RBP-1109B-RX3
Page 1of 3June 2017 (JB)
13000 Temple Ave. City of Industry, CA 91746 1-877-519-9090
2001-2006 CHEVY SILVERADO 1500-3500 CREW CAB RX3
HARDWARE INCLUDED
RECOMMENDED TOOLS
12
8-1.25mm x 25mm Hex Bolts
2
13mm Wrenches
12
8mm Lock Washers
Drill with 7/16” bit
18
8mm x 24mm OD x 2mm Flat Washers
6
8-1.25mm Hex Nuts
2
8-1.25mm Threaded Inserts
1
8mm Insert Tool
DRIVER-LEFT SIDE INSTALLATION:
STEP 1 –Remove any old steps, hardware, plastic plugs or insulation.
STEP 2–Locate the (4) tabs with holes, along the bottom edge of the driver side body panel, (Figures
1—3). IMPORTANT: Installation will use the 1st, 2nd and 4th mounting tabs only. Locate each
threaded weld nut in the inner side of the body directly above the lower mounting tabs. NOTE: The
rear mounting location does not have a factory threaded weld nut or mounting tab hole and requires
drilling.
STEP 3 –With assistance, hold the Side Step up to the bottom of the body panel. Line up the attached
brackets with the (3) mounting locations. Place a mark on the body panel for the upper rear mounting
hole and a mark on the pinch weld for the lower rear mounting hole, (Figure 4). Use a 7/16” drill bit to
drill out the (2) holes. NOTE: It is highly recommended to drill a small pilot hole for both the lower and
upper mounting locations to ensure that the pinch weld hole is properly aligned with the bracket and
threaded insert hole.
Step 4 –Assemble the metal Insert Tool as shown in Figure 5. Push the Tool and Insert assembly into
the drilled hole. NOTE: If Metal Insert fits too tight, lightly tap it into place with a small hammer.
Firmly hold the handle on the Tool and tighten the hex bolt in the Insert until it is fully locked in place.
NOTE: Do not over tighten the Insert or a pull out may occur. Once Metal Insert is compressed,
remove the hex bolt and tool from the Insert, (Figure 6).
Step 5 –Attach each Bracket to each upper threaded insert with (1) 8mm Hex Bolt, (1) 8mm Flat
Washer, (1) 8mm Lock Washer and (1) 8mm Hex Nut, (Figure 7). Attach the lower tabs on the
mounting brackets to the bottom of the body with (3) 8mm x 25mm Hex Bolts, (3) 8mm Lock Washers

RBP-1109B-RX3
Page 2of 3June 2017 (JB)
13000 Temple Ave. City of Industry, CA 91746 1-877-519-9090
(Fig 1) Front driver/left installation location
and (3) 8mm STD Flat Washers, (Figure 8). NOTE: You may need to drill to enlarge the existing holes
for the lower bracket. Snug but do not tighten hardware at this time.
STEP 7 - Once the Side Step is fully installed, verify the fitment and alignment. Fully tighten hardware.
STEP 8 - Repeat Steps 1—7 to install the passenger side RX3 Step assembly.
Periodically check installation and re-torque all fasters to specifications.
(Fig 2) Center driver/left installation location
(Fig 3) Rear driver/left installation location
Factory Threaded Weld Nuts
Pinch Welds
Will require drilling
Front
Front
Front
It is highly recommended
to drill pilot holes to
ensure proper alignment
Use 7/16” drill bit
(Fig 4) Driver side rear mounting location
marked for drilling illustrated as example only
Front

RBP-1109B-RX3
Page 3of 3June 2017 (JB)
13000 Temple Ave. City of Industry, CA 91746 1-877-519-9090
(Fig 7) Driver side Center bracket installed
Tool
8mm Threaded Insert
8mm Hex Bolt
8mm Flat Washer
Fig 5
(Fig 6) Example of driver side
rear threaded insert installed
Front
Front
Fig 8
8mm Hex Bolt
8mm Lock Washer
8mm Flat Washer
8mm Hex Bolt
(2) 8mm Flat Washers
8mm Lock Washer
8mm Hex Nut
Front
