RealFlame C1460LP User manual

C1460LP Berthoud Fire Pit NG Conversion Kit
Improper installation, adjustment,
alteration, service or maintenance
can cause property damage
personal injury, or loss of life.
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
!!
IMPORTANT WARNING
SAVE THESE INSTRUCTIONS
!DANGER
If you smell gas:
gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and
immediately call your gas supplier or fire department.
USC
For Technical Support Please Contact Real Flame® At: 1-800-654-1704

PARTS LIST 00023105G
1
2
3
NATURAL GAS CONVERSION KIT
NOTE
This conversion kit is for changing a Liquefied Petroleum (LP) fire table into a Natural Gas
fire table.
!
WARNING
!
Natural Gas Hose and Quick Disconnect
NG Orifice Spud 3.9mm
Primary Air Mixer Sleeve
4
4
5
Conversion Plaque
Cable Kit
3
1
2
5
1
• If the information in these instructions is not followed exactly, a fire, explosion or
production of carbon monoxide may result causing property damage, personal injury
or loss of life.
• The qualified service agency is responsible for the proper installation of this kit. The
installation is not proper and complete until the operations of the converted appliance
is checked as specified in the manufacturer’s instructions supplied with this kit.
• This conversion kit shall be installed by a qualified service agency in accordance with
Real Flame’s instructions and all applicable codes and requirements of the authority
having jurisdiction.
#3.9mm
C1460LP
50,000 BTU/Hr. (14.65 kW)

NATURAL GAS CONVERSION
2
2.) Disconnect LP hose from valve.
1.) Flip the fire pit upside down. Place on a soft surface to avoid damaging
the finish.

NATURAL GAS CONVERSION
3
3.) Disconnect bellows (Corrugated Stainless Steel Tube/CSST) from
burner base.
Bellows

4
NATURAL GAS CONVERSION
4.) Remove the existing LP orifice spud.
LP Orifice Spud

5
NATURAL GAS CONVERSION
5.) Locate the new NG orifice spud, verify it is the correct number.
The sign 3.9 mm should be on the end of the orifice spud.
6.) Slip sleeve over primary air opening. See fig. 1.
Next, screw the new NG orifice spud into the burner base. See fig. 2.
3.9
Sleeve
Primary Air
Opening
NG Orifice Spud
1 2

6
NATURAL GAS CONVERSION
7.) Re-attach bellows (CSST) to new spud.
Bellows

7
8.) Attach NG hose to the input side of the valve.
9.) Attach quick disconnect to gas supply.
NATURAL GAS CONVERSION
House Natural Gas Piping
Shut-o Valve
Quick Disconnect Socket
NG Gas Hose
To Fire Table

10.) After installing the conversion kit, verify the location of the
thermocouple and igniter Pin using the illustration below.
Installing at Altitude
For installations at elevations above 2,000 ft., contact your local dealer or gas
supplier before installing because input rating should be reduced
approximately 4% for each 1,000 ft. above sea level. Refer to the National Fuel
Gas Code. Contact Real Flame for more information at 1-800-654-1704.
11.) Note to installation technicians: Verify the manifold pressure by using a
3/8” flared T-junction at the location marked by the arrow below. Then, using
a digital manometer, verify that the pressure before the orifice is 7” W.C. Also
verify that the orifice spud has the 3.9 mm stamp. This will allow you to verify
that the input rating of the appliance is correct.
NATURAL GAS CONVERSION
8
NOTE: Igniter housing removed for example only.
To Manometer
5mm
Thermocouple
Igniter

13.) Cut the existing French plaque from the control panel using wire cutters. Re-attach
French plaque and NG conversion plaque included with this kit to the fire pit using
the included cable kit.
Cut Cable Re-attach both plaques
NOTE: The normal manifold pressure for this converted appliance is 7” water column.
NOTE: The maximum inlet gas pressure for this unit is 10.5 in W.C. (2.61 kPa).
The minimum inlet gas pressure for this unit is 3.5 in W.C. (0.87 kPa).
NATURAL GAS CONVERSION
WARNING
!
Check for leaks at these locations
12. CHECKING FOR LEAKS
Make a leak check solution by mixing 1 part dishwashing soap
with 3 parts water in a spray bottle.
Make sure the re pit control knob is “OFF.” Then, turn the natural
gas on at its source.
Spray leak solution on the valve connections, paying particular
attention to the areas indicated by the arrows.
If any bubbles appear turn the natural gas o at its source,
reconnect and re-test. If you continue to see bubbles after several
attempts, disconnect the natural gas source and contact Real
Flame® at 1-800-654-1704 for assistance.
If no bubbles appear after one minute, turn the gas
source “OFF”, wipe away solution and proceed to next
step.
9
Before using this outdoor fire pit, make sure you have read, understand and are following all
information provided in the Important Safety Information section of this manual. Failure to
follow those instructions can cause property damage, serious injury or death.
French
French
NG
Conv.

14.) Lighting
Lighting Instructions
LIGHT
LOW
Control Knob
PUSH
IN
8-13”
20.3 - 30.5 cm
10
1. Read and understand all operating instructions before lighting.
2. Burner control knob must be in the OFF position.
3. Ensure that gas supply is connected and open.
4. Push and hold igniter button to create sparks.
5. While holding the igniter button with one hand, use your other
hand to push and turn the control knob to the LIGHT position
to ignite the burner.
6. Keep burner control knob pressed in for 15-30 seconds
after ignition.
7. If ignition does not occur in 15 seconds, turn control knob to
the OFF position and turn gas o at the source; wait 5
minutes until gas has cleared and repeat lighting procedure.
8. After lighting, rotate the burner control knob counter
clockwise to LOW setting. Observe flame; to make sure all
burner ports are lit.
9. Adjust the flame to the desired height with the
control knob. Flames should be between 8-13” in height.
1. Wearing heat-resistant gloves, position the burning
long match or extended lighter near the side of
the burner. DO NOT lean over the fire pit while
lighting.
2. Turn control knob counterclockwise to LIGHT.
3. Remove long match/extended lighter.
4. After lighting, rotate the burner control knob counter
clockwise to LOW setting. Observe flame; make sure
all burner ports are lit.
5. Adjust the flame to the desired height with the
control knob.
6. Replace the battery as soon as possible.
When using this method to light yourfire pit use heat-resistant gloves and follow the step-
by-step instructions. Failure to do so could result in severe injury.
If burner flame goes out during operation, immediately turn the control knob OFF position and
let the gas clear a minimum of 5 minutes before attempting to re-light the fire pit.
Using the Igniter
!
!WARNING
WARNING
If battery is dead you may TEMPORARILY use
a long match or extended butane lighter
If doing so:

NOTES AND TECHNICAL SUPPORT
Type of Gas / Type de gaz: NG/Natural Gas
Normal Hourly Input/Entrée horaire normal:
50,000 BTU/Hr. (14.65 kW)
Manifold Pressure/Pression d'admission:
7.0” water column (1.74 kPa)
The minimum inlet pressure for this fire table is:
3.5” water column (0.87 kPa)
The maximum inlet pressure for this fire table is:
10.5” water column (2.61 kPa)
®
USC
This appliance was converted on _________________
(DD/MM/YY)
to Natural Gas with Kit No._______________________
(Found on Box)
by___________________________________________,
(Name and address of organization making this conversion)
which accepts the responsibility that this conversion has
been properly made.
For additional technical support call: 1-800-654-1704
Cet appareil a été converti le
en gaz naturel avec le kit no.
par
NOTES: ______________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
11

Une mauvaiseinstallation,
d’ajustement, modification,
service ou d’entretien peut
causer des blessures ou des
dommages matériels.
Lisez l’installation, l’opération et
des instructions de maintien à
fond avant stallation ou
entretien de cet équipement.
!!
IMPORTANT
!DANGER
immédiatement votre fournisseur de gaz ou le service des incendies.
C SU
our le support technique veuillez contacter ame à
AVERTISSEMENT
CONSERVEZ CES INSTRUCTIONS
Kit de conversion NG de C1460LP Berthoud table-foyer

LISTE DES PIECES 00023105G
1
2
3
KIT DE CONVERSION DU GAZ NATUREL
NOTE
Ce kit de conversion est pour changer un table de feu de Pétrole Liquéfié (LP) dans une
table de feu de Gaz naturel.
!
Tuyau de gaz naturel et déconnexion rapide
Patate d’orifice NG # 3.9 mm
Gaine de mixage d’air principal
4
4
5
Plaque de Conversion
Kit de câble
3
1
2
5
!
AVERTISSEMENT
1
• Si l’information dans ces instructions n’est pas suivi exactement, un incendie, une
explosion ou la production de monoxyde de carbone peut causer des dommages
matériels, des blessures corporelles ou la pertes de vie.
• Le service d’entretien qualifié est responsable de l’installation appropriée de ce kit.
L’installation n’est pas bon et complet jusqu’à la fonctionnement de l’appareil converti
est contrôlé comme spécifié dans les instructions du fabricant fournies avec ce kit.
• Ce kit de conversion doit être installé par un service d’entretien qualifié con aux
instructions du Real Flame et tous les codes applicables et les exigence l’autorité
ayant la Juridiction.
C1460LP
50,000 BTU/Hr. (14.65 kW)
#3.9mm

CONVERSION DU GAZ NATUREL
2
1.) Retournez la foyer sur son côté. Placez sur une surface souple pour
éviter d’endommager la finition.
2.) Débranchez le tuyau LP de la valve.

CONVERSION DU GAZ NATUREL
3
3.) Débrancher le souet (Tubes en acier inoxydable ondulé/CSST)
de la base de brûleur.
Souets

4
CONVERSION DU GAZ NATUREL
4.)
Orifice de patate LP

5
CONVERSION DU GAZ NATUREL
5.)
numéro. Le numéro 3.9 mm devrait être sur l’extrémité d’orifice de patate.
6.) issez le gaine sur l’ouverture aérienne princiir fig.
Ensuite, vissez la nouvelle patate d ifice N ans la base de brûleur.
ir fig.
3.9
Gaine
L’ouverture
d’air principal
Patate d’orifice NG
1 2

6
CONVERSION DU GAZ NATUREL
7.) Rattachez les souets (CSST) à la nouvelle patate.
Souets

7
8.)
9.)
CONVERSION DU GAZ NATUREL
Tuyauterie de Gaz naturel de Maison
Soupape d'arrêt
Prise de déconnexion rapide
Tuyau de Gaz NG
Au Table de Feu
