Qvis APOLLO PRO DC LX User manual

APOLLO PRO DC LX
2 U
8 - 16 Channel
DVR
User’s Manual
®

DONT SETTLE FOR LESS,
ALL OUR PRODUCTS CARRY LOGOS
ENHANCE YOUR DVR WITH OUR WIDE
RANGE OF CAMERAS
OUR PRODUCTS ARE FULLY
TESTED TO WORK TOGETHER
EYEBALL DOMES VANDAL DOMES P400 CAMERAS
PTZ CAMERAS INTERNAL DOMES MINI CAMERAS

3
Directory
1 Welcome ...................................................................................... 5
2 Open-package check and cable connections ....................................6
2.1 Initial check ............................................................6
2.2 Hard disk installation ...........................................................6
2.3 Rack mount .........................................................................7
2.4 Front panel .........................................................................7
2.5 Rear panel ..........................................................................8
2.6 Audio and video input and output connections ........................9
2.6.1 Video input connections ..................................................9
2.6.2 Video output connections and options ...............................9
2.6.3 Audio signal input ........................................................9
2.6.4 Audio signal output .......................................................10
2.7 Alarm Input & output connections ......................................10
  2.7.1Alarminputportspecications .......................................11
  2.7.2Alarmoutputportspecications ...............................11
2.7.3 Alarm output port relay perameters .................................12
2.8 Speed dome connections ....................................................12
3 Basic operation ............................................................................13
3.1 Turn on ............................................................................13
3.2 Turn off ............................................................................13
3.3 System Login ....................................................................13
3.4 Preview ............................................................................14
3.5 Desktop shortcut menu ......................................................14
3.5.1 Main menu ..................................................................15
3.5.2 Playback .....................................................................16
3.5.3 Record Mode ...............................................................18
3.5.4 Alarm output ................................................................19
3.5.5 PTZ control ..................................................................19
3.5.6 Color setting .................................................................23
3.5.7 Output adjust ................................................................24
3.5.8 Logout .........................................................................24
3.5.9 Window switch .............................................................24
4 Main menu .................................................................................25
4.1 Main menu navigation ........................................................25
4.2 Record .............................................................................26
  4.2.1RecordCong ..............................................................26 
4.2.2 Playback ......................................................................27
4.2.3 Snapshot storeage .........................................................27
4.2.4 Backup ........................................................................28
4.3 Alarm ...............................................................................29
4.3.1 Motion Detect ..............................................................29
4.3.2 Video Blind ...................................................................31
4.3.3 Video Loss ....................................................................31
4.3.4 Alarm input ....................................................................32
4.3.5 Alarm output ...............................................................32
4.3.6 Abnormal .....................................................................32

4
4.4 System .............................................................................33
4.4.1 General ........................................................................33
4.4.2 Encode .........................................................................34
4.4.3 Network ......................................................................35
4.4.4 NetSevice ...................................................................35
4.4.5 GUI Display .................................................................41
4.4.6 PTZ .............................................................................42
4.4.7 RS232 set up ................................................................42
4.4.8 Tour setup .....................................................................43
4.5 Advanced ..........................................................................43
4.5.1 HDD Manage ...............................................................43
4.5.2 Account .......................................................................44
4.5.3 Online user ...................................................................46
4.5.4 TV adjustment ..............................................................46
4.5.5 Auto maintain ..............................................................46
4.5.6 Restore .......................................................................46
4.5.7 Upgrade ......................................................................47
4.5.8 Device Info ...................................................................47
4.6 Info ..................................................................................47
4.6.1 HDD info ....................................................................47
4.6.2 BPS ............................................................................48
4.6.3 Log .............................................................................48
4.6.4 Version ........................................................................49
4.7 Shut down system .............................................................49
5 FAQ and maintenance ..................................................................50
5.1 FAQ .................................................................................50
5.2 Maintenance .....................................................................54
Appendix 1.Remote controller operation .............................................55
Appendix 2.Mouse operation ............................................................55
Appendix 3.Technique parameters ......................................................56

5
1. Welcome
Thank you for purchasing our DVR!
This manual is designed to be a reference tool for the installation and operation
of your Qvis DVR series DVR system.
YouwillndinformationaboutthisQvisDVRseriesDVR'sfeaturesandfunctions,
as well as a detailed menu tree.
Before you begin installation and operation please read the following safeguards
and warnings carefully!
Important Safeguards and Warnings
Do not place heavy objects on the DVR.
PleaseensurenosolidorliquidfallintoorinltratetheDVR.
Pleasebrushprinted circuit boards, connectors, fans,machineboxand so on
regularly.
Beforecleaninghowever,pleaseswitchoffthepowersupplyandunplugitfrom
the mains.
Do not attempt to disassemble or repair the DVR by yourself. Do not attempt to
replace any components by yourself.
Environment
Please position and use the DVR in a dry environment between 0oand 40o.
Do not position or use in direct sunlight or near a heat source..
DonotinstalltheDVRindamp,smokyordustyenvironment.
Avoid shocks or physical damage to the DVR.
Please insure the DVR is level and in a stable workplace.
Please install in a well ventilated environment. Keep the vents clean.
Use within the rating input and output scope.

6
2 Initial check and cable connections
2.1 Initial check
WhenyourstreceiveyourDVR,pleasecheckthefollowing:
1. Please check whether there is any visible damage to the package
appearance. The protective materials used for the package of the DVR can
protect the DVR against most accidental damage during transportation.
2. Pleaseopentheboxandgetridofftheplasticprotectivematerials.Check
whether there is any visible damage to the DVR itself.
3. Pleaseopenthemachinecrustandcheckthedatawireinthefrontpanel,
power wire and the connection between the fan power and the main board.
Front and rear panel
l Thekeyfunctionsonthefrontpanelandtheinterfacespecicationforthe
 realpanelareinthespecication.
lPlease check the product type described on the front panel whether is the
product type you ordered.
The label on the real panel is very important for after sales service. Please
protectitcarefully.Ifyouhavetocontactusforaftersalesservice,please
provide the product type and serial number from this label.
2.2 Hard disk installation
BeforeyourstusetheDVR,pleaseinstalltheharddiskasfollows:-
1). Undo the side screws 2). Lift off the cover
3). Screw on the hard disk 4). Screw on the hard disk

7
5). Connect SATA data wire 6). Connect the power wire
7). Put the top back on 8). Screw on the cover
2.3 Rack mount installation
ThisseriesofDVRisinastandard2Ucase,soitcanberackmounted.
Step:
1. Make sure the room temperature is lower than 35°C (95°f)
2.Keepatleast15cmspacearoundtheDVRtoallowairtoow
3. Installation is from bottom to top
2.4 Front panel (may vary on some models)
(1) Direction/OK (2) Play Pause/1 (3)Previousle/2 (4) Nextle/3
(5) Playback Pause/4 (6) Indication light (7) Playback Stop / 5 (8) IR remote receiver
(9) Record search/ 6 (A) Alarm Output / 7 (B) Assistant (C) Zoom out/8
(D) Zoom in/9 (E) Preset point setup/0 (F) USB (G) ESC
(H) ScreenSwitch (I) Record (J) PTZ (K) MainMenu
(L) Shift (M) Power switch

8
Front panel function table
Serial NO Key Mark Function
1 Direction  IntheMenu,pressupordowntomoveCursor
ChangecongurationintheDrop-downmenu
Pressupordowntoselectrecordleintheplayback
status
InthePreviewscreen,pressupordowntogointo
1/4/8/9/16 multiple channels screen
 IntheMenu,pressleftorrighttomoveCursor
Intheplaybackstatus,pressleftorrighttomovecursorof
function button
Enter OK Enter
Enter into MainMenu
2 Play/Pause 
II Play or Pause when playback
5 Playback
Pause/4 IIReverse the playback
Press shift to No. 4 channel preview Or input number 2
11 Assistant FN Switch input method.
Go into assistant menu when preview
14 Preset
point/0
PRESET/0 Go into Preset point menu
Press shift to No. 0 channel preview
16 ESC ESC Back to up window or cancel operation
Back to monitor screen when playback
21 Shift SHIFT Switch some buttons function
22 Power
switch
Power off / on
2.5 Rear panel
I

9
2.6 Audio and video input and output connections
2.6.1 Video input connections
The video input port is a BNC connector plug. The type of input signal is PAL/
NTSCBNC(1.0VP-P,75Ω).
The video signal must be of the correct standard and have a high signal to noise
ratio,lowaberration andlowinterference.Theimagemustbeclear and have
natural color and brightness in the environment in which it is to operate.
Insure the monitor signal is stable and credible
The monitor should be installed in a suitable location where is away from
backlighting and low illumination or uses backlighting and low illumination
compensation.
The earth and power supply of the monitor and the DVR should be shared and
stable.
Insure the transmission line is stable
Thevideotransmissionlineshouldbeahighqualitycoaxialpairwhichissuitable
forthetransmissiondistance.Ifthetransmissiondistanceistoogreat,youshould
use shielded twisted pair, video compensation equipment or transmit by ber
optics to insure the signal quality.
The video signal line should be away from all electro magnetic Interference and
other signal line equipment. High voltage current should be especially avoided.
Insure the connection is stable
The signal and shield lines should be connected with a tight connection which
willhelpavoidfalsesignals,jointweldingandoxidation.
2.6.2 Video output connections and options
ThevideooutputisdividedintoPAL/NTSCBNC(1.0VP-P,75Ω)andVGAoutput
(selectiveconguration).
IfyoureplaceyourQvismonitorwithacomputerdisplay,therearesomeissues
to take note of.
1). Do not leave the display turned on for a long time.
2). To ensure normal working demagnetize regularly.
3). Keep the display away from electro magnetic Interference.
A TV is not a suitable replacement for a video output. It can only be used for a
short period of time and is particuarly suseptabler to nearby interferance. The TV
can also damage other equipment.
2.6.3 Audio signal input
The audio port is a BNC connection.
Astheinputimpedanceishigh,thetonearmmustbeactive.
The audio signal line should be strong and away from any electro magnetic
Interference and with a credible connection which should avoid false signals and
jointweldingandoxidation.Highvoltagecurrentshouldbeespeciallyavoided.

10
2.6.4 Audio signal output
Commonly the output parameter of a DVR audio signal is greater than 200mv
1KΩ(BNC)whichcanconnectalowimpedanceearphoneandactivesoundbox
orotheraudiooutputequipmentsthroughapoweramplier.Ifthesoundboxand
thetonearmcan notbeisolated,ahowlingphenomenaisoftenexperienced.
Here are some methods to deal with this phenomena.
1). Adopt a better directional tone arm.
2).Adjustthesoundboxvolumetobelowthethresholdthatproducesthe
howling phenomena.
3).Usetmentmaterialsthatabsorbthesoundtoreducethereectionofthe
sound.
4).Adjustthelayoutofthesoundboxandthetonearm.
2.7 Alarm input and output connections
1. Alarm input
A. Alarm input is grounding alarm input.
B. Alarm input demand is the grounding voltage signal.
C. When the alarm is connected with two DVRs or connected with DVR
  andotherequipments,itshouldbeisolatedbyrelay.
2. Alarm output
 Alarmoutputcannotbeconnectedwithhigh-powerload(nomorethan1A).
When forming the output loop it must prevent the big current from relay damage.
Usethecontactisolatorwhenthereisahigh-powerload
3. PTZ decoder connections
A. The earth for the PTZ decoder and DVR must be shared otherwise
  thecommon-modevoltagewillleadtothePTZcontrolfailure.Shielded
twisted pair is recommended.
B. Avoid high voltage. Take precaution against the thunder and lightning.
 C.Attheoutlyingendconnectaparallel120Ωresistancetoensurethe
signal quality.
D. The 485 AB lines of the DVR can not connected with other 485 output
equipment in parallel.
E. The voltage between the AB lines of the decoder must be less than 5V.
4. Front equipment earthing note
Bad earthing can lead to burnout of the chip.
5. Alarm input type unlimited
The DVR alarm output port is constant opening type.

11
(1,6,8)alarminput(2,7)grounding(3)Alarm(5)RS485(4)RS232
Parameter Meaning
G grounding (earth)
C1,NO1 Alarm output interface(constant open type)
T,R RS232 port
A,B 485 communication interface which is connected with the recording
control equipments such as the decoder
2.7.1 Alarm input port specication
1 channels alarm input. Alarm input type unlimited.
The earth and the com port of the alarm sensor are parallel (The alarm sensor
hasanexternalpowersupply).
The earth of the alarm and the DVR should be shared.
The NC port of the alarm sensor must be connected with the DVR alarm input
port.
The earth of the power supply and the alarm sensor must be shared when used
inanexternalpowersupply.
2.7.2 Alarm output port specication
1 channels alarm output. There is an external power supply when using the
externalalarmequipment.
Please refer to the relevant relay parameters to avoid overloading that damages
the DVR.

12
2.7.3 Alarm output port relay parameters
Type:JRC-27F
Interface material Silver
Rating
(resistance load)
Rating switch capacity 30VDC2A,125VAC1A
Maximalswitchpower 125VA 160W
Maximalswitchvoltage 250VAC,220VDC
Maximalswitchcurrent 1A
Isolation Homo-polarityinterface 1000VAC 1minute
Inhomo-polarityinterface 1000VAC 1 minute
Interface and winding 1000VAC 1 minute
Surge voltage Homo-polarity 1500VAC (10×160us)
Turn-ontime 3msmax
Turn-offtime 3msmax
longevity Mechanical 50×106 MIN (3Hz)
Electric 200×103 MIN (0.5Hz)
Environment temperature -40~+70oC
2.8 Speed dome connections
1. Connect the 485 lines of the speed dome with the DVR 485 interface.
2. Connect the video line with the DVR video input.
3. Connect the speed dome to a power supply.
Note: The speed dome A, B port and the DVR A, B port should be a corresponding
connection, A is +, B is -

13
3 Basic operation
Note: The button in gray display indicates nonsupport.
3.1 Turn on
Plug in and turn on the power supply switch. If the Power supply indicator light
lights up then the video recorder has turned on. After startup you will hear a
beep. The default setting of the video output is a multiple-window output
mode.Ifthestartuptimeiswithinasetvideorecordingtime,thetimingvideo
recording function will start up automatically. Then the video indicator light of the
corresponding channel will light up to let you know the DVR is working normally.
Note:
1). Make sure that the input voltage corresponds with the switch of the DVR
power supply.
2).Powersupplydemands:220V±10%/50Hz.
We suggest using UPS to protect the power supply under suitable conditions.
3.2 Turn off
There are two methods to turn off the DVR. Entering [main menu] and choosing
[turn off] in the [turn off the system] option is called soft switch. Pressing the
power supply switch is called hard switch.
Illumination:
1). Auto resume after power failure
If the DVR is shut down abnormally, it can automatically backup video and
resume the previous working status after a power failure.
2). Replace the hard disk
Beforereplacingtheharddisk,thepowersupplyswitchintherearpanelmust
be turned off.
3). Replace the battery
Beforereplacingthebattery,thesettinginformationmustbesavedandthepower
supply switch in the rear panel must be turned off. The DVR uses a button
battery. The system time must be checked regularly. If the time is not correct you
mustreplacethebattery,werecommendreplacingthebatteryeveryyearand
using the same battery type.
Note: The setting information must be saved before replacing the battery
otherwise information will be lost.
3.3 System Login
When the DVR boots up, the user must login and the system provides the
corresponding functions in the user preview. There are three user settings. The
names are admin,guest and default and these names have no password. Admin
is the super user preview; guest and default’s permissions are preview and video
playback.
User admin and guest’spasswordcanberevised,whiletheirpermissionscan’t
be revised; user default is the default login user whose permission can be revised
but not its password.

14
Picture 3.1 System Login
Password protection: If the password is entered continuously wrong for three
times, the alarm will start. If the password is continuously wrong ve times, the
account will be locked. (Through a reboot or after half an hour, the account can
be unlocked automatically).
For your system security, please modify your password after rst login.
3.4 Preview
You can right click mouse to choose the switch between the windows.
Thesystemdate,timeandchannelnameareshownineachviewingwindow.
The surveillance video and the alarm status are shown in each window.
1 Recording status 3 Video loss
2 Motion detect 4 Camera lock
Table 3.1 Preview icon
3.5 Desktop shortcut menu
In preview mode you can right click your mouse to get a desktop shortcut
menu.The menu includes: main menu, record mode, playback, PTZ control,
High Speed PTZ, Alarm Output, Color Setting, Output adjust, Logout, View
1/4/8/9/16 screens.

15
Picture 3.2 Shortcut Menu
3.5.1 Main menu
Whenyoulogin,thesystemmainmenuisshownasbelow.
Picture 3.3 Main Menu

16
3.5.2 Playback
Therearetwomethodsforyoutoplaythevideolesintheharddisk.
1). In the desktop shortcut menu.
2).Mainmenu>Record->Playback
Note: The hard disk that saves the video les must be set as read-write or read-
only state. (4.5.1)
Picture 3.4 video playback
1).Listedles 2). File information 3). File searching
4). File backup 5). Operation hint 6). Playback control
(Listed les)Lookupthelistedlesthataccordwiththesearchingcriteria.
(File information)Lookupthefoundleinformation.
(File backup)Backupthechosenle.Clickthebuttonandoperateasfollowed.
Note: The storage must be installed before the le backup. If the backup is
terminated,thelesalreadybackedupcanplaybackindividually.
Picture 3.5 detect the storage

17
Detect: Detect the storage connected with the DVR such as hard disk or universal disk.
Erasure:Choosetheletodeleteandclickerasuretodeletethele.
Stop: Stop the backup.
Backup:Clickbackupbuttonandthedialogboxispoppedup.Youcanchoose
thebackupleaccordingtothetype,channelandtime.
Picture 3.6 recording backup
Remove:Cleartheleinformation.
Add:Showtheleinformationsatisfyingthesetleattributes.
Start/Pause:Clicktheplaybuttontostartthebackupandclickthepausebutton
to stop the backup.
Cancel:Duringbackupyoucanexitthepagelayouttocarryoutotherfunctions.
(File searching)Searchtheleaccordingtothesearchingparameter.
Picture3.7lesearching
File type:Setthesearchingletype.
Channel:Setthesearchingchannel.
Start Time:Setthesearchingtimescan.
End Time:Settheendtimeofthelesearch
Play Mode:Selectdifferentplaymode,SkipDecode,AverageDecodeandFullDecode.
Sync Mode: Select it for playback all chosen channels at the same time
(Playback control) Refer to the following sheet for more information.

18
Button Function Button Function
/ Play/pause Backward
Stop Slow play
Fast play Previous frame
Nextframe Previousle
Nextle Circulation
Full screen
Table 3.2 Playback control key
Note: Frame by frame playback is only performed in the pause playback state.
(Operation hint) Display the function of the cursor place.
Special functions:
Accurate playback:Inputtime(h/m/s)inthetimecolumnandthenclickthe
play button. The system can operate accurate playback according to the
searching time.
Local zoom:Whenthesystem isinsingle-window full-screenplaybackmode,
you can drag your mouse in the screen to select a section and then left click your
mousetoviewthisinlocalzoom.Youcanrightclickyourmousetoexit.
3.5.3 Record Mode
Pleasecheckthecurrentchannelstatus:“”meansitisnotinrecordingmode,
“l” means it is in recording mode.
You can use the desktop shortcut menu or click [main menu]> [recording
function]> [recording set] to enter the recording control interface.
Picture 3.8 Record Mode
Schedule:Recordaccordingtotheconguration.
Manual:Clicktheallbuttonandtheaccordingchannelisrecordingnomatterthe
channel in any state.
Stop:Clickthestopbuttonandtheaccordingchannelstopsrecordingnomatter
the channel in any state.

19
3.5.4 Alarm output
Pleasecheckcurrentchannelstatus:“o”meansitisnotinalarmingstatus,“•”
means it is in alarming status.
You can use desktop shortcut menu or click [main menu]> [alarm function]>
[alarm output] to enter the alarm output interface.
Picture 3.9 alarm output
(Conguration)Alarmisonaccordingtotheconguration.
(Manual) Click the all button and the according channel is alarming no matter
the channel in any state.
(Stop) Click the stop button and the according channel stops alarming no matter
the channel in any state.
3.5.5 PTZ control
ThePTZOperationinterfaceisasfollowed.Thefunctionsinclude:PTZdirection
control,step,zoom,focus,iris,setupoperation,patrolbetweenspots,trailpatrol,
boundaryscan,assistantswitch,lightswitch,levelrotationandsoon.
Note:
1). Decoder A(B) line connects with the DVR A (B) line. The connection is right.
2).Click[mainmenu]>[systemconguration]>[PTZsetup]tosetthePTZparameters.
3). The PTZ functions are decided by the PTZ protocols.
Picture 3.10 PTZ setup

20
Speed:SetthePTZrotationrange.Defaultrange:1~8.
Zoom:Click/buttontoadjustthezoommultipleofthecamera.
Focus:Click/buttontoadjustthefocusofthecamera.
Iris:Click/buttontoadjusttheirisofthecamera.
Direction control:ControlthePTZrotation.8directionscontrolissupportive.
(4 directions in Front panel is supported )
High speed PTZ:Full-screenshowschannelimage.Leftmouseclicktocontrol
the PTZ rotation and orientation. Left click mouse and then rotate the mouse to
adjust the zoom multiple of the camera.
Set:Entersthefunctionoperationmenu.
Page switch:Switchsbetweendifferentpages.
Special functions:
1). Preset
Tosetapresetlocation,callupthepresetpointsandthePTZwillautomatically
turn to the setting position
1). Preset option
Tosetalocationforthepreset,theprocedureisasfollows:
Step 1: InPicture3.10,usethedirectionbuttontoturnthePTZtothepreset
  position,clicktheSettingsbuttontoenterPicture3.11.
Step 2: Clickonthepresetbuttonandthenenterthepresetpointnumberin
  thepresetbox(shows0inboxbelow),
Step 3: ClicktheSetbuttontoreturntoPicture3.10tocompletethesetup,
check that the preset points and preset position corresponds.
Clear Preset:Inputpresetpoints,clickRemovebuttontoremoveapreset.
Picture 3.11 Preset Settings
2). To go to a Preset Point
InPicture3.10,clickPageSwitchbutton,enterPTZcontrolinterfaceasshownin
Picture3.12.IntheinputNo,typethepresetpoint,thenclickthepresetbutton,
the PTZ will turn to the corresponding preset point.
Preset Button Preset point
input blank
