Q'STRAINT INQLINE User manual
INTEGRATED WINCH & RETRACTOR SYSTEM
Installaon Manual
THIS REAR-ENTRY INTEGRATED SECUREMENT SYSTEM AND COMPONENTS COMPLY WITH ALL APPLICABLE PARTS
OF RELATED SAFETY REGULATIONS AND STANDARDS INCLUDING ADA, FMVSS & CMVSS 209/302, AND CSA Z605.
IN ADDITION, ALL SYSTEMS ARE CRASH TESTED AT 30MPH (48KPH), 20G, AND FULLY COMPLY WITH RESNA WC-4,
SECTION 18 AND ISO-10542-1.
© 2019 Q'STRAINT®. All Rights Reserved.
Q'STRAINT®, Q'STRAINT® logo, OMNI® and Slide ‘N Click® are registered trademarks of Q'STRAINT®, Inc. QRT™ and INQLINE SECUREMENT™ are trademarks of
Q'STRAINT®, Inc. Products mentioned herein are for identication purposes only and may be registered trademarks or trademarks of their respective companies. All
other brand names, trademarks or registered trademarks are the property of their respective owners.
3
TABLE OF CONTENTS
IMPORTANT INSTALLATION REQUIREMENTS................................................................................................4
IMPORTANT SAFEGUARDS AND WARNINGS.................................................................................................5
INTRODUCTION .......................................................................................................................................................6
COMPLIANCE ............................................................................................................................................................6
ELECTRICAL REQUIREMENTS ..............................................................................................................................7
SYSTEM CHECKLIST ................................................................................................................................................7
EQUIPMENT DIMENSIONS AND PART NUMBERS ....................................................................................
LOCATION RECOMMENDATIONS ................................................................................................................... 10
INSTALLATION INSTRUCTIONS........................................................................................................................ 11
ORDER OF INSTALLATIONS ............................................................................................................................... 12
INQLINE SECUREMENTTM SYSTEM INSTALLATION..............................................................................
SLIDE 'N CLICK®ANCHORAGE INSTALLATION............................................................................................ 20
TESTING INQLINE SECUREMENTTM SYSTEM..........................................................................................
TROUBLESHOOTING .....................................................................................................................................
MAINTENANCE AND CARE................................................................................................................................
WARRANTY............................................................................................................................................................. 30
4
NOT alter,
MUST
NOT install
• Do NOT
stated, ONLYNOT
NOT
Shoulder and Pelvic Belt.
device.
IMPORTANT INSTALLATION REQUIREMENTS
SAVE THESE INSTRUCTIONS
5
• Do NOT
• ONLY
MUST
each use. Do NOT
MUST
NOT
MUST
SAVE THESE INSTRUCTIONS
IMPORTANT SAFEGUARDS AND WARNINGS
6
ENGINEERED TO PERFORM
This Integrated Winch and Retractor Compact System, designed by our engineers has revolutionized the industry
with its innovative design that automatically steers a wheelchair passenger up the ramp, self-tensions and secures—all
at the Touch-of-a-Button. Oering peace-of-mind and full control over the ascent and descent of the mobility device.
BUILT TO LAST
Equipped with energy-absorbing steel frame and heavy-duty precision belt retractors that hold the load in place as it
guides the wheelchair passenger up and down the ramp. The self-tensioning, high strength webbing system minimizes
rearward movement during the loading and unloading process to ensure the wheelchair occupant is always secured.
SECURED ON THE ROAD
The safe transportation of wheelchair passengers is our mission and the reason why we are involved in all major
international safety committees to assist in developing and improving wheelchair and occupant safety standards. All of
our systems are held to the highest standards by undergoing a crash test and endurance testing at a world renowned
test facility to meet and exceed all applicable requirements.
COMPLIANCE
INTRODUCTION
7
SYSTEM CHECKLIST
ELECTRICAL REQUIREMENTS
Power Supply
• All equipment and components must be installed and serviced by an experienced and trained technician.
• Connection to be 12Vdc using a 30 amp fuse between + terminal of battery and controller.
q
qand Wall Mount
q
q
q
q
q
q
The following parts make up a complete INQLINE SECUREMENT™ Wheelchair Securement System. If any
quesons arise, call your nearest Q’STRAINT ® authorized dealer or oce.
q
q®
q
q
q
q
q1 Warranty Card
INQLINE SECUREMENT™ Wheelchair Securement System
Wall Pouch
qQ'STRAINT® Wall Pouch and Hardware
SOLD SEPARATELY
8
EQUIPMENT DIMENSIONS AND PART NUMBERS
Wall Control Panel
Right
Le
Order Parts by contacng the nearest Q'STRAINT® authorized dealer or oce.
Thumb Controller with Cord Wall Mount
Thumb Controller
Wall Mount -++
-
-+
-++
-
-+
Main Control Box
QRT Retractor with Slide 'N Click
Washers and Bolts not included. ONLY use minimum grade 8.8, M8 - 1.25x16 Bolts. Bolt length = all material
thickness + .312" (8mm).
Q'STRAINT® Wall Pouch
6.94" (176.3mm)
6.57" (166.96mm)
4.28" (108.58mm)
4.5" (114.30) 2.5" (63.5mm)
5.4" (137.16)
13.13" (333.50mm)
11.5" (292.10mm)
Le INQLINE SECUREMENT™
Retractors
Right INQLINE SECUREMENT™
Retractors
9
US Occupant Securement System (Shoulder and Lap Belt)
EQUIPMENT DIMENSIONS AND PART NUMBERS
Right Retractor, 10 . Wire Harness
Le Retractor, 10 . Wire Harness
10 . Wall Unit Wire Harness
Split Wire Harness
Hook Hangers
Slide 'N Click Anchorage
UK Occupant Securement System (Shoulder and Lap Belts)
Occupant Securement
10' Wall Unit Wire Harness
Split Wire Harness
Rubber Plug
3/8" (10mm) Bolt
Floor Anchorage
Pocket
Backing Plate
Washer
Locknut
Occupant Securement
Occupant Securement will vary depending on vehicle's model.
Right RetractorWire Harness
Le RetractorWire Harness
Hook Hangers
10
LAYOUT RECOMMENDATIONS
Frontal Clear Zones (FCZ) = 26” (660mm) with Shoulder Belt
We recommend using Shoulder and Lap Belts to reduce the possibility of head and chest impacts with vehicle
components. FCZ may not be achievable with wheelchair-seated drivers.
Top View
Layout for All Anchorages
AND
Please CONTACT Q'STRAINT in the event that the vehicle’s dimensions are outside the recommended installation instructions.
45º
30º 40º
60º
32º
20º
27”
(685mm)
34”
(865mm)
13”
(330mm)
15”
(380mm)
6º
11º
Please CONTACT Q’Straint® in the event that the vehicle’s geometry is outside the recommended installation instructions.
REAR VIEW SIDE VIEW FRONT VIEW
48” - 54”
(1220mm - 1370mm)
Wheelchair
Reference Plane
Wheelchair
Reference Plane
Front
Securement Points
Rear
Securement Points
From 40” (1016mm) for 6-Year Old Child)
To 61” (1549.4mm) for a Tall Adult
8FCZ
817.72” (450mm)
Side View
88” (200mm)
88” (200mm)
816” (450mm)
8FCZ
Wall
19” (483mm) Max
2" - 5" (51mm - 127mm)
13” (330mm) - 15” (380mm)
48” (1220mm) - 54” (1370mm)
27” (685mm) - 34” (865mm)
Shoulder Belt Anchorage Floor Anchorage
From Webbing Center Line
11
INSTALLATION CHECKLIST
oSafety eye glasses MUST be worn whenever installing or servicing this system.
oBefore installation, inspect the underside of vehicle oor, note utilities, frames, cross-members, fuel tanks and other possible
obstructions—any questions contact the vehicle OEM.
oVehicle anchor points may require reinforcement. The installer or manufacturer is responsible for ensuring anchorages
are installed into suitable oor structures. Floor strength MUST meet specic regulations, standards and applicable
performance requirements from local transportation authorities.
oDo NOT install anchorages or any system components into faulty materials such as corroded metal, wood, plastic or
berglass panels.
oThe oor and shoulder belt anchorages MUST be installed onto a at and durable surface.
oOnly use Hardware with a minimum Grade 8 (M8-1.25x16) (10.9 metric), which meets ASTM F835, SAE J429 or ASTM 574
specications (depending on head style and drive), and coated for adequate protection against corrosion per ISO 7253 or
ASTM B117 or per customer requirements.
oONLY use minimum Grade 8.8, M8-1.25x16 Bolts for the INQLINE SECUREMENT™. Bolt length = all material thickness + 0.34”
(8.64mm). DO
NOT exceed this length.
oModications to Backing Plate MUST only be made where necessary as a smaller plate size reduces the oor load
distribution. Always leave a minimum of .6”(15mm) adjacent the bolt hole in the plate.
INSTALLATION INSTRUCTIONS
COMPLETE INQLINE SECUREMENT™ SECUREMENT SYSTEM
Le INQLINE SECUREMENT Retractor
Right INQLINE SECUREMENT Retractor
QRT Retractors with Slide 'N Click
Wall or Panel
Wall Control Panel
Thumb Controller
Hook Hangers
12
ORDER OF INSTALLATION
Vehicle Battery
Vehicle Interlock
-
+
-
+
Vehicle Battery
Vehicle Interlock
-
+
-
+
Occupant Securement Will Vary Depending On Vehicle's Model
Electrical Roung
1
2
3
4
5
6
13
INQLINE SECUREMENT™ SYSTEM INSTALLATION
27" (685mm) - 34" (865mm)
A
A1
assistance.
(For cut
out Le and Right Retractor Templates, go to pages 15
& 16)
B
assistance.
3. Remove left and right retractor templates and drill ½”
(12.7mm) holes through the 6 marked holes on the oor
and clean debris (C).
Before drilling, inspect the underside of the vehicle for
any obstructions.
A
A1
B
C
Le Right
27" (685mm) - 34" (865mm)
Le Right
Le Right
DRILL
Maximum 5 Degrees Inward Angel
14
INQLINE SECUREMENT™ SYSTEM INSTALLATION
4. Insert the bolts through the washers, backing plate
(not included but recommended), oor and INQLINE
SECUREMENT™ Retractors to secure them in place (D).
Recommended Torque is 42 FT-LB.
Washers and Bolts not included. ONLY use minimum grade
8.8, M8-1.25x16 Bolts. Bolt length = all material thickness
+ 0.34” (8.64mm). DO NOT exceed this length.
Install INQLINE SECUREMENT™ Retractors towards the front of
vehicle with wire harness compartments facing inward.
5. Mark location for installation and drill holes, then clean
debris. Use 4 screws (not included) to secure the Wall
Control Panel Base to the wall and 2 screws (not included) to
secure the Wall Mount (E).
Install towards the rear of the vehicle on the curb side inside
panel, where it’s easily accessible.
6. Place the Wall Control Panel onto the Base and secure it
with the 2 screws (F).
7. Insert the Thumb Controller Cable into the slot underneath
the Wall Control Panel. Then insert the Thumb Controller
into the Wall Mount (G).
FF
D
E
F
Backing Plate
Wire Harness Compartment
G
15
INQLINE SECUREMENT™ SYSTEM INSTALLATION
Le INQLINE SECUREMENT Retractor Template and 3 Holes
CUT OUT
16
INQLINE SECUREMENT™ SYSTEM INSTALLATION
Right INQLINE SECUREMENT Retractor Template and 3 Holes
CUT OUT
17
INQLINE SECUREMENT™ SYSTEM INSTALLATION
8.
H
Make sure the vehicle is turned o and the vehicle’s battery
is disconnected from the vehicle before starting the
Electrical Connections.
Final image of Wire Harnesses connected to Main Control
Box (H1).
9. Connect the Wall Control Panel Wire Harness to slot J2 on
the Main Control Box (J).
10. Connect the Split Wire Harness to slot J1 on the Main
Control Box. Then connect the Yellow Wire to the Vehicle’s
Interlock System (K). i.e Vechical parking break ground.
Vehicle Battery
Vehicle Interlock
-
+
-
+
Vehicle Battery
Vehicle Interlock
-
+
-
+
H
J
K
J2
Vehicle Battery
Vehicle Interlock
-
+
-
+
Vehicle Battery
Vehicle Interlock
-
+
-
+
J1
Vehicle Interlock
Vehicle Baery
Vehicle Interlock
Vehicle Baery
H1
Final Image of Wire Harnesses Connected to Main Control Box
18
INQLINE SECUREMENT™ SYSTEM INSTALLATION
11.
(L).
12.
Harnesses (M).
(N).
P
Vehicle Battery
Vehicle Interlock
-
+
-
+
Vehicle Battery
Vehicle Interlock
-
+
-
+
Vehicle Battery
Vehicle Interlock
-
+
-
+
Vehicle Battery
Vehicle Interlock
-
+
-
+
Vehicle Battery
Vehicle Interlock
-
+
-
+
Vehicle Battery
Vehicle Interlock
-
+
-
+
L
M
N
P
Vehicle Interlock
Vehicle Baery
Vehicle Interlock
Vehicle Baery
Vehicle Interlock
Vehicle Baery
Vehicle Battery
Vehicle Interlock
-
+
-
+
Vehicle Battery
Vehicle Interlock
-
+
-
+
Vehicle Interlock
Vehicle Baery
To J6 - J7 To J8 - J9
Le
Right
19
INQLINE SECUREMENT™ SYSTEM INSTALLATION
14. Carefully remove the Split Wire Harness from J1 and
Wire Harness from J2. Insert the wires through the 4
openings on the cover and place the Cover on the Main
Control Box (Q).
15. Insert and tighten the 4 screws into the Main Control Box
Cover. Then reconnect the Split Wire Harness into J1 and
the Wire Harness into J2 (R).
16. Reconnect the vehicle’s battery to the vehicle (S).
17. If the green wire connector for the left and right hand
wire harnesses must be disconnected for installation
purposes, use gure (T) as a reference. For the RH wire
harness ensure the thicker red wire is connected to the
terminal closest to the side labeled “R”. For the LH wire
harness ensure the thicker red wire is connected to the
terminal closest to the side labeled “W”.
-
+-
+
Q
R
S
Openings
Remove
Vehicle's Baery
J1 J2
Reconnect to Vehicle
T
LH
W
RH
R
20
SLIDE 'N CLICK ANCHORAGE INSTALLATION
18. (U).
If the vehicle does
assistance.
(V).
20. (W).
21. (X)
22. (Y).
23. (Z).
24. (AA).
25. (BB).
26. (CC).
27.
(DD).
UV
W
X
Y
Z
AA
BB
CC
DD
Locknut
Rubber Plug
Backing Plate
Washer
Anchorage
Floor
Sealant
Pocket
Table of contents
Other Q'STRAINT Wheelchair manuals
Q'STRAINT
Q'STRAINT QLK-150 User manual
Q'STRAINT
Q'STRAINT QLK-150 User manual
Q'STRAINT
Q'STRAINT QRT-1 Series User manual
Q'STRAINT
Q'STRAINT QUANTUM User manual
Q'STRAINT
Q'STRAINT QRT-1 Series User manual
Q'STRAINT
Q'STRAINT QRT-1 Series User manual
Q'STRAINT
Q'STRAINT QLK-150 User manual
Q'STRAINT
Q'STRAINT SURE-LOK DOUBLE INERTIA OCCUPANT BELT User manual
Q'STRAINT
Q'STRAINT QLK-150 User manual
Q'STRAINT
Q'STRAINT ONE User manual
Popular Wheelchair manuals by other brands
Drive
Drive Inspired Supreme BCCS-8510S instructions
Invacare
Invacare Action 4NG series user manual
aidapt
aidapt VB540 Usage and maintenance instructions
Blandino
Blandino FROG Use and maintenance handbook
Freedom
Freedom CGX Standard user guide
Bischoff & Bischoff
Bischoff & Bischoff Pyro Start Plus instruction manual
