PureEdge Lighting CCS-2-JBOX Series User manual

SAVE THESE INSTRUCTIONS!
- This product is installed to a 4" electrical box or to an
octagon electrical box using the 2" plaster ring provided.
- Minimum electrical box volume must be 6 cubic inches (98
cubic centimeters).
- This product is intended only to be used with the Linear
Suspension series.
IMPORTANT INFORMATION
1718 W. Fullerton Chicago, IL 60614
Ph: 773.770.1195 ● Fax: [phone]
www.PureEdgeLighting.com ● [email protected]
© 2016 PureEdge Lighting. All Rights Reserved.
Doc # 904-CCS-2SQ_2RD_03
Installation Instructions for 2" Round & Square Cable Grip Power
Canopies with Plaster Plate Mount
A
1
CCS-2_-JBOX-_
Install the 2" Plaster Ring
For New Construction
NOTE: Junction box must be mounted to allow clearance of
1/2" between the face of the junction box and the drywall
surface.
NOTE: 24VDC power wires must be present inside the junction
box. Refer to the installation instructions provided with the
power supply.
1: Install the 2" plaster ring to the junction box using two
#8-32 screws.
2: Use a circular saw to cut out the drywall section where the
plaster ring is located.
3: Install the drywall. If necessary plaster, and finish the
drywall.
4: Complete the installation by following steps in "Prepare
Power Cable and Install Cable Grip" section.
2-1/4"
CEILING
2" PLASTER
RING
#8-32
SCREW
JUNCTION
BOX
1
1
CUT
DRYWALL
2
B
5: Cut away the drywall where the junction box is located.
6: Uninstall the existing plaster ring by removing the #8-32
screws.
7: Install the 2" Plaster Ring to the junction box using two
#8-32 screws.
8: Plaster and finish around the junction box opening.
9: Finish Cable Grip installation by following steps in "Prepare
Power Cable and Install Cable Grip" section.
CEILING
For Remodeling
C
CUT
DRYWALL
STANDARD
PLASTER RING
#8-32
SCREW
#8-32
SCREW
6
65

2
Prepare Power Cable and Install Cable Grip
1: Feed the coaxial cable through the knurled nut, 2" canopy
and cable grip assembly respectively. Press the tab on the
cable grip to feed the cable through.
NOTE: If cable is curled or kinked, straighten by holding
between the shaft of a screwdriver and thumb and pulling the
cable through (see inset).
KNURLED
NUT
CANOPY
TAB
CABLE GRIP
ASSEMBLY
COAXIAL
CABLE
1
BRAIDED
WIRE
INNER
INSULATION
BARE
WIRE 1/8"
OUTER
INSULATION
1"
3/8"
COAXIAL CABLE
ECOAXIAL
CABLE
2
3
WIRE
STRIPPER
4
2: Use the 18AWG hole of the wire stripper to remove 1-3/8"
of the outer insulation to expose the braided wire.
3: Use the 18AWG hole of the wire stripper to remove 1" of
the braided wire making sure not to nick the inner wire
insulation.
4: Use the 20AWG hole of the wire stripper to remove 1/8" of
the inner insulated wire.
5: Unscrew the coaxial connector covers and remove from the
connector assembly.
F
CONNECTOR
ASSEMBLY
COAXIAL
CONNECTOR
COVER
COAXIAL
CONNECTOR
COVER
5
D
G1.5MM ALLEN WRENCH
2MM ALLEN
WRENCH
M4 SET
SCREW
M3 SET
SCREW 6
7
6: Using the provided 1.5mm Allen wrench, remove the M3
set screw from the coaxial connector assembly.
7: Using the provided 2mm Allen wrench to loosen (Do Not
Remove) the M4 set screw.
COAXIAL
CONNECTOR
COVER
BRAIDED
WIRE
8: Slide the connector cover over the coaxial cable.
9: Place the ferrule over the 3/8" braided wire of the coaxial
cable.
H
FERRULE
89
NOTE: Scan the QR Code to watch the video clip of
the following steps or visit
https://www.PureEdgeLighting.com/video_feed/
installation_cxc_connector

FERRULE
COAXIAL
CABLE
CONNECTOR
ASSEMBLY
10: Insert the coaxial cable into the coaxial connector until the wires of the center conductor are visible through the M3 set
screw hole.
NOTE: Ensure that the split in the ferrule is aligned 90° from the M4 set screw (see inset).
ICOAXIAL
CABLE 10
CONNECTOR
ASSEMBLY
2MM ALLEN
WRENCH
12
CONNECTOR
ASSEMBLY
COAXIAL
CABLE
M4 SET
SCREW
11: Use the provided 1.5mm Allen wrench to replace and
securely tighten the M3 set screw.
1.5MM ALLEN
WRENCH 11
CONNECTOR
ASSEMBLY
COAXIAL
CABLE
M3 SET
SCREW
J
12: Use the provided 2mm Allen wrench to securely tighten the
M4 set screw until it squeezes the wire ferrule tightly to the
coaxial cable.
K
10
13: Replace the coaxial connector cover and tighten into
place.
L
13
COAXIAL
CONNECTOR
COVER
COAXIAL
CABLE
M
14: Connect the red wire of the coaxial connector to the
+24VDC power supply wire with a wire nut.
15: Connect the black wire of the coaxial connector to the
-24VDC power supply wire with a wire nut.
16: Place all connections inside the junction box.
COAXIAL
CONNECTOR
15 14
16
JUNCTION
BOX
3
WIRE NUTWIRE NUT

4
SCREW
CABLE GRIP
ASSEMBLY
N17: Insert all wires into the junction box and mount the cable
grip assembly to the 2" Plaster Ring using the screws
provided.
O
KNURLED
NUT 18
18: Place the canopy over the cable grip against the ceiling.
Secure it in place by tightening the knurled nut to the cable
grip. Make sure the knurled cap is not cross
threaded.
19: If necessary, press the tab on the cable grip to adjust the
cable height.
17 17
TAB 19
CANOPY
18
