PROLiNK DS-3606 User manual

Version 1.00
(English | Indonesian)
Smart bulb
Quick Installation
Guide
Model No:
DS-3606

Package Contents
1
Overview
2
Notes:
•The picture illlustrations in this document may dier from actual
product.
•If your package does not contain any of the above items, please
contact your reseller immediately.
EN1
O
On (White / Colour
/ Blinking) Unit is On
Fast Blinking Unit is in Auto Add /EZ Mode Configuration
Slow Blinking Unit is in AP Mode Configuration
Unit is O
Bulb Behaviour Description
x 1x 1

Overview
2
Installation
3
EN2
To reset the bulb to factory
default
To switch between Auto Add/
EZ Mode and AP Mode
configurations
Power O – Power On the bulb
for three (3) consecutive times
Power O – Power On the bulb
for three (3) consecutive times
Activity Action Required
A. Preparation
1. Place the Smart Bulb and Phone within three feet of
the router.
Notes:
•Make sure the phone is connected to the router through a 2.4GHz
wireless network.
•Smart Bulb is operating only at 2.4GHz Wireless N standard.
English

Installation
3
EN3
2. Download, install and create an account through the
Prolink mEzee App. You can scan the QR code below
to download from Google Store or Apple App Store.
Alternatively, search for "mEzee".
For Google Assistant / Amazon Alexa users:
Step 1. Complete the steps in this Quick Installation Guide
Step 2. Follow the setup instruction available from
https://prolink2u.com/smart-home/smart-lighting/ds-3606/download/

Installation
3
EN4
B. Setting up the Smart Blub
1. Plug the Smart Bulb into an E14 base socket and
switch it on.
2. Launch the mEzee App and login with your account.
3. Tap Add Device or +on the top right-hand corner.
4. If the Bluetooth on your mobile phone is switched On,
proceed with Method A. If your mobile device does not
have Bluetooth, proceed with Method B.
Method A: Auto Add Configuration
1. Upon tapping Add Device or +from the main screen, the
app will start to discover devices.
2. Tap Add.
English

EN5
Installation
3
3. Select your Wi-Fi name, enter the Wi-Fi password,
and tap Next.

EN6
Installation
3
4. Once connected, proceed to name this device for easy
reference and tap Done.
English

EN7EN7
Method B: AP Mode Configuration
2. Toggle the top right-hand option to AP Mode if it shows
otherwise.
3. Ensure that the Smart Bulb is blinking slowly. Otherwise,
Power On and Off 3 consecutive times.
Installation
3
1. Select Lighting and tap DS-3606.

EN8
Installation
3
EN8
4. Check "Confirm the indicator is blinking or breathing
slowly" box, and tap Next.
5. Select your Wi-Fi name, enter the Wi-Fi password and
tap Next.
English

EN9
Installation
3
EN9
6. Tap Go to Connect and connect your mobile phone to
PROLiNK-XXXX or SmartLife-XXXX SSID. If you get
prompted with "SSID doesn't have Internet access",
tap Connect and return back to the App.

EN10EN10
7. Once connected, proceed to name this device for easy
reference and tap Done.
Installation
3
English

EN11
Frequently Asked Questions
4
Yes. You can share your bulbs with family and friends who
will have access to control your bulbs, plugs, cameras, and
other devices. In the app, press the Profile button and click
on the "Device Sharing" button, and you will be able to give
or revoke sharing permissions. In order to share, the other
user should already have downloaded the app and
registered a new account.
Can I share with family and friends?
Yes. You can group multiple devices of the same type
together, by room, location, or however else you want. The
same devices can be in multiple groups. For example, you
may create a light group specifically for your "Bedroom", as
well as a light group for the "Entire House". The lights which
are under the "Bedroom" light group can also be included as
part of the "Entire House" light group. From your main device
list, click on one of the devices you want to group. Press the
"•••" button on the topright for advanced settings, and click
Create Group. You will then be able to choose which devices
you would like to group together and will be able to rename
them.
Can I group multiple devices together?

EN12
Frequently Asked Questions
4
The app can control an unlimited amount of devices in an
unlimited amount of locations. However, your router may
have a limit of how many devices can be connected to one
router.
How many devices can I control?
Make sure your Wi-Fi router is online and in range. Make
sure you have the latest functionality by clicking "Check
for firmware update" in your device settings.
The device appears offline or unreachable. what should I do?
From your main device list, click on one of the devices you
want to rename, press the "•••" button on the top right for
advanced settings, and click Modify Device Name or Modify
Group Name (if applicable). You will then be able to rename
your device accordingly.
How do I rename my device?
English

EN13
Frequently Asked Questions
4
What is the wireless range?
Products need to be connected to Wi-Fi in order to use
them remotely.
If my Wi-Fi/Internet is down, will my devices still work?
The range of your home Wi-Fi is heavily dependent on your
home router and the conditions of the room. Check your
router specifications for the exact data range. You may add
a Prolink Extender to enhance and extend your Wi-Fi
coverage if needed.

ID1
Isi Kemasan
1
Keterangan
2
Catatan:
1. Gambar Ilustrasi dalam dokumen ini mungkin tampak berbeda dari
produk yang sebenarnya.
2. Jika salah satu item yang disebutkan di atas tidak termasuk dalam
paket Anda, silakan segera berkonsultasi dengan reseller Anda.
O
On (Putih /
Warna / Berkedip) Unit aktif
Berkedip Cepat Unit dalam Konfigurasi Mode Tambah
Otomatis / EZ
Berkedip Lambat Unit dalam Konfigurasi Mode AP
Unit tidak aktif
Perilaku Bohlam Deskripsi
Indonesian
x 1x 1

ID2
Keterangan
2
Instalasi
3
Untuk mengatur ulang bohlam
ke pabrik default
Untuk beralih antara Tambah
Otomatis/ Mode EZ dan Mode
AP konfigurasi
Matikan - Nyalakan bohlam
selama tiga (3) kali berturut-turut
Matikan - Nyalakan bohlam
selama tiga (3) kali berturut-turut
Aktifitas Langkah yang Diperlukan
A. Persiapan
1. Tempatkan Smart Bulb dan Telepon dalam jarak tiga kaki
dari router.
Catatan:
- Pastikan ponsel terhubung ke router melalui 2.4GHz jaringan
nirkabel.
- Smart Plug hanya beroperasi pada Wireless N 2.4GHz.

ID3
Instalasi
3
2. Unduh, instal, dan buat akun melalui Aplikasi Prolink
mEzee. Anda dapat memindai kode QR di bawah ini
untuk mengunduh dari Google Store atau Apple App
Store. Atau, cari "mEzee".
Untuk pengguna Google Assistant / Amazon Alexa:
Langkah 1. Selesaikan langkah-langkah dalam Quick Installation
Guide ini
Langkah 2. Ikuti instruksi pengaturan yang ada di
https://prolink2u.com/smart-home/smart-lighting/ds-3606/download/
Indonesian

ID4
Instalasi
3
B. Pengaturan Smart Blub
1. Colokkan Smart Bulb ke soket dasar E14 dan nyalakan.
2. Luncurkan Aplikasi mEzee dan login dengan akun Anda.
3. Ketuk Add Device atau +di pojok kanan atas.
4. Jika Bluetooth pada ponsel Anda diaktifkan, lanjutkan
dengan Metode A. Jika perangkat seluler Anda tidak
memiliki Bluetooth, lanjutkan dengan Metode B.
Metode A: Auto Add Configuration
1. Setelah mengetuk Add Device atau +dari layar
utama, tombol aplikasi akan mulai menemukan perangkat.
2. Ketuk Go to add.

ID5
Instalasi
3
Indonesian
3. Pilih nama Wi-Fi Anda, masukkan kata sandi Wi-Fi, dan
ketuk Berikutnya.

4. Setelah terhubung, lanjutkan dengan memberi nama
perangkat ini agar mudah referensi dan ketuk Done.
ID6
Instalasi
3
