Purpleline FullStop Saracen Ultra User manual

AK161/270 Hitch Lock
PRODUCT CODE: FHL600
USER MANUAL
FHL600-UM-0117
REGISTER NOW TO
ACTIVATE YOUR
5
www.purpleline.co.uk
01473 601200
YEAR
WARRANTY*
*WARRANTY REGISTRATION MUST BE COMPLETED WITHIN 14 DAYS OF PURCHASE

FHL600 User Manual Page 3
PARTS IDENTIFICATION
1. Main Body
2. Base Section
3. Male Lock Portion
4. Female Lock Portion
5. Key (x3)
6. Security Ball
7. Lock Cap
Please store your keys in a safe place
and remember to register within 14 days
of purchase, either by returning your fully
completed registration card, or online at
www.purpleline.co.uk/product-registration
FHL600 User Manual Page 2
2
3
1
4
6
7
5
LYF009-014
WEIGHT:
A4
SHEET 1 OF 1
SCALE:1:1
DWG NO.
TITLE:
REVISION
DO NOT SCALE DRAWING
MATERIAL:
DATE
SIGNATURE
NAME
DEBUR AND
BREAK SHARP
EDGES
FINISH:
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
Q.A
MFG
APPV'D
CHK'D
DRAWN

INTRODUCTION
The FullStop®Saracen Ultra Hitch Lock can be tted when your vehicle is hitched or
unhitched, but should never be tted during transit. It is against the law in the UK to
tow whilst using a Hitch Lock.
FHL600 User Manual Page 3
FITTING WHEN HITCHED
Insert key (5) into Male Lock Portion (3), push and turn 90° clockwise to unlock.
If a stabiliser is tted, lift the handle to the vertical position.
Position the Main Body (1) over the hitch handle ensuring the handle end is
recessed fully into the enclosed end of the Main Body (1). Fit the Base Section (2)
onto the bottom of the Main Body ensuring the holes line up with each other. Slide
the Female Lock Portion (4) through all the holes.
Insert the Male Lock Portion (3) into the Female Lock Portion (4) and turn 90° anti-
clockwise to lock.
Fit the protective Lock Cap (7).
If a stabiliser is tted its handle may be pushed back down into position over the
hitch lock.
FITTING WHEN UN-HITCHED
Installation of the Saracen Hitch Lock when tting onto an unhitched caravan,
is identical except that the included Security Ball (6) must be inserted into your
coupling to inhibit the caravan being hitched onto a vehicle.
NOTE
It is highly recommended that a secondary security device (such as a wheel clamp)
should be used to inhibit theft by some unconventional form of towing. Visit
www.purpleline.co.uk for details of other products in the Fullstop Security range.
MAINTENANCE
Fit the protective Lock Cap (7) over Male Locking Portion (3) to help prevent
ingress of dirt or water.
Grease the lock face and ball bearings before rst use, with a light oil such as 3-IN-
ONE or equivalent.
Thereafter spray any moving parts of the lock body with a light oil such as 3-IN-
ONE or equivalent every eight weeks.

PRODUCT SPECIFICATION
FHL600
Weight (kg) Height (mm) Width (mm) Depth (mm) Keys Supplied
3.2kg 180mm 100mm 200mm 3
© Copyright 2017. Purple Line Limited, Peninsula Business Centre, Wherstead, Suolk, IP9 2BB, UK
www.purpleline.co.uk
01473 601200
Photographs for illustration purposes only. Actual product may dier slightly.
Purple Line Limited reserve the right to alter product specication without prior notice.
Please store your keys in a safe place and remember to register your product.
Registration is quick and simple, go to www.purpleline.co.uk/product-registration
Please register within 14 days of purchase. Please retain your original purchase receipt.
Disclaimer
If used properly, your FullStop®product will be an eective deterrent. However, nothing
can stop the eorts of the most determined thief, and to this end no liability is accepted for
any loss and/or damage caused by any illegal activity including theft or vandalism. Liability
also not accepted for any loss and/or damage arising from misuse, unauthorised repair or
alteration and failure to follow the user guide directions. No form of consequential loss what
so ever will be accepted.
