Promise VessJBOD 1000 Series User manual

VessJBOD
1730,1740,
1830,1830+,1840,1840+
ProductManual
Version 2.0

VessJBOD 1000 Series Product Manual
ii
Copyright
© 2011 PROMISE Technology, Inc. All Rights Reserved. PROMISE, the
PROMISE logo, VTrak, SmartStor, SuperTrak, FastTrak, VessRAID, Vess,
PerfectPATH, PerfectRAID, SATA150, ULTRA133 VTrak S3000, BackTrak,
HyperCache, HyperCache-R, HyperCache-W, DeltaScan and GreenRAID are
registered or pending trademarks of PROMISE Technology, Inc. in the U.S. and
other countries. All other trademarks are the property of their respective owners.
Information regarding products, services and offerings may be superseded by
subsequent documents and are subject to change without notice. For the latest
information and specifications regarding PROMISE Technology, Inc. and any of
its offerings or services, please contact your local PROMISE office or the
corporate headquarters. Visit www.PROMISE.com for more information on
PROMISE products.
Important data protection information
You should back up all data before installing any drive controller or storage
peripheral. PROMISE Technology is not responsible for any loss of data resulting
from the use, disuse or misuse of this or any other PROMISE Technology
product.
Notice
Although PROMISE Technology has attempted to ensure the accuracy of the
content of this manual, it is possible that this document may contain technical
inaccuracies, typographical, or other errors. PROMISE Technology assumes no
liability for any error in this publication, and for damages, whether direct, indirect,
incidental, consequential or otherwise, that may result from such error, including,
but not limited to loss of data or profits.
PROMISE Technology provides this publication “as is” without warranty of any
kind, either express or implied, including, but not limited to implied warranties of
merchantability or fitness for a particular purpose.
The published information in the manual is subject to change without notice.
PROMISE Technology reserves the right to make changes in the product design,
layout, and driver revisions without notification to its users.
This version of the Product Manual supersedes all previous versions.
Recommendations
In this Product Manual, the appearance of products made by other companies,
including but not limited to software, servers, and disk drives, is for the purpose of
illustration and explanation only. PROMISE Technology does not recommend,
endorse, prefer, or support any product made by another manufacturer.

iii
Contents
Chapter 1: Introduction to VessJBOD . . . . . . . . . . . . . . . . . . . . . . . . .1
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
VessRAID Model Line-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Current (maximum) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Relative Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Dimensions (H x W x D) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Net Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Carton Dimensions (H x W x D) . . . . . . . . . . . . . . . . . . . . . . . . .5
Carton Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Warranty and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
CE Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
KCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Chapter 2: VessJBOD Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Unpacking the VessJBOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Mounting VessJBOD in a Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Installing Disk Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Drive Slot Numbering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Installing Your Disk Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Making Data and Management Connections . . . . . . . . . . . . . . . . .13
JBOD Expansion to a VessRAID Subsystem . . . . . . . . . . . . . .13
Drive Enclosures for a SuperTrak RAID Controller . . . . . . . . . .15
Setting Up Serial Cable Connections . . . . . . . . . . . . . . . . . . . . . . .17
Connecting the Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Front Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
I/O Module LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Disk Drive LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Setting up the Serial Connection . . . . . . . . . . . . . . . . . . . . . . . . . . .20

VessJBOD 1000 Series Product Manual
iv
Chapter 3: Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Front Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
I/O Module LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Disk Drive LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
CLI Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Cable Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Enclosure Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Factory Default Command . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Help Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Link Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Route Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Uptime Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
VPDR Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
? Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Chapter 4: Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Updating the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Downloading the Firmware Image File . . . . . . . . . . . . . . . . . . .37
Updating Firmware in WebPAM PROe . . . . . . . . . . . . . . . . . . .37
Updating Firmware with the JBOD Flash Utility . . . . . . . . . . . .39
Replacing a Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
VessJBOD 1730 and 1740 . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
VessJBOD 1830, 1830+, 1840, and 1840+ . . . . . . . . . . . . . . .41
Replacing an I/O Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Removing the old I/O module . . . . . . . . . . . . . . . . . . . . . . . . . .42
Installing the new I/O module . . . . . . . . . . . . . . . . . . . . . . . . . .43
Replacing a Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Original Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Plus Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Chapter 5: Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Contacting Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Returning the Product For Repair . . . . . . . . . . . . . . . . . . . . . . . . . .53
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

1
Chapter 1: Introduction to VessJBOD
This chapter covers the following topics:
• About This Manual (below)
• VessRAID Model Line-up (page 2)
• Features (page 3)
• Specifications (page 4)
About This Manual
This Product Manual describes how to setup, use, and maintain the VessJBOD
1730, 1740, 1830, 1830+, 1840, and 1840+ expansion units. It also describes
how to use the built-in command-line interface (CLI).
This manual includes a full table of contents, index, chapter task lists, and
numerous cross-references to help you find the specific information you are
looking for.
Also included are four levels of notices:
Note
A Note provides helpful information such as hints or alternative
ways of doing a task.
Important
An Important calls attention to an essential step or point required
to complete a task. Important items include things often missed.
Caution
A Caution informs you of possible equipment damage or loss of
data and how to avoid them.
Warning
A Warning notifies you of probable equipment damage or loss of
data, or the possibility of physical injury, and how to avoid them.

VessJBOD 1000 Series Product Manual
2
VessRAID Model Line-up
Figure 1. 12-bay VessJBOD with the “original” drive carrier design
Figure 2. 12-bay VessJBOD with the “plus” drive carrier design
Model Interface Number
of Drives Drive Carriers Power Supplies Controller Fans
1840+ SAS 16 plus 2 external
1840 SAS 16 original 2 internal
1830+ SAS 12 plus 2 external
1830 SAS 12 original 2 internal
1740 SAS 16 original 1 internal
1730 SAS 12 original 1 internal
Drive Carrier LEDs
Drive Carriers Power and Status LEDs
Drive Carrier LEDs
Drive Carriers Power and Status LEDs

Chapter 1: Introduction to VessJBOD
3
Figure 3. VessJBOD 1730 rear view
Figure 4. VessJBOD 1830 rear view
Figure 5. VessJBOD 1830+ rear view
Features
• 3.5" x 1" SAS 3 Gb/s drives
• 3.5" x 1" SATA 3 Gb/s drives
• Any combination of SAS and SATA drives in the same system.
• Hot-swappable drive bays.
• Staggered physical drive spin-up.
I/O ModuleSingle Power Supply
Internal Fans
I/O Module
Internal Fans
Dual Power Supplies
External Fans
Dual Power Supplies I/O Module

VessJBOD 1000 Series Product Manual
4
• Redundant, hot-swappable power supplies on 1830, 1830+, 1840, and
1840+ models.
• Command Line Interface via RJ-11 Serial Port.
• Three years complete system limited warranty includes 24 x 7 email and
phone support with highly experienced technical support technicians and an
advanced replacements program.
• Compatible with leading SAS hard drives, host bus adapters, and RAID
controllers.
• OS support:
• Windows 2008 Server, 2003 Server
• Red Hat Linux, SuSE Linux
• FreeBSD, VMware ESX 4.0
• Supports all background activities running on VessRAID subsystem
Specifications
Power Supply
1840+, 1840: 450W, Dual hot-swappable and redundant, 100-240 VAC auto-
ranging, 50-60 Hz, with PFC
1830+, 1830: 350W, Dual hot-swappable and redundant, 100-240 VAC auto-
ranging, 50-60 Hz, with PFC
1740: 450W, Single, 100-240 VAC auto-ranging, 50-60 Hz, with PFC and
80PLUS certification
1730: 350W, Single, 100-240 VAC auto-ranging, 50-60 Hz, with PFC and
80PLUS certification
Current (maximum)
1840 and 1840+: 8 A @ 100 VAC or 4 A @ 240 VAC current rating with two
power cords
1830 and 1830+: 6A @ 100 VAC or 3 A @ 240 VAC Current rating with two
power cords
1740: 7A @ 100 VAC or 3.5 A @ 240 VAC Current rating with one power cord
1730: 6A @ 100 VAC or 3 A @ 240 VAC Current rating with one power cord
Power Consumption
1840+, 1840, 1740: without disk drives, 72.2 W; with disk drives, 242.3 W
1830+, 1830, 1730: without disk drives, 80.3 W; with disk drives, 233.4 W

Chapter 1: Introduction to VessJBOD
5
Temperature
Normal conditions:
5° to 40°C operational (-40° to 60°C non-operational)
Conditions of running SAS disk drives with one failed cooling fan:
5° to 35°C operational (-40° to 60°C non-operational)
Relative Humidity
95 percent maximum
Vibration
Random, 0.21 grms, 5-500 Hz, 30 Mins, X, Y, Z axis.
Dimensions (H x W x D)
1840+, 1840, 1740: 13 x 45 x 46 cm (5.1 x 17.7 x 18.1 in)
1830+, 1830, 1730: 8.8 x 45 x 46 cm (3.5 x 17.7 x 18.1 in)
Net Weight
1840+: 16.6 kg (36.1 lb) without drives, 24.6 kg (53.5 lb) with 16 drives*
1840: 15.8 kg (34.8 lb) without drives, 23.8 kg (52.5 lb) with 16 drives*
1830+: 13.4 kg (29.2 lb) without drives, 19.4 kg (42.3 lb) with 12 drives*
1830: 12.6 kg (27.8 lb) without drives, 18.6 kg (41.0 lb) with 12 drives*
1740: 13.8 kg (30.4 lb) without drives, 21.8 kg (48.1 lb) with 16 drives*
1730: 10.8 kg (23.5 lb) without drives, 16.8 kg (37.1 lb) with 12 drives*
* Assuming 0.5 kg (1.1 lb) per drive.
Carton Dimensions (H x W x D)
All models: 28.5 x 57.2 x 75.2 cm (11.2 x 22.5 x 29.6 in)
Carton Weight
1840+: 21.6 kg (47.6 lb)
1840: 20.8 kg (45.9 lb)
1830+: 18.8 kg (41.4 lb)
1830: 18.0 kg (38.8 lb)
1740: 19.2 kg (42.3 lb)
1730: 16.2 kg (35.7 lb)

VessJBOD 1000 Series Product Manual
6
Safety
BSMI, CB, CCC, CE, FCC Class A, MIC, VCCI, UL, cUL, TUV.
Environmental
RoHS, China RoHS.
Warranty and Support
Warranty: Three year limited warranty on all components except the optional
battery backup unit, which has a one-year warranty.
Support: 24x7 email and phone support (English only). 24x7 access to
PROMISE support site for drivers, firmware, and compatibility.
CE Statement
Warning: This is a class B product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
KCC Statement

7
Chapter 2: VessJBOD Installation
This chapter covers the following topics:
• Unpacking the VessJBOD (below)
• Mounting VessJBOD in a Rack (page 8)
• Installing Disk Drives (page 11)
• Making Data and Management Connections (page 13)
• Setting Up Serial Cable Connections (page 17)
• Connecting the Power (page 18)
• Setting up the Serial Connection (page 20)
Unpacking the VessJBOD
The VessJBOD box contains the following items:
• VessJBOD Unit
•Quick Start Guide printed
• RJ11-to-DB9 serial data cable
• Screws for disk drives
(70 pieces for 16-bay, 50 pieces
for 12-bay)
• 1.5m (4.9 ft) Power cords
(1700 models, 1; 1800 models, 2)
•CDwithProduct Manual and Quick
Start Guide in PDF format
Warning
This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user may be
required to take adequate measures.
Warning
The electronic components within the VessJBOD enclosure are
sensitive to damage from Electro-Static Discharge (ESD).
Observe appropriate precautions at all times when handling the
VessJBOD or its subassemblies.

VessJBOD 1000 Series Product Manual
8
Mounting VessJBOD in a Rack
The VessJBOD subsystem installs to the rack using the available mounting rails.
You can also use your existing rails.
Cautions
• At least two persons are required to safely lift, place, and
attach the VessJBOD unit into a rack system.
• Do not lift or move the VessJBOD unit by the handles, power
supplies or the controller units. Hold the subsystem itself.
• Do not install the VessJBOD unit into a rack without rails to
support the subsystem.
• Only a qualified technician who is familiar with the installation
procedure should mount and install the VessJBOD unit.
• Be sure all switches are OFF before installing the VessJBOD
unit or exchanging components.
• Mount the rails to the rack using the appropriate screws and
flange nuts, fully tightened, at each end of the rail.
• Do not load the rails unless they are installed with screws as
instructed.
• The rails available for the PROMISE VessJBOD unit are
designed to safely support that PROMISE VessJBOD unit
when properly installed. Additional loading on the rails is at
the customer’s risk.
• PROMISE Technology, Inc. cannot guarantee that the
mounting rails will support your PROMISE VessJBOD unit
unless you install them as instructed.
Note
To lighten the VessJBOD enclosure, remove the power supplies.
Replace the power supplies after the VessJBOD unit is mounted in
your rack.

Chapter 2: VessJBOD Installation
9
Figure 1. A 16-bay VessJBOD mounted in a rack with the available rails
To install the VessJBOD unit into a rack with the available mounting rails:
1. Check the fit of the mounting rails in your rack system.
See page 10, Figure 2.
2. Adjust the length of the mounting rails as needed.
The rear rail slides inside the front rail. The rail halves are riveted together
and use no adjustment screws.
3. Attach the mounting rail assemblies to the outside of the rack posts, using
the attaching screws and flange nuts from your rack system.
Be sure the front rail support is on the bottom facing inward.
The alignment pins fit into the rack holes above and below the attaching
screws.
Use the attaching screws and flange nuts from your rack system. Tighten the
screws and flange nuts according to your rack system instructions.
4. Place the VessJBOD unit onto the rails.
5. Secure the VessJBOD unit to the rack.
One screw each side, in the upper hole only. Use the attaching screws and
flange nuts from your rack system. Tighten the screws and flange nuts
according to your rack system instructions.
Vertical Rack Post VessRAID subsystem
Mounting rails mount
outside the rack post
Handles mount
outside the rack post

VessJBOD 1000 Series Product Manual
10
Figure 2. Rack mount assembly diagram
This completes rack mounting. Go to “Installing Disk Drives” on page 11.
Inside of post
Rack front post
Rail attaching screws
(not included)
Rail adjustment screw
(center, outside of rail)
Flange
Inside of post
Rack back post
Front rail Rear rail
Support
Locating pins (2 on each end)

Chapter 2: VessJBOD Installation
11
Installing Disk Drives
The VessRAID subsystems and VessJBOD expansion units support:
• SAS and SATA hard disk drives
• 3.5-inch hard disk drives
For a list of supported physical drives, download the latest compatibility list from
the PROMISE support web site.
Drive Slot Numbering
You can install any suitable disk drive into any slot in the enclosure. The diagram
below shows how VessJBOD’s drive slots are numbered. Whether you have the
original or plus carriers, the slots are numbered the same.
Slot numbering is reflected in the WebPAM PROe and CLU user interfaces. See
Figures 8 and 9.
Figure 3. 16-bay VessJBOD drive slot numbering
Figure 4. 12-bay VessJBOD drive slot numbering
Install all of the drive carriers into the VessJBOD enclosure to ensure proper
airflow, even if you do not populate all the carriers with disk drives.
Installing Your Disk Drives
1. Remove a disk drive carrier.
2. Carefully lay the disk drive into the drive carrier at the front, so that the screw
holes on the sides line up.
1
5
9
13
2
6
10
14
3
7
11
15
4
8
12
16
1
5
9
2
6
10
3
7
11
4
8
12

VessJBOD 1000 Series Product Manual
12
3. Insert the screws through the holes in the drive carrier and into the sides of
the disk drive.
• Install only the counter-sink screws supplied with the VessJBOD.
• Install four screws per drive.
• Snug each screw. Be careful not to over-tighten.
4. Reinstall the drive carrier into the VessJBOD enclosure.
Repeat steps 1 through 3 until all of your disk drives are installed.
Figure 5. Disk drive mounted in a drive carrier
This completes disk drive installation. Go to “Making Data and Management
Connections” on page 13.
Caution
VessJBOD supports disk drive hot-swapping. To avoid hand
contact with an electrical hazard, do not remove more than one
drive carrier a time.
Disk drive
mounting screw
mounting screw

Chapter 2: VessJBOD Installation
13
Making Data and Management Connections
You can configure your VessJBOD as:
• JBOD Expansion to a VessRAID subsystem
• Drive enclosures for a SuperTrak RAID controller
JBOD Expansion to a VessRAID Subsystem
Configuring a Data Path
To establish the data path:
1. Connect the SAS HBA card in the Host PC to the SAS IN ports on the
VessRAID controller. See page 14, Figure 6.
2. Connect the SAS Expansion port of the VessRAID controller to the SAS IN
port on the I/O module of the first VessJBOD.
3. Connect the SAS OUT port of the VessJBOD I/O module of the first
VessJBOD to the SAS IN port on the I/O module of the second VessJBOD.
4. Connect the remaining VessJBOD units in the same manner.
All SAS ports have SFF-8088 connectors.
Configuring a Management Path
VessRAID subsystems have one RAID controller. The controller has an Ethernet
(RJ45) Management Port connector that enables you to monitor the VessJBOD
subsystems over your network using the WebPAM PROe software.
To establish the management path:
1. Connect the Management port on each VessRAID controller to your network
switch. See page 14, Figure 6.
2. Connect the Host PC’s or Server’s NIC to your network switch.
Direct Management of VessJBOD
A management connection directly to the VessJBOD uses a serial connection to
the Host PC. See “Chapter 3: Management” on page 21 for more information.

VessJBOD 1000 Series Product Manual
14
Figure 6. Data and management connections with VessRAID
This completes data and management connections. Go to “Setting Up Serial
Cable Connections” on page 17.
Host PCs or
Servers
SAS HBA
cards
Network
Switch
VessRAID 1830s+
VessJBOD 1830+
Expansion
SAS port
VessJBOD 1730
SAS OUT port
SAS IN ports
SAS IN port
Management
Port
SAS IN port

Chapter 2: VessJBOD Installation
15
Drive Enclosures for a SuperTrak RAID Controller
Configuring a Data Path
To establish the data path:
1. Connect the SuperTrak RAID Controller in the Host PC to the SAS IN port on
the I/O module of the first VessJBOD. See page 16, Figure 7.
2. Connect the SAS OUT port of the I/O module of the first VessJBOD to the
SAS IN port on the I/O module of the second VessJBOD.
3. Connect the remaining VessJBOD units in the same manner.
All SAS ports have SFF-8088 connectors.
Configuring a Management Path
The SuperTrak RAID Controller installs in the Host PC, therefore it does not
require a separate network management connection.
You can monitor the VessJBOD subsystems using the WebPAM PRO software
installed on the Host PC.
Direct Management of VessJBOD
A management connection directly to the VessJBOD uses a serial connection to
the Host PC. See “Chapter 3: Management” on page 21 for more information.

VessJBOD 1000 Series Product Manual
16
Figure 7. Data connections with SuperTrak
This completes data and management connections. Go to “Setting Up Serial
Cable Connections” on page 17.
VessJBOD 1830+
VessJBOD 1730
VessJBOD 1830
Host PC or Server
SuperTrak RAID
Controller card
SAS port on
RAID controller
SAS OUT port
SAS IN port
SAS OUT port
SAS IN port
SAS IN port
