RCA DRC62705E24G User manual

DRC62705E24G
User manual
This product contains a low power
laser device.
Este producto contiene un dispositivo
láser de baja potencia.
Producto láser
Clase 1
PRECAUCIÓN
RADIACIÓN LÁSER INVISIBLE
EN CASO DE APERTURAY
DESBLOQUEO DE CIERRE. EVITE
CUALQUIER EXPOSICIÓN AL RAYO
M

EN - 2
Remote Control
Battery Replacement
When the battery becomes weak, the operating distance of the remote control will be
greatly reduced and you will need to replace the battery.
Note:
• Iftheremotecontrolisnotgoingtobeusedforalongtime,removethebatteryto
avoid damage caused by battery leakage corrosion.
• Whendiscardingbatteries,environmentalproblemsmustbeconsideredandlocalrules
or laws governing the disposal of these batteries must be strictly followed.
WARNING:
• Donotdisposeofthebatteryinareoritmayleakand/orexplode.
• Batteriesshouldnotbeexposedtoexcessiveheatsuchassunshine,reorthelike.
CAUTION:Dangerofexplosionifbatteryisincorrectlyreplaced.Replaceonly
with the same or equivalent type.
Remove the plastic sheet
before operating the
remote control.
To Change Remote Battery
1. Open the battery door.
2. Insert one CR2025 (3V) size battery.
Using the Remote Control
• Point the remote control at the REMOTE
SENSOR located on the unit.
• When there is a strong ambient light
source, the performance of the infrared
REMOTE SENSOR may be degraded,
causing unreliable operation.

EN - 3
Using of Remote Controls
Remote controls have different color keys to identify which unit they operate. The remote
control with green keys operates Unit A which has a green stripe on the front of the unit.
The remote control with blue keys operates Unit B with a similar blue stripe on the front
of the unit.
Match the color in
remote control and
DVD player

EN - 4
Control Reference Guide
1. DVD/AVIN
Press to select between the DVD player
orexternalvideo/gamessource.
2. MENU
 Press to enter and exit the main DVD
menu. This option works only if the
DVD has a main menu.
3.
Press to navigate or to adjust settings
in SETUP, GOTO and MEMORY mode.
Press to turn volume down or press
to turn volume up.
ENTER
 Press to conrm selections on the
menu.
4. (previous)
Press to go to the previous chapter or
title on a DVD, or track on a CD.
Press and hold to fast backward
playback.
5. VIDEO MODE
Press to adjust brightness, contrast or
screen size.
PLAY/PAUSE
Press to start playback. When a disc is
paused press to resume playback.
When a disc is playing, press to pause
playback.
STOP
Press once to stop playback. Your
player remembers where you stopped.
If you press (play), your player
starts playing at the point where you
stopped.
Press twice to stop playback. If you press
(play), your player starts playing at
the beginning of the disc.
6. GOTO
Press to go directly to a location on a
DVD or CD.
7. REPEAT A-B
 Presstorepeataspecicsection(from
point A to point B) of a disc.
REPEAT DISC
Press to repeat a DVD current title,
chapter, a CD track, or entire dics of a
CD.
8. AUDIO
Press to select the DVD audio language.
This option works only if the DVD has
multiple audio languages.
9. SETUP
In stop mode, press to bring up the
Setup menu.
10. DISPLAY
Press to display information about
the disc, such as title, chapter number,
track number and time.
11. (next)
 Press to skip forward to the next
chapter or title on a DVD, or track on a
CD.
Press and hold to fast forward playback.
12. ANGLE
Press to switch between multiple
camera angles, if available on the DVD.
13. MEMORY
Press to set titles, chapters and tracks in
a favorite order.
14. SUBTITLE
Press to turn subtitles on and off, or
press to select the subtitle language.
This option works only if the DVD has
subtitles.
RETURN
Press to return to normal operation
after using the Setup menu of a DVD.
Green remote for Unit A

EN - 5
Control Reference Guide
1. VIDEO MODE
Press to adjust brightness, contrast or
screen size.
2. MENU
 Press to enter and exit the main DVD
menu. This option works only if the
DVD has a main menu.
3.
Press to navigate or to adjust settings
in SETUP, GOTO and MEMORY mode.
Press to turn volume down or press
to turn volume up.
ENTER
 Press to conrm selections on the
menu.
4. (previous)
Press to go to the previous chapter or
title on a DVD, or track on a CD.
Press and hold to fast backward
playback.
5. PLAY
Press to start playback. When a disc is
paused press to resume playback.
PAUSE
When a disc is playing, press to pause
playback.
STOP
Press once to stop playback. Your
player remembers where you stopped.
If you press (play), your player
starts playing at the point where you
stopped.
Press twice to stop playback. If you press
(play), your player starts playing at
the beginning of the disc.
6. GOTO
Press to go directly to a location on a
DVD or CD.
7. REPEAT A-B
 Presstorepeataspecicsection(from
point A to point B) of a disc.
REPEAT DISC
Press to repeat a DVD current title,
chapter, a CD track, or entire dics of a
CD.
8. AUDIO
Press to select the DVD audio language.
This option works only if the DVD has
multiple audio languages.
9. SETUP
In stop mode, press to bring up the
Setup menu.
10. DISPLAY
Press to display information about
the disc, such as title, chapter number,
track number and time.
11. (next)
 Press to skip forward to the next
chapter or title on a DVD, or track on a
CD.
Press and hold to fast forward playback.
12. ANGLE
Press to switch between multiple
camera angles, if available on the DVD.
13. MEMORY
Press to set titles, chapters and tracks in
a favorite order.
14. SUBTITLE
Press to turn subtitles on and off, or
press to select the subtitle language.
This option works only if the DVD has
subtitles.
RETURN
Press to return to normal operation
after using the Setup menu of a DVD.
Blue remote for Unit B

EN - 6
Control Reference Guide
1. OPEN
Press to open the disc door. Hold the
front panel when open the disc door.
2. (previous)
Press to go to the previous chapter,
title or track during the disc playback
or to navigate left on a menu.
(next)
 Press to go to the next chapter, title
or track during the disc playback or to
navigate right on a menu.
PLAY/PAUSE
Press to start or pause playback.
STOP/AVIN(UnitAonly)
Press to stop disc playback
Press and hold for 3 seconds to change
to AV IN or DVD mode.
/
Press to adjust volume up and down.
3. Headphone Jack
Plug headphones into this jack. When
headphones are plugged in, sound
does not come out of your player’s
speakers.
4. STANDBY/ONswitch
Slide to change your DVD player to
standby mode or to turn it on.
5. UNITA:TOUNITB/GAMEINjack
UNIT B: TO UNIT A jack
Connect 2 units together via the
connection cable.
Connect to game controller via the AV
cable to GAME IN jack.
6. DC IN Jack
Connect the car power adapter to this
jack.
7. Remote Control sensor
Receives signals from the remote
control. Do not block.
1 2
3
5
6
7
4
Unit A
Unit B
Unit A Unit B

EN - 7
Power Supply
Using the car power adapter with splitter
The included 12V car power adapter splitter allows the units to be used with vehicles that
have a 12V, negative ground electrical system.
Caution:
• Usethisunitonlywiththeincluded12Vcarpoweradapter.Usewithothercaradapters
could damage the unit, or even your vehicle.
• Theincluded12Vcarpoweradapterisforusewiththisunitonly.Donotuseitwithany
other equipment.
• Intheinterestoftrafcsafety,driversshouldnotoperatetheunitorviewvideoswhile
driving.
• Whentheinsideofthe12Vcarsocketisdirtywithashesordust,thepowersectionmay
become hot due to poor contact. Be sure to clean the 12V car socket before use.
• After use, disconnect the 12V car power adapter from both the unit and cigarette
lighter socket.
• Iftheunitisnotproperlyattachedtoavehicle,itmaybecomeairborneintheeventof
an accident and cause damage, injury, or death.
• Checkyourlocaltrafclawsforrulesgoverningtheuseofvideodevicesinvehicles.
WARNING:
Disconnect this car power adapter
when not in use. Not for use in 24V
vehicles.
IMPORTANT
This car adapter
is for use with 12
volt batteries only.
Caution
For continued
protection against
risk of re, replace
only with same type
and rating of fuse.
no use
Car Power
adapter with
splitter
Use both DVD players Use one DVD player only

EN - 8
Connections
Playing a DVD on unit A and B
You can watch the same DVD on unit A and B.
Watching a DVD on unit A and B
1. Connect the unit A and B using the
included connection cable.
2.Press the DVD / AV IN button on the
green remote control or press and hold
the STOP / AV IN button for 3 seconds
on Unit A. “AV IN” will be shown on the
screen on Unit A for a while.
Connection
cable
Unit A Unit B
Slide the STANDBY / ON switch on the
side of the unit to “ON”.
Watch same DVD on both
DVD players
- Select AV IN mode
- “AV IN” will be shown on the DVD
player for a while.
Watch different DVDs on 2
DVD players
- Select DVD mode
- “DVD” will be shown on the DVD
player for a while.
To select “AV IN” or “DVD” mode:
Play games with the included game controller (for Unit A only)
- Select AV IN (VIDEO) mode
- Opening game menu appears on Unit A.
For the operation of the game controller, refer to the game controller’s instruction
manual.

EN - 9
Usingheadphones/earphones
Turn down the volume before connecting
the headphones/earphones. Slowly raise the
volume with the headphones on until you
reach your desired volume. When headphones
are connected, the speaker is automatically
disabled.
Caution:
Avoid listening to sound at excessive levels
which could be harmful to your ears.
Headphones / Earphones
[1/8” (3.5mm) diameter plug)

EN - 10
Placement
Mounting the DVD Player
SAFETY WARNING!
•This unit should never be used by the
vehicle's driver or left unsecured in the
vehicle while driving.
•Ifthisunitisbeingusedinyourvehicle,
be sure that it is secured or held safely,
and does not obstruct any safety device,
including air bags or seat belts.
•All passengers should wear seat belts
when using this unit in a moving vehicle.
•Ifindoubt, pleasecontactyourvehicle
manufacturer for further advice.
• Please pay attention to the actual
situation during usage. Stop using
the unit if there is any uncertainty or
potentially risk.
Unit A Unit B
Car power
adapter with splitter Connection cable
Green
Remote Control
Blue
Remote Control
Mounting
Straps
Mounting in a Vehicle
Connect the connection cable and car power adapter with splitter to both units, make
sure to use correct remote for each unit (green rubber keys remote for green Unit (Unit
A), blue rubber keys remote for blue Unit (Unit B). Tightly wrap the mounting straps
around the headrest.

EN - 11
Placement
Unit A Unit B
Car power
adapter with splitter
Green
Remote Control
Blue
Remote Control
Mounting
Straps
Game Controller
Using of game controller

EN - 12
This owner’s manual explains the basic instructions for operating this unit. Some
DVDs are produced in a manner that allows specific or limited operation during
playback. Therefore, this unit may not respond to all operating commands. THIS
IS NOT A DEFECT. Please refer to the instructions accompanying the specific
DVD in question for more information about the options available on that DVD.
“ ” may appear on the screen during operation. A “ ” means that the
desired operation is not permitted by the unit or disc.
Playing a Disc
1.SlidetheSTANDBY/ONswitchtotheONposition.
See CUSTOMIZING THE DVD FUNCTION SETTINGS before proceeding to step 2.
2. Press the button and hold the front panel to open the disc door.
3. Hold the disc by its edge and gently push it onto the spindle, with the label side facing
the front, until you hear a “click”.
4. Push the disc door gently to close it. It takes a short while for your unit to load the disc.
After loading, for most DVDs, the unit will automatically take you main menu of the
DVD or start playing the DVD.
5. If the unit does not automatically start playing the DVD, press the PLAY button.
Pausing Playback (Still Mode)
Press the PAUSE button. To resume normal playback, press the PLAY button .
For a DVD, each time you press the PAUSE button, the picture advances one frame.
Stopping Playback
Press the STOP button at the location where you want to interrupt playback. To resume
playback at the position where the disc was stopped, press the PLAY button.
If you press the STOP button twice, the unit’s memory will be cleared and pressing the
PLAY button will reset the disc to the beginning.
FastForward/FastReverse
1. Press and hold the or button when a disc is playing. Each time the or
button is pressed, the playback speed changes in the following sequence:
2. Press the PLAY button when you have reached the desired point to resume playback
at normal speed.
Playing a Disc - Basic Functions
Unit Operation
Turning the unit on
1.SlidetheSTANDBY/ONswitchontheDVDplayertotheONposition.
2. The start-up picture will appear on the screens.
3.Afteruse,slidetheSTANDBY/ONswitchontheDVDplayertoSTANDBY(poweroff).

EN - 13
Notes:
•TheDVDplayermutessoundandsubtitlesduringreverseandforwardscanofDVDs.
•Thefastplaybackspeedmaydifferdependingonthedisc.
Skip(Forward/Reverse)
• Pressthe NEXTbuttontoadvancetitles,chapters/tracks.
• Pressthe PREVbuttontogobacktocurrentorprevioustitles,chapters/tracks.
Audio Selection
On some DVDs, the sound is recorded in two or more formats. Follow the directions
below to select the preferred language and sound system.
1.PressAUDIObuttononcewillswitchtonextaudioformatnumber.
2. Press the AUDIO button repeatedly to select the desired audio format.
Note:
• IfonlyoneaudioformatisrecordedontheDVD,thenumberdoesnotchange.
• SomeDVDsallowyoutochangeaudioselectionsusingthediscmenuonly.Ifthisisthe
case, press the MENU button and choose the appropriate language on the disc menu.
• Youcanselectdifferentaudiochannels(Stereo,MonoLeft,MonoRightorMix-Mono)
on an Audio CD by pressing the AUDIO button repeatedly.
Subtitle Selection
1.WhileaDVDisplaying,presstheSubtitlebutton,itwillshowthenextsubtitle.
2. Press the SUBTITLE button repeatedly to select the desired subtitle language. You can
turn subtitles off by pressing the SUBTITLE button repeatedly until the
is displayed.
Note:
• SomeDVDsare set todisplaysubtitlesautomatically,and you cannotturnthemoff
even if you set the subtitle function to off.
• Duringsomescenes,thesubtitlesmaynotappearimmediatelyafteryouselectyour
desired scene.
• Thenumberofsubtitlelanguagesrecordeddiffersdependingonthedisc.Ifonlyone
language is recorded, the language does not change.
• This function can only be used for discs on which subtitles have been recorded in
multiple languages.
• SomeDVDsallowyoutochangesubtitlesusingthediscmenuonly.Ifthisisthecase,
press the MENU button and choose the appropriate subtitle on the disc menu.

EN - 14
Display function (DVD)
While the disc is playing, press the DISPLAY button repeatedly to display information on
operation status:
Adjust the LCD screen
For the DVD player, you can adjust brightness, screen size and contrast of the screen.
1. Press the VIDEO MODE button.
2. Press the or button to select brightness, screen size or contrast.
3. Then press the or to change the setting.
4.PresstheVIDEOMODEbuttonagaintoexitthemenu.
Angle Selection
Some DVDs contain scenes that have been
shot from a number of different angles. For
these discs, the same scene can be viewed
from each of these different angles.
1. While you are playing a DVD with different
angles recorded, press the ANGLE button
to view the number of current angles
available.
2.PresstheANGLEbuttonrepeatedlytochangethescenetothenextrecordedangle.
• Afterapprox.twoseconds,playbackwillcontinuefromthenewangleselected.
• Ifnobuttonispressedwithin10seconds,playbackcontinueswithoutchangingthe
current angle.
Note: This function can only be used for discs on which scenes shot from multiple angles
have been recorded.

EN - 15
Repeat Playback
YoucanplayaspecicDVDtitleorchapterrepeatedly(titlerepeat,chapterrepeat,A-B
repeat).
Repeating a Chapter
1. While the DVD is playing, press the REPEAT DISC button until the indicator
displays on the screen. The current chapter is played repeatedly.
Repeating a Title
2. While the DVD is playing, press the REPEAT DISC button until the indicator
displays on the screen. The current title is played repeatedly.
To Resume Normal Playback
3. While the DVD is playing, press the REPEAT DISC button until the indicator
displays on the screen.
Repeating a Single Track
You can play a single CD track or the whole disc repeatedly.
1. While the CD is playing, press the REPEAT DISC button until the Track indicator
displays on the screen. The current track is played repeatedly.
Repeating the Whole Disc
2. While the CD is playing, press the REPEAT DISC button until the All indicator
displays on the screen. The whole disc is played repeatedly.
To Resume Normal Playback
3. While the CD is playing, press the REPEAT DISC button until the indicator
displays on the screen.
RepeatingaSpecicSection
Youcanplayaspecicsectionrepeatedly.
1. While the disc is playing, press the REPEAT A-B button at the beginning of the section
(is displayed) you want to play repeatedly.
2. Press the REPEAT A-B button again at the end of the section ( is displayed).
3. The unit will immediately begin replaying your selection.
To Resume Normal Playback
4. While the disc is playing, press the REPEAT A-B button until the indicator
displays on the screen (the repeat indicator disappears from the screen for a CD). The
system will return to normal playback.
Note:
• SomediscsmaynotpermitA-Brepeatoperation.
• Youcanspecifyasegmentonlywithinthecurrenttitleortrack.
• Theremay beaslightdifferencebetweenpointAandthe locationwhereplayback
actually resumes depending on the disc.

EN - 16
LocatingaSpecicChapter/Title
If you know the chapter/title number for the chapter/title that you want to play, you can
locate it by directly selecting that number.
1. Press the GOTO button.
2. Press the / buttontohighlightchapter/titlenumber,thenpressthe or button to
select thechapter/titleyouwant.PresstheENTERbuttontoconrm.
3.Playbackstartsfromtheselectedchapter/title.
Note:
• Somediscsmaynotrespondtothisprocess.
• Thismethodoflocatingachapter/titleisavailableonlyonaDVDthatcontainschapter/title
numbers.
LocatingaSpecicTime
Youcanmovetoaspeciclocationbyenteringitscorrespondingtime(hours,minutes,
seconds).
1. Press the GOTO button two times.
2. Press the or button to select the setting point you want.
3. Playback starts from the selected section.
Note:
• IfthetimeenteredisnotpermittedbytheDVD, will display. You should
re-enter the correct time.
• Somediscsmaynotrespondtothisprocess.
• Somescenesmaynotbelocatedaspreciselyasyouspecied.
• Thismethodforaccessingspeciclocationsisavailableonlywithinthecurrenttitleof
the DVD.
Locating a Desired Section
::

EN - 17
This unit can play JPG les recorded on a CD-R or CD-ROM disc (CD-RW is not
recommendable).
Viewing JPG Files
1. Open the disc door.
2.HoldaJPEGlediscbyitsedgesandgentlypushitontothespindlewiththelabelside
facing up until you hear a “click”.
3.Closethediscdoor.TheJPEGlesonthediscwillbedisplayedonebyoneautomatically.
If the disc does not play automatically, press the PLAY button.
4. Press the STOP button to display a folder list. Press the / button to highlight a
JPEGletoplay.Pressthe PLAY button to start playback.
Viewing JPG Files
Note:
• Youcanpressthe PAUSE button to freeze the picture. Press the PLAY button to
resume picture slide show.
• Youcanpressthe STOP button to quit playback.
• Youcanpressthe PREV or NEXT button to change the picture.
• You can press the ANGLE button on the remote control to rotate direction of the
picture by 90°.
• Somediscsmaynotpermitthisoperation.

EN - 18
Clear: Delete all the input programs.
Exit: Exitmemorymenuandreturnto
normal playback.
Start: Start memory playback.
Next/Prev:Movetothenext/previoussetup
page.
Programmable Memory
Youcancombineyourfavoritetitles/chaptersandplaythemintheorderyoudetermine.
1. Press the MEMORY button while a DVD is playing. The following display appears.
2. Press ENTER button and use the / buttons on the remote control to select desired
title and chapter number. Press ENTER button again it will move to the next item
automatically.
•YoucanusetheCursorbuttons( , , , ) to move the highlighted bar to any item,
and re-enter the title and chapter. (Press the NEXT/ PREVtomovetothenext/
previous setup page.)
•YoucanusetheCursorbuttons( , , , ) to move the highlighted bar to “Clear”,
“Exit”,“Start”or“Next/Prev”,andpresstheENTERbuttontoconrm.
3. Press the PLAY button to start memory playback. (“ ” appears on the
screen.)
4. To resume normal playback from memory playback
• PresstheMEMORYbuttontodisplaythememorymenu.
• UsetheCursorbuttons( , , , ) to move the highlighted bar to “Stop”. Press the
ENTERbuttontoconrm“Stop”.
• UsetheCursorbuttons( , , , ) to highlight “Clear”, and then press the ENTER
buttontoconrm.
• Use the Cursor buttons ( , , , ) to highlight “Exit”, and then press the ENTER
buttontoconrm.Itwillreturntonormalplayback(“ ” disappear from the
screen.)
Note:
•IfthetitleorchapternumberenteredisnotpermittedbytheDVD,itwilldisappear.
You should re-enter correct number.
•Youshouldinputitemsonebyonefollowingthe1,2,3...sequence.
•IftheDVDcontainsonlyonetitle,youcanonlyarrangeorderforchapters.
•Somediscsmaynotpermitmemoryplaybackoperation.
•If you select repeat during memory playback, the DVD player repeats the current
memory playback.
•The programmed selections will be cleared when youpressthe STOP button two
times, open the disc tray or turn off the DVD player.

EN - 19
Customizing the DVD Function Settings
Language Setup
1. Press the SETUP button on the remote control in
stop mode (when disc is not playing).
2. Press the button to select Language Menu.
3. Use the or button to select the option (Player
Menu, Audio, Subtitle or Disc Menu), then press
the button.
4. Use the or button to select your preferred
language, then press the ENTER button to
conrm.
5. Press the button to go back to the previous
menu. Repeat steps 3 and 4 to adjust other
options.
6.ToexittheSETUPMENUandreturntothenormal
screen, press the RETURN or SETUP button.
Language Menu
Player Menu
Language Menu
Video Setup
1. Press the SETUP button on the remote control in
stop mode (when disc is not playing).
2. Press the or button to select Video Menu.
3. Use the or button to select the option
(Brightness or Contrast), then press the
button.
4. Use the or button to make adjust the
setting,thenpressENTERbuttontoconrm.
5. Repeat steps 3 and 4 to adjust other options.
Press the button to return to the previous
menu.
6.To exit the SETUP MENU and return to the
normal screen, press the RETURN or SETUP
button.
Video Menu
Video Menu
Note:
• Some DVDs may not play in the audio language selected. A prior language may be
programmed on the disc.
• SomeDVDsmaybesettodisplaysubtitlesinalanguageotherthantheoneselected.A
prior subtitle language may be programmed on the disc.
• SomeDVDsallowyoutochangesubtitleselectionsviathediscmenuonly.Ifthisisthecase,
press the MENU button and choose the appropriate subtitle from the selection on the disc
menu.
• Some DVDs may not included your pre-selected language. In this case, the DVD player
automatically displays disc menus consistent with the disc’s initial language setting.

EN - 20
TV Display
Pan Scan
• When wide-screen video is played, this mode clips the right
and left sides of the image so that it can be viewed on a
conventional screen.
• Some wide-screen DVDs that do not permit Pan Scan mode
playback are automatically played in letterbox mode (black
bands that appear at the top and bottom of the screen).
LetterBox
• When wide-screen video is played in this mode on a
conventional screen, black bands appear at the top and bottom
of the screen.
Wide Screen
• Thisisthecorrectmodeforplayingwide-screenvideosonthe
unitscreenorotherexternalwide-screens.
Note:
• ThedisplayablepicturesizeispresetontheDVD.Thereforethe
playback picture of some DVDs may not conform to the picture
size selected.
• When you play DVDs recorded in the 4:3 aspect ratio, the
playback picture will always appear in the 4:3 aspect ratio
regardless of the TV display setting.
• Select Wide Screen to conform the LCD screen on the unit.
Always be sure that your TV display conforms to the actual TV
in use if you connect the unit to a TV.
Default
It takes 3-5 seconds to reset the DVD settings to the factory
default.
Cut off when a
wide-screen video
image is played
Pan Scan
LetterBox
Wide Screen
System Setup
1. Press the SETUP button on the remote
control in stop mode (when disc is not
playing).
2. Press the or button to select System
Menu.
3. Use the or button to select the option
(Tv Display or Default), then press the
button.
4. Use the or button to adjust the
settings, then press ENTER button to
conrm.
5. Repeat steps 3 and 4 above to adjust other
options. Press the button to return to
the previous menu.
6.ToexittheSETUPMENUandreturntothe
normal screen, press the RETURN or SETUP
button.
