Pulsar LPS 7i User manual

LPS 7i Battery Pack
Manual

Content
Specifications
Description
Package Contents
Precautions
Recommendations for Use
Battery Charging
Legal Compliances and Disclaimers

Specifications
LPS 7i
SKU 79187
Type Li-Ion
Nominal capacity at +22°С
(72°F), mAh 6400
Rated output voltage, V 3.7
Input voltage/charge rate
(wired charging) PPS 6-8.5 V ⎓ 3 A; 5 V ⎓ 3 A
Charge/discharge cycles,
minimum* 300
Charge/discharge ambient
temperature, °С (°F) 0...+35/- 25...+50
(+32…+95/- 13…+122)
Dimensions, mm / inch 79х31х43 / 3.11x1.22x1.69
Weight, kg / oz 0.13 / 4.59
* Once reached the specified limit, the battery capacity may drop to 80%.
This is normal and not a defect.

Description
LPS 7i rechargeable lithium-ion power supplies are designed for use with
Pulsar Telos thermal imaging devices. Batteries support USB Power Delivery
fast charging technology when using a standard charging set from Pulsar
(USB Type-C cable, power adapter). LPS 7i batteries also support wireless
charging.

Package Contents
Battery
Protective cover
Operating Manual
Warranty card

Precautions
It is not recommended to charge the battery with the USB cable and
wireless charger at the same time. This will not increase the charge rate
and may damage the battery.
Use the USB Type-C cable and power adapter supplied with the device
(or purchased separately) to charge the LPS 7i batteries.
Follow the safety precautions described in its Manual when using the
wireless charger.
Do not place any foreign objects between the battery and wireless
charger platform.
Do not charge the battery immediately after brining it from cold to
warm. Wait at least 30 minutes for the battery to warm up.
Do not leave the battery unattended while charging.
Do not use the power adapter and wireless charger if they have been
modified or damaged.
Do not leave the battery plugged in after charging is complete.
Do not expose the battery to high temperatures and naked flame.
Do not use the battery as a power source for devices that do not support
LPS 7i batteries.
Do not disassemble or deform the battery.
Do not drop or strike the battery.
Do not submerge the battery.
Keep the battery out of the reach of children.

Recommendations for Use
The battery should be partially charged for long-term storage – 50 to 80
%.
The battery should be charged at an ambient temperature of
0°C…+35°C (+32°F…+95°F). Otherwise, lifespan of the battery will
decrease significantly.
When using the battery at sub-zero temperatures, the battery capacity
decreases, this is normal and not a defect.
Do not use the battery at temperatures outside the range of -
25°С...+50°С (-13°F…+122°F) – this may reduce battery’s life.
The battery has a short-circuit protection. However, any situation that
may cause short-circuiting should be avoided.

Battery Charging
USB Charging
1. Remove the protective cover(6).
2. Connect the plug of the USB Type-C* cable (4) to the USB Type-C
connector (1) of the battery.
3. For fast charging, connect the second end of the USB Type-C cable (4)
to the Type-C connector of the power adapter* (3) by removing the
Type-A adapter from the plug. When connected to a computer or a
Type-A power adapter, the battery will charge at normal speed.

4. Plug the power adapter (3) into a 100-240 V socket.
5. LED (2) will display battery charge level (see Table).
(2) LED indication Battery charge status
Battery defective. Do not use
the battery!
Battery charge level is from
0% to 50%
Battery charge level is from
51% to 75%
Battery charge level is from
76% to 99%
Battery completely charged.
Charging will automatically
stop. The battery can be
disconnected.
WirelessCharging

1. Place the battery with the sign side on the wireless charger** (5)
. For more efficient wireless charging, align the lightning bolt icon on
the battery with the centre of the charger platform (5).
2. Turn on the wireless charger according to its instruction manual.
3. LED (2) will display battery charge level (see Table).
* Purchased separately or supplied as package contents of a device.
** Third party-purchasing. The LPS7i battery works with all QI standard
wireless chargers.

Note: Charging with a USB cable is significantly faster than using a wireless
charger.

Legal Compliances and
Disclaimers
The manufacturer reserves the right at any time, without mandatory notice,
to make changes to the package contents, design and characteristics that
do not impair the quality of the product.
Warranty for the Battery Pack is one year.
For technical support please contact [email protected].
Answers to frequently asked questions about the devices can also be found
in the FAQ section.
