real living FP-P-2202 User manual

1. Need at least two adults to assemble this fireplace.
2. Assemble on soft , smooth surface to protect finish from being scratched.
3. DO NOT use power tools.
4. Remove all packaging material, make sure all parts are present before assembly.
5. Estimated Assembly Time: 1 hour 15 minutes. Exact assembly times will vary based on skill level and
past assembly experience.
6. Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote
control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result
the furnishing may tip over on to the child.
7. Relocating audio and/or video equipment to furniture not specifically designed to support audio and/or video
equipment may result in death or serious injury due to the furnishing collapsing or over turning onto a child.
8. To prevent serious injury or death, this product is equipped with a wall anchoring system. Before this product
can be used, the wall anchoring system must be installed as directed in the assembly instructions.
Read all instructions before starting
Clear a flat covered space to begin
We recommend 2 adults for assembly
Note that hardware required is provided for every step
Pay attention to orientation
Letter of the part corresponds to a sticker on the product
Number of the hardware corresponds to its number in the package
Helpful hints provided along the way
GENERAL BEST PRACTICES FOR ASSEMBLY
WARNINGS
MAINTENANCE
1. Clean periodically by wiping the product with a soft clean cloth.
2. Do not expose your product to any liquids. All liquids should be wiped up immediately with a soft, slightly
damp cloth in the direction of wood grain.
3. Do not expose your product to strong or direct sunlight, near heat outlets or air conditioning units, open
windows or dampness. Excessive exposure to sunlight and heat can cause fading of your furniture finish.
Extreme temperatures and humidity changes can cause wood cracking and splitting.
4. Clean using a glass/mirror cleaner and soft cloth. Do not use cleaning products containing abrasives,
as these will scratch glass/mirror.
!

TELEVISION
MAXIMUM FLAT PANEL: 48”
MAXIMUM LOAD: 60 POUNDS
BASE
MAXIMUM LOAD: 25 POUNDS
WARNING
!
MANUFACTURER: YOUNG CHAIN CO.,LTD
ITEM#: FP-P-2202
DISTRIBUTION: Big Lots Stores, Inc.
ADDRESS: P.O. BOX 28523, COLUMBUS,OH 43228-0523
COUNTRY OF ORIGIN: VIETNAM ;
MANUFACTURE DATE: 2022.05
SMALL SHELVES
MAXIMUM LOAD: 25 POUNDS
MIDDLE SHELF
MAXIMUM LOAD: 25 POUNDS
FOR USE WITH TELEVISIONS WEIGHTING 60 LBS (27.18 KG) OR LESS.
USE WITH HEAVIER TV MAY RESULT IN INSTABILITY CAUSING TIP OVER
RESULTING IN DEATH OR SERIOUS INJURY.
CAUTION
This Fireplace (FP-P-2202) is designed for flat panel LCD TVs weighing up to 60 lbs.
For items other than flat panel LCD TVs, this fireplace will support up to 135 lbs when the item is placed evenly
on the top surface. Use with other products may results in instability causing possible injury.
!

1PC
TOP
1PC1PC
BASEMIDDLE SHELF
1PC
BASE FRAME B
1PC1PC
1PC
BASE FRAME E
BASE FRAME A
1PC
BASE FRAME C
2PCS 2PCS 2PCS
SIDE PANEL PARTITION FRONT POST
BACK POST
1PC
BASE FRAME F
2PCS
INSERT STAND A
BACK PANEL
DOOR
1PC
1PC
2PCS
PART LIST
2PCS
SMALL SHELF
1PC
INSERT FIREPLACE
HEATER
BASE FRAME D
INSERT STAND B
2PCS

55pcs
CAM BOLT
55pcs
CAM LOCK
47pcs
WOOD DOWEL
3pcs
BOLT
9pcs
ROUND HEAD SCREW
5pcs
ROUND HEAD SCREW
2pcs
DOOR BLOCK
9pcs
SHELF PIN
4pcs
DOOR HINGE
25pcs
FLAT HEAD SCREW
17pcs
STICKER
1pc
TOUCH-UP PEN
HARDWARE LIST
1set
ANTI-TIPPING NOT PROVIDED
2pcs
KNOB

HELPFUL HINTS
1. Screw the cam bolt into the predrilled panel. The cam bolt should be tightened
so no threads are visible.
2. The larger ring of the cam should touch the panel.
3. Insert the cam lock into the predrilled hole in the panel. Arrow faces the
outside of the panel.
4. Connect the previously tightened cam bolt with the panel connected into the
cam lock.
5. Using a flat head screw driver, turn the cam lock halfway clockwise to secure
the cam bolt.
6. FAILURE TO PROPERLY SECURE THE CAM LOCK AND CAM BOLT COULD RESULT
IN PRODUCT INSTABALITY AND FAILURE.
RING
SHOULD
TOUCH THE
BOARD
1 2 3
456

STEP 1
STEP 2
Not provided
Figure 1
8pcs
Figure 2
Assembled View:
Assembled View:
Not provided
4pcs 2pcs
14pcs 12pcs
Place Top (A) on a soft smooth surface. The side with the most holes should be facing up. Insert the
Cam bolt (H1) into the corresponding hole of Top (A) using the screwdriver (Not provided).
Align the Door block (H8) with the pre-drilled pilot holes in the Top (A) and attach with Round head
screw (H7) using screwdriver (Not provided) as shown in figure 1.
Place Base (C) on a soft smooth surface with the side facing up as shown in figure 2. Insert the Cam bolt
(H1) into the corresponding hole of Base (C) using the screwdriver (Not provided). Insert Wood dowels (H3)
into the remaining holes as shown in figure 2.

STEP 3
STEP 4
Figure 3
Figure 4
2pcs
Assembled View:
Assembled View:
2pcs
Not provided
Place Base frame D (G), Base frame C (F) on a soft smooth surface with the holes facing up. Insert the
Cam bolt (H1) into the corresponding hole of Base frame D (G), Base frame C (F) using the screwdriver
(Not provided) as shown in figure 3.
Place Base frame D (G), Base frame C (F) on a soft smooth surface. Insert the Cam Bolts (H1) of Base
frame D (G), Base frame C (F) into the corresponding holes of Base frame F (I), Base frame E (H) and
secure in place using Cam lock (H2) using the screwdriver (Not provided) as shown in figure 4.
Not provided

STEP 5
STEP 6
Figure 5
Assembled View:
Not provided
14pcs
Place Base (C) on a soft smooth surface as shown in figure 5. Align the corresponding holes of Base frame
C (F), Base frame D (G), Base frame E (H) and Base frame F (I) with the Cam Bolts (H1) and Wood
dowels (H3) of Base (C) and slide into place. Secure the panels together with Cam lock (H2) using
screwdriver (Not provided) as shown in figure 5.
Align the corresponding holes of Base frame A (D), Base frame B (E) with the Cam Bolts (H1) and Wood
dowels (H3) of Base (C) and slide into place. Secure the panels together with Cam lock (H2) using
screwdriver (Not provided) as shown in figure 5.
Turn over the Base (C) like the figure shown below.
Insert the Cam bolt (H1) into the corresponding hole of Base (C) using the screwdriver (Not provided).
Insert Wood dowels (H3) into the corresponding holes as shown in figure 6.
Assembled View:
10pcs 10pcs
Figure 6
Note : Make sure edge of both
panel are aligned and even
before secure Cam lock.

Figure 8
Not provided
Place Partition (K), Back post (M), Front post (L) on a soft smooth surface. The side with the most holes
should be facing up. Insert Cam bolt (H1) into the corresponding holes of Partition (K), Back post (M),
Front post (L) using the screwdriver (Not provided) as shown in figure 8.
Repeat these same steps for another Partition (K), Back post (M), Front post (L) as shown in figure 8.
STEP 7
STEP 8
Assembled View:
Figure 7
Assembled View:
Align the corresponding holes of Insert stand A (Q) with the Cam Bolts (H1) and Wood dowels (H3) of
Base (C) and slide into place. Secure the panels together with Cam lock (H2) using screwdriver (Not
provided) as shown in figure 7.
Not provided
2pcs
16pcs

STEP 9
STEP 10
Figure 9
Assembled View:
4pcs
With assistance from another adult, hold Middle shelf (B) and Partition (K) vertically as shown in figure 9.
Insert Wood dowels (H3) into the corresponding holes of Middle shelf (B) as shown in figure 9. Slide the
Cam bolts (H1) of Partition (K) into the corresponding holes of Middle shelf (B) and secure in place with
Cam lock (H2) using screwdriver (Not provided).
Repeat this process to attach another Partition (K) to Middle shelf (B) as shown in figure 9.
Not provided
4pcs
Assembled View:
6pcs 8pcs
With assistance from another adult, hold Partition (K) vertically. Insert Wood dowels (H3) into the
corresponding holes of Partition (K). Insert the Cam Bolts (H1) of Back post (M) into the corresponding
holes of Partition (K) and secure in place using Cam lock (H2) as shown in figure 10.
Note:Make sure the top ends should are flush for all parts.
Repeat these same steps for another Back post (M).
Figure 10

Figure 12
Assembled View:
4pcs
With assistance from another adult, hold Middle shelf (B) and Partition (K) vertically as shown in figure 12.
Align the corresponding holes of Partition (K) with the Cam Bolts (H1) and Wood dowels (H3) of Base (C)
and slide into place. Secure the panels together with Cam lock (H2) using screwdriver (Not provided) as
shown in figure 12.
Not provided
STEP 11
STEP 12
Figure 11
Assembled View:
6pcs
Insert the Cam Bolts (H1) of Front post (L) into the corresponding holes of Partition (K) and secure in place
using Cam lock (H2) as shown in figure 11.
Note:Make sure the top ends should are flush for all parts.
Repeat these same steps for another Front post (L).
Not provided
Back side
Front side

STEP 13
STEP 14
Insert Cam bolt (H1) into the corresponding holes of Base (C) using the screwdriver (Not provided). Insert
Wood dowels (H3) into the remaining holes as shown in figure 14.
Insert Wood dowels (H3) into the corresponding holes of Side panel (J) and Partition (K) as shown in figure
14.
Assembled View:
4pcs 12pcs
Figure 14
Note : Edge with edge banding.
Figure 13
Assembled View:
4pcs
Not provided
Align the corresponding holes of Side panel (J) with the Cam Bolts (H1) and Wood dowels (H3) of Base
(C) and slide into place. Secure the panels together with Cam lock (H2) using screwdriver (Not provided)
as shown in figure 13.
Note: Shorter screwdriver is recommended for assembly the cam lock.
Note : Edge
with edge
banding.

STEP 15
STEP 16
With assistance from another adult, hold Top (A) as shown in figure 15. Align the Cam Bolts (H1) of Top
(A) with the corresponding holes of Side panel (J) and Partition (K) and slide into place. Secure the
panels together with Cam lock (H2) using screwdriver (Not provided) as shown in figure 15.
Note: Shorter screwdriver is recommended for assembly the cam lock.
Assembled View:
8pcs
Not provided
Align the corresponding holes of Insert stand B (R) with the Cam Bolts (H1) and Wood dowels (H3) of
Base (C) and slide into place. Secure the panels together with Cam lock (H2) using screwdriver (Not
provided) as shown in figure 16.
Assembled View:
4pcs
Figure 16
Not provided
Figure 15
Note : For easy assembly holes
for Cam lock should face
inwards.

STEP 17
STEP 18
4pcs 8pcs
2pcs
Figure 17
2pcs
Figure 18
Assembled View:
Assembled View:
Place the Door (O) on a soft smooth surface with the large holes facing up. Align the holes of Door hinge
(H10) with the pre-drilled holes of the Door (O) as shown in figure 17. Secure Door hinge (H10) in place
with Flat head screw (H11) using screwdriver (Not provided) as shown in figure 17.
Repeat these same steps for another Door (O).
With assistance from another adult, hold the Door (O) vertically and attach Knob (H4) to the middle of
the door with Bolt (H5) using screwdriver (Not provided) as shown in figure 18.
Repeat these same steps for another Door (O).

STEP 19
Figure 19
Figure 20
Assembled View:
Assembled View:
1
2
If the gap between the Door and Partition is not equal, adjust
this screw on each hinge until the gap is even.
Tighten this
screw after
adjusting.
Not provided
16pcs
8pcs
Not provided
With assistance from another adult, align the holes of Door hinge (H10) on the Door (O) with the
punctures in Side panel (J) and secure in place with Flat head screw (H11) using screwdriver (Not
provided) as shown in figure 19. Fully tighten all screws.
Repeat this process to attach another Door (O) to Side panel (J).
Align the holes in Back panel (P) with the pilot holes in Top (A). Secure Back panel (P) in place with
Round head screw (H6) using screwdriver (Not provided) as shown in figure 20.
STEP 20

8pcs
Figure 21
Figure 22
Assembled View:
Insert Shelf pins (H9) into Side panel (J) and Partition (K). Tilt Small shelf (N) at an angle into the mantel
and place it on Shelf pins (H9) as shown in figure 21.
STEP 21
STEP 22
Cover any visible Cam lock (H2) using Sticker (H13) as shown in figure 22.
Wood Mantel assembly is completed.
Note: Please read the instruction booklet for the assembly and function Insert Fireplace Heater and
remote control before using Fireplace.

Secure
bracket at
the
center of
the top.
STEP 23
Install the Anti-Tip Hardware (H14) to secure the stand to the wall and prevent tip over.
a) Install one bracket to each top back middle of the Console Fireplace.
b) Place the stand in the desired location and mark where the installed bracket meet the wall.
c) Remove the stand and using the remaining bracket. Mark the position for the mounting hole.
d) Attach the bracket to the wall with the provided screw.
e) Return the fireplace to the desired location and attach the Bracket on the fireplace to the bracket
on the wall using the plastic tie.
NOTE: Please insure Fireplace heater is plugged in and working correctly before securing the
Anti-tipping Strip to the Wall.
PRINTED IN VIETNAM MADE IN VIETNAM
Wall
Wall
