Puretec ES2 Series User manual

ES2 / ESR2 Series
For correct operation & installation it is essential to observe these instructions.
AS/NZS 3497
Licence No. WM 7617
Australian Certication
Services
User Guide
Undersink | Drinking Water Systems
JULY2019

2 Installation & Operation Manual Copyright © Puretec Pty Ltd 2019
Puretec Customer Service
Thank you for purchasing a Puretec water treatment system. Your system is a proven
performer manufactured from only quality materials and components and will give
years of spring-like water free of impurities, if maintained properly.
Caution: Do not use with water that is of unknown quality or outside the parameters
on page 4.
The system is designed for rainwater supply but can be used in other situations. For
other types of water supply please contact your local Puretec stockist or call our
Puretec Customer Service Helpline.
The Puretec lter systems cartridges need replacing regularly to maintain optimum
performance. This is a simple procedure when following instructions. For cartridge
replacements contact your nearest Puretec stockist.
Customer Service Helpline 1300 140 140 (Australia) 0800 130 140 (New Zealand).
What's Inside
Introduction................................................................................................................................. 2
Operation...................................................................................................................................... 3
Replacement Guide................................................................................................................. 4
Installation................................................................................................................................... 4
Installation Procedure ........................................................................................................... 5
Parts Description...................................................................................................................... 6
Quick Connect Fittings...........................................................................................................6
Battery Installation ................................................................................................................. 7
Cartridge Installation / Replacement ............................................................................ 8
UV Installation........................................................................................................................... 8
Maintenance ............................................................................................................................ 10
Warranty .................................................................................................................................... 11
What's Inside

3Copyright © Puretec Pty Ltd 2019 Undersink | Drinking Water Systems
Introduction
Operation
The Puretec water treatment systems are designed to run economically for many
years, dependent on the initial installation and periodical maintenance.
Flush systems for 10 minutes aer any period of non-use more than 2 days. For a
period of non-use of 2 weeks or more, it may be necessary to replace cartridges.
Replacement Guide
To maintain the high quality of the puried water the cartridges need changing every
6 - 12 months, dependent on water quality and usage.
You can obtain replacement cartridges and/or lamps from your local Puretec dealer
and to maintain performance and warranty use genuine Puretec replacements.
A
Cartridge
B
Cartridge
C
UV Lamp
ES2 PL011 CE941 n/a
ESR2 PL051 MC011-S RL2
Replace cartridges every 6 - 12 months. Replace all UV
Lamps (RL codes) every 12 months.
Other cartridges are available to suit a range of requirements upon request.
Important note: When replacing cartridge, ensure you reset the LED reminder light on
the faucet by removing/replacing the battery from the rubber seat. Please refer to page
7 for a detailed diagram.

4 Installation & Operation Manual Copyright © Puretec Pty Ltd 2019
Installation Guide
Installation
This system comes complete with an installation kit enabling it to be connected to 15
mm (½”) copper pipe (cold supply only - hot water should be ltered prior to heating).
This product must be installed in accordance with local plumbing regulations by a
licensed plumber.
Installation Requirements
• 15 mm (½”) cold water line.
• Power supply: 240 VAC (ESR2 model only).
• Supply pressure: 300 - 875 kPa. Install pressure limiting valve if pressure exceeds
875 kPa.
• Supply temperature 0 °C - 52 °C.
• Alternative ttings may be required if being connected to anything other than 15
mm (½") copper pipe.
• Caution: Do not use with water that is microbiologically unsafe or of unknown
quality without adequate treatment before or aer the system.
Application warning; minimum water characteristics must be met before
installation of Radre™ to ensure proper operation and continuous protection.
Iron: less than 0.3 mg/L
Hydrogen Sulphide: less than 0.05 mg/L
Suspended Solids: less than 10 mg/L
Manganese: less than 0.05 mg/L
Hardness: less than 110 mg/L
Installation Procedure
1. Before attempting installation, check all components are intact and have not been
damaged in transit.
2. Select a suitable location that is close to the point of ltered water delivery (eg.
sink). Remember to allow access room for changing lters and a suitable place
where water spillage will not cause damage. Location should not be in direct

5Copyright © Puretec Pty Ltd 2019 Undersink | Drinking Water Systems
Installation Procedure
sunlight. A power outlet is required for ESR2 models.
3. Isolate water supply and install adaptor ballvalve.
3. Choose the best position for the faucet, taking into consideration height of jugs
etc. and also the drainage of any spills. Then drill a 12 mm hole and install the
faucet as in step 5.
4. To install the faucet, connect spout to the base of the faucet, ensuring that the
white circlip is ush with the groove on the spout. Push down on the spout cap
until it clicks, then tighten by hand. Once connected, place the escutcheon and
O-ring supplied onto the base of the tap. Insert into the counter top or sink and
place the plastic washer, lock washer and locking nut onto the thread and tighten,
ensuring the tap is in the correct position on the bench. Then place the olive in the
1/4" compression nut, then onto the 1/4" Tube and the olive insert into the end of
the tube and attach to the tap thread.
5. Install the lter housing assembly by positioning it in the desired location, marking
the position of xing holes and xing with mounting screws. Allow 50 mm under
the unit for cartridge changes. For ESR2 models, also allow 350 mm clearance to
the side of the unit for lamp changes (lamp exit and entry point can be determined
by installer).
6. Fit tubing into adaptor ballvalve to the lter and lter to the faucet (see Fig. 2 on
how to use quick-connect ttings). Allow slack in the tubing. Make sure ow is right
according to inlet outlet on housing assembly.
7. Unscrew lter housing using the spanner wrench.
8. Check O-ring and lubricate with food grade silicone lubricant (or similar).
Steps 9 to 12 apply to ESR2 models only (ESR models proceed to step 13).
9. Unscrew the aluminium nuts on each end of the chamber. Never touch the
quartz (glass) and lamp surface as marks or ngerprints may interfere with UV
transmission. If lamp is soiled, please clean lamp with an alcohol based cleaner.
10. Take the quartz sleeve out of its packaging and slide one of the two O-rings over
one end of the quartz sleeve.
11. Carefully slide the quartz sleeve into the chamber via the end with no O-ring and
attach the second O-ring onto the end once it is in place.
12. Screw the aluminium nuts back onto to each end of the chamber.
13. Restore the water supply and check for leaks. The lters need to be only hand
tight. If they leak then undo housing and check the O-ring is sealed properly.

6 Installation & Operation Manual Copyright © Puretec Pty Ltd 2019
Parts Description
No. Description
1 Adaptor Ballvalve
2 Flexible Tubing
3 Filter Assembly
4 Mounting Bracket
Figure 1
7
6
5
3
24
8
1
1. Cut the tube square and push in to the
tube stop. For metal tube remove burrs and
chamfer tube end to prevent O-Ring seal
being damaged.
DISCONNECTION PROCEDURE
4. Push collet against body and slide tube out of
tting.
2. Fitting grips before it seals. Ensure tube is
pushed in to tube stop.
HOW TO USE QUICK CONNECT FITTINGS
3. Tube is secured in position.
Figure 2
5 Flexible Tubing
6Tube, Nut and Ferrule
(see separate breakdown on Fig. 3)
7 LED Faucet
8 UV Module (ESR2 model only)

7Copyright © Puretec Pty Ltd 2019 Undersink | Drinking Water Systems
Battery Installation
Faucet
Escutcheon
O-Ring
Display
Battery Seat
Circuit Board
Battery
(CR2032)
Base Upholder
Counter Top
Lock Washer
1/4"
Compression
Nut
1/4" Tube
Cone Washer/Olive
Locking Nut
Plastic Washer
Gasket
Figure 3
1. Remove the black battery seat from the
faucet lever handle (see Fig. 3).
2. Install battery into the battery seat,
positive side up.
Note: Red light ashes
twice and then followed
by the blue light.
3. Reinstall battery
seat assembly
into the faucet
lever.
Battery Installation -
LED reminder light
Important note: Battery must be replaced when
changing cartridges.
5. Red light ashes indicates your cartridges
are due to be changed (usage has
exceeded 3,000 minutes or 12 months).
Please change the battery when
changing the cartridges.
Positive
side up.
Negative on the
PCB.
4. Blue light ashes during normal operation.
Faucet
Escutcheon
O-Ring
Display
Battery Seat
Circuit Board
Battery
(CR2032)
Base Upholder
Counter Top
Lock Washer
1/4"
Compression
Nut
1/4" Tube
Cone Washer/Olive
Locking Nut
Plastic Washer
Gasket
Faucet
Escutcheon
O-Ring
Display
Battery Seat
Circuit Board
Battery
(CR2032)
Base Upholder
Counter Top
Lock Washer
1/4"
Compression
Nut
1/4" Tube
Cone Washer/Olive
Locking Nut
Plastic Washer
Gasket

8 Installation & Operation Manual Copyright © Puretec Pty Ltd 2019
Cartridge Installation
Cartridge Installation / Replacement
To change the lter cartridges adhere to the following procedure.
1. Turn mains water supply o.
2. Relieve water pressure by operating faucet lever.
3. Unscrew Filter Housing using the spanner wrench and discard cartridges. When
removing housings place a container underneath to catch any spillage.
4. Cleanse the inside of the housing using hot water and detergent. Check O-ring and
lubricate with food grade silicone lubricant (or similar). Replace O-ring if kinked or
damaged (PN: FPOR).
5. Install new cartridges and replace housing screwing them up HAND TIGHT ONLY.
Sediment lter is on the inlet side and chemical on the outlet side.
6. Restore water supply & check for leaks, rectifying them, if any, before leaving the
unit.
Aer installing cartridges ush unit for 5 - 10 minutes.
Cleaning Quartz Sleeve (ESR2 model only)
To ensure high sterilizing rate with best water quality, check sleeve regularly (about
every 3 months depending on quality of water source). To see whether there is dirt or
substances gathered. Clean with alcohol based cleaner if necessary.
Quartz Sleeve Maintenance Procedure (ESR2 model only)
1 Unplug the power supply. Remove UV lamp before taking out the quartz sleeve
and pour out water. Turn counterclockwise the aluminium nut both sides of the
chamber and extremely gently to remove the quartz sleeve.
2 Soak a piece of cloth in vinegar or citric to clean the quartz sleeve.
3 Put the quartz sleeve back into the stainless steel chamber and make equal
distance at both sides of the chamber.

9Copyright © Puretec Pty Ltd 2019 Undersink | Drinking Water Systems
UV Installation
Figure 4
4 Dampen the seal O-ring and end of the quartz sleeve then turn clockwise the
aluminium nuts with hands tightly.
5 Check all connection to prevent leakage.
6 Insert UV lamp into stainless steel chamber and put on the rubber cap to complete
the cleaning.
UV Lamp Installation / Replacement (ESR2 model only)
• Prior to performing any work on the steriliser, always disconnect the power supply
rst.
• Do not look directly into ultraviolet rays emitted from the UV lamp as they will
cause serious burns to unprotected eyes.
• This treated water will seem warm at rst ow for a short period when it is not
used, as the lamp creates heat; you can ush before use.
1. Turn aluminium nut clockwise to x the quartz position (default setting from
manufacturer, see Fig. 4).
2. Insert UV lamp into chamber through the hole of the aluminium nut end. Never
touch the quartz (glass) and lamp surface as spots of ngerprints may interfere
with UV transmission. If lamp is dirtied, please clean lamp with alcohol based
cleaner.
Aluminium
Nut
Water Outlet
O-RingLamp Power
Connector
Quartz
SleeveUV Lamp
Aluminium
NutCap
Ballast
Stainless Steel
Chamber
O-Ring
Water Inlet

10 Installation & Operation Manual Copyright © Puretec Pty Ltd 2019
Maintenance
3. Put rubber cap on the aluminium nut end to complete the assembly.
4. Plug in power connector with ballast and make sure that the LED is illuminated
steadily to start operation. This should be all carried out by relevant qualied
tradesmen.
Note: For initial use, wait 3-5 minutes to allow water to pass through the whole unit.
Turn on point of use to let water ow through the unit for 2-3 minutes to release air
and impurities from system.
Notes
Puretec water care products are designed, manufactured and supported by Puretec
Pty Ltd the name you can trust for viable and proven water solutions. The complete
range of Puretec products are developed, rened, made to meet and exceed stringent
specications for the worldwide market.
Important: Sales of products are subject to our Terms and Conditions which are
available upon request. All specications, information and photos are a guide only
and are subject to change without notice. Please ring to conrm details. Warning:
For correct operation of this appliance it is essential to observe manufacturer’s
instructions.
Warranty
Any claim under this warranty must be made within 3 Years of the date of purchase
of the product. This product is warranted to be free of defect of material and
workmanship for 3 Years from date of purchase. 3 year warranty is 1 year parts and
labour, plus 2 years parts only. Excludes cartridges.
To make a claim under the warranty, take the product and proof of purchase to place
where you purchased the product, and they will lodge a Warranty Request with Puretec.
Puretec will pay your reasonable, direct expenses of claiming under this warranty.
You may submit details and proof of your expense claim to place of purchase for
consideration.
The warranty only applies if the product was used and/or installed in accordance with
the user guide and/or installation instructions. This warranty is given in lieu of all other
express or implied warranties and manufacturer shall in no circumstance be held liable
for damages consequential or otherwise or delays caused or faulty manufacturing
except as excluded by law.

11Copyright © Puretec Pty Ltd 2019 Undersink | Drinking Water Systems
Warranty
Applicable to all above, is that the warranties need to be approved by Puretec to ensure
product was not incorrectly used, installed or claimed. False and incorrect claims will
be pursued at Puretec’s discretion, including chargeable inspection and labour costs
incurred.
Warranty/Australia
This warranty is given by Puretec Pty Ltd, ABN 44 164 806 688, 37-43 Brodie Road,
Lonsdale SA 5160, telephone no. 1300 140 140 and email at [email protected].
This warranty is provided in addition to other rights and remedies you have under
law: Our goods come with guarantees which cannot be excluded under the Australian
Consumer Law. You are entitled to replacement or refund for a major failure and to
compensation for other reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure.
Warranty/New Zealand
This warranty is given by Puretec Ltd, Reg. No 4464398, PO Box 875 Cambridge 3450
NZ, telephone no. 0800 130 140 and email at [email protected].
This warranty is provided in addition to other rights and remedies you have under
law: Our goods come with guarantees which cannot be excluded under the Consumer
Guarantees Act. You are entitled to replacement or refund for a major failure and to
compensation for other reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure.
