Lutron Electronics LMM-16R-DV-B User manual

220–240 V~ 50/60 Hz
Hereby, Lutron Electronics Co., Inc. declares that the radio equipment type
LMM-16R-DV-B are in compliance with Directive 2014/53/EU. A copy of the
DoC can be obtained by writing to: Lutron Electronics Co., Inc. 7200 Suter Road,
Coopersburg, PA 18036 U.S.A.
Complies with
ImDA Standards
DA103083
Lutron Electronics Co., Inc. | 7200 Suter Road
Coopersburg, PA 18036-1299, U.S.A.
RF Module | Installation
with Softswitch
Important Notes:
• For installation by a qualified electrician in accordance
with all local and national electrical codes.
• Note: Use copper conductors only.
• Check to see that the device type and rating is suitable
for the application.
• DO NOT install if product has any visible damage.
• If moisture or condensation is evident, allow the product
to dry completely before installation.
• Operate between 32 °F to 131 °F (0 °C to 55 °C).
• 0% to 90% humidity, non-condensing.
• For indoor use only.
Please read before installing
Warranty:
For warranty information, please visit
www.lutron.com/TechnicalDocumentLibrary/Warranty.pdf
www.lutron.com/TechnicalDocumentLibrary/Intl_Warranty.pdf
Lutron and Softswitch are trademarks or registered trademarks
of Lutron Electronics Co., Inc. in the US and/or other countries.
©2013-2019 Lutron Electronics Co., Inc.
Load
Status
LED
Toggle
Advanced
Operations
For System Setup Guide and tools
visit www.lutron.com
RF Module
RF Module Operation
Reset Factory Defaults
Note: In some instances it may be necessary to
reset the RF Module back to factory default settings.
ATriple-tap the Advanced Operations (“ADV”)
button, on the RF Module and hold until
the LED begins to flash slowly.
Within 3 seconds of flashing, release and
triple-tap the button again and the LED
will flash rapidly indicating that the unit
has been reset to factory defaults.
B
Note: Any associations or programming previously
set up with the unit will be lost and will need to be
re-programmed.
English
Customer Assistance | +91.124.439.0130 Asia/Middle East | 1.844.LUTRON1 USA/Canada | +1.610.282.3800 Others | www.lutron.com/support
RF Module can be installed in a junction box or
marshalling box (optional) using the conduit nut
(provided) or with mounting screws (not provided).
Please consult local and national electric codes
for proper installation.
RF Module Placement
RF Modules must be located within 30 ft (9 m) of an
RF signal repeater. RF Modules cannot be controlled
by the system until they are programmed using the
system programming software.
Shock Hazard. May result in
serious injury or death.
Turn off power at circuit breaker
before installing the unit.
WARNING
Installation:
1
2
3
10 mm
Wiring a Lever Operated Connector (shown)
When wiring lever operated connectors (3 supplied)
please use 14 AWG to 12 AWG (2.5 mm2to 4.0 mm2)
diameter solid or stranded copper wire.
Troubleshooting
Load does
not respond
to Wireless
Transmitter(s).
• Ensure breaker to the RF Module
is on.
• Ensure the load has been
properly wired to the RF Module.
• Ensure that the RF Module has
been activated in the system.
• Ensure that the Wireless
Transmitter battery is installed
correctly.
RF Module
does not
respond to
a keypad,
wireless
controller or
sensor.
• Improper programming.
Program from the system
programming software.
• Out of RF Range.
Reposition to be within 30 ft (9 m)
of an RF signal repeater.
• Already at current level. The RF
Module has already responded to
a command, or is already at the
requested setting.
• Wireless controller or sensor
batteries low or installed
incorrectly. Replace or install
batteries properly.
• RF interference.
Do not run RF Module wires
with other power wires or
communication wires (e.g.,
networking, audio, or video
signals).
To Load
Live (Black)
Neutral (White) (White)
21 mm Knockout Opening
Conduit Nut
Switched Hot (Red)
LMM-16R-DV-B 220–240 V~50/60 Hz 16 A
6 A Motor
041706-04
Rev. A
09/2019

RF 模块 | 安装
附带 Softswitch
重要提示：
• 请授权具有资质的电气人员按照全部的本地及国家电
气规范进行安装。
• 注：仅限使用铜线。
• 检查装置的类型与等级是否符合应用要求。
• 切勿 安装任何带有明显损坏的产品。
• 如果明显可见湿气和泠凝，请将产品放置至完全干
燥， 方可进行安装。
• 可在 0 °C 至 55 °C
• 湿度为 0% 至 90% ，不会发生冷凝。
• 仅限室内使用。
请在安装前仔细阅读
负载状态
LED 开关
高级操作
关于系统设置指南和工具，
请访问www.lutron.com
RF 模块
RF模块操作说明
重新设定出厂默认设置
注：在某些情况下，人们可能需要重新设置
射频（RF）模块为出厂默认设置。
A轻按三次高级操作按钮（RF模块上
的“ADV” 按钮）并按住，直至LED开
始缓慢闪烁。
在开始闪烁的3秒内，松开按钮并再次轻
按按钮三次，这时LED将会快速闪烁，以
示装置已被重新设置为出厂默认设置。
B
注：任何曾与该装置相关的连接或程序设计均
将丢失，您需要重新进行程序设计。
中文
客户协助 | +91.124.439.0130 亚洲/中东 | 1.844.LUTRON1 美国/加拿大 | +1.610.282.3800 其他 | www.lutron.com/support
电击危险。可导致严重的人员
伤亡。在安装之前，请切断电
路断路器的电源。
警告
故障处理
负载未对无线发
射机作出
响应。
• 确保连接至RF模块的断路器
处于开启状态。
• 确保负载与RF模块正确
连接。
• 确保系统中的RF模块已被
激活。
• 确保无线发射机的电池安
装正确。
RF模块未对按
键、无线控制器
或传感器作出
响应。
• 程序设计不当。
用系统程序设计软件进行
编程。
• 超 出 RF范围。
重新将设备安装在RF信号中
继转发器9 m范围以内。
• 已处于当前水平。
RF模块已经对命令作出响
应，或已经处于所要求的设
置状态。
• 无线控制器或传感器电池电
量低或安装不正确。
更换电池或正确安装电池。
• RF 干扰。
切勿将RF模块电线与其他电
源线或通信电线布置在一起
（如网络电线、音频电线或
视频信号电线）。
041706-04
Rev. A
09/2019
Lutron Electronics Co., Inc. | 7200 Suter Road
Coopersburg, PA 18036-1299, U.S.A.
质量保证：
关于质保的信息，请访问：
www.lutron.com/TechnicalDocumentLibrary/Warranty.pdf
www.lutron.com/TechnicalDocumentLibrary/Intl_Warranty.pdf
Lutron和Softswitch是Lutron Electronics Co., Inc.在美国和/或
其他国家的商标或注册商标。
©2013-2019 Lutron Electronics Co., Inc.
220–240 V~50/60 Hz 16 A
6 A 马达
LMM-16R-DV-B
可以使用导管螺母（随附）或安装螺钉（未随附）将RF模块安
装在接线盒或配线箱（可选）中。请遵循当地和国家的电气规
范以进行正确安装。
RF 模块布置
RF模块必须安装在RF信号中继转发器9 m的范围以内。
在使用系统程序设计软件编程之前，RF模块不受系统控制。
安装：
1
2
3
10 mm
杠杆 操作的连接器接线（如图）
当给杠杆操作的连接器（提供3个）接线时， 请使用
直径为 2.5mm2至 4.0 mm2（14 AWG至12 AWG）
的实铜线或绞铜线。
Lutron Electronics Co., Inc. 特此声明，无线电设备型号LMM-16R-DV-B
符合指令2014/53/EU。可给下列地址写信索取DoC的副本：Lutron
Electronics Co., Inc. 7200 Suter Road, Coopersburg, PA 18036 USA。
至负载
21 mm穿线孔
导管螺母
符合
ImDA标准
DA103083
火线（黑色）
中线（白色） （白色）
开关火线（红色）
220–240 V~ 50/60 Hz
