Pyxis IK-76SSS-S03 User manual

V1.2

Related Statements
The manufacturer shall not be liable for direct, indirect, special, incidental, or consequential damages resulting
from any deficiency or omission in this manual. The manufacturer reserves the right to make changes to this
manual and the products described in it at any time without notice or liability. Revised versions can be found
on the manufacturer's website. Safety Information
Please read this manual completely before unpacking, installing, and operating this equipment. In particular,
pay attention to all dangers, warnings, and precautions, otherwise, it may cause serious personal injury to the
operator or damage to the equipment.
Use of Danger Information
Danger
Indicates a potentially or urgent dangerous situation that, if not avoided, will cause death or serious injury.
Warning
Indicates a potentially or very dangerous situation that, if not avoided, may cause serious personal injury or
death.
Warning
Indicates a potentially dangerous situation that may cause a certain degree of personal injury.
Attention
Indicates conditions that if not avoided, will cause damage to the instrument. This is information that
needs special emphasis.
Warning Label
Please read all labels and marks attached to the instrument. Failure to follow the instructions on these
safety labels may result in personal injury or damage to the instrument.
If this symbol appears in the instrument, it means refer to the operation and/or safety
information in the instruction manual.
If there is this mark on the instrument housing or insulator, it means there is a risk of electric
shock or death from electric shock.
Static electricity can damage the delicate internal electronic components, resulting in reduced
performance or eventual failure of the instrument.
Electrical equipment marked with this symbol cannot be disposed of through the European
public waste system after August 12, 2005. In order to comply with European regional and
national regulations (EU Directive 2002 / 98 / EC), European electrical equipment users must
now return abandoned or expired equipment to the manufacturer for disposal without any
cost.

Catalog
Specifications.............................................................................................................................................- 1 -
IK-765SS-SO3 Panel Features......................................................................................................................- 2 -
Dimension and Mounting...........................................................................................................................- 3 -
3.1. Dimension ..................................................................................................................................................- 3 -
3.2. Tube connection.........................................................................................................................................- 3 -
3.3. Terminal Wiring..........................................................................................................................................- 4 -
Touch Screen Operation .............................................................................................................................- 5 -
4.1. Main Screen ...............................................................................................................................................- 5 -
4.2. User Login ..................................................................................................................................................- 5 -
4.3. Real-Time Monitoring ................................................................................................................................- 6 -
4.4. Menu Bar ...................................................................................................................................................- 7 -
4.5. Configurable Parameters............................................................................................................................- 7 -
4.5.1. Alarm Parameters Setting..................................................................................................................- 7 -
4.5.2. Name Definition.................................................................................................................................- 8 -
4.5.3. Diagnostic Parameters.......................................................................................................................- 8 -
4.5.4. 4-20mA Output Parameters Setting ..................................................................................................- 9 -
4.5.5. Communication Setting .....................................................................................................................- 9 -
4.6. Calibration................................................................................................................................................- 10 -
4.6.1. pH Calibration..................................................................................................................................- 10 -
4.6.2. SO3 Calibration ................................................................................................................................- 12 -
4.7. Alarm View...............................................................................................................................................- 13 -
4.8. Historical Data..........................................................................................................................................- 14 -
4.9. Historical Data Curves ..............................................................................................................................- 15 -
4.10. User Management ...............................................................................................................................- 17 -
Daily Maintenance................................................................................................................................... - 18 -
5.1. Correspondence Address.........................................................................................................................- 18 -
5.2. Operation and Maintenance....................................................................................................................- 18 -
5.3. Instrument Alarms and Descriptions .......................................................................................................- 19 -
Replacing pH and Oxidizer Electrode Head............................................................................................... - 20 -
8. Order Details............................................................................................................................................ - 26 -
7. Updating Time, Date and Firmware............................................................................................................ - 21 -
7.1. Setting Time and Date................................................................................................................................- 21 -
7.2. Firmware Update Procedure......................................................................................................................- 23-

-1 -
Specifications
Item IK-765SS-SO3
P/N 42163
Sensor Body Material 304SS
Sensor Name ST-765SS-SO3
Sulfite Range 0.00-100.00 ppm Sulfite (auto-range)
Sulfite Precision ± 1.0mg/L or 1% of the value w/pH compensation up to 9.0+
pH Range 0-14
pH Precision ±0.01 pH
Sample Operating Temperature 4 °C – 40 °C (40 – 104 °F)
Sample Inlet Pressure 7.25 – 30 psi (0.05 – 0.2MPa)
Sensor Maximum Pressure 100 psi (6.9 Bar)
Sensor Response Time T95≤60s – Oxidizer / T95≤5s - pH
Measurement Interval Continuous
Installation ST-007 (316L) Flow Cell w/PRV-Rotameter-Hall Effect Flow Meter Included
ST-007 Minimum Flow Rate 200 mL/minute
ST-007 Maximum Flow Rate 400 mL/minute
ST-007 Sample Inlet 1/4 - inch OD
ST-007 Sample Outlet 1/4 - inch OD
Panel Power Supply 96-260VAC / 50-60 Hz; 10 W
Panel Storage Temperature -4 – 158 oF (-20 – 70 oC)
Panel Operating Temperature 32 – 122 oF (-0 – 50 oC)
UC-80 Display 4.3-inch LCD Color 480 x 272 Pixel Resolution / Resistive Touch
UC-80 Input RS-485 Modbus – RTU
UC-80 Output 2 x 4-20 mA / RS-485 Modbus-RTU / Modbus-TCP
UC-80 Data Storage Built-In 128MB of Ram for Storing up to 1-Million Data/Event Records
UC-80 USB 1 x USB host, for data downloading and screen upgrade
UC-80 Relative Humidity 20% - 90% (No Condensation)
UC-80 Altitude <6,561 feet (<2,000 Meter)
Dimension (H x W x D) Panel (IK-765SS-SO3) 440H x 350W x 153D mm
Approximate Weight Panel (IK-765SS-SO3) ~ 15 kg
Wet Material 316L Stainless Steel / Polycarbonate
Rating IP-65 Panel-Display / IP-67 Sensor
Selectivity Non-Selective / cross sensitive to other oxidizing species
Compliance EPA 334.0 / ISO 7393
Regulation CE Marked / RoHS
Typical Electrode Service Life 2 years
Electrode Warranty 6 Months
Sensor Body Warranty 13 Months
*NOTE* - Pyxis Lab is consistently updating technologies, as such, specifications may change without notice.
Contact [e-mail] for details or www.pyxis-lab.com .

-2 -
IK-765SS-SO3 Panel Features
The IK-765SS-SO3 is a dual-parameter inline water analyzer specifically designed as a
‘Turn-Key’monitoring solution for clean water applications to monitor Sulfite in water
commonly used in water and process applications for scavenging of Chlorine and Oxygen.
The IK-765SS-SO3 offers highly accurate, real-time measurement, display and data-
logging of Sulfite (SO3), pH and Temperature utilizing proprietary Pyxis Lab smart sensor
technology, coupled with a Pyxis UC-80 touch screen display and data logging terminal.
The IK-765 series is offered in a convenient and easy to integrate panel mounted format
for rapid installation and simple maintenance.
Features
•Pyxis Lab’s advanced research and development sensor technologies to achieve highly accurate and stable measurement of
Sulfite, pH, and Temperature.
•Pyxis ST-765SS-SO3 is a three-parameter composite sensor used for the measurement Sulfite, pH, and temperature in
compliance with USEPA 334.0 and ISO-7393 guidelines. The sensors advanced PCB offers built-in temperature and pH
parameter compensation (up to pH 9.0+) algorithms eliminating the need for a supplemental pH sensor and controller.
Unique Bare-Gold electrode technology for Sulfite measurement eliminates membranes and electrode solution
replenishment commonly associated with conventional sensors. The ST-765SS Series has a uniquely designed flat bubble pH
electrode design for reduced fouling potential. Reduce your maintenance and cost versus conventional electrochemical
sensors by utilizing Pyxis replaceable Electrode Head (EH-765) for this sensor allowing for years of reliable service. The ST-
765SS Series may be calibrated in-situ after cleaning via DPD or similar Sulfite wet chemistry test measurement of active
sample.
•Pyxis ST-007 Single-Sensor inline stainless steel flow cell provides an Sulfite demand-free environment for the safe
installation and accurate operation of the ST-765SS-SO3 sensor. The inlet and outlet to the ST-007 are 316L stainless
steel with SwageLok fittings in ¼-inch OD. The IK-765SS-SO3 panel is also equipped with inlet PRV, Rotameter and digital
Hall Effect inlet flow meter for precise control and recording of the recommended flow range of 200-400 mL/minute. The
outlet flow should be diverted to drain or the inlet of the pretreatment system for those desiring NSF compliance.
•Simple sensor removal and replacement. The ST-765SS Series sensors are connected to the display/data logger via RS-485
Modbus (RTU) allowing for integrated sensor calibration interface and diagnostics within the display screen.
•Convenient and simple to install Back-Panel (IK-765) for rapid and easy installation. Truly a plumb and power to go
platform with intense factory setup, testing and sensor calibration prior to shipment.
•UC-80 touch screen color display/data logger prewired to the Pyxis sensor via RS-485 with calibration interface. Display/data
logger offers 2x 4-20mA, RS-485 and TCP Modbus output with remote diagnosis and parameter adjustment. Pyxis
PowerCloudTM 4G Gateway available as an optional accessory.

-3 -
Dimension and Mounting
3.1. Dimension
3.2. Tube Connection
Inlet Water: Connect the ¼-inch OD inlet water tubing to the quick adapter provided.
Outlet Line: Connect ¼-inch OD stainless steel inlet tubing to stainless steel fittings.
Figure. 1 - IK-765SS-SO3 controller size and installation size
Power Supply: 100~240V AC 50/60Hz
Water Supply: Inlet water pressure should be from 7.25 – 30 psi (0.05-0.2MPa) with an inlet feedwater line diameter of ¼-
inch OD.
Drainage: Outlet pipe diameter is ¼-inch OD，should both be connected to a discharge drain via gravity flow.
Wall Mount Space: The IK-765SS-SO3 analyzer panel size is roughly 440H x 350W x153D (mm) in dimension. Please
accommodate sufficient space for mounting.
Wall Mount Weight: Approximately 15kg. Please use appropriate mounting hardware.

-4 -
3.3. Terminal Wiring
The IK-765SS-SO3 analyzer has universal AC power supply equipment allowing users simply to plug the power supply into
a 100~240V AC 50/60Hz power outlet for normal operation.
Warning
The process of electrical connection to contact the 220V single-phase power supply, should be operated by personnel with
an electrician's license. Failure to operate according to the electrical code of practice may result in electric shock injury or
even death.
Figure. 2 - Terminal Wiring Diagram

-5 -
Touch Screen Operation
4.1. Main Screen
After the system is powered on an initial screen allows the user to log into the system.
Figure. 3 - Main Screen
4.2. User Login
After powering on the system, log in with the username and password to be able to change system settings. Click the "User
Login" button, select the user "User", enter the password: "888888" in the user password field. A new user can be added
via "User Management" in interface of the menu.
Figure. 4 - User Login Screen
If you do not need a password, or want to change the user, you can enter the system and manage in the "User
Management" screen of the menu.

-6 -
4.3. Real-Time Monitoring
Click the "Enter System" button on the main interface to enter the real-time monitoring screen of the system. The data
detected by the Pyxis sensors will be displayed in real-time. See a functional overview of each section of this screen
highlighted below. (Numbers 1-4)
Figure. 5 - Real-time monitoring screen
Section
Number
Functional Overview
1
The blue area will scroll any alarm information in real time until the alarm is cleared.
2
Real-time display of current sensor measurement value.
3
Real-time display of the current sensor's 4-20mA signal value.
4
Historical data is recorded as a live curve, with the horizontal coordinate being the time
and the vertical coordinate being the measured value.
Table 1 - Main interface functional overview
Press and hold the curve area for 2 seconds and then let go, the Y-axis curve range setting dialog box will appear. Users may
change the display value range of Y-axis for each measurement index curve. Click the outer area of the screen to save and
exit the setting screen after modifications are made.
Figure. 6 - Curve Range Setting

- 7 -
4.4. Menu Bar
Click the button in the upper left corner of the screen to enter the system's menu interface, where the user can select to
enter the desired operation interface.
Figure. 7 - Menu Bar
4.5. Configurable Parameters
Click the "Parameter" button in the menu bar. Here you can select to enter "Alarm Parameters" and "4-20mA Output"
setting interface etc.
Figure. 8 - Parameter Settings
4.5.1. Alarm Parameters Setting
Users can set the upper and lower alarm limits. Click "Alarm Parameters" to enter the alarm parameter settings. When the
measured sensor value is lower than the set lower limit (the XX lower limit alarm) or when the measured value is higher
than the set upper limit (the XX upper limit alarm), the corresponding sensor alarm will be displayed on the real-time
monitoring screen. The user can also choose to turn the alarm display on or off at the top left of the corresponding
parameter list.

- 8 -
Figure. 9 - Alarm Parameter Setting
4.5.2. Name Definition
Click the orange dialog box to customize the sensor name.
Figure. 10 - Name Definition
4.5.3. Diagnostic Parameters
Click “Diagnosis Parameters” to the diagnosis page. In the diagnosis page, the raw data measured by the probe is displayed.
To help troubleshooting possible issues with the probe, please save an image of this data when the probe is placed in a
clean water, in a standard, and in the sample that the probe is intended for.
Figure. 11 - Diagnostic Parameters

- 9 -
4.5.4. 4-20mA Output Parameters Setting
Click "4-20mA Output " to enter the 4-20mA output parameter setting interface. The 4mA and 20mA output values should
corresponds to the lower and upper limits of the sensor range. *NOTE* The closer the value is set to the measurement value
the more accurate the data. It is recommended to set according to the range of the sensor.
Figure. 12 - 4-20mA Output Setting
4.5.5. Communication Setting
Communication parameters generally do not need to be changed. If the communication station number and other
parameters need to be changed on site, they can be changed on this interface.
Figure. 13 - Modbus RTU
Figure. 14 - Modbus TCP

- 10 -
4.6. Calibration
Click on the "Calibration" button in the menu bar and select the sensor to be calibrated.
Figure. 15 - Sensor Calibration
4.6.1. pH Calibration
The pH function is thoroughly calibrated at the Pyxis Lab factory. After checking with a pH standard buffer solution, if the
sensor value has shifted, then the user may choose from single-point, two-point or three-point calibration to re-calibrate
the pH portion of the ST-765SS-SO3 sensor as desired.
Figure. 16 - pH Calibration

- 11 -
Single Point pH Calibration
Remove the ST-765SS-SO3 sensor and rinse 3x with DI water. Submerge the sensor into a beaker with pH=7 buffer solution.
Click "pH7 calibration". A dialog box will pop up to confirm whether to perform this operation, click "OK" if the calibration
operation is confirmed, if the calibration is successful the dialog box will show "calibration success".
Figure. 17 - pH Calibration Success Prompt
Two Point pH Calibration
Remove the ST-765SS-SO3 sensor and rinse 3x with DI water. Submerge the sensor into a beaker with pH=7 buffer solution.
Click "pH7 calibration". A dialog box will pop up to confirm whether to perform this operation, click "OK" if the calibration
operation is confirmed, if the calibration is successful the dialog box will show "calibration success".
After pH7 is successfully calibrated, you can choose acid calibration or alkali calibration for the second calibration point. If
you choose acid calibration, clean beaker 3x with deionized water. Fill the beaker with pH=4 buffer solution. Enter the value
4 in the calibration value dialog box, and click "Acid Calibration", then a dialog box will pop up to confirm whether to perform
this operation. Click "OK" if the calibration operation is confirmed and the dialog box will show "Calibration Successful" if
the calibration is successful. Similarly, a pH=10 buffer solution can be selected for the second point calibration if desired.
Three Point pH Calibration
Remove the ST-765SS-SO3 sensor and rinse 3x with DI water. Submerge the sensor into a beaker with pH=7 buffer solution.
Click "pH7 calibration". A dialog box will pop up to confirm whether to perform this operation, click "OK" if the calibration
operation is confirmed, if the calibration is successful the dialog box will show "calibration success".
After pH7 is successfully calibrated, you can choose acid calibration or alkali calibration for the second calibration point. If
you choose acid calibration, clean the beaker 3x with deionized water. Fill the beaker with pH=4 buffer solution. Enter the
value 4 in the calibration value dialog box, and click "Acid Calibration", then a dialog box will pop up to confirm whether to
perform this operation. Click "OK" if the calibration operation is confirmed and the dialog box will show "Calibration
Successful" if the calibration is successful.
After successful acid calibration, select pH=10 for alkali calibration. Clean the beaker 3x with deionized water. Fill the beaker
with pH=10 buffer solution. Enter the value 10 in the calibration value dialog box, and click "Alkali Calibration", then a dialog
box will pop up to confirm whether to perform this operation. Click "OK" if the calibration operation is confirmed and the
dialog box will show "Calibration Successful" if the calibration is successful. The three-point calibration is completed.

- 12 -
4.6.2. SO3 Calibration
The measurement module of the ST-765SS-SO3 sensor is thoroughly calibrated at the Pyxis Lab factory. To calibrate, the
user can perform a single point calibration according to the requirements of the application.
Calibration of the ST-765SS-SO3 sensor for Sulfite should be done with the sensor inline exposed to active flowing sample
water. Use titration, colorimeter or fluorometer methods (i.e. Pyxis SP-800 / SP-910, Hach DR-1300 or similar) to test the
active (flowing) water sample in the flow tee assembly of the IK-765SS-SO3 panel. Once you have tested and confirmed the
Sulfite concentration value in the active (flowing) flow tee assembly, enter the recorded test result value in Calibration
Screen and click "High Cal". A dialog box will pop up to confirm whether to perform this operation. If the calibration
operation is confirmed, click "OK", and if the calibration is successful, the dialog box will show "Calibration Success".
*NOTE* Click the restore button in the calibration interface of each sensor to restore the data of pH/residual SO3 sensor. If
a user error is made during calibration and other operations, you may restore the factory settings of the sensor through the
restore function.
Figure. 18 - SO3 Calibration
Figure. 19 - Awaiting execution Screen of SO3 Calibration

- 13 -
4.7. Alarm View
Click the "Alarm View" button on the main screen to enter the alarm view screen.
Figure. 20 - Alarm View
In this screen users can browse all logged alarms. Drag the right scroll bar up and down to view the history of alarms. Click
"Previous" and "Next" to advance to the next page. Click “Query” then enter the alarm number in the pop-up box to query
that alarm.
Figure. 21 - Alarm Data Query Screen
The Delete button in the lower left corner will delete all alarm records. After clicking delete, you must exit the screen and
reenter before the historical data within the data report will be cleared.

- 14 -
4.8. Historical Data
Click the "Historical Data" button in the menu bar to enter the data report interface.
Figure. 22 - Historical Data Screen
In the data report, the user can view the stored data of all parameters. The system records sensor readings every 4 seconds
by default but this can be edited by the user if desired. Drag the scroll bar on the right to slide up or down or click "Previous"
and "Next" to view historical data records. The data record can save up to 100,000 data entries. New data will overwrite the
previously saved data after recording 100,000 data entries. The user can click the “Periodicity” button to change the data
recording time interval.
Figure. 23 - Data Storage Cycle Time Setting
Click “Delete” in the lower left corner. After entering the retention time, click the “Delete” button to clear all historical
data within the retention time range.
Figure. 24 - History Data Deletion Screen

- 15 -
Click the “Query “button in the lower right corner, enter the start time and end time and then click the “Query” button.
Note that the start time and end time must be filled in exactly and completely according to the system time format.
Figure. 25 - Historical Data Query and Export Screen
Insert a USB disk behind the display screen and enter the time range of the data to be exported in the query area. Click on
the “Data Export” to download the data to the USB disk. The data quantity will be shown as a positive number if data export
is successful. If the data export was not successful, please check whether the time format is correct.
4.9. Historical Data Curves
Click the "Historical Curve" button in the menu bar to enter the trend curve interface. You can click the buttons below the
X-axis to browse and view the values in a different time range. Click on Y-axis Range to change the minimum and maximum
Y-axis values for a proper range.
Figure. 26 - History Curve Screen

- 16 -
Figure. 27 - Y-axis Range Setting
Figure. 28 - Button Function Review
Figure. 29 - Time Setting Screen

- 17 -
4.10. User Management
Click the "User" button on the menu bar and then you can select "Login", "Logout" and "Manage" operations.
Figure. 30– User Management
Logout enables the user to log out of the logged-in state and only view the real-time readings but cannot perform operations
such as parameter settings. Click “Manage” to enter the user management interface, where you can add users, change
passwords and other operations. Users can set their own username and password and select the user group they belong
to. Only users in the administrator group can set parameters such as calibration.
Figure. 31 - User Management Screen
Modify Password: Select the user you want to change, then click Modify User button, enter the user's own password in the
User Password column and Confirm Password column, and click Confirm to modify successfully. *NOTE* If you do not want
to set the password, you can delete the password and save it.
Figure. 32 Modifying the User Screen
