Quadra-Fire 31M-ACC-AU User manual

1 7033-362C 11/21
NOTICE: DO NOT DISCARD THIS MANUAL
R
3100 MILLENNIUM AUSTRALIAN
WOOD APPLIANCE
AUTOMATIC COMBUSTION
CONTROL (ACC)
MODEL NUMBER:
31M-ACC-AU
Owner’s Manual
Operation & Care
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with question on installation, operation, or service.
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
WARNING
Hot glass and appliance will cause burns.
• Do not touch glass until it is cooled
• Use leather gloves when reloading fuel
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room
as appliance.
• Alert children and adults to hazards of
high temperatures
• High temperatures may ignite clothing or other
ammable materials.
• Keep clothing, furniture, draperies and other
ammable materials away.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may over re and generate
poisonous gases (i.e. carbon monoxide).
• Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any
other appliance.
• Do not over re - If appliance or chimney connector
glows, you are over ring. Over ring will void
your warranty.
• Comply with all minimum clearances to combustibles
as specied.
Failure to comply may cause house re.
WARNING
If the information in these instructions is
not followed exactly, a re could result
causing property damage, personal injury,
or death.
This unit has been retired.
Service parts pages within have
been removed.
For replacement parts, please
refer to the individual service parts
list located on the brand website.

2 7033-362C 11/21
CONFIDENTIAL PROPERTY OF HEARTH & HOME TECHNOLOGIES INC.
PART NAME:
DRAWN BY: SCALE: MATERIAL:
SHEET:
PART NUMBER: REV:
THIS PRINT IS CHECKED AND CONTROLLED BY THE ENGINEERING
DEPARTMENTS OF HEARTH & HOME TECHNOLOGIES INC.
ECO # DATE BYREV
UNLESS OTHERWISE SPECIFIED DIMS ARE INCHES[MM] & : TOLERANCES ARE: (2) PLACE DEC : ± 0.03 (3) PLACE DEC: ± 0.005 ANGLE: ± 2° FRACTION: ± 1/16
OUTSIDE MATERIAL. NORMAL DIM & INSIDE MATERIAL. OUTSIDE APEX INSIDE APEX - DIMS ENCLOSED BY AN OVAL ARE CRITICAL DIMENSIONS
REVISIONS
ITEM PART NUMBER PART NAME QTY
BARCODE LABEL
Hearth & Home Technologies, 352 Mountain House Road,
Halifax, PA 17032 United States of America
HF
o
QUADRA-FIRE WOODFIRE COMPLIANCE LABEL
This appliance has been TESTEDTO AS/NZS4013 for Hardwood by HRL Technology Report # HCMG/12/043A - Date tested: May 2012
MODEL QUADRA-FIRE 3100 SERIES ACC FREESTANDING WOOD STOVE
OVERALL AVERAGE EFFICIENCY BURNING HARDWOOD
WHEN TESTED IN ACCORDANCE WITH AS/NZS 4012: ......................................................... 71%
AVERAGE PARTICULATE EMISSION FACTOR BURNING HARDWOOD
WHEN TESTED IN ACCORDANCE WITH AS/NZS 4013: ......................................................... 1.4 g/kg
MAXIMUM AVERAGE HEAT OUTPUT BURNING HARDWOOD:
.......................... 7.1 kW
APPROVED FUEL:
............................................................................................................... BURN ONLY HARDWOOD WITH A MOISTURE CONTENT
LESS THEN 25% (dry basis).
Wetback - All Models:.........................................................................................
Manufactured by:................................................................................................
PERFORMANCE MAY VARY FROM TEST VALUES DEPENDING ON ACTUAL OPERATING CONDITIONS.
U.S. ENVIRONMENTAL PROTECTION AGENCY
Export stove. May not be operated within the United States
NOTE:
7033-309G
INSTALLATION
DATE:
Serial No. /
N de série:
Date of Manufacture / Date de fabrication:
2021 2022 2023 JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC
MILLENIUM
LIMITED EDITION
Serial
No.
Model
Name
Test Lab &
Report No. Mfg. Date
SAMPLE
A. Sample of Serial Number / Safety Label
LOCATION: Back of appliance
NOTE: Clearances may only be reduced by means approved by the regulatory
authority having jurisdiction

3 7033-362C 11/21
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
A. Sample of Serial Number / Safety Label ........... 2
B. Warranty Policy .............................. 4
C. Quick Start Guide............................. 6
1 Listing and Code Approvals
A. Appliance Certication . . . . . . . . . . . . . . . . . . . . . . . . . 7
B. BTU & Efciency Specications.................. 7
C. Glass Specications........................... 7
2 Operating Instructions
A. Over-Firing Your Appliance ..................... 8
B. Wood Selection & Storage...................... 8
C. Burning Process.............................. 8
D. Air Controls ................................. 9
E. Using Burn Rate Air Control & ACC System ........ 9
F. Burn Rates and Operating Efciency ............. 10
G. Building A Fire .............................. 11
H. Correct Bafe & Blanket Placement.............. 12
I. Opacity (Smoke) ............................. 13
J. Clear Space ................................ 13
K. Negative Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
L. Frequently Asked Questions.................... 14
3 Maintenance and Service
A. Quick Reference Maintenance Guide ............ 15
B. General Maintenance......................... 16
4 Troubleshooting Guide ....................... 18
5 Service Part Replacement
A. Glass Replacement - Door Assembly ............ 19
B. Firebrick Replacement ....................... 19
C. Door Handle Assembly ....................... 19
D. Bafe Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
E. Tube Channel Assembly Replacement ........... 21
6 Reference Materials
A. Service and Maintenance Log . . . . . . . . . . . . . . . . . . 22
Quadra-Fire is a registered trademark of Hearth & Home Technologies.

4 7033-362C 11/21
2000-645H 1
AUSTRALIAN WARRANTY INFORMATION
Hearth & Home Technologies (HHT)
7571 215th Street West, Lakeville, MN 55044
0011-1-651-345-1777
www.hearthnhome.com
HHT extends the following manufacturer’s warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are
purchased from an HHT authorized dealer.
HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership
of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance will
be free from defects in materials and workmanship at the time of manufacture.
After installation, if covered components manufactured by HHT are found to be defective in materials or workmanship during
the applicable warranty period, HHT will, at its option, repair or replace the covered components. HHT, at its own discretion,
may fully discharge all of its obligations under this manufacturer’s warranty by replacing the product itself or refunding the
verifi ed purchase price of the product itself. The maximum amount recoverable under this warranty is limited to the purchase
price of the product. This warranty is subject to conditions, exclusions and limitations as described below.
Warranty coverage begins on the date of original purchase. In the case of new home construction, coverage under this
manufacturer’s warranty begins on the date of fi rst occupancy of the dwelling or six months after the sale of the product by
an independent, authorized HHT dealer/ distributor, whichever occurs earlier. The warranty period for this manufacturer’s
warranty shall commence no later than 24 months following the date of product shipment from HHT, regardless of the
installation or occupancy date. The manufacturer’s warranty period for parts and labour for covered components is produced
in the following table.
The term “Limited Lifetime” in the table below is defi ned as: 20 years from the beginning date of warranty coverage for gas
appliances, and 10 years from the beginning date of warranty coverage for wood, pellet and coal appliances. These time
periods refl ect the minimum expected useful lives of the designated components under normal operating conditions.
Warranty Period HHT Manufactured Appliances and Venting
Parts Labor Gas Pellet Wood Electric Venting Components Covered
1 year X X X X X
All parts including handles, external enameled
components and other material except as covered by
Conditions, Exclusions, and Limitations listed
2 years
X X Igniters, Auger Motors, Electronic Components, and
Glass
X
Electrical components limited to modules, remotes/
wall switches, valves, pilots, fans, junction boxes, wire
harnesses, transformers and lights (excluding light bulbs)
X X Molded Refractory Panels, Glass Liners
3 years X Firepots, Burnpots, Mechanical Feeders/Auger
Assemblies
5 years 1 years X Vent Free Burners, Vent Free Logs
X X Castings Medallion and Ba󰀪es
AUSTRALIAN WARRANTY INFORMATION
Hearth & Home Technologies (HHT)
7571 215th Street West, Lakeville, MN 55044
0011-1-651-345-1777
www.hearthnhome.com
HHT extends the following manufacturer’s warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are
purchased from an HHT authorized dealer.
HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership
of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance will
be free from defects in materials and workmanship at the time of manufacture.
After installation, if covered components manufactured by HHT are found to be defective in materials or workmanship during
the applicable warranty period, HHT will, at its option, repair or replace the covered components. HHT, at its own discretion,
may fully discharge all of its obligations under this manufacturer’s warranty by replacing the product itself or refunding the
veried purchase price of the product itself. The maximum amount recoverable under this warranty is limited to the purchase
price of the product. This warranty is subject to conditions, exclusions and limitations as described below.
Warranty coverage begins on the date of original purchase. In the case of new home construction, coverage under this
manufacturer’s warranty begins on the date of rst occupancy of the dwelling or six months after the sale of the product by
an independent, authorized HHT dealer/ distributor, whichever occurs earlier. The warranty period for this manufacturer’s
warranty shall commence no later than 24 months following the date of product shipment from HHT, regardless of the instal-
lation or occupancy date. The manufacturer’s warranty period for parts and labour for covered components is produced in
the following table.
The term “Limited Lifetime” in the table below is dened as: 20 years from the beginning date of warranty coverage for gas
appliances, and 10 years from the beginning date of warranty coverage for wood, pellet and coal appliances. These time
periods reect the minimum expected useful lives of the designated components under normal operating conditions.
2000-645G (5-20) Page 1 of 3
B. Warranty Policy

5 7033-362C 11/21
2000-645H 2
Warranty Period HHT Manufactured Appliances and Venting
Parts Labor Gas Pellet Wood Electric Venting Components Covered
6 years 3 years X Catalyst - Limitations Listed
7 years 3 years X X Manifold Tubes HHT
Chimney and Termination
10 years 1 year X Burners, Logs and Refractory
Limited
Lifetime 3 years X X X Firebox and Heat Exchanger, FlexBurn
®
System
(engine, inner cover, access cover and reback)
1 year None X X X X X All Replacement Parts beyond Warranty Period
OTHER RIGHTS
The HHT manufacturer’s warranty is in addition to other rights and remedies that you may have under Australian
law.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
WARRANTY CONDITIONS AND EXCLUSIONS:
• The HHT manufacturer’s warranty only covers HHT appliances that are purchased through an HHT authorized dealer
or distributor. A list of HHT authorized dealers is available on the HHT branded websites.
• This warranty is only valid while the HHT appliance remains at the site of original installation.
WARRANTY EXCLUSIONS:
This HHT manufacturer’s warranty does not cover the following:
• Changes in surface nishes as a result of normal use. As a heating appliance, some changes in color of interior and
exterior surface nishes may occur. This is not a aw and is not covered under warranty.
• Damage to printed, plated, or enamelled surfaces caused by ngerprints, accidents, misuse, scratches, melted items,
or other external sources and residues left on the plated surfaces from the use of abrasive cleaners or polishes.
• Repair or replacement of parts that are subject to normal wear and tear during the warranty period. These parts in-
clude: paint, wood, pellet and coal gaskets, rebricks, grates, ame guides, light bulbs, batteries and the discoloration
of glass.
• Expansion, contraction, or movement of certain parts causing noise. These conditions are normal and complaints
related to this noise are not covered by this warranty.
• Damages resulting from: (1) failure to install, operate, or maintain the appliance in accordance with the installation
instructions, operating instructions, and listing agent identication label furnished with the appliance; (2) failure to in-
stall the appliance in accordance with local building codes; (3) shipping or improper handling; (4) improper operation,
abuse, misuse, continued operation with damaged, corroded or failed components, accident, or improperly/incorrectly
performed repairs; (5) environmental conditions, inadequate ventilation, negative pressure, or drafting caused by
tightly sealed constructions, insu󰀩cient make-up air supply, or handling devices such as exhaust fans or forced air fur-
naces or other such causes; (6) use of fuels other than those specied in the operating instructions; (7) installation or
use of components not supplied with the appliance or any other components not expressly authorized and approved
by HHT (8) modication of the appliance not expressly authorized and approved by HHT in writing; and/or (9) interrup-
tions or uctuations of electrical power supply to the appliance.
2000-645G (5-20) Page 2 of 3
OTHER RIGHTS
The HHT manufacturer’s warranty is in addition to other rights and remedies that you may have under Australian
law.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
WARRANTY CONDITIONS AND EXCLUSIONS:
• The HHT manufacturer’s warranty only covers HHT appliances that are purchased through an HHT authorized dealer or
distributor. A list of HHT authorized dealers is available on the HHT branded websites.
• This warranty is only valid while the HHT appliance remains at the site of original installation.
WARRANTY EXCLUSIONS:
This HHT manufacturer’s warranty does not cover the following:
• Changes in surface fi nishes as a result of normal use. As a heating appliance, some changes in color of interior and
exterior surface fi nishes may occur. This is not a fl aw and is not covered under warranty.
• Damage to printed, plated, or enamelled surfaces caused by fi ngerprints, accidents, misuse, scratches, melted items, or
other external sources and residues left on the plated surfaces from the use of abrasive cleaners or polishes.
• Repair or replacement of parts that are subject to normal wear and tear during the warranty period. These parts include:
paint, wood, pellet and coal gaskets, fi rebricks, grates, fl ame guides, light bulbs, batteries and the discoloration of glass.
• Expansion, contraction, or movement of certain parts causing noise. These conditions are normal and complaints related
to this noise are not covered by this warranty.
• Damages resulting from: (1) failure to install, operate, or maintain the appliance in accordance with the installation
instructions, operating instructions, and listing agent identifi cation label furnished with the appliance; (2) failure to install
the appliance in accordance with local building codes; (3) shipping or improper handling; (4) improper operation, abuse,
misuse, continued operation with damaged, corroded or failed components, accident, or improperly/incorrectly performed
repairs; (5) environmental conditions, inadequate ventilation, negative pressure, or drafting caused by tightly sealed
constructions, insuffi cient make-up air supply, or handling devices such as exhaust fans or forced air furnaces or other
such causes; (6) use of fuels other than those specifi ed in the operating instructions; (7) installation or use of components
not supplied with the appliance or any other components not expressly authorized and approved by HHT (8) modifi cation
of the appliance not expressly authorized and approved by HHT in writing; and/or (9) interruptions or fl uctuations of
electrical power supply to the appliance.

6 7033-362C 11/21
2000-645H 3
• Non HHT venting components, hearth components or other accessories used in conjunction with the appliance.
• Any part of a pre-existing fi replace system in which an insert or a decorative gas appliance is installed.
• Removal, installation, reinstallation, set up or any other costs associated with a claim including travel and shipping
charges for parts
• HHT’s obligation under this warranty does not extend to the appliance’s capability to heat the desired space. Information
is provided to assist the consumer and the dealer in selecting the proper appliance for the application. Consideration
must be given to appliance location and confi guration, environmental conditions, insulation and air tightness of the
structure.
This warranty is void if:
• The appliance has been over-fi red or operated in atmospheres contaminated by chlorine, fl uorine, or other damaging
chemicals. Over-fi ring can be identifi ed by, but not limited to, warped plates or tubes, rust colored cast iron, bubbling,
cracking and discoloration of steel or enamel fi nishes.
• The appliance is subjected to prolonged periods of dampness or condensation.
There is any damage to the appliance or other components due to water or weather damage which is the result of, but not
limited to, improper chimney or venting installation.
HOW TO CLAIM
• To make a claim against this warranty, contact your local distributor during regular business hours. See addresses below
for a dealer nearest you. (Vic) Pty Ltd ACN 005 872 159 (Jetmaster).
• Additional service fees may apply if you are seeking warranty service from a dealer other than the dealer from whom you
originally purchased the product.
• Check with Jetmaster in advance for any costs to you when arranging a warranty call. Travel and shipping charges for
parts are not covered by this manufacturers’ warranty.
• HHT and Jetmaster will assess your claim. HHT or Jetmaster may need to inspect the product as part of the assessment
of your claim. If the product requires inspection, HHT or Jetmaster will discuss with you the best way for this to occur.
• To make a claim under this manufacturer’s warranty, you must be able to prove when you purchased the product. The
easiest way to do this is through your original proof of purchase, for example your invoice or receipt. However, if you do
not have your original proof of purchase HHT or Jetmaster may accept other evidence of the date of purchase.
VIC / TAS/ SA/ NSW and QLD
Jetmaster
444 Swan Street
Richmond 3121
[phone]
WA
Fireplace Corner
277 Lord Street
East Perth 6000
[phone]

7 7033-362C 11/21
C. Quick Start Guide
1 2 3
4 5
6 7
NOTE: These are generic drawings and may not represent your specifi c model.
ITEMS NEEDED FOR FIRST FIRE: 10 Pieces of Newspaper, 10-20 Pieces of Dry
Kindling and Few Pieces of Dry Split Wood.
OPEN AIR
CONTROLS
HIGH
BURN RA
TE
CONTROL
(Upper Right
Corner)
AUTOMATIC
COMBUSTION
CONTROL (ACC)
(Middle right hand side)
HIGH
LOAD WOOD
ADD NEWSPAPER
ADD KINDLING
LIGHT THE PAPER
ADD MORE WOOD
REDUCE AIR
CONTROLS
Set to desired heat output.
LOW
BURN RATE
CONTROL
(Upper Right
Corner)
AUTOMATIC
COMBUSTION
CONTROL (ACC)
(Middle right hand side)
LOW
The appliance is ready for
normal operation.
Warning! Risk of Fire.
Close and securely latch the door after
the fi re has started, and after refueling, to
prevent:
- Spillage of smoke, fl ame and carbon
monoxide
- Spillage of sparks, coals, and logs
- Over fi ring
DO NOT leave the appliance unattended
with the door open.
Starting a fi re may not require an open
door for draft. The air control should
supply adequate draft.

8 7033-362C 11/21
This wood appliance needs periodic inspection and repair for proper operation. It is against federal regulations to operate
this wood appliance in a manner inconsistent with operating instructions in this manual.
The Quadra-Fire 3100 Millennium Australian Wood Appliance is Hardwood Certied. Particulate Emissions equaling 1.4 g/
kg with a space heating efciency of 71%.
A. Appliance Certication
B. BTU & Efciency Specications
Overall Average Efciency
Burning Hardwood (AS/NZS
4012)
71%
Average Particulate
Emission Factor Burning
Hardwood (AS/NZS 4013)
1.4 g/kg
Maximum Average Heat
Output Burning Hardwood 7.1kW
Wetback
Wetbacks are NOT an
approved option and
must be tted.
Vent Size: 6 inches
Firebox Size: 2 cubic feet
Recommended Wood
Length: 16 inches
Fuel Orientation: Front-to-Back
Approved Fuel
Hardwood only with a
Moisture content less
than 25% (dry basis)
Model
Number: 3100 Millennium AU Wood Appliance
Laboratory: HRL Technology
Report No: HCMG/12/043A
Type: Hardwood only at 25% dry basis
Standard: AS/NZS 2918:2001
1 Listing and Code Approvals
NOTE: Hearth & Home Technologies, manufacturer of this appliance, reserves the right to alter its products, their
specications and/or price without notice.
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
For assistance or additional information, consult a qualied
installer, service agency or your dealer.
C. Glass Specications
This appliance is equipped with 5mm ceramic glass.
Replace glass only with 5mm ceramic glass. Please
contact your dealer for replacement glass.
• Installation and use of any damaged appliance.
• Modication of the appliance.
• Installation other than as instructed by Hearth &
Home Technologies.
• Installation and/or use of any component part not
approved by Hearth & Home Technologies.
• Operating appliance without fully assembling
all components.
• Operating appliance without legs attached (if
supplied with appliance).
• Do NOT Over re - If appliance or chimney connector
glows, you are over ring.
Any such action that may cause a re hazard.
WARNING
Fire Risk.
Hearth & Home Technologies disclaims any
responsibility for, and the warranty will be
voided by, the following actions:

9 7033-362C 11/21
User Guide
2 Operating Instructions
1. Symptoms of Over-Firing
Symptoms of over-ring may include one or more of
the following:
- Chimney connector or appliance glowing
- Roaring, rumbling noises
- Loud cracking or banging sounds
- Metal warping
- Chimney re
2. What To Do if Your Appliance is Over-Firing
- Immediately close the door and air controls to
reduce air supply to the re.
- If you suspect a chimney re, call the re
department and evacuate your house.
- Contact your local chimney professional and have
your appliance and appliance pipe inspected for
any damage.
- Do not use your appliance until the chimney
professional informs you it is safe to do so.
A. Over-Firing Your Appliance
C. Burning Process
B. Wood Selection & Storage
Dead wood lying on the forest oor should be considered
wet, and requires full seasoning time. Standing dead wood
can be considered to be about 2/3 seasoned. To tell if wood
is dry enough to burn, check the ends of the logs. If there
are cracks radiating in all directions from the center, it is
dry. If your wood sizzles in the re, even though the surface
is dry, it may not be fully cured.
Splitting wood before it is stored reduces drying time.
Wood should be stacked so that both ends of each piece
are exposed to air, since more drying occurs through the
cut ends than the sides. This is true even with wood that
has been split. Store wood under cover, such as in a shed,
or covered with a tarp, plastic, tar paper, sheets of scrap
plywood, etc., as uncovered wood can absorb water from
rain or snow, delaying the seasoning process.
In recent years there has been an increasing concern
about air quality. Much of the blame for poor air quality
has been placed on the burning of wood for home heating.
In order to improve the situation, we at Quadra-Fire
have developed cleaner-burning wood appliances that
surpass the requirements for emissions established by our
governing agencies. These wood appliances, like any other
appliances, must be properly operated in order to insure
that they perform the way they are designed to perform.
Improper operation can turn most any wood appliance into
a smoldering environmental hazard.
3. Kindling or First Stage
It helps to know a little about the actual process of
burning in order to understand what goes on inside
a appliance. The rst stage of burning is called the
kindling stage. In this stage, the wood is heated to a
temperature high enough to evaporate the moisture
which is present in all wood. The wood will reach the
boiling point of water (212°F) and will not get any hotter
until the water is evaporated. This process takes heat
from the coals and tends to cool the appliance.
Fire requires three things to burn - fuel, air and heat.
So, if heat is robbed from the appliance during the
drying stage, the new load of wood has reduced the
chances for a good clean burn. For this reason, it is
always best to burn dry, seasoned rewood. When
the wood isn’t dry, you must open the air controls and
burn at a high burn setting for a longer time to start it
burning. The heat generated from the re should be
warming your home and establishing the ue draft, not
evaporating the moisture out of wet, unseasoned wood,
resulting in wasted heat.
Burn only dry seasoned wood. Store wood under cover,
out of the rain and snow. Dry and well-seasoned wood will
not only minimize the chance of creosote formation, but will
give you the most efcient re. Even dry wood contains at
least 15% moisture by weight, and should be burned hot
enough to keep the chimney hot for as long as it takes to
dry the wood out - about one hour. It is a waste of energy to
burn unseasoned wood of any kind.
Fire Risk
Do not over-re.
Over-ring may ignite creosote or will damage
the appliance and chimney.
WARNING
To prevent over-ring your appliance, DO NOT:
• Use ammable liquids
• Overload with wood
• Burn trash or large amounts of scrap lumber
• Permit too much air to the re
Visit www.quadrare.com/shopping-tools/videos to view
product and use & care videos.
Hearth & Home Technologies WILL NOT warranty
appliances that exhibit evidence of over-ring. Evidence
of over-ring includes, but is not limited to:
• Warped air tube
• Deteriorated refractory brick retainers
• Deteriorated bafe and other interior components

10 7033-362C 11/21
D. Air Controls
E. Using Burn Rate Air Control & ACC System
1. Start up and Reloading Fuel
Open both Burn Rate Air Control and ACC systems
fully. To do this with the Burn Rate Air Controls push
spring handle up to high. For the ACC timer system
push knob towards back of appliance until the knob is
located under the high position (Figure 10.1).
2. Maximize Heat with The ACC System
To maximize heat output with the ACC timer System
or also known as high burn push the ACC Air Control
lever towards the back of the appliance and leave.
This combined with having the main burn rate control
lever pushed up will deliver the most amount of air
needed to achieve the highest amount of heat output
(Figure 10.1).
3. Manual Timer Over-Ride
If you need to shut the ACC system off before it goes
through the cycle of shutting itself off; 25 minutes,
reach towards the back of the appliance on the
right side and pull the lever towards the front of the
appliance (Figure 10.2).
4. Second Stage
The next stage of burning, the secondary stage, is the
period when the wood gives off ammable gases which
burn above the fuel with bright ames. During this
stage of burning it is very important that the ames be
maintained and not allowed to go out. This will ensure
the cleanest possible re. If the ames tend to go out,
it is set too low for your burning conditions. The air
control located at the upper right hand corner is used
to adjust for burn rates. This is called the Burn Rate Air
Control (Figure 11.1 on page 11).
5. Final Stage
The nal stage of burning is the charcoal stage. This
occurs when the ammable gases have been mostly
burned and only charcoal remains. This is a naturally
clean portion of the burn. The coals burn with hot blue
ames.
It is very important to reload your appliance while
enough lively hot coals remain in order to provide the
amount of heat needed to dry and rekindle the next
load of wood. It is best to open the Burn Rate Air and
Start-Up Air Controls before reloading. This livens
up the coal bed and reduces excessive emissions
(opacity/smoke). Open door slowly so that ash or
smoke does not exit appliance through opening. You
should also break up any large chunks and distribute
the coals so that the new wood is laid on hot coals.
Air quality is important to all of us, and if we choose
to use wood to heat our homes we should do so
responsibly. To do this we need to learn to burn our
appliances in the cleanest way possible. Doing this
will allow us to continue using our wood appliances for
many years to come.
Users will need to nd their preferred setting between
high and low based on desired heat output, installation
conguration, and fuel type.
1. Burn Rate Air Control
This air supply enters at the upper front of the rebox,
near the top of the glass door. This preheated air
supplies the necessary fresh oxygen to mix with the
unburned gases, helping to create second, third and
fourth combustions. This air is regulated by the Burn
Rate Air Control. When the control is moved all the way
up it is on the High setting and when moved all the way
down it is on the Low setting (Figure 10.1).
2. Automatic Combustion Control System (ACC)
To engage the Automatic Combustion Control (ACC)
timer system push the lever towards the back of the
appliance to the “HI” position, then pull forwards
towards the front of the appliance until the knob stops.
The timer will slowly close in about 25 minutes. Use
this feature when reloading fuel or if you want more air
supplied to the re (Figure 10.3).
Injury Risk.
• Gloves recommended
CAUTION
Figure 10.1
Figure 10.2
HIGH
MED
LOW
Burn Rate
Air Control
Start-Up
Air Control
Manual
Timer (ACC)
Shut Down
PullForward
to Shut Down
Figure 10.3
Over rides timer & opens
rear air to open locked
position
Open rear air medium air
flow
Engages timer push knob
towards HI then back to
any point within dotted line
Open rear air medium-low
air flow
Closes front and rear air

11 7033-362C 11/21
Figure 11.1
High (Open)
Low (Closed)
Burn Rate
Air Control
Start-Up Air
Control
LOW
Timer
Timer Manual
Rear Air Channel
Operates independently
from Timer Shut-off
Shown with Side
Shield Removed
Front Air Channel
Operated by Timer
HIGH
After activating the timer (ACC), if the control is placed
within the rear air section on the label it will allow rear air
to enter the rebox. This will not interfere with the timer
gradually closing the front air channel in 25 minutes. If
control is set on “HI” it over-rides the timer (ACC).
F. Burn Rates and Operating Efciency
For maximum operating efciency
This wood appliance has a manufacturer-set minimum
low burn rate that must not be altered. It is against federal
regulations to alter this setting or otherwise operate this
wood appliance in a manner inconsistent with operating
instructions in this manual.
• Burn dry, well-seasoned wood.
Burn Rates
1. Low burn setting:
- Burn Rate Air Control spring handle up to high
position for 5 minutes.
- Then activate the ACC timer system by pushing the
knob all the back toward the appliance to “HI” then
pull forwards towards the front of the appliance
until the knob stops (Figure 10.1 on page 10).
- At that point close the Burn Rate Air Control by
moving the spring handle to the low setting.
2. Medium low burn setting:
- Burn Rate Air Control spring handle up to high
position for 5 minutes.
- Then activate the ACC timer system by pushing the
knob all the back toward the appliance to “HI” then
pull forwards towards the front of the appliance
until the knob stops.
- At that point move the Burn Rate Air Control spring
handle to 1/8”-1/2” from the low setting.
3. Medium high burn setting:
- Burn Rate Air Control spring handle up to
high position.
- Then activate the ACC timer system by pushing the
knob all the back toward the appliance to “HI” then
pull forwards towards the front of the appliance
until the knob stops.
- At that point move the Burn Rate Air Control spring
handle to 1/2” – high.
4. High burn setting:
- Burn Rate Air Control spring handle up to
high position.
- Also activate ACC timer system knob pushed back
to the “HI” position.
NOTE: The above information is provided as a guideline
only. Altitude and other circumstances may
require control adjustments to achieve the
desired burn rates.
NOTE: Operate appliance on High Burn 45 minutes a
day to help keep ue/chimney clean.
NOTE: If using the optional blower use burn settings
1-3 burn settings the blower shall be off for the
rst 30 minutes and then be operated in the high
position at 30 minutes. For high burn setting,
blower may continue to be on full after the
loading of the fuel.
WARNING
Risk of Fire.
When set on High Burn Rate and over-riding
the Automatic Combustion Control system an
over re situation can occur and may result in
a chimney re.
Over ring will void the appliance warranty.

12 7033-362C 11/21
Baffle Board even with front tube & resting
on all tubes
Burn Rate
Air Control
Start-Up Air
Control
Tube Channels
Ceramic Blanket on Top
2 pc Baffle Board
Figure 12.2
Figure 12.1
G. Building A Fire
Before lighting your rst re in the appliance:
NOTE: The special high temperature paint that your
appliance is nished with will cure as your
appliance heats. You will notice an odor and
perhaps see some vapor rise from the appliance
surface; this is normal. We recommend that you
open a window until the odor dissipates and
paint is cured.
NOTE:
• Build re on brick rebox oor.
• Do NOT use grates, andirons or other methods to
support fuel. It will adversely affect emissions.
WARNING
Fire Risk
Do NOT store wood:
• Closer than required clearances to
combustibles to appliance
• Within space required for loading or ash
removal.
Do NOT operate appliance:
• With appliance door open.
• With ash removal system door open.
1. Conrm the bafe is correctly positioned. It should
be even with the front tube and resting on all tubes
(Figure 12.1 and Figure 12.2).
2. Remove all labels from glass and inside of appliance.
There are many ways to build a re. The basic principle is
to light easily-ignitable tinder or paper, which ignites the
fast burning kindling, which in turn ignites the slow-burning
rewood. Here is one method that works well:
3. Open the Burn Rate Air and ACC Controls fully; refer
Start-Up Guide on page 7.
4. Place several wads of crushed paper on the rebox
oor. Heating the ue with slightly crumpled newspaper
before adding kindling keeps smoke to a minimum.
5. Lay small dry sticks of kindling on top of the paper.
6. Make sure that no matches or other combustibles
are in the immediate area of the appliance. Be
sure the room is adequately ventilated and the ue
unobstructed.
7. Light the paper in the appliance. NEVER light or
rekindle re with kerosene, gasoline, or charcoal lighter
uid; the results can be fatal.
8. Once the kindling is burning quickly, add several full-
length logs 3 inches (76mm) or 4 inches (102mm) in
diameter. Be careful not to smother the re. Stack the
pieces of wood carefully; near enough to keep each
other hot, but far enough away from each other to allow
adequate air ow between them.
9. Set the Burn Rate Air Control and activate the ACC
timer system.
10. When ready to reload, It is best to fully open both
the Burn Rate Air and Start-up Air Controls before
reloading. This livens up the coal bed and reduces
excessive emissions (opacity/smoke). Open door
slowly so that ash or smoke does not exit appliance
through opening. Large logs burn slowly, holding a re
longer. Small logs burn fast and hot, giving quick heat.
11. As long as there are hot coals, repeating steps 6
through 8 will maintain a continuous re.
Fire Risk
• Do NOT burn wet or green wood.
• Store wood in dry location.
• Stack wood so both ends are exposed
to air.
Wet, unseasoned wood can cause
accumulation of creosote.
WARNING

13 7033-362C 11/21
INCORRECT POSITIONS
H. Correct Bafe & Blanket Placement
Figure 13.1
Figure 13.2
CORRECT POSITION
Ceramic Blanket and Bafe Board are NOT in contact
with the back of the rebox.
Ceramic Blanket is NOT in contact with the back of the
rebox and NOT even with the Bafe Board in the front.
Ceramic Blanket is bunched up at the back of the rebox
and NOT even with the Bafe Board in the front.
Ceramic Blanket
Back of
Firebox
Baffle Board
Ceramic Blanket and Bafe Board MUST be in contact
with the back of the rebox and even with each other in
the front.
Ceramic Blanket
Back of Firebox
Baffle Board
Baffle Retainer
Bracket
CAUTION
The bafe boards are FRAGILE. Use extreme caution
when loading rewood to prevent:
• Cracking, breaking or damaging the bafe boards
DO NOT operate the appliance without bafe boards
WARNING
Fire Risk
Firebox damage due to improper bafe
placement is not covered by warranty.
Operate the wood burning appliance with the
bafe in the correct position only.
Not doing so could result in:
• Reduced efciency
• Overheating the chimney
• Overheating the rear of the rebox
• Poor performance
Ensure correct bafe placement and replace
bafe components if damaged or missing.

14 7033-362C 11/21
I. Opacity (Smoke)
This is the measure of how cleanly your appliance is
burning. Opacity is measured in percent; 100% opacity is
when an object is totally obscured by the smoke column
from a chimney, and 0% opacity means that no smoke
column can be seen. As you become familiar with your
appliance, you should periodically check the opacity. This
will allow you to know how to burn as nearly smoke-free as
possible (goal of 0% opacity).
J. Clear Space
• Do NOT place combustible objects within 1.2m of the
front of appliance (Figure 13.1).
• Mantel - avoid placing candles and other heat-sensitive
objects on mantel or hearth. Heat may damage
these objects.
Figure 14.1
Maintain 4 ft (1.22m) clearance to
combustibles in front of appliance
WARNING
Do NOT place combustible objects in front of the
appliance. High temperatures may ignite clothing,
furniture or draperies.
WARNING
Fire Risk.
• DO NOT BURN GARBAGE OR
FLAMMABLE FLUIDS SUCH
AS GASOLINE, NAPHTHA OR
ENGINE OIL.
• Do NOT burn treated wood or wood with
salt (driftwood).
• May generate carbon monoxide if burn
material other than wood.
May result in illness or possible death.
WARNING
Fire Risk.
Keep combustible materials, gasoline and
other ammable vapors and liquids clear
of appliance.
• Do NOT store ammable materials in the
appliance’s vicinity.
• DO NOT USE GASOLINE, LANTERN
FUEL, KEROSENE, CHARCOAL
LIGHTER FLUID OR SIMILAR LIQUIDS
TO START OR “FRESHEN UP” A FIRE
IN THIS APPLIANCE.
• Keep all such liquids well away from the
appliance while it is in use.
• Combustible materials may ignite.
When burning your rst re, you will experience smoke
and odor from the appliance resulting from the curing
of paint and burning off of any oils remaining from
manufacturing; suggest:
• Open windows during initial burn to dissipate smoke
and odors!
• Odors may be irritating to sensitive individuals.
• Smoke detectors may activate.
CAUTION

15 7033-362C 11/21
Negative pressure results from the imbalance of air
available for the appliance to operate properly. It can be
strongest in lower levels of the house.
Causes include:
• Exhaust fans (kitchen, bath, etc.)
• Range hoods
• Combustion air requirements for furnaces, water
appliances and other combustion appliances
• Clothes dryers
• Location of return-air vents to furnace or air
conditioning
• Imbalances of the HVAC air handling system
• Upper level air leaks such as:
- Recessed lighting
- Attic hatch
- Duct leaks
K. Negative Pressure
ISSUES SOLUTIONS
Odor from appliance When rst operated, this appliance may release an odor for the rst several hours. This is
caused by the curing of the paint and the burning off of any oils remaining from manufacturing.
Metallic noise
Noise is caused by metal expanding and contracting as it heats up and cools down, similar to
the sound produced by a furnace or heating duct. This noise does not affect the operation or
longevity of the appliance.
Whirring sound If the optional blower has been installed, the blower produces a whirring sound which
increases in volume as the speed is increased.
L. Frequently Asked Questions
To minimize the effects of negative air pressure:
• Install the outside air kit with the intake facing prevailing
winds during the heating season
• Ensure adequate outdoor air for all combustion
appliances and exhaust equipment
• Ensure furnace and air conditioning return vents are
not located in the immediate vicinity of the appliance
• Avoid installing the appliance near doors, walkways or
small isolated spaces
• Recessed lighting should be a “sealed can” design
• Attic hatches weather stripped or sealed
• Attic mounted duct work and air handler joints and
seams taped or sealed
WARNING
Asphyxiation Risk.
• Negative pressure can cause spillage
of combustion fumes, soot and
carbon monoxide.
• Appliance needs to draft properly
for safety.
WARNING
Fire Risk.
• DO NOT BURN GARBAGE OR
FLAMMABLE FLUIDS SUCH AS
GASOLINE, NAPHTHA OR ENGINE OIL.
• Do NOT burn treated wood or wood with
salt (driftwood).
• May generate carbon monoxide if burn
material other than wood.
May result in illness or possible death.
Fire Risk.
Keep combustible materials, gasoline and
other ammable vapors and liquids clear of
appliance.
WARNING
• Do NOT store ammable materials in the
appliance’s vicinity.
• DO NOT USE GASOLINE, LANTERN FUEL,
KEROSENE, CHARCOAL LIGHTER FLUID OR
SIMILAR LIQUIDS TO START OR “FRESHEN UP” A
FIRE IN THIS APPLIANCE.
• Keep all such liquids well away from the appliance
while it is in use.
• Combustible materials may ignite.
CONTACT YOUR DEALER for additional information regarding operation and troubleshooting.
Visit www.quadrare.com to nd a dealer.
Table 15.1

16 7033-362C 11/21
Start the rst inspection after the rst 2 months of use,
or if performance changes, and adjust your schedule
accordingly. Maintenance is required for safe operation and
must be performed to maintain your warranty.
3 Maintenance and Service
A. Quick Reference Maintenance Guide CAUTION!
Allow the appliance to completely cool down before
performing any cleaning or maintenance.
FREQUENCY TASK
Baffl e & Blanket
MONTHLY
or after every
one (1) cord of
wood
Baffl e and blanket placement is critical to heat output, effi ciency and
overall life of the appliance. Make sure the baffl e is pushed all of the
way to the back of the fi rebox and the blanket is laying fl at. Inspect
baffl e for cracks.
Ceramic Blanket
Back of Firebox
Baffle Board
Baffle Retainer
Bracket
Chimney System
EVERY TWO
MONTHS
or after every
four (4) cords of
wood
The chimney and chimney cap must be inspected for soot and
creosote every two months during the burn season or more frequency
if chimney exceeds or is under 14-16 ft (4.3m-4.8m) measured from
bottom of appliance.
This will prevent pipe blockage, poor draft, and chimney fi res.
Always burn dry wood to help prevent cap blockage and creosote
build-up.
Firebrick & Ash Removal
WEEKLY
or after every 25
loads of wood
Ashes must be cool before you can dispose of the ashes in a non-
combustible container.
Firebrick is designed to protect your fi rebox. After ashes are removed,
inspect the fi rebrick and replace fi rebricks that are crumbling, cracked
or broken.
Door & Glass Assemblies
WEEKLY
or after every 25
loads of wood
Keep door and glass gasket in good shape to maintain good burn.
To test: place a dollar bill between the appliance and door and then
shut the door. If you can pull the dollar out, remove one washer from
door handle behind latch cam and try again. If you can still pull it out,
replace the door gasket.
Check the glass frame for loose screws to prevent air leakage.
Check glass for cracks.
Door Handles
WEEKLY
or after every 25
loads of wood
Check the door latch for proper adjustment. This is very important
especially after the door rope has formed to the appliance face.
Check door handle for smooth cam operation.
These are generic drawings and may not represent your model.
Table 16.1

17 7033-362C 11/21
1. Creosote (Chimney) Cleaning
• Frequency: Every 2 months during heating season or
as recommended by a certied chimney sweep; more
frequently if chimney exceeds or is under 14-16 ft.
(measured from bottom of appliance)
• By: Certied Chimney Sweep
Remove all ash from the rebox and extinguish all hot
embers before disposal. Allow the appliance to cool
completely. Disconnect ue pipe or remove bafe and
ceramic blanket from appliance before cleaning chimney.
Otherwise residue can pile up on top of the bafe and
ceramic blanket and the appliance will not work properly;
see Bafe Removal on page 21. Close the door tightly.
The creosote or soot should be removed with a brush
specically designed for the type of chimney in use. Clean
out fallen ashes from the rebox.
It is also recommended that before each heating season
the entire system be professionally inspected, cleaned and
repaired if necessary.
Inspection:
Inspect the system at the appliance connection and at
the chimney top. Cooler surfaces tend to build creosote
deposits quicker, so it is important to check the
chimney from the top as well as from the bottom.
Formation and Need For Removal:
When wood is burned slowly, it produces tar and other
organic vapors which combine with expelled moisture
to form creosote.
The creosote vapors condense in the relatively cool
chimney ue of a newly-started or a slow-burning re. As
a result, creosote residue accumulates on the ue lining.
When ignited, this creosote creates an extremely hot re
which may damage the chimney or even destroy the house.
The chimney connector and chimney should be inspected
once every 2 months during the heating season to
determine if a creosote or soot buildup has occurred. If
creosote or soot has accumulated, it should be removed to
reduce the risk of a chimney re.
B. General Maintenance
3. Cleaning Plated Surfaces
• Frequency: Prior to rst burn and then as desired
• By: Homeowner
Clean all the ngerprints and oils from plated surfaces
BEFORE ring the appliance for the rst time. If not
cleaned properly before lighting your rst re, the oils can
cause permanent markings on the plating.
After the plating is cured, the oils will not affect the nish
and little maintenance is required. Wipe clean as needed.
2. Disposal of Ashes
• Frequency: When ash is within 44mm of rebox lip
• By: Homeowner
Ashes should be placed in a metal container with a tight
tting lid. The closed container of ashes should be placed
on a non-combustible oor or on the ground, well away
from all combustible materials, pending nal disposal. If the
ashes are disposed of by burial in soil or otherwise locally
dispersed, they should be retained in the closed container
until all cinders have thoroughly cooled.
Fire Risk.
Disposal of Ashes
• Ashes should be placed in metal
container with tight tting lid.
• Do not place metal container on
combustible surface.
• Ashes should be retained in closed
container until all cinders have
thoroughly cooled.
WARNING
Fire Risk.
• Do not use chimney cleaners or ame
colorants in your appliance. Will corrode
chimney pipe.
WARNING
WARNING
Fire Risk.
Prevent creosote buildup.
• Inspect chimney connector and
chimney once every two months during
heating season.
• Remove creosote to reduce risk of
chimney re.
• Ignited creosote is extremely HOT.
CAUTION
• Do not use polishes with abrasives. It will scratch
plated surfaces.

18 7033-362C 11/21
4. Glass Cleaning
• Frequency: As desired
• By: Homeowner
Clean glass with a non-abrasive glass cleaner. Abrasive
cleaners may scratch and cause glass to crack. If the
deposits on the glass are not very heavy, normal glass
cleaners work well. Heavier deposits may be removed by
using a damp cloth dipped in wood ashes or by using a
commercially available oven cleaner.
After using an oven cleaner, it is advisable to remove any
residue with a glass cleaner or soap and water. Oven
cleaner left on during the next ring can permanently stain
the glass and damage the nish on metal surfaces.
A portion of the combustion air entering the rebox is
deected down over the inside of the door glass. This
air ow “washes” the glass, helping to keep smoke from
adhering to its surface.
When operated at a low burn rate, less air will be owing
over the glass and the smokey, relatively cool condition of a
low re will cause the glass to become coated.
Operating the appliance with the Burn Rate Air Control and
Start-Up Air Control all the way open for 30-45 minutes
should remove the built up coating.
CAUTION
• Do not use polishes with abrasives. It will scratch
plated surfaces.

19 7033-362C 11/21
With proper installation, operation, and maintenance your wood appliance will provide years of trouble-free service. If
you do experience a problem, this troubleshooting guide will assist you or a qualied service person in the diagnosis of a
problem and the corrective action to be taken.
Start Fire Problems Possible Cause Solution
Can not get re started
Excessive smoke or spillage
Burns too slowly
Not enough heat output
Not enough kindling/paper or
no kindling/paper
Use dry kindling, more paper. Arrange kindling &
wood for air movement.
Not enough air for re to ignite
Check for restricted termination cap
Check for blockage of outside air kit (if installed).
Check for ue blockage.
Warm ue before starting re (refer to Building a
Fire Section).
Check for adequate vent height (refer to Chimney
Height Section).
Open window below the appliance towards the
wind.
Wood condition is too wet, too
large
Use dry, seasoned wood (refer to Seasoned Wood
Section).
Bed of coals not established
before adding wood
Start with paper & kindling to establish bed of coals
(refer to Building a Fire Section).
Flue blockage such as birds’
nests or leaves in termination
cap
Have chimney inspected for creosote and cleaned
by a certied chimney sweep.
Down draft or negative
pressure
Competition with exhaust
devices
Do not use exhaust fans during start-up (refer to
Negative Pressure Section).
Open window below the appliance towards the
wind.
Fire burns too fast
Extremely dry or soft wood
Mix in hardwood.
Mix in less seasoned wood after re is established
(refer to Wood Fuel Section).
Over drafting
Check for correct vent height; too much vertical
height creates over drafting.
Check location of vent termination (refer to
Chimney Termination Requirement Section).
4 Troubleshooting Guide
Table 19.1

20 7033-362C 11/21
A. Glass
(Replace with 5mm ceramic glass only)
1. Ensure that the re is out and the appliance is cool to
the touch.
2. Protect a table or counter top with padding or towels.
Protect your hands and wear gloves to prevent injury.
3. Remove the door with the broken glass by lifting the
door up and off of the hinges.
4. Lay door face down on a table or counter making sure
the handle hangs over the edge so the door lays at,
on a soft surface.
5. Remove the screws from each glass retainer and
remove the glass. (If screws are difcult to remove,
soak with penetrating oil rst).
6. Center the glass with edges evenly overlapping the
opening in the door, (i.e. same space top and bottom,
left and right sides).
7. Replace the glass retainers. Be careful not to cross
thread the screws.
8. Tighten each retainer just a few turns until each is
secured. Check again for centering of glass in door
frame. Continue to tighten each retainer alternately, a
few turns at a time, until the glass is secure.
NOTE: DO NOT OVER TIGHTEN - can cause glass
to break.
9. Replace the door on the appliance.
Quadra-Fire appliances are equipped with ceramic super
heat-resistant glass, which can only be broken by impact
or misuse.
Figure 20.1
C. Door Handle Assembly
1. Slide door handle through door.
2. Install additional washer(s) as shown in Figure 20.1
3. Install key in groove.
4. Align groove in latch cam with key; slide latch cam
over shaft
5. Install locknut but do not over tighten, the handle needs
to rotate smoothly.
6. Install ber handle (Figure 20.1).
Locknut
Latch Cam
Spacing
Washers
Door Cross Section
(example)
Door Handle
Fiber Handle
Square
Key
B. Firebrick Replacement
Replace the rebrick if they become crumbly and/or if there
is a 6.35mm gap between the bricks.
Inspect the rebrick after each ash removal.
The rebox is lined with high quality rebrick, which has
exceptional insulating properties. There is no need to use a
grate; simply build a re on the rebox oor. Do not operate
appliance without rebrick.
1. After the coals have completely cooled, remove all old
brick and ash from appliance and vacuum rebox.
2. Remove new brick set from box and lay out to
diagram shown.
3. Lay bottom bricks in appliance.
4. Install rear bricks on the top of the bottom bricks. Slide
top of bricks under clip on back of rebox wall and
push bottom of brick back.
5. Install side bricks. Slide top of brick under clips on side
of rebox and push the bottom of the brick until it is
ush with the side of the appliance.
WARNING
Injury Risk.
• Use only glass specied in manual.
• DO NOT REPLACE with any
other material.
CAUTION!
Do not over tighten lock nut. The door handle needs to
move smoothly.
Handle glass assembly with care.
When cleaning glass:
• Avoid striking, scratching or slamming glass.
• Do NOT clean glass when hot.
• Do NOT use abrasive cleaners.
• Use a hard water deposit glass cleaner on white lm.
• Use commercial oven cleaner on heavier deposits.
• Remove all residue of oven cleaner or will
permanently stain glass on next ring. Refer to
maintenance instructions.
Glass
Assembly
CAUTION!
5 Service Part Replacement
