PURE EVOKE-2S User manual

Owner’s manual
IT
DE
Bedienungsanleitung
Manuale dell’utente
Manuel de l’utilisateur
Brugsvejledning
Gebruikershandleiding
DK
NL
FR
EN
S

Safety instructions
Do not use the radio near water.
Do not remove screws from or open the radio casing.
Keep the unit away from heat sources and do not place sources of naked flames
(such as candles) on the unit.
Unit ventilation should not be impeded by covering the ventilation openings with
papers, curtains etc.
Do not place the unit in closed bookcases or racks without proper ventilation.
Do not place any objects containing liquids on the unit, such as vases.
Ensure that the mains plug is readily accessible in case isolation from the mains
is required.
Excessive sound pressure from earphones and headphones can cause hearing loss.
Consignes de sécurité
Ne pas utiliser cet appareil à proximité d’une source d’eau.
Ne pas ouvrir le boîtier de l’appareil, ni en retirer les vis.
Tenir l’appareil éloigné des sources de chaleur et ne pas déposer de flamme nue
(comme une bougie) sur l’appareil.
Ne pas couvrir ni obstruer les orifices de ventilation de l’appareil.
Assurer un dégagement suffisant autour de l’appareil pour permettre une bonne
ventilation.
Ne pas déposer d’objets contenant du liquide (comme un vase) sur l’appareil.
Veiller à ce que la prise de courant soit facilement accessible, pour le cas où l’on
aurait besoin d’isoler la chaîne du réseau électrique.
Un volume excessif peut causer des lésions auditives.
Sicherheitsanweisungen
Verwenden Sie das Gerät nicht in der Nähe von Wasser.
Nehmen Sie die Schrauben nicht vom Gehäuse des Radios ab.
Schützen Sie das Gerät vor Hitze und offenen Flammen. Stellen Sie keine
brennenden Kerzen auf dem Gerät ab.
Die Belüftungsschlitze des Geräts dürfen nicht etwa mit Papier oder Vorhängen
versperrt werden.
Stellen Sie das Gerät nicht in geschlossenen Schrankfächern oder Regalen
ohne ausreichende Belüftung ab.
Stellen Sie keine Gegenstände mit Flüssigkeiten (wie zum Beispiel
Blumenvasen) auf dem Gerät ab.
Vergewissern Sie sich, dass der Netzstecker leicht zugänglich ist, damit die
Verbindung zum Netz jederzeit unterbrochen werden kann.
Das Radiohören über Kopfhörer in übermäßiger Lautstärke kann Hörschäden
hervorrufen.
Istruzioni per la sicurezza
Non utilizzare la radio vicino all’acqua.
Non rimuovere le viti della custodia della radio e non aprirla.
Tenere l’unità lontano da fonti di calore e non appoggiarvi sopra oggetti o
apparecchi contenenti fiamme libere (es. candele).
Non coprire le prese d’aria con carta, tende o simili, in quanto potrebbero impedire
una corretta ventilazione dell’unità.
Non disporre l’unità su librerie o scaffalature chiuse che potrebbero impedirne una
corretta ventilazione.
Non collocare oggetti contenenti liquidi (es. vasi) sull’unità.
Assicurarsi che la spina di alimentazione principale sia facilmente accessibile in
caso si renda necessaria la disconnessione dalla rete di alimentazione principale.
L’ascolto di cuffie o auricolari a volume eccessivo può provocare danni irreparabili
all’udito.
Copyright
Copyright 2008 by Imagination Technologies
Limited. All rights reserved. No part of this
publication may be copied or distributed,
transmitted, transcribed, stored in a retrieval
system, or translated into any human or
computer language, in any form or by any
means, electronic, mechanical, magnetic,
manual or otherwise, or disclosed to
third parties without the express written
permission of Imagination Technologies
Limited.
Trademarks
EVOKE-2S, the EVOKE-2S logo, Intellitext,
textSCAN, ChargePAK, PURE, the PURE logo,
PURE Digital, the PURE Digital logo, EcoPlus,
the EcoPlus logo, Imagination Technologies,
and the Imagination Technologies logo
are trademarks or registered trademarks
of Imagination Technologies Limited. All
other product names are trademarks of
their respective companies. Version 2
October 2008.
Copyright
Copyright 2008 by Imagination Technologies
Limited. Alle Rechte vorbehalten. Kein Teil
dieser Publikation darf ohne ausdrückliche
und schriftliche Zustimmung von Imagination
Technologies Limited in irgendeiner Form
(elektronisch, mechanisch, magnetisch,
manuell oder auf andere Weise) kopiert,
verteilt, übermittelt, überschrieben, in einem
Suchsystem gespeichert, in eine andere
natürliche oder Computersprache übersetzt
oder Dritten zugänglich gemacht werden.
Warenzeichen
EVOKE-2S, das EVOKE-2S Logo, Intellitext,
textSCAN, ChargePAK, PURE, das PURE
Logo, PURE Digital, das PURE Digital Logo,
EcoPlus, das EcoPlus logo, Imagination
Technologies und das Imagination
Technologies Logo sind Warenzeichen
oder eingetragene Warenzeichen von
Imagination Technologies Limited. Alle
anderen Produktnamen sind Warenzeichen
ihrer jeweiligen Besitzer. Version 2.
Oktober 2008
Copyright
Copyright 2008 Imagination Technologies
Limited. Tous droits réservés. Aucune partie
de la présente publication ne doit être
copiée ou diffusée, transmise, retranscrite,
stockée dans un système de récupération
de données ou traduite, que ce soit dans
une langue humaine ou dans un langage
informatique, sous quelque forme et par
quelque moyen que ce soit, électronique,
mécanique, magnétique, manuel ou autre,
ou encore diffusée auprès de tiers sans
autorisation écrite expresse de Imagination
Technologies Limited.
Marques commerciales
EVOKE-2S, le logo EVOKE-2S, Intellitext,
textSCAN, ChargePAK, PURE, le logo PURE,
PURE Digital, le logo PURE Digital, EcoPlus,
le logo EcoPlus, Imagination Technologies
et le logo Imagination Technologies sont
des marques commerciales ou des marques
déposées de Imagination Technologies
Limited. Tous les autres noms de produits
sont des marques commerciales de leurs
détenteurs respectifs. Version 2 er Octobre
2008.
Copyright
Copyright 2008 by Imagination Technologies
Limited. Tutti i diritti riservati. Nessuna parte
della presente pubblicaziEVOKE-2S può
essere copiata o distribuita, trasmessa,
trascritta, memorizzata in un sistema di
archiviaziEVOKE-2S, o tradotta in un formato
normalmente comprensibile, in qualsiasi
forma o con qualsiasi mezzo, elettronico,
meccanico, magnetico, manuale o altro, o
divulgata a terze parti senza il permesso
scritto di Imagination Technologies
Limited.
Marchi
EVOKE-2S, il logo EVOKE-2S, Intellitext,
textSCAN, ChargePAK, PURE, il logo PURE,
PURE Digital, il logo PURE Digital, EcoPlus,
il logo EcoPlus, Imagination Technologies e il
logo Imagination Technologies sono marchi o
marchi registrati di Imagination Technologies
Limited. Tutti gli altri nomi di prodotti sono
marchi di proprietà delle rispettive società.
Version 2. Ottobre 2008.
Sikkerhedsanvisninger
Undlad at bruge radioen i nærheden af vand.
Du må ikke fjerne skruer fra eller åbne radiokabinettet.
Beskyt enheden mod varmekilder, og undlad at anbringe åben ild (for eksempel
lys) på enheden.
Undlad at tildække enhedens udluftningskanaler med papir, gardiner etc.
Undlad at anbringe enheden i lukkede kasser eller rack-enheder uden
tilstrækkelig ventilation.
Undlad at anbringe genstande med væsker som for eksempel vaser på enheden.
Kontroller, at netstikket er let tilgængeligt, såfremt der kræves afbrydelse fra
el-nettet.
Overdrevne lydtryk fra høre- og hovedtelefoner kan forårsage høreskade.
Copyright
Copyright 2008 tilhører Imagination
Technologies Limited. Alle rettigheder
forbeholdes. Ingen dele af denne publikation
må kopieres eller distribueres, transmitteres,
omskrives, gemmes i et system, hvor den kan
hentes, eller oversættes til menneskeligt
forståeligt sprog eller computersprog, i
nogen som helst form eller med nogen som
helst midler, det være sig elektroniske,
mekaniske, magnetiske, manuelle eller på
anden måde, eller fremvises til tredje parter
uden udtrykkelig, skriftlig tilladelse fra
Imagination Technologies Limited.
Varemærker
EVOKE-2S, EVOKE-2S-logoet, Intellitext,
textSCAN, ChargePAK, PURE, PURE-logoet,
PURE Digital, PURE Digital-logoet, EcoPlus,
EcoPlus-logoet, Imagination Technologies
og Imagination Technologies-logoet er
varemærker eller registrerede varemærker,
der tilhører Imagination Technologies Limited.
Alle andre produktnavne er varemærker, der
tilhører deres respektive virksomheder.
Version 2. Oktober 2008.
Veiligheidsaanwijzingen
Gebruik de unit niet in de nabijheid van water.
Verwijder geen schroeven uit de behuizing van de radio en open deze niet.
Houd de unit uit de buurt van warmtebronnen. Plaats geen open vlammen
(zoals kaarsen) bij of op de unit.
De ventilatie van de unit mag niet worden belemmerd door de ventilatie-
openingen met papier, gordijnen of dergelijke te blokkeren.
Plaats de unit niet in een afgesloten boekenkast of rek zonder goede ventilatie.
Plaats geen voorwerp dat water bevat, zoals een bloemenvaas, bij de unit.
Zorg ervoor dat de netspanningsstekker gemakkelijk bereikbaar is in geval het
apparaat van de netspanning moet worden afgesloten.
Overmatige geluidsdruk van oortelefoons en hoofdtelefoons kan doofheid
veroorzaken.
Copyright
Copyright 2008 door Imagination
Technologies Limited. Alle rechten
gereserveerd. Geen enkel gedeelte van deze
publicatie mag gekopieerd of gedistribueerd,
uitgezonden, overgeschreven, opgeslagen
in een retrieval system of vertaald in om
het even welke menselijke of computertaal,
in geen enkele vorm of door geen enkel
middel, elektronisch, mechanisch,
magnetisch, manueel of anders of bekend
gemaakt aan derde partijen zonder de
uitdrukkelijke geschreven toestemming
van Imagination Technologies Limited.
Handelsmerken
EVOKE-2S, het EVOKE-2S logo, Intellitext,
textSCAN, ChargePAK, PURE, het PURE logo,
PURE Digital, het PURE Digital logo, EcoPlus,
het EcoPlus logo, Imagination Technologies
en het Imagination Technologies logo
zijn handelsmerken of geregistreerde
handelsmerken van Imagination
Technologies Limited. Alle andere
productnamen zijn handelsmerken van hun
respectieve firma’s. Versie 2. Ok tober 2008.

1
Contents
Getting started ......................................................... 2
Quick set up .........................................................................................2
Controls at a glance ..............................................................................3
Rear connectors and controls .................................................................3
Using your EVOKE-2S................................................. 4
Tone control ..........................................................................................4
Switching between DAB, FM and an Auxiliary device .................................4
Changing stations..................................................................................4
Changing the information shown on screen..............................................5
Using textSCAN™ to pause and control scrolling text ................................5
ReVu™ − pause and rewind live radio......................................................5
Intellitext® ............................................................................................6
Using a ChargePAK™..............................................................................6
Setting the alarm & timers......................................... 7
Setting the alarm ..................................................................................7
To cancel a sounding tone or radio alarm ................................................8
Kitchen timer ........................................................................................8
Storing and selecting presets................................... 10
Setup options ......................................................... 11
Options only available in DAB...............................................................11
Options only available in FM.................................................................11
General options...................................................................................12
Display settings...................................................................................12
Energy saving......................................................................................12
Help and Specifications........................................... 13
Secondary and inactive stations ...........................................................13
Hints and tips .....................................................................................13
Software Updates................................................................................13
Technical Specifications.......................................................................14
Contents
ENEN

2
Unclip the aerial from the clip on the rear of the radio and fully extend it (Aand B).
Insert the supplied mains cable into the socket on the rear of the radio (C).
Connect the mains plug to the mains supply (D), make sure the power switch (E) is on
and press the Standby button.
Wait for EVOKE-2S to complete an Autotune for all available DAB stations (this takes
about a minute). When the Autotune is complete, a station will be selected.
Getting started
Quick set up
Getting started
EcoPlus
EcoPlus
AuxIn LineOut USB
B
A
C
DEcoPlus
EcoPlus
AuxIn LineOut USB
E
0
I
0
I
0
I
0
I
PURE EVOKE-2S 52
Now tuning...
1
Talking to the people wh
BBC Radio 2
Energy saving
enabled
(> page 12)

3
Controls at a glance
Controls and connectors
Volume dial
Turn to adjust volume
Push to mute volume Tune dial
Browse and select radio
stations > page 4
Use textSCAN > page 5
Presets 1 −6+
Store up to 50 DAB
and 50 FM preset
stations > page 9
Light sensor
Auto-adjusts
the display
brightness
> page 12
Menu
Set the alarm > page 6
Adjust the display > page 12
Setup options > page 11
Source
Switch audio
source
> page 4
Standby
Switch the radio into
standby or off if running
off ChargePAK > page 6
Tone
Adjust the bass and
treble > page 4
Info
Change the
information
shown on
screen > page 5
Rear connectors and controls
0
I
Aux In Line Out
USBUSB
USB connector
for upgrades
only. Mini-B
type.
Analogue
stereo input
for iPod,
MiniDisc, etc.
3.5 mm
headphone
socket.
Connect to
an external
amplifier.
Mains socket and power
switch.
Press to pause and play live
radio then rotate Tune to fast-
forward/rewind. Press Tune to
return to live radio.
> page 5
View news, sports
results and more from
participating stations.
> page 10
Alarm/Timer
Set the alarm, kitchen
timer or sleep timer.
> page 6
ENEN

4
Using your EVOKE-2S
Tone control
Adjusting the bass
1. Push the Tone button and push the Tune dial to select ‘Bass’.
2. Turn the Tune dial left or right to adjust the bass level and push to set.
Adjusting the treble
1. Push the Tone button and turn and push the Tune dial to select ‘Treble’.
2. Turn the Tune dial left or right to adjust the treble level and push to set.
Switching between DAB, FM and an Auxiliary device
Press the Source button and then repeat to listen to DAB, FM or Auxiliary device (a separate
device such as an MP3 player).
Changing stations
When listening to DAB
Turn the Tune dial left or right to browse through the list of available DAB stations. The current
station remains at the top of the screen. Push the Tune dial to change the station.
When listening to FM
Seek Tuning
Turn and release the Tune dial right or left to seek to the next or previous FM station that has a
strong signal.
Manual Tuning
1. Change the FM tuning mode to ‘Manual’ (> page 11).
2. Turn the Tune dial right or left to step up or down 0.05 MHz.
Using your EVOKE-2S
Source
FM
Tune
Tune
Tune
BBC Radio 6Music
BBC Radio 2 Now playing: Race For T BBC Radio 6Music
MERCURY
87.50MHz FM
Searching... >
1. 5
87.50MHz FM

5
Changing the information shown on screen
You can change the information that is displayed on screen. Press the Info button and repeat to
cycle through the information display options available for the current audio source.
Scrolling text Information broadcast by most DAB stations and some FM (RDS) stations.
Signal strength Displays a meter illustrating the strength of the DAB or FM signal.
Signal quality Displays DAB signal quality: 85 to 100 good; 70 to 84 OK; 0 to 69 poor.
Full screen time Displays the time, mode icon and an alarm indicator, if set.
ChargePAK status Displays a charging or percentage power remaining indicator for the
optional ChargePAK E1 rechargeable battery pack (> page 6).
Using textSCAN™ to pause and control scrolling text
1. When ‘Scrolling text’ information is displayed in either DAB or FM, push the Tune dial to
pause the scrolling text.
2. Turn the Tune dial right and left to scroll forwards and backwards through the current scrolling
text. To exit textSCAN push the Tune dial again.
ReVu™ − pause and rewind live radio
ReVu enables you to pause and rewind radio by saving an audio ‘buffer’ of the current station. You
can rewind for approximately 10-15 minutes depending on the broadcast quality of the current
station and/or how long you’ve been tuned to the current station.
To pause and rewind live radio
1. Press to pause the current station and enter ReVu mode.
2. When the audio is paused you can do the following:
Using your EVOKE-2S
Tune
Now playing: Race For T
BBC Radio 6Music Playing: Race For Th BBC Radio 6Music
Tune Tune
Rewind up to the
start of the audio
buffer.
Press to
stop rewinding or
rotate the Tune dial
one click in the
opposite direction.
Press to play and
pause.
Press and hold to
return to live radio.
Fast-forward through
the audio buffer.
Press to
stop fast-forwarding
or rotate the Tune
dial one click in the
opposite direction.
Talking to the people wh
BBC R2 [00:02]
REVU
REVU
Tune
ENEN

6
Intellitext®
Intellitext provides on-demand text information such as sports headlines, weather, and news from
DAB stations that support the service including BBC Radio Five Live and talkSPORT. The text is
updated by the broadcasters and stored in your radio while you listen to stations. Intellitext is
listed by station and split into categories.
To view Intellitext messages
1. Press to enter the Intellitext menu. Push the Tune dial to select ‘View’ and access a
list of stations for which you have Intellitext information (if you see ‘No data’ you need to tune
to a station broadcasting Intellitext for a few minutes before information is received).
2. Push the Tune dial to select a station and rotate and push the Tune dial to browse Intellitext
categories for that station, e.g., BBC Radio 5Live > SPORT > FOOTBALL. The selected
information will scroll across the screen. Press to go back up to the previous
category.
Note: You can use textSCAN (> page 5) to pause and control Intellitext messages.
To change Intellitext options
Press to enter the Intellitext menu. Turn the Tune dial and push to select one of the
following options:
Set timeout Choose to delete old Intellitext messages after 1 week (default) or 1 day.
Clear all Delete all stored Intellitext messages immediately.
Using a ChargePAK™
ChargePAK E1 is a rechargeable battery pack which plugs into the socket in the radio’s battery
compartment. Whenever your radio is connected to a mains supply and the power switch on the
rear is switched on, the ChargePAK will be charging and the power remaining will be available
to view as a percentage in the Information display options (> page 5). A complete charge will
provide about 20 hours of portable listening.
To purchase a PURE ChargePAK E1, contact your nearest PURE dealer, visit the shop on our
website at www.pure.com or call the PURE order line on 0845 045 1122.
Important: EVOKE-2S can only be powered with a ChargePAK E1 and is not compatible with any
other batteries, either disposable or rechargeable, or any other ChargePAK model. Always switch
the unit off and disconnect it from mains power before inserting or removing a ChargePAK. Charge
a new ChargePAK for 24 hours before first using battery power. Carefully follow the separate fitting
instructions that are supplied with the ChargePAK E1.
+
™
ChargePAK
+
Using your EVOKE-2S

7
Setting the alarm & timers
Setting the alarm
EVOKE-2S has an alarm which switches the radio on (if in standby mode) and tunes to a DAB or
FM radio station, or sounds an alarm tone.
1. Press the (Alarm/Timer) button and select ‘Alarm’ to display the alarm status screen.
2. Push the Tune dial to select ‘Set alarm’, scroll to ‘Alarm on’ and push the Tune dial to select.
The alarm is now active.
3. Push the Tune dial to select ‘Set time’. To set the time you want the alarm to sound turn the
Tune dial to adjust the hours and then push to confirm. Repeat to adjust the minutes.
4. Push the Tune dial to select ‘Set days’. Choose when you want the alarm to repeat (turn the
Tune dial to browse through the options and push to select).
Daily Every day
Weekday Monday –Friday, every week
Weekend Every weekend
Saturday Every Saturday
Sunday Every Sunday
Once only The alarm will sound at the time you have selected and not repeat.
5. Push the Tune dial to select ‘Set mode’ and choose the type of alarm you want to sound:
DAB, FM or Tone. If you select ‘Tone’, there are no further options.
6. For DAB and FM alarms only, push the Tune dial to select ‘Select station’ and choose which
DAB or FM radio station you want to sound for the alarm.
For DAB alarms
Select a DAB station from the station list.
For FM alarms
Choose between ‘Last tuned’ or an FM preset station. If you select ‘Last tuned’ the alarm will
tune to the last FM station you listen to before the alarm sounds.
Tune
08:00 set hour
07:00
Tune
If you want to set
a ‘one-off’ alarm
choose ‘Once only’.
Tune
Tune Tune
Set alarm
Alarm off
Alarm on
Alarm off
Setting the alarm & timers
ENEN

8
7. If you have selected a DAB or FM alarm you can push the Tune dial to select ‘Alarm volume’
and turn to adjust the volume level for the alarm from 1 (very quiet) to 27 (very loud).
That’s it! You can see if the alarm is switched on in the ‘Full screen time’ display (> page 5).
To cancel a sounding tone or radio alarm
When a tone alarm is sounding, push the Tune dial, or press the Alarm or Standby button to
cancel the alarm. To cancel a DAB or FM alarm press any button, the alarm will be cancelled and
the button will preform its normal function.
Kitchen timer
EVOKE-2S has a countdown timer which will sound an alarm after a set time period – handy for
use in the kitchen.
To set a kitchen timer
1. Press the (Alarm/Timer) button and select ‘Kitchen timer’.
2. Turn the Tune dial to change the hours and push to confirm. Turn again to change the minutes
and push to confirm and start the countdown timer.
The alarm will sound after the time period you have set whether the radio is on or in standby.
Cancel the beeping alarm tone by pressing any button on the radio.
To stop and reset the kitchen timer to zero
To stop and reset the kitchen countdown timer to zero before it sounds a beeping alarm tone,
press and hold down the (Alarm/Timer) button for three seconds until you see the
message ‘Timers cleared’.
Setting the alarm & timers
Tune Tune
Tune Tune
01 hours 00 mins
01 hours 25 mins
08:30
08:30
DAB
Tune Tune
Timers cleared
22:45
08:30
08:30
The alarm is set to
sound at 8:30 am
DAB
Alarm volume
08
Tune
10 set volume

9
Setting the sleep timer
EVOKE-2S has a sleep timer that switches your radio into standby (or off if powered by a
ChargePAK) after a number of minutes has elapsed. Use this if you want to fall asleep to the radio.
To set a sleep timer
1. Press the (Alarm/Timer) button and select ‘Sleep timer’.
2. Rotate the Tune dial to increase the duration of the sleep from 15 to 90 minutes in fifteen
minute intervals. Press the Tune dial to start the sleep timer.
You can see if the timer is currently switched on in the ‘Full screen time’ display (> page 5)
To cancel a sleep timer
Select ‘Sleep timer’ (as above) and set the duration of the Sleep timer to ‘Sleep off’. Alternatively,
press and hold the (Alarm/Timer) button for three seconds until you see the message
‘Timers cleared’.
22:45
The sleep timer is
set to switch o
in 15 minutes
DAB
15
15
Setting the alarm & timers
ENEN

10
Storing and selecting presets
Store up to 50 of your favourite DAB and up to 50 FM radio stations as presets for easy access.
To quick-store a DAB or FM station to a preset button (1–5)
Tune to the DAB or FM station you want to store. Press and hold one of the numbered Preset
buttons (1–5)for two seconds until you see the ‘Preset saved’ message on the bottom line.
To store a DAB/FM station to the preset list (1–50)
1. Tune to the DAB or FM station you want to store.
2. Press and release the 6+ button to view the numerical list of stored presets, then turn the
Tune dial to choose any Preset number between 1 and 50.You can overwrite existing presets.
3. Press and hold the 6+ button (or the Tune dial) for two seconds until you see the ‘Preset
saved’ message. The current DAB/FM station is now stored to that number on the Preset list.
To recall a preset when listening to DAB or FM
1. To tune to Presets 1 to 5, press the corresponding numbered button on the unit (1to 5).
2. To access the full list of presets (from 1 to 50), press and release the 6+ button, turn the
Tune dial right or left to scroll through the list of presets, then push and release the Tune dial
to tune to the selected preset.
Storing and selecting presets
Empty preset
Preset 06 Empty Preset
Preset 10
Preset 10 saved
Classic FM
erformed by New Phil
Classic FM
erformed by New Phil
Classic FM
Preset 01 saved
BBC Radio 6Music
BBC Radio 6 Music
Now playing: No Cars G
2
Tune
Tune
2
Tune
Classic FM
Preset 10
Tune
Tune
Tune 2

11
Setup options
Options only available in DAB
When listening to DAB, press the Menu button, turn the Tune dial to scroll through the options
and push the Tune dial to select.
DRC
DRC (Dynamic Range Control) value makes the quieter sounds in a DAB broadcast easier to hear
at low volume or in a noisy environment. Check with the broadcasters to find out if they use DRC.
DRC full Applies the DRC level as sent with the broadcast.
DRC half DRC level is set to half that sent with the broadcast.
DRC off Any DRC level broadcast will be ignored.
Autotune
Scans all DAB frequencies for stations and automatically adds any new stations found to the
station list. This may take a few minutes. To stop an Autotune press Menu.
Station order
Change the order that DAB stations appear in the list.
Alphanumeric Lists all stations in alphanumeric order.
Active station Lists active stations first on the station list
Multiplex Lists stations in groups according to their multiplex – a group of stations
broadcast by the same operator.
Trim stn. list
Removes inactive stations from the station list. (> page 14)
Options only available in FM
FM tuning mode
Seek
When you turn the Tune dial, the radio tunes to the next station with a good signal.
Manual
When you turn the Tune dial, the radio tunes up or down the FM frequency range by 0.05 MHz.
FM stereo mode
Choose from Stereo (default) or Mono. Mono may improve audio clarity where stereo signals are
weak.
Setup options
ENEN

12
General options
Display settings
You can adjust the brightness and time-out duration of the display for when the unit is switched
on and in standby. To change display options:
1. Press Menu, scroll to ‘Display settings’ and push the Tune dial.
2. Now choose either ‘Active’ to change settings that apply when the unit is switched on, or
‘Standby’ to change settings that apply in standby.
Changing the display time-out duration
Select ‘Duration’ and choose from the following two modes:
Always on The screen is always set to your preferred brightness level.
Timed off The screen is set to your preferred brightness level when a button is pressed and
then switches off after 7 seconds of inactivity.
Changing your preferred brightness level
Select ‘Brightness’ and choose from the following options:
Automatic The brightness of the screen adjusts automatically depending on the ambient light
levels in the room (default).
1–10 Turn the Tune dial to vary the brightness level between 1 (very dim) and 10 (very
bright) and push to confirm your preferred setting.
Set clock
You can manually set the time and date if required. If you have a DAB signal and/or a good FM
(RDS) reception these will be updated automatically.
Energy saving
EVOKE-2S is part of the PURE EcoPlus product family, designed and manufactured to minimise
power consumption when the unit is switched on and to use less than 1 Watt in standby. One way
this low power consumption is enabled is by not collecting and storing Intellitext messages when
the unit is in standby. You can override this option by switching off energy saving mode, but this
will increase standby power consumption. Two options are available:
On EVOKE-2S updates the Intellitext data when you tune to a station that broadcasts
Intellitext. Intellitext data is not collected in standby.
Off EVOKE-2S collects Intellitext data in standby from the last station you tuned to
with Intellitext, which increases standby power consumption.
Note: if you fit the optional ChargePAK E1 the unit will switch off when you press the Standby
button and not enter standby, as long as the unit is not connected to mains power.
Setup options

13
Help and Specifications
Secondary and inactive stations
(<</>>) Secondary DAB services
Secondary services accompany some stations, providing extra information or alternative content
and may only be broadcast at certain times. If a station has secondary services available, the
station shows ‘>>’ next to its name in the station list and the secondary service appears next to
the station in the list. A secondary service has a ‘<<’ before its name in the station list.
(?) Inactive or unavailable DAB stations
Inactive or unavailable stations appear on the station list preceded by ‘?’ and cannot be tuned
to. A station may be inactive or unavailable because the station is not broadcasting at the current
time (check with the station), you are out of range, or it has stopped broadcasting altogether.
Hints and tips
Display says ‘No stations available’ or ‘ Station not available’
Use Autotune (> page 11) to search for stations. Try adjusting your aerial or radio position.
Receiving new DAB stations that have started broadcasting
Use Autotune (> page 11) to scan for new stations and add them to the station list.
Using the alarm when a ChargePAK E1 is fitted
When the radio is powered by a ChargePAK E1 for portable listening, i.e., a ChargePAK
rechargeable battery is fitted and the unit is not connected to mains power, the radio switches off
completely when the Standby button is pressed and the alarm will not sound. In this case, the
message ‘Disabling alarm’ will be displayed when the Standby button is pressed.
Resetting your radio
Resetting your radio removes all presets, clears the station list and resets all options to defaults.
1. Press and hold the Menu button for four seconds.
2. Turn and push the Tune dial to select ‘Factory Reset’.
3. Push the Tune dial within 8 seconds to confirm the reset or the reset will cancel.
Software Updates
Software updates for your EVOKE-2S may be made available in the future. If you register your
product and include a valid e-mail address you will receive notification of software updates
(register at www.pure.com/register or fill in the supplied warranty card). Alternatively, visit
http://support.pure.com at any time to check for available software updates.
To update your software
Connect your radio to your PC using a suitable A-to-mini-B type USB cable. Follow the instructions
provided with the software download at http://support.pure.com
Note: USB update requires a PC (not Mac) with internet access running Windows XP and a
suitable USB cable (not included).
Help and Specifications
ENEN

14
Technical Specifications
General Stereo digital radio with full Band III and FM reception. ETS 300 401
compliant and capable of decoding all DAB transmission modes 1-4 up to and
including 192 kbps. Supports FM RDS and RadioText. Future upgrade supported
for DAB+
Frequency ranges DAB Band III 174–240 MHz, FM 87.5–108 MHz.
Speakers Two mid-range 3” drive units + two ¾” dome tweeters.
Inputs 220-240V AC power socket for supplied power cable. 3.5mm Line-in for auxiliary
devices. USB (mini-B type) for product upgrades.
Outputs 3.5mm headphone, 3.5mm line out (analogue).
Presets 50 DAB and 50 FM presets.
Display High contrast yellow graphical 128 x 22 organic LED (OLED) display
Power cable Detachable mains lead supplied.
Approvals CE marked. Compliant with the EMC and Low Voltage Directives (2004/108/EC
and 2006/95/EC).
Dimensions (mm) 210 high x 290 wide x 120 deep.
Aerial: Removable telescopic aerial supplied.
Help and Specifications
Components are selected for
minimised environmental impact.
Disposal of Waste Electrical & Electronic Equipment
This symbol on the product or on its packaging indicates that this product should not be
treated as household waste. Instead it should be handed over to a suitable collection
point for the recycling of electrical and electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate
waste handling of this product. The recycling of materials will help to conserve natural
resources. For more detailed information about recycling of this product, please contact
your local council office, your household waste disposal service or the shop where you
purchased the product.

1
Inhalt
Erste Schritte............................................................ 2
Quick Setup - Schnellstart......................................................................2
Die Bedienelemente auf einen Blick........................................................3
Anschlüsse und Schalter auf der Rückseite des Geräts .............................3
Bedienung Ihres EVOKE-2S ........................................ 4
Klangregler ...........................................................................................4
Umschalten zwischen DAB, UKW und einem Zusatzgerät............................4
Senderwechsel ......................................................................................4
Angezeigte Display-Informationen ändern ................................................5
textSCAN™ zum Anhalten und Überprüfen von Lauftext .............................5
ReVu™ − Anhalten und Zurückspulen des Radioprogramms.......................5
Intellitext® ............................................................................................6
Verwendung von ChargePAK™ .................................................................6
Einstellen von Wecker und Timer ................................ 7
Einstellen des Weckers...........................................................................7
Abschalten eines aktuell ertönenden Wecksignals ....................................8
Küchenwecker .......................................................................................8
Voreinstellungen speichern und anwählen................. 10
Einstellungsoptionen ............................................... 11
Nur im DAB-Betrieb verfügbare Optionen ...............................................11
Nur im UKW-Betrieb verfügbare Optionen...............................................11
Allgemeine Optionen............................................................................12
Display settings (Anzeigeeinstellungen) .................................................12
Energiesparmodus...............................................................................12
Hilfe und Spezifikationen......................................... 13
Sekundärstationen / inaktive Sender ....................................................13
Tipps und Tricks...................................................................................13
Software-Updates................................................................................13
Technische Daten ................................................................................14
Inhalt
DE

2
Lösen Sie die Antenne aus der Klemmhalterung auf der Rückseite des Radios und
ziehen Sie den Teleskopstab zu voller Länge aus (Aund B).
Stecken Sie den Stecker des mitgelieferten Netzkabels in die Buchse auf der Rückseite
des Radios (C).
Schließen Sie das Netzkabel an eine Netzsteckdose an (D), vergewissern Sie sich, dass
der Netzschalter (E) eingeschaltet ist und drücken Sie die Standby-Taste.
Warten Sie, bis der EVOKE-2S die automatische Sendersuche für alle verfügbaren DAB-
Sender abgeschlossen hat (dies dauert etwa eine Minute). Wenn die automatische
Sendersuche abgeschlossen ist, wird ein Sender ausgewählt.
Erste Schritte
Quick Setup - Schnellstart
Erste Schritte
EcoPlus
EcoPlus
AuxIn LineOut USB
B
A
C
DEcoPlus
EcoPlus
AuxIn LineOut USB
E
0
I
0
I
0
I
0
I
PURE EVOKE-2S 52
Now tuning...
1
Talking to the people wh
BBC Radio 2
Energy saving
enabled
(> Seite 12)

3
Die Bedienelemente auf einen Blick
Regler, Schalter und Anschlüsse
Lautstärkeregler
Drehen Sie diesen Regler, um
die Lautstärke zu verändern,
und drücken Sie ihn, um das
Gerät stummzuschalten. Frequenzsteller
Radiosender suchen und
auswählen > Seite 4
Verwendung von textSCAN >
Seite 5
Speicherplätze 1 −6+
Speichern Sie bis zu 50
DAB- und 50 UKW-Sender als
Voreinstellungen. > Seite 9
Lichtsensor
Automatische
Anpassung der
Anzeigehelligkeit
> Seite 12
Auswahl
Einstellen des Weckers > Seite 6
Anpassen des Displays > Seite 12
Einstellungsoptionen > Seite 11
Source (Quelle)
Audioquelle
umschalten
> Seite 4
Standby
Schalten des Radios in
den Stand-by-Modus oder
Ausschalten bei eingesetztem
ChargePAK. > Seite 6
Tone (Klang)
Bass- und Höhenregler
> Seite 4
Info
Anpassung der
auf dem Display
angezeigten
Informationen >
Seite 5
Anschlüsse und Schalter auf der Rückseite des Geräts
0
I
Aux In Line Out
USBUSB
USB-
Anschluss, nur
für Upgrades.
Typ Mini-B.
Analoger
Stereoeingang
für iPod,
Minidisc-Player
usw.
3,5-mm-
Buchse für
Stereokopfhörer
Anschluss
für externen
Verstärker
Netzanschluss und
Netzschalter.
Drücken Sie, um das laufende
Radioprogramm zu unterbrechen
oder fortzusetzen. Drehen
Sie den Frequenzsteller Tune,
um die Wiedergabe vor- und
zurückzuspulen. Drücken Sie
den Frequenzsteller Tune, um
zum laufenden Radioprogramm
zurückzukehren. > Seite 5
Anzeigen von Nachrichten,
Sportergebnissen und
anderen Informationen von
teilnehmenden Sendern.
> Seite 10
Wecker/Timer
Stellen Sie den Wecker,
den Küchen-Timer oder
den Sleep-Timer ein.
> Seite 6
DE

4
Bedienung Ihres EVOKE-2S
Klangregler
Regelung der Bässe
1. Drücken Sie die Klangreglertaste Tone und die Frequenzstellertaste Tune und wählen Sie die
Option ‘Bass’ aus.
2. Drehen Sie den Frequenzsteller Tune nach links oder rechts um die Bässe anzupassen.
Drücken Sie anschließend die Taste, um die gewünschten Einstellungen vorzunehmen.
Regelung der Höhen
1. Drücken Sie die Klangreglertaste Tone, drücken und drehen Sie die Frequenzstellertaste Tune
und wählen Sie die Option ‘Treble’ aus.
2. Drehen Sie den Frequenzsteller Tune nach links oder rechts um die Höhen anzupassen.
Drücken Sie anschließend die Taste, um die gewünschten Einstellungen vorzunehmen.
Umschalten zwischen DAB, UKW und einem Zusatzgerät
Drücken Sie die Quelltaste Source ein oder mehrere Male, um zwischen DAB, UKW oder Aux
(einem separaten Zusatzgerät wie etwa einem MP3-Player) umzuschalten.
Senderwechsel
Bei DAB-Betrieb
Drehen Sie den Frequenzsteller Tune nach links oder rechts um sich durch die Liste der
verfügbaren DAB-Sender zu bewegen. Der aktuelle Sender bleibt dabei auf der ersten Zeile des
Displays angezeigt. Drücken Sie den Frequenzsteller Tune, um den Sender zu wechseln.
Bei UKW-Betrieb (FM)
Automatische Sendersuche
Starten Sie durch Drehen des Frequenzstellers Tune nach rechts oder links und anschließendes
Loslassen den Suchlauf zum jeweils nächsten bzw. vorigen UKW-Sender mit einem stärkeren Signal.
Manuelle Senderwahl
1. Wechseln Sie den UKW-Frequenzwahlmodus auf manuell (> Seite 11).
2. Drehen Sie den Frequenzsteller Tune nach links oder rechts, um sich jeweils um 0,05 MHz
fortzubewegen.
Bedienung Ihres EVOKE-2S
Source
FM
Tune
Tune
Tune
BBC Radio 6Music
BBC Radio 2 Now playing: Race For T BBC Radio 6Music
MERCURY
87.50MHz FM
Searching... >
1. 5
87.50MHz FM
