Pyle Pro PWMA50B User manual

Microphone Jack
In Aux
Charge Socket
Power switch / volume button
LED indicator
Power indicator
USB
1¡ (introduction)
Congratulations! Please
read this manual carefully so that you can use this product easy. We try our best
to make it accurate; errors may still exist in this manual, so
please tell us your suggestions. specification subject to change without notice.
2¡(features)
long durable time up to 8 hours after full charge
Lithium battery, long battery life
loud-speaker works pretty good
easy to use, can work as mp3 speaker
strong ABS plastic material, make the quilt strong
and durable
(electric specifications)
working temperature: 10C¡-60C¡
Maximum output power: 50 W
frequency Response: 100HZ~13KHZ
Mic sensitivity: -53dBV/Pa¡3dB
battery voltage: DC7.4V
Battery type: rechargeable lithium battery
3¡ ( battery charge )
Please charge battery if the LED light is dim or off.
Shut off the voice amplifier, and then insert the plug of the power adapter into charge socket of the voice amplifier
plug the power adapter to 110 V power source
When charge process complete, the LED turn from red to green
To extend the battery life, please charge after the battery is use out
4¡ ( voice amplifier wearing )
With the attached waistband, you can fix the voice amplifier to your waist in front or back of your body, as shown below
You can adjust the length of the waistband, also as shown below
Multi-functional Voice Amplifier Manual
Rwww.pyleaudio.com

There is a white line on the
end of microphone, please
Position against mouth.
Roughly 2~3 cm
Attentions before wearing
the Ear-hanging microphone:
Before wearing, please
don't turn on the power
and volume.
5¡( microphone using )
Wear microphone as the figure below
The two hole inside the sponge must aim at your mouth
The suitable distance between the microphone and the mouth is 20~30 millimeter
Insert the plug of the microphone into the right hole of the voice amplifier
To achieve a maximum effect, please choice the microphone we provide
cut in and pull out the plug often may cause a bad connection between microphone and amplifier
6¡ ( begin to use )
Fix the voice amplifier to your body as show before
Wear microphone to your head and insert the plug of the microphone into the voice amplifier
Turn the power switch clockwise, then LED light is lightened, that means the amplifier is working
Turn the volume button clockwise or anticlockwise can increase or decrease the volume
Decrease the volume to avoid noises
7¡ ( battery change )
Don't change the battery by yourself under warranty
The battery we provide can work long time and avoid the damage to the voice amplifier
Be sure that the pole is right when you change the battery
8¡£FAQ££
Question: why the voice amplifier produce so much noise?
Answer: Adjust the microphone and decrease the volume to avoid the noises.
Question: how long is needed for battery charge?
Answer: generally about 3-4 hours is needed for battery charge, temperature and other factors may change the time.
Question: can you tell me the life of the battery, and can l change the battery one year later.
The battery life is about 2-4 year, and it is changeable, please get in touch with us or our dealers.
Question: can you tell me why my voice amplifier can not work now?
Answer: please check: ¢your microphone is inserted into the right hole, ¢the battery is not used out, ¢your voice amplifier is on. Please get
in touch with us or our dealers if you still can solve it by yourself.
