real living Teal Mesh HG-3079-10 User manual

Assembly Instruction
Item No. :HG-3079-10
SKU No. :810469335
Description:Teal Mesh Office Chair
WARNING
Caution: Adult assembly required.
Assemble on soft surfaces to prevent damage to the product finish.
DO NOT use power tools.
CARE AND CLEANING
DO NOT scratch or chip the finish. DO NOT use abrasive chemicals for cleaning.
Clean with dry cloth thoroughly.
MAINTENANCE
Check bolts/screws periodically and tighten if necessary.
WARNING: Should this product become damaged, and/or components are broken or
missing, DO NOT USE.
For spare hardware, please contact Big Lots Customer Care
Tel:[phone] E-Mail:[e-mail]
Page 1 of 5

Page 2 of 5
Tools Required
Allen key
(Included)
Hardware
included
7PCS
A
The above diagram is a guide to
help you to identify the different
parts of the unit when removing
them from the packaging. Please
follow the listed steps in order to
complete the assembly process.
2PCS
B
2
5
1
3
4
6
7
8
9

STEP2
Turn part (2) onto the
wheels. Insert part (3)
into the center hole of
part (2) as shown in
the diagram.
STEP1
Insert part (1) into part (2)
as shown in the diagram.
1
2
3
4
Page 3 of 5

STEP3
STEP4
Page 4 of 5
Align the holes in part (5) with
the holes in part (6). Using
screws (A) and Allen Key, attach
part (5) to part (6) as shown in
the diagram. Fully tighten all
screws.
Align the holes in part (7) with the
holes in part (5). Using screws (B)
and Allen Key, attach part (7) to
part (5) as shown in the diagram.
Fully tighten all screws.
AA
AA
6
5
B
5
67

Page 5 of 5
STEP5
STEP6
Printed In China
Align the holes in part (9) with
the holes in part (7). Using
screws (A) and Allen Key, attach
part (9) to part (7) as shown in
the diagram. Fully tighten all
screws. Attach part (8) to cover
the screws.
Align the center hole of part (5)
with the top of part (3) and
press firmly into place.
Assembly is now complete.
Use the lever to raise and
lower the seat as desired.
9
7
8
A
3
5
