USER MANUAL
Please read and keep these instrucons
FOLDING
WALKING
FRAME
B4070WS

redgumbrand.com.au
BASICS by Redgum owns the copyright to the Folding Walking Frame user manual.
Any informaon contained in this user manual shall not be photocopied, reproduced or
translated into any other languages without the prior wrien consent of BASICS by Redgum.
BASICS by Redgum strives to provide the highest quality products possible.
Product is subject to change without noce.
© Copyright BASICS by Redgum 2021
BASICS by Redgum is part of FOR-DE Group Pty Ltd

redgumbrand.com.au
CONTENTS
1. INTRODUCTION - INTENDED USE
2. PRODUCT OVERVIEW - FEATURES / SPECIFICATIONS
3. SET UP - UNPACK and INSPECT SUPPLIED PARTS
4. SET UP - UNFOLD FRAME
5. ASSEMBLY - FIT REAR GLIDES
6. ASSEMBLY - FIT FRONT WHEELS
7. SET UP - WALKING FRAME HEIGHT ADJUSTMENT
8. USAGE - FOLDING WALKING FRAME
9. USAGE GUIDELINES - DO’s + DON’Ts
10. PRODUCT CARE - INSPECTIONS / CLEANING
11. WARRANTY
12. BASICS by Redgum - PRODUCT RANGE

redgumbrand.com.au
INTRODUCTION
Thank you for purchasing this quality BASICS by Redgum product.
If you have any issues or quesons about the Folding Walking Frame
please contact your supplier or BASICS by Redgum direct:
T: [phone]
E: [e-mail]
A: 1 Business Way, Malaga Western Australia 6090
INTENDED USE
This product has limitaons and should be used in accordance
to these guidelines. Failure to follow these guidelines may result
in damage to the product and injury to the user. It is the
responsibility of the user to ensure the suitability of this product
for its intended use. The user should consult their appropriate
healthcare professional if unsure of the correct product usage
for their unique circumstances.
Only use the Folding Walking Frame
for its intended purpose which is as a
stability aid on which to lean on for
support to maintain balance
whilst standing or walking.
Refer to usage guideline page for informaon
on how to use the Folding Walking Frame in
a safe manner.
IMPORTANT NOTE
This equipment MUST
be assembled for use
by a competent person.
1.

redgumbrand.com.au
PRODUCT OVERVIEW
FEATURES
Stable standing / walking frame
Great independent living aid
Adjustable height
Ø125mm front wheels / rear glides
Folds up for transit or storage
Strong lightweight construcon
Comfortable hand grips
SPECIFICATIONS (All dimensions shown are nominal)
Overall:
595mm (W) - 440mm Internal (W)
530mm (D)
825 - 1000mm (H) - 8 height sengs
Overall - Folded:
625mm (W)
100mm (D)
860mm (H) at lowest seng
Wheels:
Ø125 (5”) x 20mm - Grey PVC tyre / Black PP rim (replacements available)
Glides:
80 x 30mm - White PP (replacements available)
Product Weight: 2.6kg
Maximum User Weight: 136kg
Please contact BASICS by Redgum if you would like any further informaon
on the Folding Walking Frame .
2.

redgumbrand.com.au
SET UP- UNPACK and INSPECT SUPPLIED PARTS
Ensure you have been supplied with the following parts:
We recommend that you visually inspect the Folding Walking Frame parts
prior to assembly:
3.
IMPORTANT NOTE:
If you see any damage
suspect a fault
or are missing parts
DO NOT ASSEMBLE
THE PRODUCT and
contact your supplier
for support.
LEG
WITH
GLIDE
(x2)
LEG
WITH
WHEEL
(1 x LEFT)
(1 x RIGHT)
FRAME
(x1)

redgumbrand.com.au
4.
SET UP- UNFOLD FRAME
The Folding Walking Frame needs to be unfolded out of the box.
Please follow these steps
to unfold the frame:
1. Rotate out the side
frame that is on the
outside of frame.
2. Rotate out the
other side frame.
A loud ‘click’ will be
heard when the side
frames have been locked
into posion.
The adjustable legs are now
ready to t.
Loud ‘CLICK’
will be hear when
frame is locked into
posion.

redgumbrand.com.au
ASSEMBLY- FIT REAR GLIDES
Please follow these steps to t rear glides to frame:
1. Put the unfolded frame on its side.
2. Oer up leg with glide to REAR LEG of side frame.
Align holes in leg with press buon on frame.
3. Slide leg onto frame.
4. Push in press buon and connue to slide leg onto frame unl press buon pops
out of hole in leg. (Refer to page 7 for walking frame height adjustment)
5. Repeat process to t other leg with glide onto frame.
5.
1. Push in press buon
Locate tube with glides onto
REAR leg on frame
2. Slide leg onto frame unl press
buon pops out of hole in leg.
IMPORTANT NOTE
Press buon MUST protrude
3mm out from tube when
properly located in place.

redgumbrand.com.au
6.
ASSEMBLY- FIT FRONT WHEELS
Please follow these steps to t front wheels to frame:
1. Put the unfolded frame on its side.
2. Oer up leg with wheel to FRONT LEG of side frame.
Ensure wheel is facing toward OUTSIDE of frame.
Align holes in leg with press buon on frame.
3. Slide leg onto frame.
4. Push in press buon and connue to slide leg onto frame unl press buon pops
out of hole in leg. (Refer to page 7 for walking frame height adjustment)
5. Repeat process to t other
leg with wheel onto frame.
1. Push in press buon
2. Slide leg onto frame unl press
buon pops out of hole in leg.
IMPORTANT NOTE
Press buon MUST protrude
3mm out from tube when
properly located in place.

redgumbrand.com.au
Straight arm
when holding
walking frame
SET UP- WALKING FRAME HEIGHT ADJUSTMENT
We recommend that the
Folding Walking Frame be set at
the correct height for the user.
The user should be able to hold
onto the hand grip with a straight
arm when using the walking frame.
To adjust the height of the frame:
- Push in press buon and slide leg
onto frame unl press buon pops
out of required hole in leg.
- Repeat process to adjust other
legs onto walking frame.
Use numbers on leg tube to ensure
all legs are set at the same height.
7.
IMPORTANT NOTE
Press buon MUST protrude
3mm out from tube when
properly located in place.

redgumbrand.com.au
USAGE- FOLDING WALKING FRAME
The Folding Walking Frame can be folded
for storage and transit.
To fold the Walking Frame
follow these steps:
- Press down on
the raised secon
of the plasc part
found on the
upper cross
tube and rotate
in the side frame.
- Rotate in the
other side frame.
To unfold frame refer to page 4.
8.
Press
down

redgumbrand.com.au
USAGE GUIDELINES - DO’s + DON’TS
Please follow these guidelines to get the opmal benet
from the Folding Walking Frame.
Failure to follow these guidelines may result in damage
to the Folding Walking Frame and put the user at risk.
The Folding Walking Frame is designed
to take 136kg Maximum Load.
Do not overload the product!
Periodically inspect to the Folding Walking Frame
prior to use to ensure it is in good working order.
(Refer to page 9)
Always adjust the Folding Walking Frame to correct height for the user.
(Refer to page 7)
Never use the Folding Walking Frame to pull yourself up into a standing posion
as it may p over. Use as a balancing aid once standing.
Never hang any objects (ie. bag) o the
Folding Walking Frame as it might p over.
Avoid liing the Folding Walking Frame
o the ground where possible.
Ensure wheels and glides are
in contact with the ground.
Take care when using
Folding Walking Frame
on uneven or wet ground.
If you have any issues or quesons
about the Folding Walking Frame
please contact your supplier or
BASICS by Redgum direct.
9.

redgumbrand.com.au
10.
PRODUCT CARE - INSPECTIONS / CLEANING
INSPECTIONS
We suggest that the Folding Walking Frame is visually checked periodically for signs of
damage or wear prior to use. Overall check the following:
- Frame has no distoron.
- Hand grips are not damaged or worn.
- Front wheels are not damaged and spin freely (Remove any hair or lint).
- Rear glides are not damaged or worn.
Withdraw the Folding Walking Frame immediately if you suspect damage
or any other fault. If in any doubt, please do not issue or use, but
immediately contact your supplier for service support.
CLEANING
Clean the Folding Walking Frame using
a non-abrasive cleaner or mild detergent
with a so cloth.
Abrasive cleaners or abrasive cleaning
pads could damage the Walking Frame
and should not be used.
If you have any issues or quesons
about the Folding Walking Frame
please contact your supplier or
BASICS by Redgum direct.

redgumbrand.com.au
11.
WARRANTY
The BASICS by Redgum:
B4070WS - FOLDING WALKING FRAME
is covered by a 12 Month Warranty from the date of purchase.
If the product has any manufacturing faults during this period contact the place of
purchase for assessment. Failures as a result of ACCIDENTAL MISUSE, MODIFICATION
OR WEAR AND TEAR ARE NOT COVERED BY THIS WARRANTY.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entled to a replacement part for a major failure and for
compensaon for any other reasonably foreseeable loss or damage. You are entled
to have the goods repaired or replaced if the goods fail to be of acceptable quality
and failure does not amount to major failure.
If you have any issues or quesons about the Folding Walking Frame
please contact your supplier or BASICS by Redgum direct on:
T: [phone]
E: [e-mail]
A: 1 Business Way, Malaga
Western Australia 6090
Please keep this
User Manual
in a safe place
for future reference.

redgumbrand.com.au
12.
BASICS by Redum - PRODUCT RANGE
BASICS by Redgum oer a range of products including:
Please contact BASICS by Redgum for further informaon:
T: [phone] E: [e-mail]
A: 1 Business Way, Malaga Western Australia 6090
W: www.redgumbrand.com.au
Step
B68H
Step with handle
B68SH
Bedside commode
B580
Seat walker
(Burgundy red + Silver)
B4204S
Bariatric commode chair
B588
