ProSoft inRAx MVI56-DEM User manual

MVI56-DEM
ControlLogix Platform
Honeywell DE Communication Module
User Manual
March 06, 2008

Please Read This Notice
Successful application of this module requires a reasonable working knowledge of the Rockwell Automation
hardware, the MVI56-DEM Module and the application in which the combination is to be used. For this
reason, it is important that those responsible for implementation satisfy themselves that the combination will
meet the needs of the application without exposing personnel or equipment to unsafe or inappropriate
working conditions.
This manual is provided to assist the user. Every attempt has been made to ensure that the information
provided is accurate and a true reflection of the product's installation requirements. In order to ensure a
complete understanding of the operation of the product, the user should read all applicable Rockwell
Automation documentation on the operation of the Rockwell Automation hardware.
Under no conditions will ProSoft Technology be responsible or liable for indirect or consequential damages
resulting from the use or application of the product.
Reproduction of the contents of this manual, in whole or in part, without written permission from ProSoft
Technology is prohibited.
Information in this manual is subject to change without notice and does not represent a commitment on the
part of ProSoft Technology Improvements and/or changes in this manual or the product may be made at any
time. These changes will be made periodically to correct technical inaccuracies or typographical errors.
Warnings
UL Warnings
A Warning - Explosion Hazard - Substitution of components may impair suitability for
Class I, Division 2.
B Warning - Explosion Hazard - When in Hazardous Locations, turn off power before
replacing or rewiring modules.
Warning - Explosion Hazard - Do not disconnect equipment unless power has been
switched off or the area is known to be nonhazardous.
C Suitable for use in Class I, division 2 Groups A, B, C and D Hazardous Locations or
Non-Hazardous Locations.
ATEX Warnings and Conditions of Safe Usage:
Power, Input, and Output (I/O) wiring must be in accordance with the authority having
jurisdiction
A Warning - Explosion Hazard - When in hazardous locations, turn off power before
replacing or wiring modules.
B Warning - Explosion Hazard - Do not disconnect equipment unless power has been
switched off or the area is known to be non-hazardous.
C These products are intended to be mounted in an IP54 enclosure. The devices shall
provide external means to prevent the rated voltage being exceeded by transient
disturbances of more than 40%. This device must be used only with ATEX certified
backplanes.
D DO NOT OPEN WHEN ENERGIZED.

Electrical Ratings
Backplane Current Load: 800 mA @ 5 V DC; 3mA @ 24V DC
Operating Temperature: 0 to 60°C (32 to 140°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Shock: 30g Operational; 50g non-operational; Vibration: 5 g from 10 to 150 Hz
Relative Humidity 5% to 95% (non-condensing)
All phase conductor sizes must be at least 1.3 mm(squared) and all earth ground
conductors must be at least 4mm(squared).
Markings:
II 3 G 0C <=Ta<= 60C EEx nA IIC T4 DEMKO 07ATEX0710717X
Your Feedback Please
We always want you to feel that you made the right decision to use our products. If you have suggestions,
comments, compliments or complaints about the product, documentation or support, please write or call us.
ProSoft Technology
1675 Chester Avenue, Fourth Floor
Bakersfield, CA 93301
[phone]
[phone] (Fax)
http://www.prosoft-technology.com
Copyright © ProSoft Technology, Inc. 2000 - 2008. All Rights Reserved.
MVI56-DEM User Manual
March 06, 2008
PSFT.DEM.MVI56.UM.08.03.06
ProSoft Technology ®, ProLinx ®, inRAx ®, ProTalk® and RadioLinx ® are Registered Trademarks of
ProSoft Technology, Inc.

Contents MVI56-DEM ♦ControlLogix Platform
Honeywell DE Communication Module
ProSoft Technology, Inc. Page 5 of 80
March 6, 2008
Contents
PLEASE READ THIS NOTICE................................................................................................................2
Warnings............................................................................................................................................2
Your Feedback Please ......................................................................................................................3
GUIDE TO THE MVI56-DEM USER MANUAL.......................................................................................7
1START HERE....................................................................................................................................9
1.1 System Requirements.................................................................................................................9
1.2 Package Contents.....................................................................................................................10
1.3 Install the Module in the Rack...................................................................................................10
1.4 Connect your PC to the Processor ...........................................................................................12
1.5 Download the Sample Program to the Processor.....................................................................13
1.5.1 Configuring RSLinx.................................................................................................................... 14
1.6 Connect your PC to the Module................................................................................................15
2INSTALLING AND CONFIGURING THE MODULE.......................................................................17
2.1 Module Configuration................................................................................................................22
2.1.1 Module Data (DEMModule) ....................................................................................................... 22
3LADDER LOGIC .............................................................................................................................27
4DIAGNOSTICS AND TROUBLESHOOTING.................................................................................29
4.1 Reading Status Data from the Module......................................................................................29
4.1.1 The Configuration/Debug Menu................................................................................................. 29
4.1.2 Required Hardware ................................................................................................................... 30
4.1.3 Required Software..................................................................................................................... 30
4.1.4 Using the Configuration/Debug Port .......................................................................................... 30
4.1.5 Main Menu................................................................................................................................. 32
4.2 LED Status Indicators ...............................................................................................................35
4.2.1 Troubleshooting......................................................................................................................... 36
5REFERENCE...................................................................................................................................37
5.1 Product Specifications...............................................................................................................37
5.1.1 Features and Benefits ............................................................................................................... 37
5.1.2 General Specifications............................................................................................................... 37
5.1.3 Hardware Specifications............................................................................................................ 38
5.1.4 Functional Specifications........................................................................................................... 39
5.2 Functional Overview..................................................................................................................39
5.2.1 General Concepts...................................................................................................................... 39
5.2.2 Data Flow .................................................................................................................................. 46
5.2.3 Reading from Honeywell Smart Transmitters ............................................................................ 47
5.2.4 Writing to Honeywell Smart Transmitters .................................................................................. 48
5.2.5 PV Value Integrity...................................................................................................................... 50
5.2.6 Data Base Mismatch ................................................................................................................. 50
5.3 RS-232 Configuration/Debug Port ............................................................................................51
5.3.1 Disabling the RSLinx Driver for the Com Port on the PC........................................................... 52
5.4 DB9 to RJ45 Adaptor (Cable 14) ..............................................................................................54
5.5 Application Port Connection......................................................................................................54
5.5.1 Installation Instructions .............................................................................................................. 55
5.5.2 DEM Board Power Cabling........................................................................................................ 55
5.5.3 Non-Redundant Configurations ................................................................................................. 55
5.5.4 Redundant Configurations......................................................................................................... 55
5.6 MVI56-DEM Read Block ...........................................................................................................56
5.7 MVI56-DEM Write Block ...........................................................................................................59
5.8 DE Parameter Descriptions ......................................................................................................62

MVI56-DEM ♦ControlLogix Platform Contents
Honeywell DE Communication Module
Page 6 of 80
March 6, 2008
5.8.1 Device Status Flags #1.............................................................................................................. 62
5.8.2 Device Status Flags #2.............................................................................................................. 64
5.8.3 Number of PVs.......................................................................................................................... 65
5.8.4 SV updated counter................................................................................................................... 66
6SUPPORT, SERVICE & WARRANTY........................................................................................... 69
6.1 How to Contact Us: Sales and Support.................................................................................... 70
6.2 Return Material Authorization (RMA) Policies and Conditions................................................. 70
6.2.1 All Product Returns ................................................................................................................... 71
6.3 Procedures for Return of Units Under Warranty ...................................................................... 71
6.4 Procedures for Return of Units Out of Warranty ...................................................................... 72
6.4.1 Un-repairable Units ................................................................................................................... 72
6.4.2 Purchasing Warranty Extension ................................................................................................ 73
6.5 LIMITED WARRANTY.............................................................................................................. 73
6.5.1 What Is Covered By This Warranty ........................................................................................... 73
6.5.2 What Is Not Covered By This Warranty..................................................................................... 74
6.5.3 DISCLAIMER REGARDING HIGH RISK ACTIVITIES .............................................................. 75
6.5.4 DISCLAIMER OF ALL OTHER WARRANTIES......................................................................... 75
6.5.5 LIMITATION OF REMEDIES**.................................................................................................. 75
6.5.6 Time Limit for Bringing Suit ....................................................................................................... 75
6.5.7 No Other Warranties ................................................................................................................. 76
6.5.8 Intellectual Property................................................................................................................... 76
6.5.9 Additional Restrictions Relating To Software And Other Intellectual Property........................... 76
6.5.10 Allocation of risks ...................................................................................................................... 76
6.5.11 Controlling Law and Severability ............................................................................................... 77
INDEX.................................................................................................................................................... 79

Start Here MVI56-DEM ♦ControlLogix Platform
Honeywell DE Communication Module
ProSoft Technology, Inc. Page 7 of 80
March 6, 2008
Guide to the MVI56-DEM User Manual
Function Section to Read Details
Introduction
(Must Do)
→
Start Here (page 9)
This Section introduces the customer to the
module. Included are: package contents,
system requirements, hardware installation,
and basic configuration.
Verify Communication,
Diagnostic and
Troubleshooting
→Verifying
Communication
(page 35)
Diagnostics and
Troubleshooting
(page 29)
This section describes how to verify
communications with the network. Diagnostic
and Troubleshooting procedures.
Reference
Product Specifications
Functional Overview
Glossary
→Reference (page
37)
Functional
Overview (page 39)
Product
Specifications
(page 37)
These sections contain general references
associated with this product, Specifications,
and the Functional Overview.
Support, Service, and
Warranty
Index
→Support, Service
and Warranty
(page 69)
This section contains Support, Service and
Warranty information.
Index of chapters.

MVI56-DEM ♦ControlLogix Platform Start Here
Honeywell DE Communication Module
Page 8 of 80 ProSoft Technology, Inc.
March 6, 2008

Start Here MVI56-DEM ♦ControlLogix Platform
Honeywell DE Communication Module
ProSoft Technology, Inc. Page 9 of 80
March 6, 2008
1 Start Here
In This Chapter
System Requirements .............................................................................9
Package Contents .................................................................................10
Install the Module in the Rack ...............................................................10
Connect your PC to the Processor ........................................................12
Download the Sample Program to the Processor..................................13
Connect your PC to the Module ............................................................15
Installing the MVI56-DEM module requires a reasonable working knowledge of
the Rockwell Automation hardware, the MVI56-DEM Module and the application
in which they will be used.
Caution: It is important that those responsible for implementation can complete the
application without exposing personnel, or equipment, to unsafe or inappropriate working
conditions. Safety, quality and experience are key factors in a successful installation.
1.1 System Requirements
The MVI56-DEM module requires the following minimum hardware and software
components:
Rockwell Automation ™ processor, with compatible power supply and one
free slot in the rack, for the MVI56-DEM module. The module requires 800mA
of available power.
Rockwell Automation RSLogix 5000 programming software version 2.51 or
higher.
Rockwell Automation RSLinx communication software
Pentium® II 450 MHz minimum. Pentium III 733 MHz (or better)
recommended
Supported operating systems:
oMicrosoft Windows XP Professional with Service Pack 1 or 2
oMicrosoft Windows 2000 Professional with Service Pack 1, 2, or 3
oMicrosoft Windows Server 2003
128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended
100 Mbytes of free hard disk space (or more based on application
requirements)
256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color
1024 ×768 recommended)
CD-ROM drive
HyperTerminal or other terminal emulator program.

MVI56-DEM ♦ControlLogix Platform Start Here
Honeywell DE Communication Module
Page 10 of 80 ProSoft Technology, Inc.
March 6, 2008
Note: You can install the module in a local or remote rack. For remote rack installation, the module
requires EtherNet/IP or ControlNet communication with the processor.
1.2 Package Contents
The following components are included with your MVI56-DEM module, and are
all required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are
present.
Qty. Part Name Part Number Part Description
1 MVI56-DEM
Module
MVI56-DEM Honeywell DE Communication Module
1 Cable Cable #15, RS232
Null Modem
For RS232 Connection to the CFG Port
1 Cable Cable #14, RJ45 to
DB9 Male Adapter
cable
For DB9 Connection to Module's Port
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
1.3 Install the Module in the Rack
If you have not already installed and configured your ControlLogix processor and
power supply, please do so before installing the MVI56-DEM module. Refer to
your Rockwell Automation product documentation for installation instructions.
Warning: You must follow all safety instructions when installing this or any other electronic
devices. Failure to follow safety procedures could result in damage to hardware or data, or even
serious injury or death to personnel. Refer to the documentation for each device you plan to
connect to verify that suitable safety procedures are in place before installing or servicing the
device.
After you have checked the placement of the jumpers, insert MVI56-DEM into the
ControlLogix chassis. Use the same technique recommended by Rockwell
Automation to remove and install ControlLogix modules.
Warning: When you insert or remove the module while backplane power is on, an electrical arc
can occur. This could cause an explosion in hazardous location installations. Verify that power is
removed or the area is non-hazardous before proceeding. Repeated electrical arcing causes
excessive wear to contacts on both the module and its mating connector. Worn contacts may
create electrical resistance that can affect module operation.
1 Turn power OFF.

Start Here MVI56-DEM ♦ControlLogix Platform
Honeywell DE Communication Module
ProSoft Technology, Inc. Page 11 of 80
March 6, 2008
2 Align the module with the top and bottom guides, and slide it into the rack
until the module is firmly against the backplane connector.
3 With a firm but steady push, snap the module into place.
4 Check that the holding clips on the top and bottom of the module are securely
in the locking holes of the rack.
5 Make a note of the slot location. You will need to identify the slot in which the
module is installed in order for the sample program to work correctly. Slot
numbers are identified on the green circuit board (backplane) of the
ControlLogix rack.
6 Turn power ON.
Note: If you insert the module improperly, the system may stop working, or may behave
unpredictably.
Note: If you are installing MVI56-DEM with other modules connected to the PCI bus, the peripheral
modules will not have holding clips. Make sure all of the modules are aligned with their respective
slots before you snap them into place.

MVI56-DEM ♦ControlLogix Platform Start Here
Honeywell DE Communication Module
Page 12 of 80 ProSoft Technology, Inc.
March 6, 2008
1.4 Connect your PC to the Processor
1 Connect the right-angle connector end of the cable to your controller at the
communications port.
2 Connect the straight connector end of the cable to the serial port on your
computer.

Start Here MVI56-DEM ♦ControlLogix Platform
Honeywell DE Communication Module
ProSoft Technology, Inc. Page 13 of 80
March 6, 2008
1.5 Download the Sample Program to the Processor
Note: The key switch on the front of the ControlLogix module must be in the REM position.
To download the sample program from RSLogix 5000 to the ControlLogix processor
1 If you are not already online to the processor, open the Communications
menu, and then choose Download. RSLogix will establish communication
with the processor.
2 When communication is established, RSLogix will open a confirmation dialog
box. Click the Download button to transfer the sample program to the
processor.
3 RSLogix will compile the program and transfer it to the processor. This
process may take a few minutes.
4 When the download is complete, RSLogix will open another confirmation
dialog box. Click OK to switch the processor from Program mode to Run
mode.
Note: If you receive an error message during these steps, refer to your RSLogix documentation to
interpret and correct the error.

MVI56-DEM ♦ControlLogix Platform Start Here
Honeywell DE Communication Module
Page 14 of 80 ProSoft Technology, Inc.
March 6, 2008
1.5.1 Configuring RSLinx
If RSLogix is unable to establish communication with the processor, follow these steps:
1 Open RSLinx.
2 Open the Communications menu, and choose Configure Drivers.
This action opens the Configure Drivers dialog box.
Note: If the list of configured drivers is blank, you must first choose and configure a driver from the
Available Driver Types list. The recommended driver type to choose for serial communication with
the processor is "RS-232 DF1 Devices".

Start Here MVI56-DEM ♦ControlLogix Platform
Honeywell DE Communication Module
ProSoft Technology, Inc. Page 15 of 80
March 6, 2008
3 Click to select the driver, and then click Configure. This action opens the
Configure Allen-Bradley DF1 Communications Device dialog box.
4 Click the Auto-Configure button. RSLinx will attempt to configure your serial
port to work with the selected driver.
5 When you see the message "Auto Configuration Successful", click the OK
button to dismiss the dialog box.
Note: If the auto-configuration procedure fails, verify that the cables are connected correctly
between the processor and the serial port on your computer, and then try again. If you are still
unable to auto-configure the port, refer to your RSLinx documentation for further troubleshooting
steps.
1.6 Connect your PC to the Module
With the module securely mounted, connect your PC to the Configuration/Debug
port using the RJ45-DB-9 Serial Adapter Cable and the Null Modem Cable
included in the package with the MVI56-DEM module.
1 Connect the RJ45-DB-9 Serial Adapter Cable to the Null Modem Cable.
2 Insert the RJ45 cable connector from the RJ45-DB-9 cable into the
Configuration/Debug port of the module.
3 Attach the other end to the serial port on your PC or laptop.

MVI56-DEM ♦ControlLogix Platform Start Here
Honeywell DE Communication Module
Page 16 of 80 ProSoft Technology, Inc.
March 6, 2008

Installing and Configuring the Module MVI56-DEM ♦ControlLogix Platform
Honeywell DE Communication Module
ProSoft Technology, Inc. Page 17 of 80
March 6, 2008
2 Installing and Configuring the Module
In This Chapter
Module Configuration ............................................................................22
This chapter describes how to install and configure the module to work with your
application. The configuration process consists of the following steps.
1 Use RSLogix 5000 to identify the module to the processor and add the
module to a project.
Note: The RSLogix 5000 software must be in "offline" mode to add the module to a project.
2 Modify the example ladder logic to meet the needs of your application, and
copy the ladder logic to the processor. Example ladder logic files are provided
on the CD-ROM.
Note: If you are installing this module in an existing application, you can copy the necessary
elements from the example ladder logic into your application.
The rest of this chapter describes these steps in more detail.
The first step in installing and configuring the module is to define the module to
the system. Right-click the mouse button on the I/O Configuration option in the
Controller Organization window to display a pop-up menu. Select the New
Module option from the I/O Configuration menu.

MVI56-DEM ♦ControlLogix Platform Installing and Configuring the Module
Honeywell DE Communication Module
Page 18 of 80 ProSoft Technology, Inc.
March 6, 2008
This action opens the following dialog box.
Select the 1756-Module (Generic 1756 Module) from the list and click OK. The
following dialog box appears.

Installing and Configuring the Module MVI56-DEM ♦ControlLogix Platform
Honeywell DE Communication Module
ProSoft Technology, Inc. Page 19 of 80
March 6, 2008
Fill in the dialog box as shown adjusting the Name, Description and Slot options
for your application. You must select the Comm Format as Data - INT in the
dialog box. Failure to set the Assembly Instance and Size values correctly will
result in a module that will not communicate over the backplane of the
ControlLogix rack. Click Next to display the following dialog box.
Select the Request Packet Interval value for scanning the I/O on the module.
This value represents the minimum frequency that the module will handle
scheduled events. This value should not be set to less than 1 millisecond. Values
between 1 and 10 milliseconds should work with most applications.
After completing the module setup, the Controller Organization window displays
the module's presence. The data required for the module is defined to the
application, and objects are allocated in the Controller Tags data area. The
Controller Organization window is shown in the following example:

MVI56-DEM ♦ControlLogix Platform Installing and Configuring the Module
Honeywell DE Communication Module
Page 20 of 80 ProSoft Technology, Inc.
March 6, 2008
The next step in the module's setup is to define the User Defined Data Types to
be used with the module. Copy these data types from the example ladder logic if
you are not using the example. They are already defined if you are starting from
the example ladder logic. The Controller Organization window should display the
User Defined Data Types shown in the following example:
The next step in module setup is to define the data tag to be used to interface
with the module and the ladder logic. Open the Controller Tags Edit Tags dialog
box and enter the values shown in the following example. The MVI56-DEM
module is defined in the example as DEM1 to hold all data related to the module
(type DEMModule). The tag name can be set to any valid tag name desired.
When using the example ladder logic, this step has already been performed.
