LSR-LSG Single Line Lasers
Instructions
The following instructions cover the LSR and LSG single line indoor xed laser range. (LSR-5MW-1,
LSR-10MW-1, LSG-5MW-1 and LSG-10MW-1)
These lasers produce a xed line that can be directed exactly where you want them for various
engineering and manufacturing requirements.
Laser Line Output
Laser Line Length
Adjustment
Laser Line Focus
Rotation Adjustment
Pivot Up/Down
Adjustment
Laser Alignment Adjustment
Power Switch
12V input from
Mains Adaptor or
12V cable
Earth Connector if
required
CONTROL BOX

Set up
Plug the supplied mains adaptor or 12v cigarette lighter cable into the control box power socket as shown overleaf.
Power the laser on using the rocker switch located on the front of the control box. The laser should now be visible from
the output, making sure not to look directly at the output.
Mount the laser into the required position and direct the laser line using the Rotation adjustment, Pivot adjustment and
Alignment adjustment.
The length of the laser line can be adjusted by rotating the rotation adjustment ring on the front of the laser unit.
The laser sharpness can be adjusted by rotating the laser focus adjuster on the barrel of the laser. Note you may need
to slide more of the laser through the holder to get full access.
Specications
Laser Output:
LSR-5MW-1 - Red Class 3r 635-670nm <5mW
LSR-10MW-1 - Red Class 3B 635-670nm <10mW
LSG-5MW-1 - Red Class 3r 522-542nm <5mW
Power Input: 12V centre +ve
Range: Dependent on Ambient Light
Warranty: 12 Months
FOCUS
LINE
LENGTH
Trouble Shooting & Precautions
- No Laser Output
1. Check 12V power cable is completely inserted into the control box.
2. Check mains adaptor is plugged in and power outlet is turned on.
- Laser Fuzzy
1. Focus in beam using the adjustment screw located inside the barrel of the laser, see instructions above.
2. Check laser output lens is clean.
WARNING - Never shine laser at people and never stare into the beam, staring into the beam can cause eye damage.
This range of laser is designed for indoor operation and is not water resistant, Do not get mains adaptor wet.
Distributed by CMI Industries Pty Ltd - 18b Tarkin Court, Bell Park, Vic 3215 03 5240 3999 - See inclosed warranty slip for conditions - duration of warranty 12 Months from date of purchase.
