RayTek Raynger MX4 User manual

The Professional’s Choice
The new Raynger MX family of handheld, infrared thermometers takes noncontact temperature
measurement technology into the future. Designed for ease-of-use, unmatched performance,
and new laser technology, the MX is the professional’s tool of choice.
Enhanced Features and Accuracy
The MX features an optically matched coaxial laser sighting system, that precisely and accurately
outlines the target measurement area. Improved optics (D:S 60:1) allow temperature measurement
from any distance, and the bar graph display automatically charts the last 10 temperature points
using maximum and minimum temperature values to establish the range. The locking trigger allows
continuous temperature monitoring.
The MX2 is the standard model. Just point, shoot, and read. The MX4 is the high-performance
model that accepts K & J thermocouples, thermistor (NTC), power input, and allows for data
output. The MX4+ package includes Windows™
-compatible data management software, a
thermocouple K probe, an RS232 computer cable, and a plug-in power supply. A useful table
of 30 preset material emissivity listings is easily accessed on both the MX4 and MX4+. Simply
scroll to locate the correct material.
Now two new MX models are available. The MXSZ (Subzero) and MXCF (Close Focus) special
purpose models are designed for specialized applications requiring measurement of very low
temperature targets or extremely small target areas. Both MXSZ and MXCF feature Raytek’s
advanced optically matched coaxial laser sighting system and are available in the MX2, MX4 and
MX4+ configurations.
Software
With Raytek graphing software. you can use your computer to organize, display, and print
temperature and time data. The software also includes the ability to store data points, continuous
or manual single-point recording, programmable time intervals, temperature scales and limits,
built-in material table of emissivity values, customizable log locations, and displays both contact
and infrared temperatures.
MX4+ Package includes: Windows-compati-
ble data management software •thermocou-
ple K probe •RS232 computer cable •plug-
in power supply.
Windows-compatible MX4+ software graphs
both contact and noncontact temperature points.
RAYNGER®MX™SERIES
RAYNGER MX SERIES
Now Available in
Close Focus and
Subzero Models
25mm
@ 0m
1.0"
@ 0"
19mm
@1.15m
0.76"
@ 3'10"
286mm
@10m
11"
@ 32.8'
Temperature range -30 to 900°C (-25 to 1600°F), MX2, MX4, MXCF
-50 to 500°C (-58 to 932°F), MXSZ
Accuracy* ±1% of reading or ±1°C (±2°F), whichever is greater
Repeatability* ±0.5% of reading or ±1°C (±2°F), whichever is greater
Response time (95%) 250 mSec
Spectral response 8 to 14 µm, thermopile detector
Display resolution tenth degree reading up to 900°C (0.2°F to 999.8°F)
Ambient operating range 0 to 50°C (32 to 120°F)
Relative humidity 10-95% RH noncondensing @ up to 30°C (86°F)
Storage temperature -30 to 50°C (-25 to 122°F) without battery
Power 2 AA batteries, DC power for MX4 and MX4+
Tripod mount 1/4-20 UNC
Dimensions 200 x 170 x 50 mm (7.9 x 6.7 x 2 inches)
Weight 480 g (1 lb. 6 oz)
*only at 23°C (73°F)
MX2 MX4 MX4+
Adjustable emissivity ✓✓✓
On-board emissivity table - ✓✓
*16-point laser circle spot; meets IEC ✓✓✓
Class 2 & FDA Class II requirements
*Single Laser Class III ✓--
Audible/visible High alarm ✓✓✓
Audible/visible Low alarm ✓✓
MAX and MIN temperature ✓✓✓
DIF and AVG temperature - ✓✓
Bar graph display ✓✓✓
Data output: RS232 or - ✓✓
1 mV per degree (°C or °F)
100 points of data logging - ✓✓
Windows-compatible - - ✓
Data Graphing Software - - ✓
Power Supply (110 or 220V), - - ✓
RS232 Computer Cable, 1.5 m (60 in),
K thermocouple probe
*MX2 available with either 16-point class II, or single point class III laser sighting system.
MX2, MX4, MX4+ and MXSZ
D:S = 60:1 at Focus Point
Target Spot Sizes and Distances
RAYNGER MX PORTABLE NONCONTACT THERMOMETERS
FEATURES
SPECIFICATIONS
■Windows-based Data Graphing Software* ■Thermistor (NTC) probe
■ RS232 computer cable* ■Portable thermal printer
■Thermocouple K probe* ■Calibration Certification
■Plug-in Power Supply (110 or 220V)* ■Soft pouch
*Standard with Raynger MX4+
OPTIONS / ACCESSORIES
The rugged, ergonomic MX has many uses:
■check for hot spots in electrical panels, circuit
breakers, generators, and gearboxes
■monitor supply and return registers, air stratification,
and duct leakage
■monitor temperatures of gasoline and diesel
engine cylinders and railroad axles and bearings
■food preparation and storage
■Industrial predictive and preventative maintenance.
■Checking for icing and deicing on planes
and asphalt
■Checking for depleted refrigeration media
■Cold storage and walk-in refrigeration applications
■Frozen food safety and processing
■ISO 9000 proactive maintenance programs
■Checking for bearing failures and motor misalignment
■Power distribution trouble shooting
■Electrical bench work in the shop or lab
APPLICATIONS
25mm
@ 0mm
1.0"
@ 0"
6mm
@300mm
0.24"
@ 11.4"
70mm
@1000mm
2.81"
@ 40"
MXCF (Close Focus)
D:S = 50:1 at Focus Point
Raytek, the Raytek logo, and Thermalert are registered trademarks
of Raytek Corporation.
©2001 Raytek Corporation, Printed in USA, 3/01 Rev. A
Specifications subject to change without notice. 3-1022
Worldwide Headquarters
Raytek Corporation
Santa Cruz, CA USA
Tel: 1 831 458 1110
800 866 5478 (U.S. and Canada only)
Fax: 1 831 425 4561
www.raytek.com
5710 Kenosha Street
Richmond, Illinois 60071 USA
Phone: +1 (815) 678-2211
FAX: +1 (815) 678-3961
Internet: www.watlow.com
e-mail: info@watlow.com RIC-MX-0401
