Rage Micro VINTAGE STICK User manual

Specifications
Wingspan: 16-5/8" (422.3mm)
Length: 14-3/4" (374.7mm)
Flying Weight: 1 oz. (28g)
Baery: 3.7V 1S 150mAh LiPo
Motor: Brushed w/Gearbox
On-Board Electronics: 4-in-1 Receiver (2 Servos/ESC)
Wing Area: 75 sq.in. (4.84 dm/sq)
Transmier: 4-Channel 2.4GHz w/Integrated LiPo Charger
Versatile and Nostalgic Flying Fun

2
Micro Vintage Stick Story
The Rage R/C ™ Micro Vintage Sck takes a step backwards in me to a nostalgic look that
evokes memories of yesteryear, but with modern carbon ber materials and updated radio
technologies like 2.4GHz. This classic-appearing aircra is not only a great way to build R/C
pilong skills, but also an enjoyable model for experienced R/C enthusiasts to y in compact
areas. The Micro Vintage Sck is produced with simple and durable construcon techniques –
such as the carbon ber “sck” airframe and foam ying surfaces. The featherweight
(24g without baery) construcon and high-capacity ight baery combine to deliver adequate
power for aerobacs like loops, spins, and barrel rolls or extended ight mes when enjoying
more relaxed ight maneuvers.
The Micro Vintage Sck features a factory-applied vintage WWI-style trim scheme with
everything required to y in the box; including a 2.4GHz 4-channel capable transmier that also
doubles as a charger for the 3.7V 150mAh LiPo ight baery and integral control board with
ESC and servos. The only addional items required are four AA baeries for the transmier and
you can enjoy ying a classic aircra from a bygone era at your local park or gymnasium within
minutes of opening the box!
Table of Contents
Specicaons 1
Table of Contents 2
General Precauons 2
Micro Vintage Sck Story 3
Safety Precauons 3
LiPo Baery Warning 3
Micro Vintage Sck RTF Contents 4
FCC Informaon 4
Charging LiPo Baery 5
Baery Install 5
Center of Gravity 5
Transmier Details 6
Servo Reversing 6
Control Movement 7
Binding/Arming 8
Prop Replacement 8
First Flight 8
Parts List 9
Notes/Flight Log 9
Limited Warranty 10

3
IMPORTANT NOTE: Lithium Polymer baeries are signicantly more volale than the
alkaline, NiCd or NiMH baeries also used in RC applicaons. All instrucons and
warnings must be followed exactly to prevent property damage and/or personal injury
as mishandling of LiPo baeries can result in re. By handling, charging or using the
included LiPo baery you assume all risks associated with LiPo baeries. If you do
not agree with these condions please return the complete product in new, unused
condion to the place of purchase immediately.
LiPo Battery Warning
Safety Precautions
Failure to use this product in the intended manner as described in the following instrucon can
result in damage and/or personal injury. A Radio Controlled (RC) airplane/helicopter/quadcopter
is not a toy! If misused, it can cause serious bodily harm and damage to property.
Keep items that could become entangled away from the propeller, including loose clothing,
tools, etc. Be especially sure to keep your hands, face and other parts of your body away from
the propeller.
As the user of this product, you are solely and wholly responsible for operang it in a manner
that does not endanger yourself and others or result in damage to the product or the property
of others.
This model is controlled by a radio signal that is subject to possible interference from a variety
of sources outside your control. This interference can cause momentary loss of control so it is
advisable to always keep a safe distance from objects and people in all direcons around your
model as this will help to avoid collisions and/or injury.
• Never operate your model if the transmier baery voltage is too low.
• Always operate your model in an open area away from obstacles, people, vehicles,
buildings, etc.
• Carefully follow the direcons and warnings for this and any oponal support
equipment. (chargers, rechargeable baeries, etc.).
• Keep all chemicals, small parts and all electronic components out of the reach of
children.
• Moisture causes damage to electronic components. Avoid water exposure to all
electronic components, parts, etc. not specically designed and protected for use
in water.
General Precautions

4
This device complies with part 15 of the FCC rules. Operaon is subject to the following two
condions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operaon.
Cauon: Changes or modicaons not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This product contains a radio transmier with wireless technology which has been tested
and found to be compliant with the applicable regulaons governing a radio transmier in
the 2.400GHz to 2.4835GHz frequency range.
The associated regulatory agencies of the following countries recognize the noted
cercaons for this product as authorized for sale and use: USA, UK, AU
Micro Vintage Stick RTF Contents
FCC Information

5
Battery Install
Insert the baery into the baery holder with the
plug end facing the rear of the aircra. Plug the
control board connecon into the baery. Be
careful to maintain the correct polarity. The red dot
on the baery should be on the same side as the
red dot on the plug.
Move charge plug out and close door
maintain correct polarity by aligning the red dots lights during charging. When the light goes out,
charging is complete.
Yellow Charge Light
Charging LiPo Battery
Center of Gravity
With the supplied baery installed in the baery holder, the CG of the Vintage Sck will
automacally be in the correct locaon. If a dierent baery is used or repairs have been made
to the airframe, the CG should be rechecked and weight adjusted to acheive the proper CG.
The Vintage Sck is very tolerant to changes in the CG locaon.

6
Right trim button under left stick.
This button is pressed and held
during all servo reversing steps.
Please Note: This is a step that should not be required. It is included in the event that
a servo has become reversed and needs to be changed. Always check the direcon of
travel of the control surfaces as part of your preight safety check before every ight.
Servo Reversing
PLEASE NOTE: Install 4 AA baeries ( not supplied ) into the baery compartment
located on the back of the transmier, under the baery hatch cover. Make sure
that the baeries are installed with correct polarity per the diagram inside the
baery compartment.
Elevator Trim
Rudder Trim
Charge Indicator Light
Antenna
Flight Battery
Charger Inside
Throttle Stick
Not Used for
This Model
Throttle Trim
Power Switch
Power Light
Rudder/Elevator
Stick
Handle
Transmitter Details
The Micro Vintage Sck transmier features servo reversing on the rudder and elevator
channels. The servo direcon was set correctly at the factory for the model. However, in case
any of the controls are operang in the wrong direcon or you use the electronics in other
models later on, please follow these steps to change the servo direcons as needed. Complete
all steps with the transmier and aircra powered on.
Rudder Channel Servo Reversing
Press and hold the right trim buon under the le sck, then
press the right trim buon under the right sck. Release both
buons and the servo direcon will be reversed. Repeat to
change back.
Elevator Channel Servo Reversing
Press and hold the right trim buon under the le sck, then
press the down elevator (top) trim buon. Release both
buons and the servo direcon will be reversed. Repeat to
change back.

Rudder
Left
Rudder
Right
When the right sck is moved to
the le of the transmier the
rudder should move le. When in
ight this will yaw the tail to the
right (the nose of the aircra will
move to the le).
When the right sck is moved to
the right of the transmier the
rudder should move right. When
in ight this will yaw the tail to the
le (the nose of the aircra will
move to the right).
7
Elevator
Down
Control Movement
With both the transmier and the aircra powered on, check the movement of the control
surfaces.
When the right sck is moved
toward the boom of the
transmier the elevator should
move up. When in ight this will
raise the nose.
When the right sck is moved
toward the top of the
transmier the elevator should
move down. When in ight this
will lower the nose.
Elevator
UP

8
First Flight
The Micro Vintage Sck can be own indoors in a gymnasium or basketball court. Its light weight
and generous wing area allow the aircra to y very slowly at reduced throle sengs. Place
the airplane on the oor and slowly advance the throle, the model will take o within several
feet. Full throle is not required or desired for most indoor ying. The airplane is very nimble,
best results are achieved with small and smooth sck movement.
The Micro Vintage Sck is also fully capable of outdoor ight in light wind condions. These
usually are present early in the day or near sunset. The model has enough power for spirited
ying and loops and rudder rolls are easily achieved. If there isn't a suitable place for ROG
(Rise o Ground) take o, hand launching is very easy to do. Landing is as easy as reducing the
throle and leng the model descend to land. A lile added throle just before touch down
will aid is making the landing smooth.
Binding/Arming
Throttle trim buttons
Binding
The Vintage Sck comes bound to the
transmier. Should you need to re-bind,
follow these steps.
• Turn on both transmier and aircra
• Press both throle trim buons
simultaneously
• The transmier will beep unl binding
is completed automacally
• Rudder and elevator will move briey
• Beeping will stop, binding complete
Arming
When the transmier and airplane are
powered on, the aircra binds automacally
and the tail surfaces move briey. Aer that
all funcons are acve including throle.
Prop Replacement
OFF
Grasp the large gear just behind the
prop. Holding it with your ngers works
well for this. Rotate the prop in the
direcon of normal rotaon to remove.
Reverse the process to install the new
prop.

ItemNumber Description
RGRA1111 VintageStickMicroRTF
RGRA1220 Fuselage;VintageStick
RGRA1221 MainWingw/Support;VintageStick
RGRA1222 TailSet;VintageStick
RGRA1223 DecalSet;VintageStick
RGRA1224 LandingGear;VintageStick
RGRA1225 3-in-1ControlBoard;VintageStick
RGRA1226 2-BladePropeller;VintageStick
RGRA1227 PropShaftw/Gear;VintageStick
RGRA1228 PushRodSet;VintageStick
RGRA1229 Motorw/Gearbox;VintageStick
RGRA1230 1S3.7V70mAh25CLiPoBattery;VintageStick
RGRA1231 4-ChannelTXw/200mACharger;VintageStick
Parts List
See your local hobby shop or place of purchase rst. If unavailable, parts can be ordered direct
at www.ragerc.com or call 1-800-622-7223 M-F 9:00-5:00PM Mountain Time
Notes/Flight Log
9

10
© HRP Distribung, Inc.
Printed in China
Limited Warranty
Warranty Period: Rage R/C warrants that the Micro Vintage Stick (“Product”) will be free from
original factory defects in materials and workmanship upon purchase (“Warranty Period”).
What is Not Covered - This warranty is not transferable and does not cover (a) cosmetic
damage, (b) damage due to acts of God, accident, misuse, abuse, negligence, commercial
use, or due to improper use, installation, operation or maintenance, (c) modication to any
part of the Product, (d) attempted service by anyone other than a Rage R/C authorized
service center, or (e) Product not purchased from an authorized Rage R/C dealer.
OTHER THAN THE EXPRESS WARRANTY ABOVE, RAGE R/C MAKES NO OTHER
WARRANTY OR REPRESENTATION, AND THREFORE DISCLAIMS ANY AND ALL IMPLIED
WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF
NON-INFRINGEMENT, MERCHANTABILITY AND SUITABILITY FOR A PARTICULAR
PURPOSE. THE PURCHASER ACKNOWLEDGES THAT THEY ALONE HAVE
DETERMINED THAT THE PRODUCT WILL MEET THE REQUIREMENTS OF THEIR
INTENDED USE.
Purchaser’s Remedy - Rage R/C’s sole obligation and purchaser’s sole and exclusive remedy
shall be that Rage R/C will, at its option, either (a) service, or (b) replace, any Product
determined by Rage R/C to be defective. Rage R/C reserves the right to inspect any and all
Product(s) involved in a warranty claim. Service or replacement decisions are at the sole
discretion of Rage R/C. Proof of purchase is required for all warranty claims.
SERVICE OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
PURCHASER’S SOLE AND EXCLUSIVE REMEDY.
Limitation of Liability - RAGE R/C SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT,
INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR PRODUCTION
OR COMMERCIAL LOSS IN ANY WAY, REGARDLESS OF WHETHER SUCH CLAIM IS
BASED IN CONTRACT, WARRANTY, TORT, NEGLIGENCE, STRICT LIABILITY OR ANY
OTHER THEORY OF LIABILITY, EVEN IF RAGE R/C HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
Further, in no event shall the liability of Rage R/C exceed the individual price of the Product
on which liability is asserted. As Rage R/C has no control over use, setup, nal assembly,
modication or misuse, no liability shall be assumed nor accepted for any resulting damage or
injury. By the act of use, setup or assembly, the user accepts all resulting liability. If you as the
purchaser or user are not prepared to accept the liability associated with the use of the
Product, purchaser is advised to return the Product immediately in new and unused condition
to the place of purchase.
Law - These terms are governed by Utah law (without regard to conict of law principals).
This warranty gives you specic legal rights, and you may also have other rights which vary
from state to state. Rage R/C reserves the right to change or modify this warranty at any time
without notice.
Rage R/C, an exclusive brand of:
HRP Distributing, Inc.
2034 South 3850 West
Salt Lake City, Utah 84104

11
Look for these other great products from Rage RC at
your local hobby retailer or online at ragerc.com
Model D17 "Staggerwing" RTF
RGRA1105 Super Cub 750 RTF Airplane
Equipped with the PASS (Pilot Assist Stability Software) system,
the Super Cub MX is an ideal airplane for someone who wants
to get started in micro RC ight or an enthusiast who’s looking
for a fun airplane to y in smaller spaces. The 500mm wingspan
also makes it easy to transport to and from favorite ying spaces.
RGRA1109 Beechcraft Model 17 Staggerwing Micro RTF
This ultra-micro sized scale model of the historic Beechcraft
Staggerwing 17 delivers smooth and capable ight performance
that sport to experienced pilots will enjoy. It includes amazing
scale details not typically seen in micro-sized aircraft, plus added
features like functional retracts and aps.
RGRB1130 Black Marlin MX RTR Boat
The size and speed of the Black Marlin MX make it ideal for use
in small lakes and ponds and the black hull and sleek trim scheme
make it an attractive choice and fun to drive, even for beginners.
Plus, the self-righting feature quickly and automatically turns the
boat right side up if it ips over on the water.
RGR4300 Triad FPV 3-in-1 Pocket Drone RTF
The Triad FPV Drone is a great product for pilots looking for an indoor
racing type drone to test their skills. It comes with a trio of ying
options - a 5.8GHz camera system that connects to FPV goggles;
a WiFi camera system to use when WiFi is a better option; and basic
canopies for ying with less weight and longer ight times.

2018 HRP Distribung, Inc
