RedBack Lasers 3D3XR User manual

CONTENTS
User Safety 2
Introduction and 3D3X Accessories 3
3D3X Diagram 4
Operating Instructions 7
Batteries 7
Power 8
Manual Mode. 9
Pulse Mode 10
LLR705 Receiver 11
Mounting Options 12
Calibration Self Check & Technical Specications 13
Care & Maintenance, Trouble Shooting 15
Warranty 16
User Safety
• Laser output sign lies near the output aperture.
• Do not stare directly into laser beam.
• Do not disassemble the instrument or attempt to
perform any internal servicing. Repairs and service
should be performed only authorised service
centres of Redback Lasers.
• This instrument complies with the safety
Classication standards of laser radiation.
2
3D3XR CAUTION: Class 3r laser <5mW at 635nm.
3D3XG CAUTION: Class 3r laser <5mW at 522nm.
Do NOT stare into laser beam or aim at another
person.
Follow relevant Australian Standards
Copyright © CMI LasersTM RedBack lasersTM and Level1LasersTM . All rights reserved CMI Industries Pty Ltd 2021Copyright © CMI LasersTM RedBack lasersTM and Level1LasersTM . All rights reserved CMI Industries Pty Ltd 2021
No artwork or photographs produced by CMI Industries Pty Ltd may be used copied or reproduced without the written consentNo artwork or photographs produced by CMI Industries Pty Ltd may be used copied or reproduced without the written consent
from CMI Industries Pty Ltdfrom CMI Industries Pty Ltd

3
3D3XINTRODUCTION
Congratulations on purchasing one of the RedBack Pro Trade 3D3X Auto
Levelling 3x 360 line laser models. These instructions cover both the 3D3XR
(red beam) and 3D3XG (green beam) models. Please note that some of
the features described in this manual may be specic to just one of these
models and will be indicated as so.
Both the 3D3XR and 3D3XG feature three full 360olines, one horizontal and
two vertical at 90 degrees to each other. The 3D3XR has an ultra bright red
beam laser and the 3D3XG has an ultra bright green beam laser.
The 3D3X models are ideal for all manner of internal t out and installation
application by providing a fast self levelling horizontal line around the whole
room as well as 2 vertical lines again 360ocoverage and at 90oto each other
for alignment and squaring plus also providing plumb up and down crosses.
In addition these models has pulse mode and so can be used outdoors with
an optional line receiver such as the LLR705 or LLRMM30 by RedBack.
The 3D3X’s Comes with a Li-ion rechargeable battery and charger. The 3D3X
models are also able to be operate with standard “AA” Alkaline batteries.
The 3D3X’s feature manual mode for setting on a manual slant and comes
with an elevating magnetic base which can also be mounted on an optional
tripod such as the RedBack IET68.
3D3X Kit Included Accessories
• a 3D3X Laser Unit (either R or G)
• Protective Carry Case
• Rechargeable Li-ion Battery
• Charger
• Std “AA” Battery Compartment
• Elevating Magnetic Base
• Enhancement Glasses
• Laser target
• Instruction Manual
Note: 3D3XG comes with Green Glasses & Target
www.redbacklasers.com.au

4
3D3X DIAGRAMS
3D3XR & 3D3XG Laser Units
1
2
3
1. Laser Output Windows
2. Control Keypad
3. Pendulum Locking Knob
4. Battery Compartment
5. Tripod/Mounting Threads 5/8”, 1/4”
4
1
5

5
Keypad
www.redbacklasers.com.au
Power & Low
Battery LED
Pulse Mode
LED
Select Vertical
Line 1
Pulse Mode &
Manual Mode
Function Button
Manual Mode
LED
Service power Access
(Not compatible with supplied charger)
Select Horizontal
Line Toggle Switch
Select Vertical
Line 1

6
3D3X DIAGRAMS
Mounting Bracket
5/8” Thread
Magnetic
Mount
Tripod Mounts
5/8” Thread &
1/4” Thread
Lock for Elevating
Laser Level Platform
Locking Knob
3D3X to Bracket

7
www.redbacklasers.com.au
3D3X OPERATING INSTRUCTIONS
Battery Instructions
To charge this battery pack simply insert
the charger cable into the charging
socket on the Li-ion battery pack itself.
Note; the socket on the laser level is
for service use and the supplied charger
does not t this..
When the power LED on the keypad
ashes, the rechargeable battery pack
needs recharging or standard “AA”
batteries need replacing.
Handy Hints
• Prior to initial use, fully charge the rechargeable battery.
• If when you insert a battery pack the laser does not power up try re-
loading the battery pack to make sure there is a good connection.
• Remember the 3D3X can operate using standard “AA” batteries when
rechargeable pack is out of charge or charging.
• When laser is not going to be used for an extended period of time it is
best to remove both “AA” and Rechargeable pack if installed.
The 3D3X’s have two battery options either 4 x standard “AA” size Alkaline
or the Li-ion rechargeable pack. For standard 4 x “AA” alkaline operation
simply insert “AA” batteries into standard battery holder in the direction
indicated and slide the holder into battery recess and close the battery
compartment cover.
To use the rechargeable battery
pack rst remove standard
pack if inserted and place into
the same battery recess in
direction indicated and close
the battery compartment
cover.
5/8” Thread
Tripod Mounts
5/8” Thread &
1/4” Thread
Locking Knob
3D3X to Bracket

8
Turning On the 3D3XR or 3D3XG
To power up, simply unlock the pendulum by moving it to the “ON” position,
this will automatically self level the laser. If when you unlock the pendulum
all laser ash and a beeping sound is emitted then the laser is out of self
levelling range, place the laser on a more level surface for the device to self
level.
Next select the lasers press either the “H” Horizontal button or “V” Vertical
buttons. To power down the laser level simply re-lock the pendulum by
switching it to the “OFF” Position.
Always transport the RedBack 3D3X laser level with the pendulum in the
locked “OFF” position to protect the device when not being used.
3D3X OPERATING INSTRUCTIONS cont.

9
www.redbacklasers.com.au
Manual Mode
Manual mode allows you to turn on one or more of the 360 degree lines
with the pendulum in the locked position and so allows you to set up a laser
line at an angle such as for installing balustrades. Manual mode is activated
by pressing the manual mode top right button when the pendulum is in the
locked “OFF” position. The manual mode LED light will ash warning you
that the laser is not self levelling. You can turn on the various lines in the
normal way. To exit manual mode double press the same button. First press
enters pulse mode and second powers down.
Note that the 3D3X top right button has two functions, Manual Mode and
Pulse Mode. See page 10
Unit featured is 3D3XR in manual mode. Also pictured is an optional iet68 elevating tripod and
optional GD12 grade dial plate; a camera style tripod with pan and tilt will provide a similar result.

10 www.redbacklasers.com.au
3D3X OPERATING INSTRUCTIONS cont.
Pulse Mode
Pulse mode allows the 3D3XR or 3D3XG to be used with a line receiver such
as the RedBack LLR705 or LLRMM30 and so allowing the laser to be used
outside for general site levelling, patios, decking etc.
To enable pulse mode rst unlock the pendulum to power up the laser
then you press the top right function button once. The Pulse LED light will
indicate when pulse mode is enabled, to disable once again press the top
right function button.
To enable pulse mode when the laser is in manual mode rst press the top
right function button to enter that mode then press the same button once
more to enable pulse. A third press of the same function button will power
down the laser level.

11
www.redbacklasers.com.au
Laser Receiver LLR705 (OPTIONAL Accessory)
The receiver can be used hand held or together with the sta clamp with a
sta. The LLR705 has a 1mm level zone for maximum accuracy.
• A press of the Power button on the receiver will turn on and o
the receiver.
• Pressing the Speaker button toggles speaker on and o. Note the
sound is dierent for above, below and on level.
• Pressing the Near/Far button enables the receiver to best work
within 5m for Near and over 5m for Far. Note default mode when rst
powered up is Near (under 5m) Mode as indicated on the LCD display
by a symbol of two triangles and a line between . If you are
using the receiver beyond 5m switch to far mode indicated by a line
symbol .
The LLR705 has 3 LED light displays which indicate laser is above, below and
on level and a large LCD display which has a progressive display indicating
when the laser gets closer to the level mark. If the receiver is left turned on
without a laser being received it will auto power down after 10 minutes. For
picking up horizontal lines hold the receiver as shown below, for picking up
vertical lines place on its side.
Indicates laser beam is below
line - slide receiver down.
Indicates laser beam is above
line - slide receiver up.
Indicates laser beam is on the
line.
LED lights
duplicate LCD
results.
The RedBack LLR705 is an OPTIONAL receiver for the 3D3XR & 3D3XG
models. It allows the laser beam to be picked up outside at up to 150m
3D3XR and 50m 3D3XG in any lighting conditions. Ideal for decking, sheds,
slabs, framing and much more.

12 www.redbacklasers.com.au
3D3X Mounting Options
The 3D3X’s come with a magnetic mounting bracket and this mounting
bracket features an elevating plate which allows the height of the horizontal
laser line to be nely adjusted. The elevating plate also features a locking
knob to prevent the lasers height changing once set.
The bracket and laser housing features a 5/8” survey thread which allows the
3D3X to be mounted onto an indoor elevating tripod such as the RedBack
Lasers IET68 or outdoor heavy duty tripod HDF94. The bracket and housing
of the laser level also feature a 1/4” thread allowing it to be mounted onto
a camera style tripod.
Finally the bracket features strong vertical magnets that allow mounting onto
ferrous metals for installation applications.
3D3X OPERATING INSTRUCTIONS cont.

13
3D3X TECHNICAL SPECIFICATIONS
Laser Wavelength 635nm Red
Laser Class 3r <5mW
Visible Range (light dependent) Up To 35m
Range with Optional Receiver Up to 150m radius (Full Sunlight)
Accuracy ±2mm/10m
Number 360olines 3
Self Levelling Range ±3o
Temperature Range -10oC - +40oC
IP Dust Water Resistance IP55
Power 4 x “AA” Alkaline or Li-ion pack
Low Power Power LED Flash
Technical Specications
3D3XR - Red Beam
Range with Receiver as tested with RedBack LLR705 receiver, range may vary depending on type of
line receiver used.

14 www.redbacklasers.com.au
3D3X TECHNICAL SPECIFICATIONS
Technical Specications
Calibration & Self Check
All Redback Lasers have been checked for calibration and certied by one
of our technicians here in Australia prior to despatch and should under
normal conditions not go out of calibration. A calibration certied sticker
with the date and name of technician is located on the laser itself. It is
worth checking calibration from time to time particularly after any known
knocks or drops. An easy way to continually check calibration is to always
double check you work with the laser located in a dierent position or use
an alternate vertical line. Various other methods for checking calibration can
be found at www.redbacklasers.com.au/downloads or the laser can be
returned to our service department for checking and re-calibration. Please
see warranty conditions on page 16.
3D3XG - Green Beam
Laser Wavelength 522nm Green
Laser Class 3r <5mW
Visible Range (light dependent) Up To 35m
Range with Optional Receiver Up to 60m radius (Full Sunlight)
Accuracy ±2mm/10m
Number 360olines 3
Self Levelling Range ±3o
Temperature Range -10oC - +40oC
IP Dust Water Resistance IP55
Power 4 x “AA” Alkaline or Li-ion pack
Low Power Power LED Flash

15
3D3X TROUBLE SHOOTING
• Keep laser and accessories stored in protective case.
• Make sure laser is stored dry, dry out before storage to prevent damage.
• Remove batteries when not used for an extended period of time to prevent
leakage. (battery leakage not covered by warranty)
• The 3D3X is a precision instrument and should not be subjected to excessive
knocks, drops or vibrations.
• Self check calibration from time to time. See page 14
• For service contact Redback Lasers. www.redbacklasers.com.au
www.redbacklasers.com.au
Care & Maintenance

REDBACK LASERS WARRANTY
Duration of warranty is xed and automatic, when we advertise 2 years on a particular model,
its two years. No drop down to a lesser time if you forget to register, registration is NOT
required just proof of purchase showing date.
Although the duration of our warranties are for a particular period it does not mean we will
charge you for a genuine warranty failure a month or two outside that warranty period, we
believe in a fair go.
Even though a product shows signs of accidental damage, scratches and the like, we will not
automatically fail the warranty claim, if the fault is NOT caused by a drop or misuse and is a
genuine warranty failure then we will cover it.
Calibration is not covered by warranty much the same as the wheel balance on your car is not
covered by warranty, we do however oer a one o free re-calibration service during the period
of warranty, conditions and details below.
RedBack LasersTM distributed by CMI Industries Pty Ltd
P.O. Box 7324 - Geelong West - Victoria - 3218 - Australia
Ph: 1800 769 585 email: [email protected]
CMI Industries Pty Ltd provides consumers with a warranty to our products, this is in addition to requirements of any
relevant legislation such as the Competition and Consumer Act 2010. Denitions:
“CMI”, “We” or “Our” refers to CMI Industries Pty Ltd (ABN 29 102 713 922) of Unit2 381-383 Thompson Rd, Bell Park,
Victoria 3215 ph 1800 769 858
“You” or “Consumer” refers to the initial purchaser of the product.
“Product” refers to goods manufactured by or for CMI Industries Pty Ltd under the brands of RedBack Lasers,
Level1Laser and CMI Lasers.
“Material” refers to material or component used in the construction and manufacture of the product.
“Workmanship” refers to handling, assembly and manufacturing processes done by or for CMI Industries Pty Ltd in
order to manufacture the products.
“Warranty Period” For the 3D3XR and 3D3XG is Two Years. Warranty period is from original purchase date, no
extension is made in the event of warranty replacement products supplied or time spent being repaired.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure. LLR705 receivers 2 Year warranty, Ni-Mh Battery/Charger 1 Year Warranty.
CMI warrants that our products will be free from defects in material and workmanship for the warranty period.
CMI promises to repair or replace, free of charge, the product or part of product if found to be faulty due to defective
workmanship or materials within the duration of the warranty as long as the following terms and conditions are met;
• Product must not have been misused or abused, must not have incurred accidental damage or had un-authorised
repair or tampering that has caused or contributed to its fault or failure.
• You must contact CMI by phone, mail or email immediately when a fault or defect has become apparent and within
the warranty period.
• Product must be returned to store of purchase or directly to CMI, we will cover cost of postage only when sent by
our reply paid Australia Post service (Australian Main land and Tasmania only) details will be provided upon phone, post
or email communications with us.
• CMI will cover cost of freight back of repaired or replaced product to original purchase store or you directly
(depending on how it was sent Australian Main Land and Tasmania only).
• CMI will determine whether to repair or replace the product or part of product on a case by case basis.
• Further exclusions in this warranty include damage or defect caused by use of non-original accessories or parts,
damage in transportation, normal wear and tear, damage through moisture, damage due to electric surge, failure due
to neglect or damaged caused by adjustments not outlined in CMI’s instructions.
Subject to the requirements of all applicable Australian Acts or legislation and to the extent permitted by law, CMI
accepts no liability (whether expressed or implied) of any nature whatsoever for any loss of earnings, hiring of
replacement equipment, Inaccurate work carried out by the consumer or agent, damage or injury arising as a result of
any fault in the product. It is the consumers responsibility to maintain good working practices and regularly test their
tools for accuracy and serviceability.
Calibration of the product is not covered by warranty subject to the requirement of all applicable Australian Acts or
legislation and to the extent permitted by law, CMI does however oer a free re-calibration service (once within the
period of the warranty) you are liable for the cost to send the product to us then we will recalibrate and return the
product to you free of charge. Note this oer is invalid if the product shows signs of misuse or accidental damage that
has caused it to go out of calibration.
A CMI product returned that fails to fall within the terms and conditions of this warranty will be quoted for repair.
