 8mm Female
Knob
Handle 8mm Male Knob
Support Rod
Cable Guide Weight Rod with
Weight Closer

2
Cables Storage Bag
1 × (Red) 11  1 × (Red) 6.7  1 × (Red) 3.3 
2 × (Blue) 11  2 × (Blue) 6.7  2 × (Blue) 3.3 
Safety Hints of Jib Crane
ATTENTION: PLEASE READ THIS BEFORE USING TO PREVENT DAMAGE TO EQUIPMENT &
OPERATOR
 The crane may not be assembled or operated under inuence of alcohol, drugs or any other intoxicang
substances. Lack of aenon while connecng the components together can cause substanal damage
to equipment / operator.
 The crane may only be operated on levelled horizontal posion. Make sure that the surface is stable.
 To prevent any harm or injury, properly join all secons of the crane. It is suggested to use the support
stand while telescoping the complete length.
 Always connect the steel cables properly to provide stability to the system. They should not negavely
impact the movements of crane in any way.
 The complete panning & liing range around it must be kept free. Avoid anybody standing under the
crane. No loose objects may be stored or placed on it. Be very careful while using indoors.
 Never operate the crane in the immediate vicinity of high-voltage power cables. It holds danger to life.
 Parcular care is required when operang the crane in unfavourable weather condions. The crane
must be shut down in sucient me. When it is used in a rainy day, the pan-lt head / gimbal head and
controlling bar shall be protected against rain.
 When you want to transport the crane, lock the Pan & Tilt Axis for safety. Make sure that the
components do not rub together and cause any material wear.
 Before the counterweights are removed, ensure the remote head is resng on the support stand. Then
gradually remove the counterweights before remote head, camera or other parts.
 In the interest of safe crane operaon, avoid abruptly swivelling or stopping the crane, otherwise it may
cause serious damage to equipment.
FOLLOWING THESE GUIDELINES WILL PROVIDE BETTER SHOTS AND TROUBLE FREE OPERATION.
SHOULD YOU NEED ADDITIONAL INFORMATION, TECHNICAL ASSISTANCE IS AVAILABLE ‘ONLINE’ BY
CONTACTING THE SALES REPRESENTATIVE.

3
SETUP INSTRUCTIONS
 Install the Hub (Secon 2 of Jib) into bowl of your 100mm tripod stand and ghten the hub with center
locking knob.
Knobs
Jib Secons Setup
Connecng Secon 2 with 3:
 Loosen the provided knob at the end of secon 2 to slide the bars of secon 3 into the end of secon 2.
Then ghten both the secons together using the provided knobs.
Cable Guide & Support Rod Setup
For Aaching Secon 2a with 2, 2b with 2a, 2c with 2b & 1 with 2c:
 Aach cable guide to cable guide clamp on 2nd secon properly. Loosen the knob, ahead of cable guide
clamp in order to aach cable guide support rod to it. Reghten the knob to secure properly.

4
Cables Setup
 Now aach one end of 14.5 blue cable to blue hook on back side of jib (secon 3) and the other end of
blue cable to blue hook on front secon of jib (secon 1). Similarly aach the second blue cable and
align both the blue cables to the side of support rod.
 Now aach one end of 14.3 red cable to red hook on back side of jib (secon 3) and align the red cable
to the cable guide from top. Then, aach the other end of red cable to red hook on front secon of jib
(secon 1).
Adjustment Wire Tensioner
 The wires have the screw-in wire adjustment system in order to adjust the wire tension to level the jib.
 The jib arm can be locked (lng) with the help of this knob. Then Insert the weight rod & weights (not
supplied) to both ends and secure with the help of closers.

5
 The central fork has free hole to aach LCD mount bracket (not included).
 The camera plate can be lted upwards & downwards with the help of provided handle.
YOUR PROAIM ALPHABET 21FT JIB CRANE
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)

6
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
