PURE move 2500 User manual

1
Thank you for choosing Move 2500. This manual
will get you up and running in no time and
explains how to make the most of Move 2500’s
great features. If you need additional help with
topics not covered in this manual, please visit the
Pure support pages at www.pure.com.

2
Move 2500 Safety Instructions
1. Read these instructions – All the safety and operating instructions should be
read before this product is operated.
2. Keep these instructions – The safety and operating instructions should be
retained for future reference.
3. Heed all warnings – All warnings on the appliance and in the operating
instructions should be adhered to.
4. Follow all instructions – All operating and use instructions should be followed.
5. Clean only with dry cloth.
6. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
7. Only use attachments/accessories specified by the manufacturer.
8. Unplug the apparatus during lightning storms or when unused for long periods
of time.
9. Refer all servicing to qualified personnel. Servicing is required when the
apparatus has been damaged in any way, does not operate normally, or has
been dropped.
10. To reduce the risk of electric shock, do not remove plastic cover or screws
as there are no user-serviceable parts inside. Refer servicing to qualified
personnel.
11 Avoid liquids getting into Move. Should not be immersed in water, or used
where this may happen, such as a bathroom.
ChargePAK M1 Safety Instructions
1. Read the instructions for ChargePAK use in this document.
2. Only use your ChargePAK with original Pure products.
3. Store ChargePAK in a cool, dry place at normal room temperature. Remove
from devices that will be stored unused for extended periods.
4. Do not puncture, modify, drop, throw, or cause other unnecessary shocks
to your ChargePAK. May present a risk of fire, explosion, or chemical burn if
mistreated.
5. Do not dispose of ChargePAK in a fire or incinerator, or leave in hot places
such as a motor car under direct sunlight. Do not store near oven, stove, or
other heat source.
6. Do not connect ChargePAK directly to an electrical source, such as a building
outlet or automobile power-point. Do not place into a microwave oven, or any
other high-pressure container.
7. Do not immerse ChargePAK in water or otherwise expose it to liquids.
8. Do not short circuit ChargePAK.
9. Do not use or charge a ChargePAK that appears to be leaking, discoloured,
rusty, deformed; emitting an odour; or is otherwise abnormal.
10. Do not touch a leaking ChargePAK directly; wear protective material to remove
and dispose of it properly immediately.
11. Do not store where children may have access.
12. Dispose of ChargePAK as per normal rechargeable batteries according to the
local laws and regulations of your region. Some batteries may be recycled,
and may be accepted for disposal at your local recycling centre.

3
Contents
4 What’s in the box?
5 Quick guide to Move 2500
6 Getting started
6 Insert the ChargePAK
7 Connect headphones
7 Switch on
7 Select language
7 Autotune
8 Reading the display
9 Using the navigation dial
10 Listening to digital radio
10 Listening to FM radio
11 Favourites
12 Settings
12 Time (12/24h)
12 Language
12 Factory reset
12 Version
12 Update
13 FM stereo
13 Autotune
13 Sleep timer
14 Audio settings
14 Display settings
15 Help and specifications
15 Hints and tips
15 Technical specifications
17 Pure Warranty Statement for Australia

4
What’s in the box?
Move 2500 Noise-isolating headphones
(Plus a choice of small,
medium or large earbuds)
ChargePAK M1 Power adapter
(Attach the appropriate pins for
your region)

5
Quick guide to Move 2500
Display
Navigation dial
See page 9 for information.
Top
Bottom
Micro USB socket
For connecting the mains
adapter or a USB cable (for
software updates).
Lock switch
Slide to lock the navigation dial
and the Select button to prevent
accidental use.
3.5mm socket
For headphones.
Select button

6
Getting started
Insert the ChargePAK
1. Press plastic catch on rear and slide the rear cover and lift off as
shown.
2. Insert ChargePAK M1. It can only be inserted one way, with the
ChargePAK logo facing up.
3. Once ChargePAK M1 is securely inserted, place the rear cover
back on. Press down slightly near the catch while sliding the cover
back on.
Note: Before using Move for the first time, we recommend that you
charge it for at least 3 hours.
Remove ChargePAK M1 if you are storing Move unused for a long
period.
Under normal circumstances your ChargePAK M1 will give you
years of trouble-free use, but as with all rechargeable batteries its
performance will gradually reduce with age. To replace it, visit your
local Pure dealer or buy direct from www.pure.com.

7
Connect headphones
For optimum sound quality and noise
isolation, attach the size of earbuds that best
fit your ears.
Unravel the earphone cable and plug the
headphones into the socket on the bottom
of Move.
Warning: Damage to hearing can occur with
consistent exposure to high volume when
using headphones. Always check the volume
level before using Move.
Note: Because the headphone cable doubles
as an aerial, using headphones with shorter
or asymmetrical cables or using headphones
with volume controls may affect reception.
Switch on
Press Source to switch Move on.
Select language
Turn the navigation dial and press Select to
choose from English, French, German or
Italian.
Autotune
Move will perform an autotune for digital
stations and tune to a station when complete.
The number of stations found is displayed
during an autotune.
Note: An autotune can take up to two
minutes.
DR
ST
Scanning... 32
Move 2500
Language *
English
DR
ST
BBC Radio 2
Now playing: P

8
Reading the display
DR
ST
FM
Bringing you hot
1Xtra - BBC
AM
PM
ST
Stereo signal
DR
Digital radio
FM
FM radio
Volume/mute
Signal strength
Sleep timer
Displayed when the sleep
timer is set
Text area
Displays menus,
settings and station
information
Battery charge level
Animated when charging.
Removed when fully
charged.
Current time
AM/PM
indicator

9
Using the navigation dial
Turn
Press
During normal listening
Turn the dial to adjust the volume level.
When in a menu
Turn the dial to scroll through options.
Select (centre button)
Confirm selections.
Menu
Access options and settings. Press again to
go back one step.
Fav
Press to display the favourites list. Hold to
save a favourite. You can save up to 10 digital
and 10 FM stations as favourites.
Source (also On/Off)
Switch between digital and FM radio. Press to
switch on and hold to switch off.
Stations
Displays the station list in digital radio or
tuning screen in FM.
DR
ST
Volume
25
DR
ST
Digital radio
Settings

10
ST
FM
Listening to digital radio
Tuning
Press Stations to show the station list. Turn
the navigation dial to scroll through stations
and press Select to tune. Press Menu or
Stations to exit.
Listening to FM radio
Tuning
Press Stations to show the FM tuning screen
then use one of the following methods to find
the station you want:
Seek tune
Press left (Stations) or right (Fav) on the
navigation dial to seek to the previous or next
station with a strong signal. Press Select to
exit.
Manual tune
Turn the navigation dial to manually tune to a
frequency. Press Select to exit.
DR
ST
Station list
Absolute
FM tuning
87.50MHz
FM
Scanning
88.30MHz

11
Favourites
Saving a favourite
You can save up to 10 digital and 10 FM
stations as favourites for easy access.
1. Press Fav to show the favourites list.
2. Turn the navigation dial to scroll through
favourites.
3. Press and hold Fav or Select to save the
current station as a favourite. You can
save over existing favourites.
Selecting a favourite
1. Press Fav to show the favourites list.
2. Turn the navigation dial to scroll through
favourites.
3. Press Select to tune.
DR
ST
Favourites
3: Empty
DR
ST
Favourites
3: Absolute
DR
ST
Favourite 3
Stored

12
DR
ST
Settings
Time (12h/24h)
Switch between 12 or 24 hour clock.
Language
Select a menu language from English,
French, German or Italian.
Factory reset
Select Yes to delete all personal settings and
favourites. Restarts with default settings.
Version
Displays the current software version.
Update
Contact Pure technical support
(http://support.pure.com) for more
information on how to update Move 2500 to
the latest software version.
Press Menu, select Settings and choose a setting to adjust:
Time (12h/24h)
24 hour
DR
ST
Language *
English
DR
ST
Factory reset?
<No> Yes
DR
ST
Version
V1.0_M_dab-mmi
DR
ST
Update?
<No> Yes

13
FM stereo
(FM radio only)
Press Menu, then select FM stereo and
choose between Stereo or Mono FM
reception. Mono may improve weaker
reception.
ST
FM
FM stereo *
Stereo
Autotune
(Digital radio only)
Press Menu, then select Autotune to search
for new stations and remove those no longer
broadcasting.
DR
ST
Scanning... 32
Sleep timer
1. Press Menu, then select Sleep timer.
2. Turn the navigation dial and press Select
to set the timer for up to 90 minutes or
choose Sleep off to cancel.
The sleep timer icon will appear when a sleep
timer is set.
The sleep timer can be set to switch Move off after a period of time.
DR
ST
Set sleep time
30 minutes
DR
ST
1Xtra - BBC
Bringing you

14
Audio settings
1. Press Menu, then select Audio.
2. Select Bass or Treble.
3. Turn the navigation dial and press Select
to set the level from -6 (low) to 6 (high).
To adjust the bass and treble settings:
DR
ST
Treble
3
Display settings
Backlight
Adjust how long the display backlight stays
on. Choose from Always on, Timed off (after
7 seconds) or Off.
Information
(Digital radio only)
Choose the information shown on the display.
Scrolling text
Provided by the broadcaster.
Signal strength
The clear block indicates reliable reception
level.
Signal quality
From 0 (low) to 100 (high).
Press Menu, select Display and select one of the following options:
DR
ST
Backlight
Always on
DR
ST
Information
Sig. quality

15
Help and specifications
Hints and tips
The current value for most settings is indicated on the display by an
asterisk (
*
).
Technical specifications
Radio DAB/DAB+/DMB-R (Band III and L-Band) and
FM (RDS).
Headphones Noise-isolating, 16 Ohm, 10 mm drivers.
Input Micro USB for power supply and software
upgrade.
Output 3.5mm stereo output for headphones.
Mains power 100-240V, 50/60Hz 5V DC 800mA external
power adapter.
Battery ChargePAK M1 1000mAh.
Dimensions 102 mm x 56 mm x 15 mm
Approvals CE marked. Compliant with the EMC and
Low Voltage Directives (2004/108/EC and
2006/95/EC) ETSI EN 300 401 compliant.
Australian C-Tick N1600 and Electrical Safety.

16
Warranty information
Imagination Technologies Ltd. warrants to the end user that this product will
be free from defects in materials and workmanship in the course of normal
use for a period of two years from the date of purchase. This guarantee covers
breakdowns due to manufacturing or design faults; it does not apply in cases
such as accidental damage, however caused, wear and tear, negligence,
adjustment, modification or repair not authorised by us. Should you have a
problem with your unit please contact your supplier or contact Pure Support at
http://support.pure.com.
Disclaimer
Imagination Technologies Limited makes no representation or warranties with
respect to the content of this document and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose. Further,
Imagination Technologies Limited reserves the right to revise this publication
and to make changes in it from time to time without obligation of Imagination
Technologies Limited to notify any person or organization of such revisions or
changes.
Trademarks
Move 2500, ChargePAK, Pure, the Pure logo, Imagination Technologies, and
the Imagination Technologies logo are trademarks or registered trademarks of
Imagination Technologies Limited.
Copyright
Copyright © 2012 Imagination Technologies Limited. All rights reserved. No part
of this publication may be copied or distributed, transmitted, transcribed, stored
in a retrieval system, or translated into any human or computer language, in any
form or by any means, electronic, mechanical, magnetic, manual or otherwise, or
disclosed to third parties without the express written permission of Imagination
Technologies Limited. Version 3 April 2012.
Disposal of Waste Electrical & Electronic Equipment
This symbol on the product or on its packaging indicates that this
product should not be treated as household waste. Instead it should
be handed over to a suitable collection point for the recycling of elec-
trical and electronic equipment. By ensuring this product is disposed
of correctly, you will help prevent potential negative consequences
for the environment and human health, which could otherwise be
caused by inappropriate waste handling of this product. The recy-
cling of materials will help to conserve natural resources. For more
detailed information about recycling of this product, please contact
your local council office, your household waste disposal service or
the shop where you purchased the product.

17
Pure Warranty Statement for Australia
This statement replaces any reference to warranty which may be contained
elsewhere within this manual.
What do you need to do now?
Option 1: You can register your purchase on-line at https://www.pure.com/au/
register/register.asp
Option 2: Or you can do nothing other than keep your proof of purchase as
evidence of your purchase date. This proof of purchase would need to be
presented if warranty service was ever required.
If you have any questions about your warranty you can call us toll free:
1800 988 268
What’s covered by this warranty?
• Pure agrees to refund, repair or replace, at your election, without charge to
you, any part found to be defective during the warranty period.
• If equipment has been used according to its accompanying instruction
manual and is used in a domestic situation, a two year warranty period
applies (excludes rechargeable ChargePAK where fitted. A one year warranty
period applies to all ChargePAKs).
How do you make your claim?
Call 1800 988 268 for instructions on how to return your Pure product for warranty
service or go to: http://support.pure.com/au/ and complete the contact us form.
What’s NOT covered by this warranty?
Under this express warranty Pure will not be liable for loss or damage of any kind
whatsoever, whether direct, indirect, incidental, consequential or otherwise.
• Replacement of parts due to normal wear and tear
• Products with serial number defacement, modification or removal
• Water damage or corrosion caused by dampness
• Any damage or deterioration due to shipments
• Any damage or deterioration due to shipment
• Any product which has been subjected to misuse, abuse or accident
Australian consumers —The benefits to the consumer given by this express
warranty are in addition to other rights and remedies of the consumer under a law
in relation to the goods or services to which this warranty relates. Our goods
come with guarantees that cannot be excluded under the Australian Consumer
Law, You are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Pure is distributed and supported in Australia by PIONEER ELECTRONICS
AUSTRALIA PTY LTD, 5 ARCO LANE, HEATHERTON, VICTORIA, 3202

103HZ
www.pure.com
connect.pure.com
www.facebook.com/pure
Pure
Imagination Technologies Ltd
Home Park Estate
Kings Langley
Herts, WD4 8LZ
United Kingdom
http://support.pure.com
Pure Australasia Pty Ltd
PO Box 5049
Wonga Park
Victoria 3115
Australia
[e-mail]
http://support.pure.com/au
