Pyramid Smart Site 3500ss User manual

User Guide
3700
stamp
+
3500ss/3600ss/3700HDss

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700ss
1pyramidtimesystems.com TABLE OF CONTENTS
TABLE OF CONTENTS
TABLE OF CONTENTS . . . . . . . . . . . . . . . . . . . . . . . 1
PRODUCT OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . 2
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
GETTING STARTED & INSTALLATION . . . . . . . . . . . . . . . . 4
PROGRAMMING & FEATURES SET UP & BUZZERS . . . . . . . . . 4-5
MESSAGES & COUNTER MODE . . . . . . . . . . . . . . . . . . 6-7
BUZZERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PRINTING MODES. . . . . . . . . . . . . . . . . . . . . . . . 9
ADJUSTING DOCUMENT EDGE . . . . . . . . . . . . . . . . . . 9
USING TIME CLOCK . . . . . . . . . . . . . . . . . . . . . . . 10
TIME CARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
TIME CARD PRINT FORMAT . . . . . . . . . . . . . . . . . . . . 11
PRINTING CUSTOM MESSAGES (3600SS) . . . . . . . . . . . . . 12
REPLACING RIBBON CARTRIDGE . . . . . . . . . . . . . . . . . 13
MASTER RESET. . . . . . . . . . . . . . . . . . . . . . . . . 14
FAQs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . 14
WARRANTY & CUSTOMER SUPPORT . . . . . . . . . . . . . . . 15
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . 16
MOUNTING TEMPLATE . . . . . . . . . . . . . . . . . . . . . 17
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700ss
2 PRODUCT OVERVIEW & FEATURES 888.479.7264
Thank you for choosing a 3500ss / 3600ss/3700HDss SmartSite™ Time Clock & Docu-
ment Stamp! The 3500ss/3600ss/3700HDss are our most versatile time clocks, ready to
perform employee time tracking, document stamping & preset message stamping. The
3600ss features custom message stamping & sequential page numbering. These clocks
feature the exclusive patent pending SmartSite™ viewing guide and are equipped with
a red LED alignment guide to ensure perfectly aligned time card punches & document
stamping time after time.
The 3500ss/3600ss/3700HDss is able to punch employees In & Out and stamps time sensi-
tive documents using one of 14 preset messages. The 3600ss also stamps custom mes-
sages with up to 2 lines of alphanumeric type and stamps sequential page numbering up
to 9999 consecutive stamps using automatic or manual stamping. These clocks feature
an adjustable document edge to accommodate any size document. Simple set-up, simple
operation & simple ribbon changes make these time clocks a favorite with small business!
Please read through this User Guide for simple set-up & operation.
PRODUCT OVERVIEW
TIME CLOCK & DOCUMENT STAMP : FEATURES
Employee Capacity Unlimited
Alignment SmartSite™ Red LED guide
Custom Type (3600ss) Date stamp & up to 2 lines (16 characters per line)
alphanumeric custom type
Preset Messages 14 Preset Messages for stamping time
sensitive documents
Counter Mode (3600ss) Sequential numbering up to 9999
Loading Side, adjustable document edge
Ribbon Ink Black
Audio Signal (3600ss) Buzzer
Language Printing English, Spanish & French
Printing Semi-automatic or manual
Display Time, date & day of week (AM/PM or Military Time
Format)
Printing Format Date & Time (AM/PM, Military, Military Hundredths,
Military Tenths)
Printing Dot matrix
Automatic Time Reset Short months, Leap Year & Daylight Savings Time
Battery Back-Up
Safeguards data & settings for up to 7 days
without power
Tamper-Proof Security lock protects against costly time theft
Warranty 1-Year manufacturer's limited warranty
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700ss
3pyramidtimesystems.com CONTENTS
CONTENTS
WHAT YOU WILL NEED TO MOUNT ON THE WALL
KNOW YOUR SERIAL #
CH751
CH751
3500ss/3600ss/3700HDss
SmartSite™ Time Clock &
Document Stamp
35100-10
Time Card (25)
Mounting Template
(see inside back cover)
3500ss/3600ss/3700HDss
User Guide
Security
Keys (2)
Power
Adaptor
Tape Measure Pencil Screw Driver Power Drill
(Optional)
IMPORTANT:
Please write down serial #
located on back of time
clock before mounting.
Write your
serial # here:
Made in China
L4988
Model 3500SS
Time Clock & Document Stamp
UL LISTED POWER SUPPLY
US PATENT NO. 9,358,811 B1
45 Gracey Avenue
Meriden, CT 06451
888.479.7264
www.pyramidtimesystems.com
000000000
INPUT: 12.5V 1.5A
+
+
Positionthis line
approximately45 inches
fromfloor
I2244
WALL MOUNTING TEMPLATE
MODEL 3600SS
q
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss
#10 Screw (2)
(2) Plastic Anchors
User Guide
stamp
+
q
3500ss/3600ss/3700HDss
Smart Site™ Registrador De Tiempo Y
Sellador De Documentos
Horloge pointeuse et dateur de document
Smart Site™
3700

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700ss
4 GETTING STARTED & PROGRAMMING 888.479.7264
SET UP
PROGRAMMING
1
1
2
2
3
4
Remove time clock from carton & place on a at, level surface.
Unlock & remove top cover.
Connect power adaptor in port located behind display screen & plug unit
into AC wall outlet.
Use key to unlock and remove cover.
Locate programming buttons labeled SELECT,
p /and q /  .
Press SELECT and using p / q scroll to display
desired feature is (see chart on page 5).
After display feature is changed, press
SELECT button to save change. Repeat this
step for other features until you cycle back
to main display showing TIME/DATE.
Press p /or q /  to scroll through feature
options.
WALL MOUNTING
Select a location convenient to employees
clocking IN & OUT. Be sure power outlet is
within 5 feet of mounting location.
Use masking tape to hold mounting template on
wall, making certain template is positioned so
bottom of time clock is approximately 45 inches
from oor.
Drill holes using template as a guide.
Remove template from wall & install #10 screws
(not included), leaving approximately 3/16 inch
of screws exposed. For sheetrock walls, use
plastic anchors.
Hang time clock on wall, aligning keyholes on the
rear with screw heads. Press downward on time
clock until it lowers onto screws.
Plug unit into AC wall outlet.
2
3
3
4
5
6
1
To change or set feature, press SELECT
button until desired feature is displayed.
Use / (UP) or /(DOWN) buttons
to change feature or move cursor.
After display feature is changed, press
SELECT button to change other features
& to return to the main display.
42643
Rev.H
//
p /Moves cursor UP or LEFT
in Custom Messaging
q /  Moves cursor DOWN or RIGHT
in Custom Messaging
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700ss
5pyramidtimesystems.com FEATURES SETUP
3500SS/3600SS TIME CLOCK & DOCUMENT STAMP :FEATURES SET UP
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss
FEATURE
(SELECT) DISPLAY OPTIONS (SCROLL pq)
Set Language LANG ENGLISH ENGLISH,
French (FRANCAIS),
Spanish (ESPANOL)
Set Date
Format
DATE FMT MMDDYY MM/DD/YR (USA),
DD/MM/YR (EURO),
YY/MM/DD
Set Year SET YEAR 2021 DISPLAYED YEAR +/- 1 Year
Set Month SET MONTH JAN DISPLAYED MONTH +/- 1 Month
Set Date SET DAY 1 DISPLAYED DATE +/- 1 Day
Set Daylight
Savings Time
(DST) Rule
DAYL’T SAV USA USA: USA DST: Begins 2nd SUN of
MAR, Ends 1st SUN of NOV 2am
EURO: European DST: Begins Last
SUN of MAR, Ends Last Sun of OCT 1am
OTHER: Set a custom DST Rule.
1
2am
OFF: No adjustment for DST.
Set Format DSPLY FMT AM/PM AM/PM: 12 Hour,
MIL: Military, 24 Hour
Set Printed
Time Format
PRINT FMT AM/PM AM/PM: 12 Hour (e.g. 3:30PM)
MIL: Military, 24 Hour (e.g. 15:30)
ATAAP: Military, 24 Hour, Minutes
expressed in hundredths of one hour
(e.g. 15.50)
24H.1: Military, 24 Hour, Minutes
expressed in tenths of one hour
(e.g. 15.5)
Set Print
Direction
PRINT DIR RIGHT Right = Print in right direction on
time card.
Left = Print in left direction on time
card.
Set Mode MODE AUTO SEE PRINTING MODES PAGE 9
Setup Pre-
programmed
message
SET FMT MSGS NO/DATE TIME SEE PREPROGRAMMED MESSAGES
PAGE 6
Setup Cutom
Message
Schedule a
Buzzer Event
(3600SS)
SET EVENT NO NO: No event(s) scheduled.
YES: Schedule event(s) SET
EVENT #1-50, Page 8
CST MSGS (1,2) NOT USED SEE CUSTOM MESSAGING, PAGE 7
(3600ss Only)
Set Hour SET HOUR 12AM DISPLAYED HOUR +/- 1 Hour
Set Minutes SET MINUTES 0 DISPLAYED MINUTE +/- 1 Minute
1 SELECT DAY’L SAV=OTHER. SCROLL & SELECT START & END SUNDAY (Available options are
the 1st, 2nd, 3rd, 4th and last Sunday of each month). Remember: The number of weeks in a
given month changes each year. You will have to reprogram your custom DST if either the
START or END date falls on the last day of the month.
DEFAULT
SETTINGS

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700ss
6 PREPROGRAMMED & CUSTOM MESSAGES 888.479.7264
SET FORMAT MESSAGES (SET FMT MSGS)
In the FMT=DATE TIME (3500ss/3700HDss) menu or the SET FMT MSGS (3600ss)
menu, press p (UP) or q (DOWN) to choose “YES”.
Press SELECT.
Press p (UP) or q (DOWN) to scroll through preprogrammed messages. (see chart
below)1
Press SELECT to choose desired message2& advance to next menu.
If no custom message is desired “CST MSG1=NOTUSED”, press SELECT, or to program a
custom message “CST MSG1”, follow steps on page 7. (3600ss Only)
If custom message is not desired “CST MSG2=NOTUSED”, press SELECT, or to program a
second custom message “CST MSG2”, follow steps on page 7.
2
3
4
5
6
1
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss
DISPLAY EXAMPLE
FMT=DATE TIME (Default Settings) JUL 12 07:46PM
FMT=DATE YR TIME JUL 12 ’20 07:46PM
FMT=DATE YR APVD JUL 12 ’20 APVD
FMT=DATE YR FAXD JUL 12 ’20 FAXD
FMT=DATE YR FILE JUL 12 ’20 FILE
FMT=DATE YR IN JUL 12 ’20 IN
FMT=DATE YR OUT JUL 12 ’20 OUT
FMT=DATE YR PAID JUL 12 ’20 PAID
FMT=DATE YR RCVD JUL 12 ’20 RCVD
FMT=DATE YR SENT JUL 12 ’20 SENT
FMT=DATE YR ORIG JUL 12 ’20 ORIG
FMT=DATE YR VOID JUL 12 ’20 VOID
FMT=DATE YR USED JUL 12 ’20 USED
FMT=DATE YR CMPL JUL 12 ’20 CMPL
MESSAGES & COUNTER MODE
PREPROGRAMMED MESSAGES
The 3500ss/3600ss/3700HDss functions as a document stamp and is preprogrammed
with 14 common message formats. In addition, the 3600SS allows you to enhance each
of these preprogrammed messages with up to two lines of customizable print, or with a
sequential counter.
1By default, clock will print DATE TIME format if no message is selected.
2Selected preprogrammed message will print rst (date stamp on 3600SS).

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700ss
7pyramidtimesystems.com CUSTOM MESSAGES & COUNTER MODE
NAVIGATE TO CUSTOM MESSAGES (3600ss)
COUNTER MODE (3600SS)
Set: SET FMT MSGS = YES, then press SELECT
Set: (your) FMT, then press SELECT
Set: CST MSG1 = USE, then press SELECT
Display will show 4 lines:
Line A: NUMBERS, Space and Arrow q
Line B: CAPITAL LETTERS, Space and Arrows q
p
Line C: CLR (clear), DONE, COUNT and Arrow
p
Line D: CUSTOM MESSAGE 1 (up to 16 places) (Blinking place to set)
(LEFT) or  (RIGHT) moves character to dark back ground in each line (right/
left).
The arrow with a dark background moves the cursor to other line (A,B,or C) after
pressing SELECT.
The character (number/letter/space) with a dark background is registered in a
blinking space of CUSTOM line after pressing SELECT and the next space starts to
blink.
If you make a mistake set cursor to “CLR” and press SELECT to clear last character
or hold SELECT (3 sec) to clear all characters and then start again.
To set whole CUSTOM MESSAGE 1 for Counter Set for “COUNT” and press SELECT.
To nish a message move the cursor “DONE” to dark background and press SELECT.
CST MSG2 = NOT USED - apply the same roles as CST MSG1.
2
3
4
5
6
7
8
1
NOTE: The counter is reset when set “CLR” and press SELECT then set “COUNT” and
press SELECT again.
NOTE: IF “CST MSG1=NOT USE”, the clock setting goes to “SET EVENT”. Then “CST
MSG1=NOT USE” and “CST MSG2=USE” will not be printed. The counter “CST MSG2” will be
incrementing internally (when it was set “USE” and “COUNTER”).
9
10
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss
The counter mode is activated when SELECT “<COUNTER>” is in custom message position
(see step 8 & 9 above). Every “DATE STAMP” is counted.
An increasing number (1,2,3,-9999) will print on the second or third time you print fol-
lowing “date stamp” or “custom message” (during a three second period).Once 9999 is
reached, numbers will reset automatically back to 1.
1You may not move the cursor of custom message backwards. (see step 7 above)
2It is recommended to reset time after creating custom messages.

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700ss
8BUZZERS
SET EVENT USING BUZZER (3600SS)
The 3600SS Time Clock & Document Stamp has an internal buzzer to alert workers of
start times, breaks, lunch and dismissal times.
MENU :SET EVENT pq
SCHEDULE AN EVENT (e.g. Ring Internal Buzzer)
FEATURE
(SELECT) DISPLAY DEFAULT SETTING
OPTIONS (SCROLL pq)
Set Event
Schedule NO Scroll p(UP)or q(DOWN)to
schedule event
Assign the
Event a
Number (1-50)
SET EVENT
(e.g.1, 2, 3 ... 50)
Set the
Event’s
Duration
OFF OFF, .5 SEC, 1-15 SEC (determines
length of time buzzer)
Set the
Event’s Hour 12 HR: 12AM 24 HR: 00 EVENT HOUR +/– One Hour 12 HR: 12AM-11PM
24 HR: 00-23
Set the
Event’s Minute 00 EVENT MINUTE +/– One Minute (e.g. 00, 17, 59)
Set the
Event’s Day ALL All week event, ALL: SUN-SAT
Monday thru Friday Event: M-F
One day event: SUN, MON, TUE, WED,
THU, FRI, SAT
pyramidtimesystems.com
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700ss
9
The 3500ss/3600ss/3700HDss can be set to print automatically or manually using the SET
MODE feature. When set to AUTO the clock will print whenever the actuator is activated.
When set to MANUAL , the clock will only print when the “manual button” located in the
left, top corner above the display screen is pressed.
The actuator can be adjusted to accommodate different document widths.
Place clock on its side so the viewing window is facing towards you.
Locate the “actuator adjustment knob” on the bottom of the clock.
Push “actuator adjustment knob” in while sliding the actuator back or forth to
adjust position.
3
4
2
1
PRINTING MODES
ADJUSTING DOCUMENT EDGE
DISCONNECT POWER PLUG
BEFORE ADJUSTMENT
Disconnect power plug before adjustment
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss
1 2 3 4 5
1 2 3 4 5
PRINTING MODES & ADJUSTING DOCUMENT EDGE
Manual Button
Actuator

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500SS/3600SS
10 USING TIME CLOCK 888.479.7264
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss
USING TIME CLOCK
1
2
To punch time card or stamp document, gently feed time card (35100-10 or
35100-10F) or document into slot at base of time clock, while aligning red LED
SmartSite™ alignment guide to location where time stamp is desired.
A - Continue to feed time card or document until the print actuator is
activated. (Mode=Auto)
B - Feed time card or document, and press Manual Button. (Mode=Manual)
Align red LED SmartSite™ alignment guide to
location where time stamp is desired

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500SS/3600SS
11TIME CARD & PRINT FORMAT 888.479.7264
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss
TIME CARDS
TIME CARD PRINT FORMAT
The time card (#35100-10 or 35100-10F) is used for weekly pay periods.
Printing will appear as follows:
PUNCH IN JUL12 7:00AM
Prints Month, Date & Punch Time
PUNCH OUT JUL12 3:00PM
Prints Month, Date & Punch Time
Time card #35100-10 or 35100-10F

12
PRINTING CUSTOM MESSAGES (3600SS)
Scenario: It is 7:46AM on 7/12/20. You have selected “ DATE YR Time ” from the Set
Format Messages “( SET FMT MSGS )” menu. You have set Custom Message 1 “( CST MSG 1 )”
to PYRAMID TIME SYS. You have set Custom Message 2 to “<COUNTER>”. The clock
will print to your document as follows:
First print DATE
Second print MESSAGE 1
Third print MESSAGE 2
After clock prints date stamp (line 1) “JUL 12’20” you have three seconds to print cus-
tom message (line 2), “PYRAMID TIME SYS”. If you do not print rst custom message
(line 2, second print) within 3 seconds, the 3rd print (message 2) will not print and the
clock will revert to date stamp (line 1).
Example A
First print DATE
Second print
If longer then 3 seconds the message won’t appear, and clock defaults back to time. The
counter will advance but will not print because we didn’t make 2nd print during the rst 3
seconds.
After you print rst custom message (line 2), “PYRAMID TIME SYS”, you have three
seconds to print second custom message (line 3), “1”. Again, if you do not print second
custom message (line 3) within 3 seconds, the clock will revert to date stamp (line 1).
Example B
First print DATE
Second print MESSAGE 1
Third print MESSAGE 2
After you print second custom message (line 3), “1”, the clock automatically will return to
date stamp (line 1).
Example C
First print DATE
NOTE: Each time date stamp prints(Examples A, B & C) the counter advances +1 (even
though sequential numbers did not print).
JUL 12’20 7:46AM
PYRAMID time sys
JUL 12’20 7:46AM (if 3 seconds or more goes by, after the
2nd print, message will not appear)
JUL 12’20 7:46AM
PRINTING CUSTOM MESSAGES 888.479.7264
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss
JUL12’20 7:46AM
PYRAMID time sys (print within 3 seconds after First print)
1 (print within 3 seconds after the Second print)
JUL 12’20 7:46AM
JUL 12’20 7:46AM (if 3 seconds or more goes by, after the
1st print, message will not appear)

13
REPLACING RIBBON CARTRIDGE
1
2
3
4
Unlock and remove cover.
Press p (UP) for 3 seconds to park ribbon carriage (Clock has to dispaly TIME).
Unplug power to time clock *IMPORTANT*.
Turn clock on its side so ribbon cartridge & holder are on top.
Slide actuator to far left and out of the way which is located underneath the
clock. (see diagram).
Remove old ribbon cartridge by holding tab and lifting up.
Snap in new ribbon cartridge between printer head and mylar.
Turn the knob, follow arrow to stretch the ribbon. It will turn easily.
Replace cover, lock unit & plug in.
Feed time card through unit to test print quality.
Readjust the actuator.
If ribbon is not completely over print head the resulting print will show incomplete
characters. If ribbon cartridge is not completely snapped in holder, the resulting print
will be increasingly lighter.
5
6
7
8
9
pyramidtimesystems.com REPLACING RIBBON CARTRIDGE
10
11
Ribbon clips
Ribbon tabs
Slide actuator
far right and out
of the way (located
underneath the unit)
Mylar
Printer head
Knob
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss

14
MASTER RESET
1
2
3
4
Unplug power to time clock.
Press & hold p (UP) button while plugging unit back in.
Release p (UP) button when “ 88:88, time not set” displays.
Re-program time clock.
FAQS
Q: Do I have to use special cards?
A: Pyramid 35100-10 or 35100-10F (French) cards are designed for use with
the 3500SS/3600SS when it is used for payroll, but you can use it to stamp
other documents.
Q: What does ATAAP mean?
A: ATAAP is the acronym used by the U.S. government that describes how time
is accounted for using hundredths of hour (i.e. 1.25 hrs = 1hr 15min.)
ACCESSORIES
3500SS/3600SS/3700HDSS : ACCESSORIES
MASTER RESET 888.479.7264
PART # DESCRIPTION
5000R Replacement Ink Ribbon Cartridge
35100-10 Time Cards (100pk)
35100-10M Time Cards (1000pk)
35100-10F Time Cards (100pk) English/French
35100-10FM Time Cards (1000pk) English/French
400-10 10 Capacity Adjustable Time Card Rack
400-3 25 Capacity Adjustable Time Card Rack
400-X 25 Capacity Expanding Time Card Rack
41479K Replacement Key
300-1 Heavy Duty Metal Time Card Rack, 25 Card Capacity
NOTE: This will delete all settings and reset to factory defaults
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss

15
pyramidtimesystems.com
LIMITED HARDWARE WARRANTY
◦Pyramid Time System warrants its equipment to original user against defective
material or workmanship for a period of 1-year from date of purchase. Proof of
purchase & purchase date are required for warranty service on this product.
◦Please remember to register your product at
pyramidtechnologies.com/ProductRegistration
◦Pyramid Time Systems’ responsibility under this warranty is limited to
replacement of defective part(s). Replacement is the sole discretion of
Pyramid Time Systems.
◦For Return Shipments to Pyramid Time Systems, product must be shipped in its
original carton or equivalent. The cost & method of return freight for warranteed
product is the sole responsibility of the customer. Pyramid Time Systems will
not assume any responsibility for loss or damage incurred in shipping.
◦Pyramid Time Systems reserves the right to determine whether parts failed
because of defective material, workmanship or other causes.
◦Failure caused by accident, alteration, misuse or improper packaging of
returned unit is not covered by this warranty.
◦Any repair done by the customer without the consent from Pyramid Time Systems
will automatically void the warranty.
◦Users in countries other than Canada and USA should contact the Dealer from
whom the unit was purchased.
◦The rights under this warranty are limited to the original user and may not be
transferred to subsequent users.
CONTACT US:
For more information, visit pyramidtimesystems.com or
call our technical support team at 888.479.7264 during
regular business hours: 8:30am-5pm EST, M-F, or email
[email protected]
WARRANTIES
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss

SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500SS/3600SS
16
SPECIFICATIONS
3500SS/3600SS :SPECIFICATIONS
OPERATING CONDITIONS
Temperature 0°C - 50°C, 32°F - 122°F
Humidity 10-95% RH, non condensing
POWER 100-240VAC, 50/60 Hz
POWER FAILURE
Battery Back-Up 7 Days, Data & Time
Battery Life 10 Years
CALENDAR Automatic Leap Year & Daylight Savings Time,
Year up to 2099
CLOCK ACCURACY Less than 30 seconds/year
WEIGHT 2.6lbs (1.17kg)
DIMENSIONS 6.125inW x 5.75inH x 6.75inD (15.5cm x 14.6cm x 17.2cm)
CERTIFICATIONS UL and CUL (power supply)
MOUNTING Desktop or Wall mountable
SPECIFICATIONS 888.479.7264
CONTACT US:
For more information, visit pyramidtimesystems.com
or call our technical support team at 888.479.7264
during regular business hours: 8:30am-5pm EST,
Monday-Friday.
Copyright © 2021 Pyramid Time Systems, LLC. All rights reserved.
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500ss/3600ss/3700HDss

MOUNTING TEMPLATE/PLANTILLA DE MONTAJE/MODEL DE MONTAGE
SMART SITE™ TIME CLOCK & DOCUMENT STAMP
Model 3500SS/3600SS
3”
3500SS/3600SS/3700HDSS MOUNTING TEMPLATE
3500SS/3600SS/3700HDSS PLANTILLA DE MONTAJE
3500SS/3600SS/3700HDSS MODELE DE MONTAGE
LEVEL LINE MARKER/MARCADOR DE LÍNEA DE NIVEL/ REPÈRE DE LA LIGNE DE NIVEAU
UP/ ARRIBA / EN HAUT
SCREW GUIDE TEMPLATE BELOW IS ACTUAL SIZE
LA PLANTILLA DE GUÍA DE TORNILLO A CONTINUACIÓN ES DE TAMAÑO REAL
LE MODE D’EMPLOI ET SCHÉMA DES VIS CI-DESSUS EST DE TAILLE RÉELLE
17

888.479.7264
CONTACT US:
For more information, visit pyramidtimesystems.com
or call our technical support team at 888.479.7264
during regular business hours: 8:30am-5pm EST,
Monday-Friday.
Copyright © 2021 Pyramid Time Systems, LLC. All rights reserved.
I2279FS Rev N
Copyright Information
© 2021 Pyramid Time Systems, LLC. All rights reserved.
Reproduction, adaptation or translation without prior written permission is prohibited,
except as allowed under copyright laws.
The information contained herein is subject to change without notice.
The only warranties for Pyramid Time Systems products are set forth in the express
warranty statements accompanying such products. Nothing herein should be construed
as constituting an additional warranty. Pyramid Time Systems shall not be liable for
technical or editorial errors or omissions contained herein.
