Raymarine ST70 Instrument User manual

Welcome to ST70+
Congratulations on having chosen Raymarine ST70+.
ST70+ Instruments and Pilot Controllers give you easy access to
the important information you need and fingertip control over your
Raymarine autopilot, to make your boating experience both safe
and enjoyable.
Contents
This Operating Guide
This Operating Guide describes how to use ST70+ Instruments and Pilot Controllers on a
day-to-day basis. If you need more comprehensive information, refer to the ST70+ User
Reference Manual.
General
Getting started......................................................................................................Card 1
Display grouping & control .................................................................................Card 2
Setting display brightness...................................................................................Card 3
Setting the correct local time ..............................................................................Card 4
Setting the screen colors.....................................................................................Card 5
Choosing the data units.......................................................................................Card 6
Data list................................................................................................................Card 21
Pilot Controller
Setting up a Pilot Controller display...................................................................Card 7
Basic autopilot operation ....................................................................................Card 8
Using AutoTack ....................................................................................................Card 9
Using autopilot Track mode ..............................................................................Card 10
Using autopilot Wind Vane mode......................................................................Card 11
Using autopilot fishing patterns........................................................................Card 12
Instrument
Switching instrument pages on & off...............................................................Card 13
Setting instrument page rollover ......................................................................Card 14
Changing information on a page.......................................................................Card 15
Changing the page layout..................................................................................Card 16
Using alarm clock...............................................................................................Card 18
Using race timers ...............................................................................................Card 18
Setting alarms.....................................................................................................Card 19
Alarm events.......................................................................................................Card 20
ST70+ Operating Guide
Raymarine UK Ltd, Anchorage Park, Portsmouth, Hampshire PO3 5TD, United Kingdom
Tel: [phone], Fax:[phone]
Raymarine Inc,21 Manchester Street, Merrimack, New Hampshire 03054, USA
Tel: [phone], Fax: [phone]
Part Number: 81309-1
Date: January 2009 www.raymarine.com
81309_1.book Page 1 Wednesday, March 11, 2009 3:25 PM

Finding information
The edges of cards for Pilot Controller and Instrument functions are color-coded to help you
easily find the information you want:
Important information
Important
Before using your ST70+ products, ensure they have been prepared for use in accordance with the Commissioning
Procedures. Refer to the ST70+ User Reference Guide or the ST70+ installation Guide.
EMC conformance
AllRaymarineequipmentandaccessoriesaredesignedtothebestindustrystandardsforusein therecreationalmarine
environment.
Thedesignandmanufactureof Raymarineequipmentandaccessoriesassurescompliancewith theappropriate
Electromagnetic Compatibility(EMC) regulations, butcorrectinstallationis requiredtoensurethatperformanceis not
compromised.
Product documents
Theinformationinthis guideis validforST70+ productsand systemswhichhavebeen installedandcommissioned in
accordancewiththecorrectRaymarineprocedures.Relevantdocuments are:
• ST70+UserReferenceManual(contains commissioning,maintenance &troubleshootingprocedures).
• ST70+InstallationGuide(includes commissioningprocedures).
•SeaTalk
ng ReferenceManual.
Technical accuracy
Tothe best ofour knowledge,the informationin this document was correct at the time it was produced. However,
Raymarine cannotaccept liabilityfor any inaccuraciesor omissionsit maycontain.Inaddition,our policy ofcontinuous
productimprovementmay change specificationswithoutnotice.As aresult,Raymarinecannot acceptliabilityforany
differences between the product and this document.
Waste Electrical and Electronic (WEEE) Directive
TheWEEEDirective requirestherecyclingofwasteelectricalandelectronicequipment.
WhilsttheWEEEDirectivedoesnotapplytosomeofRaymarine'sproducts,wesupportitspolicyandaskyoutobe
awareofhow todisposeof thisproduct.
Thecrossedoutwheeliebinsymbol(illustratedhere)foundonourproductssignifiesthatthisproductshouldnotbe
disposedof ingeneralwasteorlandfill.
Pleasecontactyour localdealer, nationaldistributor orRaymarineTechnicalServicesforinformationon productdisposal.
• Cards with information applicable to both Pilot Controller and Instrument are white.
• Cards describing Pilot Controller and autopilot functions are colored
• Cards describing Instrument functions are colored•
WARNING: Product installation & operation
This equipment must be installed and operated in accordancewith the Raymarine
instructions provided. Failureto do so could result in personal injury, damage to your boat
and/or poor product performance.
WARNING: Ensure safe navigation
Thisproductisintendedonlyasanaidtonavigationandmustnever beusedinpreferencetosound
navigational judgment. Only official government charts and notices to mariners contain all the
currentinformationneededforsafenavigation,andthecaptainisresponsiblefortheirprudentuse.
It is the user’s responsibility to use official government charts, notices to mariners, caution and
proper navigational skill when operating this or any other Raymarine product.
WARNING: Ensure Commissioning Procedures have been completed
If the ST70+ Commissioning procedureshave not been completed, your displays could be
displaying misleading information.Before using ST70+, ensure that the Commissioning
Procedures in the ST70+ Installation Guide (also provided in theUser Reference Manual)
have been successfully carried out.
www.raymarine.com
81309_1.book Page 2 Wednesday, March 11, 2009 3:25 PM

1
ST70+ display functions
Each ST70+ display is set up as an Instrument or a Pilot Controller during commissioning,
and is controlled from an external keypad. Instrument and Pilot Controller keypad types are
fitted as appropriate. Note that the type of Pilot Controller keypad fitted depends on boat type
(power or sail boat).
Switching on
To switch on an ST70+ display or display group, or to re-apply power to individual displays in
a working group that have been switched off, press and release , on an associated key-
pad. All displays in the relevant group then power up.
At power up, each display shows the page that was in use when the power was last switched
off, once the system has been commissioned.
WARNING:
Do not use a display until the appropriate commissioning procedure has been
successfully carried out (as in the ST70+ Installation Guide or the ST70+ User
Reference Manual).
If a Language page is displayed when you switch on, the display has
not been commissioned, so you need to carry out the commis-
sioning procedure before using the display.
Switching off
Important: In the ‘Switched Off’ condition, power is still supplied to the displays. If you
want to remove power completely, switch it off at the relevant distribution panel.
To switch offa display, hold down on an associated keypad. Acountdown starts and a popup
shows the progress and indicates which displays you are switching off (default is Group). Con-
tinue holding down until the countdown completes and the selected displays power down.
If you want to change which units are being switched off:
1. Duringthe countdown,release topausethecountdown,thenuse either the RotaryCon-
trolor
-1 and +1 ontheassociatedkeypadto selecteither:
•Group - to switch off all the displays in this group (default setting), or
•Display - to switch off just this display.
2. Holddown againuntilthecountdowncompletesand the selecteddisplayspowerdown.
Applicability: The procedures on this card apply to ST70+ Instruments and Pilot Controllers.
Display Instrument
keypad PilotController keypad (power) PilotController keypad (sail)
Typical Instrument page Typical Pilot Controller page
D11015-1
D11016-1
Language
English (UK)
Press OK to select
ST70+ general information
Getting started
81309_1.book Page 1 Wednesday, March 11, 2009 3:25 PM

Card continued
1
General operation
For information on display/keypad grouping, refer to Card 2.
Selecting & confirming options & values
Many ST70+ setup functions, display options and values are set up by using the keyboard to
scroll to the required option or value, then confirming, by pressing
OK .
The manner in which you do this depends on keypad type.
Scrolling .
To scroll to an option or set a value, either:
• Press the
< and > buttons on the sail boat Pilot Controller
keypad, or
• Turn the Rotary Control on the power boat Pilot Controller
keypad or the Instrument keypad.
OK function
To OK selections and edited values, either:
• Press the
OK button, on the sail boat Pilot Controller keypad, or
• Press the center of the Rotary Control inwards, on the power boat
Pilot Controller keypad or the Instrument keypad.
ST70+ Instruments
On an ST70+ Instrument display:
• Data is displayed on operational pages. Up to eight pages are available.
• Each page can be divided into up to six separate data areas or ‘frames’.
To move from page to page, use
PAGE UP or PAGE DN on the associated keypad. You can
also apply a rollover (see Card 14) to change pages automatically
Customizing pages
You can change any operational page, to show only the information you want. You can:
• Change the information in any frame of any page. Refer to Card 15.
• Rebuild any page, so it has a different frame layout with different data. Refer to Card 16.
ST70+ Pilot Controllers
On an ST70+ Pilot Controller display, you can
choose one of three different page types to view
navigational information.
To move from one Pilot Controller page type to
another, hold down MENU for 1 second.
Refer to Card 7 for a description of the data on the different Pilot Controller page types.
or
Scrolling
=
OK functions
Depth
ft
9. 0
Lat
N
Speed
kts
7. 0
Heading
xx
63
Time
24H
11:23
o
47
o
Lon
47
Page 1
D11018-1
Page 2Page 3
Page 4
Page 5
Page 6 Page 7 Page 8
GILKICKER POINT
GILKICKER POINT
Standby
Plain view Compass Rose view Isometric view
ST70+ general information
Getting started
81309_1.book Page 2 Wednesday, March 11, 2009 3:25 PM

2
Your ST70+ displays can be configured to operate in groups. The ST70+ commissioning
instructions describe how to set up groups and allocate keypads. Refer to the ST70+ User
Reference Manual or the ST70+ Installation Guide.
Group parameters
Each group:
• Can contain up to four displays of the same type i.e. EITHER Instrument OR Pilot Con-
troller. You cannot mix Instruments and Pilot Controllers in the same group.
• Can be controlled by one or more keypads of the appropriate type.
Selecting displays
In any display group, you can control one display at a time.
To select the display you want to control, use the (Select Display) button on any keypad
in the group. The ‘selected’ display screen is highlighted.
Each time you press the Select Display button, the next display in the group is selected.
Applicability: The procedures on this card applyto all configurations of ST70+ Instruments and Pilot Controllers.
D11020-1
Selected display
Depth
FT
Lat
N
Speed
KTS
Heading
MAG
63
Time
24H
11:23
o
o
o
47 o
Lon
67
6 .0 7 .0
Time
24H
11:23
Heading
MAG
63
o
Lat
N
o
47
o
Lon
67
Depth
FT
6 .0
Speed
KTS
7 .0
Time
24H
11:23
Heading
MAG
63
o
Lat
N
o
47
o
Lon
67
Depth
FT
6 .0
Speed
KTS
7 .0
Time
24H
11:23
Heading
MAG
63
o
Lat
N
o
47
o
Lon
67
Depth
FT
6 .0
Speed
KTS
7 .0
ST70+ general information
Display grouping & control
81309_1.book Page 3 Wednesday, March 11, 2009 3:25 PM

2
ST70+ - general information
Display grouping
81309_1.book Page 4 Wednesday, March 11, 2009 3:25 PM

3
Introduction
Use this procedure to set the screen brightness on any ST70+ display type (Instrument or
Pilot Controller). You can set the brightness on either just one display, all the displays in a
group, or all displays in a system. The group setting is the default.
Procedure
1. Starting
With any operational page displayed, press
MENU to display the Main Menu then scroll to
the Display Settings option.
Press OK to show the Display Settings menu.
2. Select option
At the Display Settings page, scroll to the Brightness
option.
Press
OK to display the 1. Brightness - select zone setup
box.
3. Select displays
Scroll to select the displays on which you want to adjust
the screen brightness. The options are:
•This group - affects all displays in the same group as
the selected display (default setting).
•All displays
- affects all displays in the system.
•This display - affects just this display.
Press
OK to display the 2. Brightness - select value screen
4. Set brightness level
Scroll to set the screen brightness.
Press
OK to save the setting and return to the Display
Settings menu.
Returning to operating page
To return to normal operation from the Display Settings
menu, press CANCEL twice.
Applicability: The procedures on this card applyto all configurations of ST70+ Instruments and Pilot Controllers.
i
D11021-1
Press OK to continue
1. Brightness - select zone
This group
iSelect the zone for brightness
changes, using < & >.
i
D11022-1
Press OK to accept
2. Brightness - select value
Adjust brightness using < & >.
50
%
ST70+ general information
Setting display brightness
81309_1.book Page 5 Wednesday, March 11, 2009 3:25 PM

3
81309_1.book Page 6 Wednesday, March 11, 2009 3:25 PM

4
If your ST70+ system is receiving GPS data, use the procedure on this card to set the correct
local time as your system time.
Note: Ifyou wanttochangethe timeordateformat,use theprocedureinthe ST70+UserReferenceManual.
Setting the time
Note: IfyourST70+ displayisconnectedto aRaymarinemultifunctiondisplay,thenthe timeoffsetis controlledbythemul-
tifunctiondisplaysoyoucannotusethisprocedureto changeit.
1. Starting
With any operational page displayed, press
MENU , to display the Main Menu , then scroll to
the Display Settings option.
Press OK to show the Display Settings menu.
2. See current settings
At the Display Settings page, scroll to the Time & Date
option.
Press
OK to display the Time & date summary page.
• To return to the Display Settings menu without chang-
ing any values, press
CANCEL .
• To set up the local time, press
OK , to select the Time &
Date menu.
3. Select time offset
With the Time & Date menu displayed, scroll to Set time
offset. Press OK to display the Set time offset setup
page.
The time offset is the difference in time between GMT
(time at Longitude 0°) and local time.
1. Scrolltosettheappropriate time offsetforyourarea.
2. Press
OK toacceptthevalueanddisplaythe Time &
Date summarypage.
Returning to operating page
To return to normal operation from the Time & Date
summary page displayed, press CANCEL three times.
Applicability: The procedures on this card apply to ST70+ Instruments and to ST70+ Pilot Controllers, connected to SeaTalk and
SeaTalkng pilot types. Date and time information are availableonly if your ST70+ display is receiving GPS data.
i
D11028-1
Press OK to continue
Time & Date
These are your current settings.
Time 11:01:03
Date 14/06/07
Time Offset -1 Hrs
Time Format 24-hour
Date Format dd/mm/yy
10
0
D11029-1
Time & Date
Set time offset
Press OK to select
i
D11105-1
Press OK to accept
Set time offset
-1
Use < & > to adjust.
CANCEL exits without saving.
Hrs
ST70+ general information
Setting the correct local time
81309_1.book Page 7 Wednesday, March 11, 2009 3:25 PM

4
ST70+ - general information
Choosing data units
81309_1.book Page 8 Wednesday, March 11, 2009 3:25 PM

5
Use these instructions to set the screen colors for optimum viewing (daytime and nighttime).
There are four different color settings plus an inverse video option.
Choosing colors
1. Starting
With any operational page displayed, press
MENU , to display the Main Menu , then scroll to
the Display Settings option.
Press OK to show the Display Settings menu.
2. Select option
At the Display Settings page, scroll to the Colors option.
Press
OK to display the 1. Colors - select zone screen.
3. Select displays
Scroll to select the displays on which you want to set the
screen colors:
•This group - affects all displays in the same group as
the selected display (default setting).
•All displays
- affects all displays in the system.
•This display - affects just this display.
Press OK to display the 2. Colors - select value screen.
4. Select color
Scroll to select the screen colors you want. You can
choose from.
•Mode1
•Mode2
•Mode3
•Red/black (recommended for night time viewing)
•Inverse
Press
OK to save the setting and return to the Display
Settings menu.
Returning to operating page
To return to normal operation from the Display Settings menu, press CANCEL twice.
Applicability: The procedures on this card applyto all configurations of ST70+ Instruments and Pilot Controllers.
i
D11023-1
Press OK to continue
1. Colors - select zone
Select the zone for color
changes, using < & >.
This group
i
i
D11024-1
Press OK to accept
1. Colors - select value
Select colors using < & >.
Mode 1
ST70+ general information
Setting the screen colors
81309_1.book Page 9 Wednesday, March 11, 2009 3:25 PM

5
81309_1.book Page 10 Wednesday, March 11, 2009 3:25 PM

6
Use these instructions to choose the data units you want to use. You can choose from a
range of imperial and metric units. Data unit settings are applied to the whole system.
Procedure
1. Starting
With any operational page displayed, press
MENU , to display the Main Menu , then scroll to
the Display Settings option.
Press OK to show the Display Settings menu.
At the Display Settings menu, scroll to the Units option.
Press
OK to display the first Units summary page.
2. Select option
Press OK again to display the second Units summary
page.
Press OK to display the Select units menu.
3. Select units.
Scroll to the unit you want to change.
Press
OK to display the selection screen for the units you
have chosen.
4. Set units
Scroll to select the units you want, then.Press
OK to save
the setting and return to the first Units summary
page.
If you want to set up other units, repeat the Select option
and Select units procedures above.
Returning to normal operation
When you have finished setting the units and the Select
units menu is displayed:
1. Scroll to the Continue option.
2. Press
OK toreturntoyouroperationalpage.
Applicability: The procedures on this card applyto all configurations of ST70+ Instruments and Pilot Controllers.
i
D11025-1
Press OK to continue
Units summary
These are your current settings.
Speed KTS
Distance NM
Depth FT
Wind Speed KTS
Heading M
Flow Rate G/H
Temperature °C
i
D11026-1
Select units
Wind Speed Units
Select units to change, using <
or >.
Press OK to select
i
D11106-1
Press OK to accept
Wind Speed Units
KTS
Select required units, using < or
>. CANCEL exits without saving.
i
D11027-1
Select Units
Continue
Select units to change, using <
or >.
Press OK to select
ST70+ general information
Choosing the data units
81309_1.book Page 11 Wednesday, March 11, 2009 3:25 PM

6
ST70+ general information
Choosing data units
81309_1.book Page 12 Wednesday, March 11, 2009 3:25 PM

Card7
continued ...
Introduction
Use this procedure to set up your ST70+ Pilot Controller display, to display:
• The type of pilot page you want.
• The data you want to see in the on-screen data boxes.
To scroll to any menu selection, use either the Rotary Control or the < & >buttons, as appro-
priate for the keypad you are using.
WARNING: Autopilot safety
Do NOT attempt any Pilot Controller setup procedures unless the
autopilot is disengaged.
Selecting display type
The Pilot Controller display shows one of three page views:
continued ...
Applicability: The procedures on thiscard apply to ST70+ Pilot Controllers used with Raymarine SeaTalk and SeaTalkng autopilots.
They do NOT apply to ST70+ Instruments.
GILKICKER POINT
GILKICKER POINT
Standby
Rudder bar
Name of next waypoint
Current heading in Standby mode
Locked heading when autopilot
has control
Mode
Rudder bar
Name of next waypoint
Mode
North indicator
Data boxes
Rudder bar
Mode
Planned track
Data boxes
Next waypoint
Current heading (in Standby mod
e
Locked heading (when autopilot
has control)
Planned track
Wind direction indicator
Wind direction indicator
Name of next waypoint
Current heading in Standby mode
Locked heading when autopilot
has control
North indicator
Plain view
Compass Rose view
Isometric view
D11118-1
ST70+ Pilot Controller
Setting up a Pilot Controller display
81309_1.book Page 13 Wednesday, March 11, 2009 3:25 PM

Card continued
7
Selecting Pilot Controller page types
To change the type of view on your Pilot Controller screen, hold down MENU for 1 second.
The next view in the sequence is then displayed.
You can also change the view by using the menu system.
To do this:.
1. Press
MENU todisplaytheMain Menu.
2. ScrolltothePilot View option,thenpress
OK, todisplay
thePilot View menu.
3. Scrolltotheviewyouwant:
•Plain view,
•2D view (Compass Rose view), or
•3D view (Isometric view.)
4. Press
OK toconfirmtheselection.
Setting up data boxes
You can select which data appears in the data boxes in the 2D and 3D pilot views. To do this:
1. Press
MENU todisplaytheMain Menu.
2. ScrolltoDisplay Settings thenpress
OK, todisplaythe
Display Settings menu.
3. ScrolltoData Boxes thenpress
OK toselecttheData
Boxes menu.
4. Scrolltothedata box youwanttosetup(1,2or3)then
press OK toselectthesetuppage for that box.
5. Scrolltothedata you want inthedatabox.Alistofavail-
abledatafor pilot ControllersisgivenonCard 22.
6. Press
OK toreturntotheData Boxes menu, and repeat
steps4and5 of theSettingupdataboxes procedure for
eachdatabox you want tosetup.
Returning to operating page
To return to normal operation from the Data Boxes menu, press CANCEL three times.
i
D11119-1
Pilot View
2D View
Press OK to select
0.00
////
////
////
0
00
////
N
S
W E
////
////
////
////
N
W
E
////
////
i
D11120-1
Data Boxes
Box 1
Select the data for box 1.
Press OK to select
3
3
1
1
2
2
i
Press OK to accept
Data Boxes
BTW
Select data to be shown.
Press CANCEL to exit without saving.
D11121-1
1
1
ST70+ Pilot Controller
Setting up a Pilot Controller display
81309_1.book Page 14 Wednesday, March 11, 2009 3:25 PM

Card8
continued ...
Planned course
D11122-1
Operating modes
When you first switch on your system, your autopilot is in Standby mode. This means that
you have full manual control, and the autopilot has no control over your boat. To enable the
autopilot to steer your boat, you need to use one of the autopilot control modes.
Autopilot control modes
Auto mode gives the autopilot basic steering control over your boat. The autopilot steers
your boat on a fixed heading that you determine.
Other modes in which the autopilot has control are:
•Track mode is available where GPS information is available on your system. The autopi-
lot steers the boat on a pre-determined course defined by waypoints. (Refer to Card 10).
•Wind Vane mode is available on SAIL BOATS ONLY, if Wind information is available.
The autopilot maintains a fixed course with respect to the wind. (Refer to Card 11).
•Fishing patterns are available on FISHING BOATS ONLY. The autopilot navigates the
boat according a pre-programmed pattern. You can select the pattern you want and
change the pattern parameters. (Refer to Card 12).
Using your autopilot in Auto mode
WARNING: Autopilot safety
Do NOT engage your autopilot until you
are sure it is safe to do so.
Important
To return to manual steering at any time, press STANDBY on your
Pilot Controller keypad.
To use your autopilot to steer your boat.
1. Manuallysteer your boat onto theheadingyou
want.
2. Ifnecessary,engagetheautopilotclutch(refer
totheoperatingguidesuppliedwithyourautopilotsystem).
3. Ensuringyouhaveenoughclearwaterinthedirectionof travel, press
AUTO onyourPilot
Controllerkeypad,toenter Auto mode. Theautopilotthensteersyourboatontheheading
youhavechosen.
If necessary, use the keypad controls to change course when running in Auto mode:
•On a sail boat use either -1 or -10 to turn to port, or +1 or +10 to turn to starboard.
•On a power boat turn the Rotary Control either clockwise to turn to starboard, or
coun-
terclockwise to turn to port. Each click of the control equals one degree of course
change.
Returning to manual control
To return to manual steering at any time, press STANDBY.
Applicability: The procedures on thiscard apply to ST70+ Pilot Controllers used with Raymarine SeaTalk and SeaTalkng autopilots.
They do NOT apply to ST70+ Instruments.
ST70+ Pilot Controller
Basic autopilot operation
81309_1.book Page 15 Wednesday, March 11, 2009 3:25 PM

Card continued
8
Dodging obstacles
To steer around an obstacle when running under autopilot
control:
1. AtthePilotControlkeypad, press DODGE .toregainman-
ualcontroloftheboati.e.enterStandbymode.ADODGE
screenisdisplayed.
2. Steer theboatawayfrom the obstacle.
3. When clear ofthe obstacle, presseither:
•
AUTO to return to Auto mode steering on the previ-
ous autopilot heading, or
•
DODGE again to return to Auto mode on the heading you are now steering.
Returning to manual control
To return to manual steering at any time, press STANDBY.
D11041-1
Intended course
Obstacle
either on
original course or apply new course
Dodge
ResumeAuto
Dodge
course
Obstacle
D11123-1
ST70+ Pilot Controller
Basic autopilot operation
81309_1.book Page 16 Wednesday, March 11, 2009 3:25 PM

Card9
Introduction
On a SAIL boat under autopilot control, you can use AutoTack to define how the boat tacks.
• When using AutoTack outside of Wind Vane mode (standard AutoTack), the AutoTack
angle is the angle between a port tack and a starboard tack. The default angle is 100°. .
• When using AutoTack in Wind Vane mode, the tack angle relative to the wind on one tack
is mirrored on the other side of the wind on the next tack.
Standard AutoTack (not in Wind Vane mode)
AutoTack to starboard
Either:
• With the Main Menu displayed,
select Tack Starboard,
or
• Press
+1 and +10 simultaneously.
The boat AutoTacks to starboard.
AutoTack to port
Either:
• With the Main Menu displayed,
select Tack Port,
or
• Press
-1 and -10 simultaneously.
The boat AutoTacks to port.
Trimming the helm
If necessary after an AutoTack, use -1 and +1 to trim the helm to the required wind angle.
Using AutoTack in Wind Vane mode
Note: AfteranAutoTackin WindVanemode,the helmautomaticallytrimstothecorrectwind angle.
AutoTack to starboard
Either:
• With the Main Menu displayed, select Tack
Starboard,
or
• Press
+1 and +10 simultaneously.
The boat AutoTacks to starboard.
AutoTack to port
Either:
• With the Main Menu displayed, select Tack Port,
or
• Press
-1 and -10 simultaneously.
The boat AutoTacks to port.
Applicability: The procedures on this card apply to ST70+ Pilot Controllers used withRaymarine SeaTalk and SeaTalkng autopilots
ON SAIL BOATS only. They do NOT apply to ST70+ Instruments.
Wind Wind
Starboard tack Port tack
'Standard' AutoTack
Tack angle, 100° default
(can be changed in User cal) Tack angle maintained
Tack
angle
Wind Wind
Tack
angle
mirrored
Starboard tack Port tack
AutoTack in
WInd Vane mode
ST70+ Pilot Controller
Using AutoTack
81309_1.book Page 17 Wednesday, March 11, 2009 3:25 PM

9
ST70+ - Pilot Controller
81309_1.book Page 18 Wednesday, March 11, 2009 3:25 PM
