Technical Note TN-136 06/10/TM
RAE Systems by Honeywell 877-723-2878 raesystems.com 1
ULTRARAE AND ULTRARAE 3000 OPERATION TIPS
This document describes several helpful tips for operating the
UltraRAE and UltraRAE 3000.
SAMPLING WITH THE ULTRARAE
How To Make An Airtight Seal For The Inlet
Probe
When inserting a RAE-Sep tube into the inlet adapter,
push the tube into the rubber gasket until you feel
that the tube is properly sealed. Next screw on
the tube holder cap to seal the other end of the
RAE-Sep tube. Then simultaneously twist and
push down on the tube cap nut to ensure that the
rubber adapters inside the tube holder form good
seals against both ends of the RAE-Sep tube.
How To Select The Tube Name
1. Remove the tube from the inlet. Press [Y/+]
while the UltraRAE displays the “Ready...” message.
2. The display should show “No Tube” and
“Manual select?” press [Y/+].
3. The display should show a tube name, such as
“Benzene?” Press [N/-] if you want to change the
tube name. Press [Y/+] to accept the tube name.
4. The display should show the selected tube name and “Start?”
message alternately. Press [Y/+] to start the testing.
What To Do If The Tube Reader Shows “Invalid Lamp For ....
Xxxx Tube”
This message means that the UV lamp installed inside the unit
does not work with the given tube. The correct UV lamp information
(9.8 eV, 10.6 eV or 11.7 eV) is printed on the label of the tube box.
After installing the correct lamp, the user also needs to change the
monitor setup because the unit will not recognize the lamp type
automatically:
1. Press both the [N/-] and [MODE] keys together for 3
seconds, the display shows the first programming mode
menu: “Calibrate Monitor?” Press [N/-] four times.
2. The display should show “Change Monitor?” Press the [Y/+] key.
3. The display should show “Change Measure
Wait Time?” Press the [N/-] key.
4. The display should show “Change lamp?” Press the [Y/+] key.
5. The display should show “Lamp = xxxx eV?” where
“xxxx” is the current UV lamp selection.
6. Press the [N/-] key until the correct UV lamp type is
displayed. Then press [Y/+] key to accept the correct UV
lamp. Press the [Y/+] key again to confirm the change.
7. Press the [MODE] key twice to return to normal display
with “Ready...” message. The unit is now ready to
accept the tube with the newly installed UV lamp.
Note About Multiple-Tube Operation
When using different types of RAE-Sep tubes in the UltraRAE, it
is very important to calibrate each type of tube before using the
monitor. Thereafter, simply insert the tube into the inlet adapter, and
the tube reader will recognize the tube name and use the proper
calibration data to perform the gas measurement. If there are
more than eight different types of tubes available, the PC program
(ProRAE Suite) must be used to select eight tubes and download
the tube data to the monitor. See the Operation and Maintenance
Manual for details on the download procedure.
SAMPLING WITH THE ULTRARAE 3000
Before performing a compound-specific measurement for
Benzene or Butadiene using a RAE-Sep separation tube,
make sure the UltraRAE 3000 is in Tube Mode and that the
appropriate tube type is selected. The UltraRAE 3000 only
acts as a compound-specific measurement device when
it is equipped with a 9.8eV lamp. Therefore, make sure
the UltraRAE 3000 is equipped with a 9.8eV lamp and
manually set to use it whenever it is to be used for
compound-specific sampling such as for benzene.
Make sure the UltraRAE 3000 is set to operate with
your selected tube:
1. Enter Programming Mode.
2. Select Measurement.
3. Select Tube Selection.
4. Make a choice of Benzene or Butadiene.
5. Save your choice.

Technical Note TN-136 06/10/TM
RAE Systems by Honeywell 877-723-2878 raesystems.com 2
To begin measuring, turn on the UltraRAE 3000. This screen is
shown, which includes the CF (correction factor) and measurement
gas type (benzene, butadiene, etc.) for calibration reference:
Press [N/-] to advance. You will see this screen:
Do not begin sampling yet!
Before you start sampling, you must insert a RAE-Sep separation
tube into the inlet/holder. Follow the Separation Tube Preparation
and Placing A Tube Into The UltraRAE 3000 instructions before
pressing any buttons on the UltraRAE 3000. Once the tube is in
place, then proceed to measuring.
IMPORTANT! Once a tube’s ends are broken off, the material
inside is exposed. Therefore, use the tube for sampling as soon as
possible.
Separation Tube Preparation
CAUTION! Wear hand and eye protection when breaking tube tips.
Use caution in handling tubes with broken ends. Keep away from
children. RAE-Sep tubes should be disposed of according to local
regulations. See footnotes of data sheets for disposal information.
1. Open a package of RAE-Sep separation tubes and remove one.
2. Place the tip in the package’s tube tip breaker (the
small hole on the front) and snap off the tip.
3. Turn the tube around and snap off the other end.
CAUTION! Handle tubes with care. Tube ends are sharp after ends
are broken off.
Inserting The Separation Tube
1. Unscrew the front of the sampling probe from the base.
2. Slip the tube into the rubber holder in the front portion.
3. Insert the other end of the tube into the middle of the base while
turning the front portion to tighten it onto the base’s threads.
IMPORTANT! Do not overtighten any portion of the sampling
assembly.
MEASURING
WARNING! If a 15-minute test is performed and less than 1/4 of
the tube is not yellow-orange at the bottom, retest with a new tube
for 1 minute. If at least 1/4 of the tube is not yellow-orange at the
bottom, the test should not be considered valid, and VOCs may be
dangerously high.

Technical Note TN-136 06/10/TM
RAE Systems by Honeywell 877-723-2878 raesystems.com 3
Once the tube is in place, begin measuring by pressing [Y/+].
The display shows a countdown (60 seconds is shown here, but
sampling time depends on the type of separation tube selected and
the temperature):
Note: You can abort the sampling by pressing [N/-] at any time.
Once the countdown is complete, the reading is shown:
Press [Y/+] to continue sampling with the tube for 15 minutes to
establish a STEL reading, or press [N/-] to return to the main menu.
WARNING! At least 1/4 of the tube should still be yellow-
orange at the bottom. If not, the STEL value is not valid. Abort the
measurement and change the tube. Then do a snapshot test instead
of a STEL test. Note: If the STEL is exceeded, the UltraRAE 3000
goes into alarm.
If you press [N/-] to return to the main menu, which shows the tube
type instead of the CF (correction factor):
Press [N/-] to advance to this screen:
If you press [Y/+], you are asked, “Clear peak value! Are You Sure?”
to confirm:
Press [Y/+] to clear the Peak value and exit to VOC operation.
If you press [N/-], this display is shown:
Remove the tube and put the inlet back together. Then press [N/-].
This display is shown:
After a few seconds, the UltraRAE 3000 enters VOC mode and
shows this display:
You can step through the rest of the steps by pressing [N/-]
repeatedly until you reach the main menu again.
