Rage SPINNER MISSILE XL User manual

Nose Cone
Propeller
Stakes
Parachute
Compartment
Charging Port
LED’s
Function Button
Launch Pad
2
Flying the Spinner Missile X
Replacing Damaged Propellers
1.
2. Place the Spinner Missile X on the launch pad. Press the launch button and the rocket will
4 seconds before the parachute opens. For the rocket to reach
NOTE: There is a 3 second delay from the time that the launch button is pressed and the Spinner
Missile X begins its launch. This allows time to walk a safe distance away from the missile.
Loading the Parachute
1. Check for any entanglement of the parachute chords, untangle if necessary.
2. Fold the bottom of the parachute over so it touches the base of the nose cone.
3. Push the release piston down, then carefully insert the parachute chords and folded
parachute into the compartment.
4. Push the nose cone down onto the compartment. Check that none of the parachute fabric
is stuck between the nose cone and the parachute compartment.
The Spinner Missile X features a parachute to reduce the impact during landings. Loading the
parachute correctly will reduce the possibility of a malfunctioning parachute.
To replace a damaged propeller, remove the screw holding it in place and slide the propeller
screw. If you are not able to remove the old propeller by hand, use pliers to assist.
Warning:
To avoid injury and damage, check the propeller
regularly for nicks and breaks and make sure it is
Use only the propeller intended for this product
Part# RGR4138.
Do not alter, repair, modify or customize the propellers
The Spinner Missile X includes an internal Lithium battery.
Never place or store this product in a hot location.
Keep the product in dry and cool environment at all times.
Use only the included USB cable to charge the Spinner Missile X
Charge the battery per instructions in this manual only.
Do not damage or puncture the Lithium battery.
Charge the Lithium battery every 6 months for maximum service life.
directly at www.ragerc.com or call 1-800-622-7223 M-F 9:00-5:00PM Mountain Time
Item number Description
RGR4131 Spinner Missile X Electric Free-Flight Rocket
RGR4137 500mA USB Charger; Spinner Missile X
RGR4138 Propeller; Spinner Missile X
3
NOTE:
Missile X look for a location that
is free of trees or other obstructions
that the missile might get caught
landing spots like grass whenever
possible.
Before launching, observe the wind
direction. The Spinner Missile X will
drift downwind during its descent.
Check that there are no obstructions
in the downwind direction.
If any repairs to the foam are necessary,
use a sutiable foam-safe CA adhesive (Super Glue).
Make sure that the lines or
chute are not pinched by
the nose cone.
Make sure that the lines are
not twisted or tangled.
Lithium Battery Warning
Replacement Parts
its highest altitude
Packaging Contents: Missile USB Charging Cable Launch Pad & Stakes
Warranty
Warranty Period: Rage warrants that the Spinner Missile XL (”product”) will be free from
origInal factory defects in materials and workmanship upon purchase (”Warranty Period”).
What is Not Covered - This warranty is not transferable and does not cover (a) cosmetic
damage, (b) damage due to act of God, assident, misuse, abuse, neglegence, commercial
use, or due to improper use, installation, operation or maintenance, (c) modication to any
part of the Product, (d) attempted service by enyone other than a Rage authorized service
center, or (e) Product not purchased from an authorized Rage dealer.
OTHER THAN THE EXPRESS WARRANTY ABOVE, RAGE MAKES NO OTHER WARRANTY OR
REPRESENTATION, AND THEREFORE DISCLAIMS ANY AND ALL IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF NON-INFRINGMENT,
MERCHANTABILITIES AND SUITABILITY FOR A PERTICULAR PURPOSE. THE PURCHASER
ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL MEET
THE REQUIREMENTS OF THEIR INTENDED USE.
Purchaser’s Remedy - Rage’s sole obligation and purchaser’s sole and exclusive remedy
shall be that Rage will, at it’s option, either (a) service, or (b) replace, any Product
determined by Rage to be defective. Rage reseves the right to inspect any and all Product(s)
involved in a warranty claim. Service or replacement decisions are at the sole discretion of
Rage. Proof of purchase is required for all warranty claims.
SERVICE OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE PURCHASERS
SOLE AND EXCLUSIVE REMEDY.
Limitations of Liability - RAGE SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL
OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS, OR PRODUCTION OR COMMERCIAL
LOSS IN ANY WAY, REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN CONTRACT,
WARRANTY, TORT, NEGLIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY,
EVEN IF RAGE HAS BEEN ADVISED OF THE POSSABILITY OF SUCH DAMAGES.
Further, in no event shall the liability of Rage exceed the individual price of the Product on
which liability is asserted. as Rage has no control over use, setup, nal assembly,
modication or misuse, no liability shall be assumed nor accepted for any resulting damage
or injury. By the act of use, setup or assembly, the user accepts all resulting liability. If you ,
as the purchaser or user, are not prepared to accept the liability associated with the use of
the Product, purchaser is advised to return the Product immediately in new and unused
condition to the place of purchase.
Law - These terms are governed by Utah law (without regard to conict of law principals).
This warranty gives you specic legal rights, and you may also have other rights which vary
from state to state. Rage reserves the right to change or modify this warranty at any time
without notice.
Rage, an exclusive brand of:
HRP Distributing, Inc.
2034 South 3850 West
Salt Lake City, Utah 84104
©HRP Distributing, Inc.
Printed in China
4 1
Specication
Motor Run Time 1 Press – 7 sec
2 Press – 9 sec
3 Press – 12 sec
Flying height: Over 150ft (50m) With 3 presses
Launches per Charge: Up to 20
Internal Battery: 3.7V 300mAh
LiPo Charging time: 40 minutes
Height: 10.7” (272mm)
Weight: 2.1 oz. (59.5g)
Prop: 6” weighted (152.4mm)
SAFETY WARNINGS:
• All of the safety and operating instructions should be read, adhered
to and followed before the unit is operated.
•To avoid injury, do not touch the product while ying or the propeller
while moving.
•Be careful to keep your body and any loose clothing away from the
moving propellor.
• Do not modify or change this product without authorization
Charging Instructions:
1. Connect the included USB charge cord to the port located on the back side of the rocket
and the USB connector to a power source, such as a laptop.
Charge time is about 40 minutes.
2. The main indicator light on the front of the rocket will be red during charging and will turn
off when the charge is complete.
CAUTION:
Use only the included USB
charger to charge the
Spinner MIssile XL battery.
Other chargers may damage
this product.
INSTRUCTIONS
Printed 06/22
Up to 40
Up to 150’ (50m)
3.7V 250mAh LiPo
30 Minutes
1.7 oz. (49g)
Power LED
Nose Cone
Parachute Compartment
Launch Button
Weighted Propeller
Launch Pad
Charging Port
Launch Pad
Missile USB Charging Cable
Instruction Manual
Motor Run Time
Flights Per Charge
Flying Height
Internal Battery
Charge Time
Missile Weight
Missile Height 9” (228mm)
1. Connect the included USB charger to the charge port on the Spinner Missile X and a USB power
source, such as a laptop. The indicator light on the USB charger will be red during charging and
turn o when the battery is fully charged. Charge time is about 30 minutes.
2. Disconnect the USB charger when the battery is fully charged. Do not attempt to over charge!
CAUTION:
Use only the included USB
charger to charge the
Spinner Missile X battery.
Other chargers may damage
the product!
1 Press = 4 Sec
2 Press = 8 Sec
Specications
Package Contents:
Charging Instructions:
1
X
48
4

Packaging Contents: Missile USB Charging Cable Launch Pad & Stakes
23
IMPORTANT: Before launching, observe the wind direction. The Spinner Missile XL will drift
according to wind direction during its descent, so make sure you nd a location that is free of
trees or other obstructions that the rocket may get caught up in as it lands. For best results,
make sure you have a clear space of at least 50 yards on all sides and avoid launching in winds
that are more than 5 to 10mph.
To avoid damage to the rocket, choose soft landing spots like grass whenever possible.
If any repairs to the foam are necessary, use a suitable foam-safe CA adhesive, like
Super Glue.
Part Number Description
RGR4155 Propeller
RGR4156 600mA USB Charge Cable
RGR4157 Launch Pad w/ Stakes
Operating Instructions
1. Place the base of the rocket on the shaft at the center of the launch pad so that it is
standing upright.
2. Press the Function Button to turn the unit on. The red LED will be lit when the unit is on.
3. Short press the Function Button again for ight time selection: One press for 7 seconds,
two for 9 seconds and three presses for 12 seconds.
4. After the ight time is selected the propeller will begin to slowly spin and the yellow LED will
turn on. This will give you time to safely move away from the rocket before it launches.
5. After about 5 seconds, the LEDs will switch from yellow to green and the prop begins to
accelerate for launch. During ight, all of the LEDs on the unit will be on.
6. When the motor stops at apogee, the parachute will release and the rocket will slowly
descend to the ground. Only the red LED will remain on as a power indicator.
7. To launch again return to Step 1 of the instruction.
8. When you have nished with your ights, press and hold the Function Button until the red
power indicator LED turns off.
Replacing Damaged Propellers
To replace a damaged propeller, remove the screw holding it in place and slide the propeller
away from the rocket and off the shaft. Slide the new propeller into position and reinstall the
screw. If you are not able to remove the old propeller by hand, use pliers, as needed.
Warning: To avoid injury and damage, check the
propeller regularly for nicks and breaks and make
sure it is securely attached before and after each ight.
Use only the propeller intended for this product
Part# RGR4155.
Do not alter, repair, modify or customize the propellers.
Loading the Parachute
The Spinner Missle XL features a parachute to reduce the impact during landing. Loading the
parachute correctly will reduce the possibility of the parachute not deploying correctly.
1. Check for any entanglement of the parachute chords and untangle, if necessary.
2. Fold the bottom of the parachute over so it touches the base of the nose cone.
3. Push the release piston down, then carefuly insert the parachute chords and folded
parachute into the compartment.
4. Push the nose cone down onto the compartment. Check that none of the parachute fabric
is stuck between the nose cone and the parachute compartment.
For A More Stable launch:
Install the included stakes as shown
into a dirt or grass launch site.
Make sure that neither
the chords nor the
fabric are pinched by
the nose cone.
Make sure that the
lines are not
twisted or tangled.
Replacement Parts
See your local hobby shop or place of purchase rst. If unavailable, parts can be ordered
direct at www.ragerc.com or call 1-866-724-3811 M-F 8:00AM-5:00PM Mountian Time.
Lithium Battery Warnings
•The Spinner Missile XL includes an internal Lithium battery.
•Do not dispose of the Spinner Missile XL with battery in a re.
•Never place or store this product in a hot location.
•Keep the product in a dry and cool environment at all times.
•Use only the included USB charge cord to charge the Spinner Missile XL.
• Charge the battery per instructions in this manual only.
•Do not damage or puncture the Lithium battery.
• Charge the Lithium battery every 6 months for maximum service life.
