TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
Thank you for choosing a TimeTrax Sync™ 7000/7000BDL110 Master Clock System.
The TimeTrax Sync™ 7000/7000BDL110 synchronizes up to 200 TimeTrax Sync™ Analog
Clocks (part #5200) and/or Digital Clocks (part #DIG-4B, DIG-6B 41357G, 61357G).
The system can provide power to eight TimeTrax Sync™ Analog Clocks (part #5200) using
RJ45 connector. Digital Clocks need to have their own 100-240V AC 50/60Hz power supplied.
The TimeTrax Sync™ 7000 integrates with 24V DC bells or horns and is able to operate a
bell/horn schedule up to 300 events.
The TimeTrax Sync™ 7000BDL110 includes a Relay SPDT contact for 110V AC bells and
horns. The 7000BDL110 provides contacts to bells and horns up to a total of 10amps @
125V AC. Please refer to page 15 for a complete list of bell and horns.
Analog or
Digital Clock
7000 master control
(BCD updates up to 200 clocks*)
DC Bells/Horns
or AC Relay Control
*Powers up to 8 analog clocks using RJ45 cable.
All other clocks must be supplied power.
OVERVIEW
2PRODUCT OVERVIEW

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
Synchronization Capacity 200 TimeTrax Sync™ Analog and/or
Digital Clocks
200 TimeTrax Sync™ Analog and/or
Digital Clocks
Synchronization Distance Up to 300 feet Up to 300 feet
Analog Clock Power Up to 8 Analog Clocks (part #5200) Up to 8 Analog Clocks (part #5200)
Bell/Horn Interface 24V DC Bells and Horns 110V AC Bells and Horns
Bell Scheduling Up to 300 Events Up to 300 Events
Bell & Horn Power
Up to 35 bells (part #41361 & 41392)
or 800 milliamps (mA) per event
Up to 20 horns (part #41362) or 800
millIamps (mA) per event
Contact SPDT 10amps total @ 125V
AC, 7A @ 250V AC
Bells #41397R & #41398G
Horns #41363
Display Date & Time (AM/PM or Military) Date & Time (AM/PM or Military)
Automatic Time Adjustment Short months, Leap Year & Daylight
Saving Time
Short months, Leap Year & Daylight
Saving Time
Tamper-Proof Security Lock Yes Ye s
Warranty 1-Year manufacturer's limited
warranty
1-Year manufacturer’s limited
warranty
7000/7000BDL110 MASTER CLOCK CONTROLLER : FEATURES
7000 7000BDL110
3 FEATURES 888.479.7264

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
CONTENTS
CH751
CH751
TimeTrax Sync™ 7000
Master Clock Controller
Security
Keys (2)
Mounting Screws (4)
Wall Anchors (4)
RJ45 Splitter Cable
110 Relay
(7000BDL110 ONLY) 7000/7000BDL110
User Guide
Power Adapter
RJ45 Cable
4CONTENTS
Master Clock Controller
User Guide
pyramidtimesystems.com

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
Use key to unlock and open front cover.
Select a location for mounting.
Power outlet should be within 5 feet of
mounting location.
With door, open, hold the case in desired
location and mark holes for drilling.
Drill holes for mounting.
Install screws in wall, leaving approximately
3/16 inch of screws exposed. For sheet rock
walls, use plastic anchors.
Hang TimeTrax Sync™7000 on wall, aligning
keyholes on the rear with screw heads.
Press downward on case until it lowers
onto screws.
1
WALL MOUNTING
1
2
3
4
5
5 WALL MOUNTING 888.479.7264

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
INSTALLATION/7000
Route the power supply through cable channel located on right side or bottom of
the 7000 case. Connect power supply into power port labeled POWER.
Plug power supply into standard electrical wall outlet.
SELECT
SET-UP INSTRUCTIONS
To change or set feature,
press SELECT until desired
feature is displayed.
Use or to change
feature.
1
2
DATA POWER
After displayed feature is
changed, press SELECT to
change other feature &
return to main display.
3
24 VDC
+ -
41301A
pyramidtimesystem.com
2
1
2
1
2
6INSTALLATION

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
1
2
3
Locate programming buttons labeled SELECT, (s) (UP) & (t) (DOWN).
Press SELECT until desired feature is displayed (see chart on next page).
Press (s) (UP) or (t) (DOWN) to scroll through feature options.
Press SELECT to save option setting and move onto next feature.
SELECT
SET-UP INSTRUCTIONS
To change or set feature,
press SELECT until desired
feature is displayed.
Use or to change
feature.
1
2
DATA POWER
After displayed feature is
changed, press SELECT to
change other feature &
return to main display.
3
24 VDC
+ -
41301A
pyramidtimesystem.com
4
PROGRAMMING
7 PROGRAMMING 888.479.7264

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
7000 MASTER CLOCK CONTROLLER : PROGRAMMING
FEATURE
(SELECT) DISPLAY DEFAULT SETTING OPTIONS (SCROLL st)
Schedule Bells NO NO: No event(s) scheduled.
YES: Schedule event(s) SET EVENT
#1-300 See instruction on p.12.
Date Format USA Use the UP or DOWN key to select
USA or EURO (European) display
format for time.
Set Year 2009 Use the UP or DOWN key to set the
current year.
Set Month JAN Use the UP or DOWN key to set the
current month.
Set Day 1Use the UP or DOWN key to set the
current day of month.
Set Daylight
Saving Time
(DST) Rule
USA USA: USA DST: Begins 2nd
SUN of MAR, Ends 1st SUN of NOV
EURO: European DST: Begins Last
SUN of MAR, Ends Last Sun of OCT
OTHER: Set a custom DST Rule
Choose from LINE or CRYSTAL time base.
OFF: No adjustment for DST.
Set Format AM/PM AM/PM: 12 Hour
MIL: Military, 24 Hour
Set Hour 12AM Use the UP or DOWN key to set the
current hour of day.
Set Minutes 00 Use the UP or DOWN key to set the
current minute.
8PROGRAMMING

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
Using RJ45 BCD Cable, connect one end of the cable to the 7000 port labeled
DATA and route cable through cable channel located on the right side or bottom
of 7000 case.
Connect the other end of the RJ45 cable to port located on back of Analog or
Digital clock.
Mount and install wall clocks according to instructions included with clock.
1
2
3
CLOCK CONNECTION
1
SELECT
SET-UP INSTRUCTIONS
To change or set feature,
press SELECT until desired
feature is displayed.
Use or to change
feature.
1
2
DATA POWER
After displayed feature is
changed, press SELECT to
change other feature &
return to main display.
3
24 VDC
+ -
41301A
pyramidtimesystem.com
2
9 CLOCK CONNECTION 888.479.7264

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
Use RJ45 Splitter Cable (part # 41270) to add more clocks. Up to 200 clocks may
be added to the system, however clocks should be located within 300 feet of 7000
unit to receive the synchronization time data.
1
CLOCK CONNECTION
1
SELECT
SET-UP INSTRUCTIONS
To change or set feature,
press SELECT until desired
feature is displayed.
Use or to change
feature.
1
2
DATA POWER
After displayed feature is
changed, press SELECT to
change other feature &
return to main display.
3
24 VDC
+ -
41301A
pyramidtimesystem.com
1
10CLOCK CONNECTION

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
Wire 24V DC Bells or Horns to the 7000
terminal labeled 24 VDC using 16-18
gauge wire (part #41449 sold separately)
Route the bell wire through the
cable channel located on right side
or bottom of 7000 case. A total of 35
bells or 20 Horns can be connected
to the circuit if using Pyramid bells
(part #41361, 41392) and horns (part
#41362).
Use the following table to set a bell/
horn schedule. Program up to 300
bell/horn events.
1
1
SELECT
SET-UP INSTRUCTIONS
To change or set feature,
press SELECT until desired
feature is displayed.
Use or to change
feature.
1
2
DATA POWER
After displayed feature is
changed, press SELECT to
change other feature &
return to main display.
3
24 VDC
+ -
41301A
pyramidtimesystem.com
RED (+) BLACK (-)
3
2
2
1
DC BELL CONNECTION
The 7000 will provide power to 24V DC bells or horns, up to 800 milliamps (mA) per event.
SELECT
SET-UP INSTRUCTIONS
To change or set feature,
press SELECT until desired
feature is displayed.
Use or to change
feature.
1
2
DATA POWER
After displayed feature is
changed, press SELECT to
change other feature &
return to main display.
3
24 VDC
+ -
41301A
pyramidtimesystem.com
2
NC
COM NO
ON
0 115 230
24Ø
LINE
NEUTRAL
LOAD
AC BELL CONNECTION
CAUTION: 110V BELL RELAY MUST BE INSTALLED
BY A LICENSED ELECTRICIAN. Please refer to diagram.
7000
110V
Relay
2
BELL CONNECTION & SCHEDULE
11 BELL CONNECTION 888.479.7264
Line = Black
Neutral = Red or White
POWER IN 110V AC

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
MENU :SET EVENT
SCHEDULE AN EVENT (e.g. Sound Bells/Horns)
FEATURE
(SELECT) DISPLAY DEFAULT SETTING OPTIONS (SCROLL )
Set Event
Schedule
NO Scroll (UP)or (DOWN)to
schedule event
Assign the
Event a
Number (1-300)
1SET EVENT
(e.g.1, 2, 3 ... 300)
Set the
Event’s
Duration
OFF OFF, .5 SEC, 1-15 SEC (determines
length of time buzzer/bell/horn
sounds)
Set the
Event’s Hour
12 AM (AM/PM)
00 (MIL)
EVENT HOUR +/– One Hour
12 HR: 12AM-11PM
24 HR: 00-23
Set the
Event’s Minute
00 EVENT MINUTE +/– One Minute
(e.g. 00, 17, 59)
Set the
Event’s Day
ALL Monday thru Friday Event: M-F
One day event: SUN,
MON, TUE, WED,
THU, FRI, SAT
All week event, SUN-SAT: ALL
SET EVENT
12BELL SCHEDULE

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
7000 SPECIFICATIONS
Time Set Manual
Power Output 800mA
BCD Time Updates
Up to 200 clocks, 35 bells, 20 horns and powers up
to 8 Analog Clocks (Part #5200) using RJ45
Operating Temp -30°F (-34.44°C) to 130°F (54.44°C)
Display LCD, date & time
Housing Textured powder coat surface metal
Color Black
Mounting Wall Mount
Warranty 1-Year manufacturer’s limited warranty
Dimensions 5.5”W x 7.125”H x 1.75”D
(13.9cm x 18.1cm x 4.4cm)
Weight 1.81lbs (.81kg)
Shipping Weight 4.451lbs (2.01kg)
SPDT CONTACT (10A @125V AC, 7A @250V AC) RELAY SPECIFICATIONS
Color Putty
Mounting Wall Mount
Dimensions 3.125”W x 5.25”H x 2.625”D
(7.93cm x 13.33cm x 6.66cm)
Weight .75lbs (.34gr)
Shipping Weight 1lb (.045gr)
SPECIFICATIONS
13 SPECIFICATIONS 888.479.7264

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
14SPECIFICATIONS
7.125in
5.5in
1.75in
5.5in
2.625in 3.125in
5.25in
SPECIFICATIONS
SPDT RELAY

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
15 ACCESSORIES 888.479.7264
ACCESSORIES
DIG-4B 4” x 4-digit Red LED Independent Digital Clock
DIG-6B 4” x 6-digit Red LED Independent Digital Clock
41357G 4” x 4-digit Red LED Digital Clock
61357G 4” x 6-digit Red LED Digital Clock
5200 13” Analog Clock 12 Hour Face
41200 Power Adaptor 120V AC/18V AC
41269 RJ45 BCD Cable, 50’
41314 RJ45 BCD Cable, 100’
41270 RJ45 Y-Splitter Cable
41361 6” 24V DC Bell
41392 8” 24V DC Bell
41362 24V DC Horn
41397R 6” 110V AC Bell, red (7000BDL110 ONLY)
41398G 8” 110V AC Bell, grey (7000BDL110 ONLY)
41362 110V AC Horn (7000BDL110 ONLY)
41449 Bell Wire, 100’ Spool
41450 Bell Wire, 250’ Spool
PART # DESCRIPTION
1
1Powers eight 5200N Analog Clocks.

TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
Should you need to speak live to one of our representatives, please call toll-free
(US/Canada) at 888.479.7264 during regular business hours: 8am-5pm EST, M-F.
1-YEAR LIMITED WARRANTY
Pyramid warranties its Synchronized Clock Systems to the original user against defective
material or workmanship for a period of 1 year from date of purchase.
The manufacturer’s responsibility under this Warranty is limited to repair or replacement
of defective part or parts. Pyramid reserves the right to determine whether parts failed
because of defective material, workmanship, or other causes. Failure caused by accident,
alteration, misuse or improper packaging of returned unit is not covered by this Warranty.
Any repair to equipment other than by Pyramid voids the Warranty. Users in territories
other than USA, Canada, South America & Australia should contact the Dealer from whom
the unit was purchased. The rights under this Warranty are limited to original user and
may not be transferred to subsequent users.
If Customer Support cannot troubleshoot your problem over the phone, we will replace
your unit free of charge if it is within warranty period. Please contact Customer Support
at 888.479.7264 between the hours of 8am-5pm EST for details.
WARRANTY
TECHNICAL SUPPORT
16WARRANTY & TECHNICAL SUPPORT

CONTACT US:
For more information, visit pyramidtimesystems.com or
call our technical support team at 888.479.7264 during
regular business hours: 8am-5pm EST, Monday-Friday.
Copyright © 2017 Pyramid Time Systems, LLC. All rights reserved.
I2020 Rev. H
