USER MANUAL
Please read and keep these instrucons
ALL TERRAIN
COMPACT SEAT WALKER
RG4412

redgumbrand.com.au
REDGUM Brand owns the copyright to the All Terrain Compact Seat Walker user manual.
Any informaon contained in this user manual shall not be photocopied, reproduced or
translated into any other languages without the prior wrien consent of REDGUM Brand.
REDGUM Brand strives to provide the highest quality products possible.
Product is subject to change without noce.
© Copyright REDGUM Brand 2021
REDGUM Brand is part of FOR-DE Group Pty Ltd

redgumbrand.com.au
CONTENTS
1. INTRODUCTION - INTENDED USE
2. PRODUCT OVERVIEW - FEATURES / SPECIFICATIONS
3. SET UP - UNPACK and INSPECT SUPPLIED PARTS
4. SET UP - UNFOLDING / FOLDING WHEELS
5. SET UP - UNFOLDING / FOLDING FRAME
6. SET UP - FIT BAG
7. OPERATION - HANDLE ADJUSTMENT
8. OPERATION - HAND BRAKES
9. OPERATION - BRAKE ADJUSTMENT
10. USAGE GUIDELINES - DO’s + DON’Ts
11. PRODUCT CARE - INSPECTIONS / CLEANING
12. WARRANTY

redgumbrand.com.au
INTRODUCTION
Thank you for purchasing this quality REDGUM Brand product.
If you have any issues or quesons about the All Terrain Compact Seat Walker
please contact your supplier or REDGUM Brand direct:
T: [phone]
F: [phone]
E: [e-mail]
A: 1 Business Way, Malaga Western Australia 6090
INTENDED USE
This product has limitaons and should be used in accordance to these guidelines.
Failure to follow these guidelines may result in damage to the product and injury
to the user. It is the responsibility of the user to ensure the suitability of this product
for its intended use. The user should consult their appropriate healthcare professional
if unsure of the correct product usage for their unique circumstances.
Only use the All Terrain Compact Seat Walker for its intended purpose which is as a
walking aid and a short term stac seang soluon.
The All Terrain Compact Seat Walker is designed
to be used both inside and outside the home.
Refer to usage guideline page for informaon
on how to use All Terrain Compact Seat Walker
in a safe manner.
IMPORTANT NOTE
This equipment MUST be assembled for
use and operated by a competent person.
1.

redgumbrand.com.au
PRODUCT OVERVIEW
FEATURES
Strong lightweight construcon
User friendly loop brake handles
Height adjustable handles
Ergonomic handgrips to reduce pressure
Brake + park brakes
Simple brake cable adjustment
Mesh seang
Padded Backrest
Large diameter wheels for excellent mobility
Pneumac tyres
Swivelling front wheels
Removable bag
Walking sck holder
Folds up for transit or storage
SPECIFICATIONS (All dimensions shown are nominal)
Overall: 890mm L x 610mm W x 900mm H
Overall Folded: 450mm L x 220mm W x 670mm H
Handle Height: 900 - 1025mm (5 sengs)
Seat: 460mm W x 250mm D x 600mm H
Wheel Diameter: Ø305mm / 12”
Carry Bag: 370mm L x 200mm W x 200mm D
Weight: 11kg
Maximum User Weight: 136kg
Please contact REDGUM Brand if you would like any further informaon
on the All Terrain Compact Seat Walker.
2.

redgumbrand.com.au
SET UP- UNPACK and INSPECT SUPPLIED PARTS
Ensure you have been supplied with the following parts:
We recommend that you visually inspect
the following aspects of the seat walker
prior to use:
- Framework
- Upholstery
- Wheels
- Brakes + cables
IMPORTANT NOTE:
If you see any damage
or suspect a fault,
DO NOT USE
THE PRODUCT
and contact
your supplier
for support.
3.
BAG
FOLDED
WALKER
Backrest / Seat
not shown for clarity
TYRE PUMP included
(Not shown)

redgumbrand.com.au
4.
SET UP- UNFOLDING / FOLDING WHEELS
The All Terrain Compact Seat Walker comes folded
and requires unfolding prior to use.
Please follow these steps:
1. Lay the folded seat walker on its side.
2. Remove both hand screws.
3. Rotate front and rear wheels
down as shown.
4. Fix wheels into place with
hand screws.
5. Flip seat walker over and repeat process
on other side.
HAND SCREWS
IMPORTANT NOTE
Ensure all hand screws
have been suciently ghtened
prior to using seat walker
Backrest / Seat
not shown for clarity

redgumbrand.com.au
SET UP- UNFOLDING / FOLDING FRAME
The All Terrain Compact Seat Walker
requires unfolding prior to use.
Please follow these steps:
1. Pull OUT on both of the handles at the
same me to open out the seat walker.
2. Push down rmly on the outside edges
of seat unl two loud clicks are heard.
3. Check to ensure seat walker is fully unfolded
and locked in posion prior to use.
To fold seat walker:
- Pull UP on handle in middle of seat.
5.
Important note:
DO NOT place ngers
underneath seat when
unfolding seat walker!
PUSH DOWN
ON SIDES
OF SEAT
PULL OUT
ON HANDLES
Backrest / Seat
not shown for clarity

redgumbrand.com.au
SET UP- FIT BAG
The All Terrain Compact Seat Walker comes with a bag that can be aached to the front
of the walker. Please follow these steps to t bag correctly:
1. Posion bag with bag opening facing
the front of the walker.
2. Line up straps on bag with pegs
on seat frame.
3. Slide both straps onto pegs.
4. Ensure both straps
fully locate
onto pegs.
Note:
Bag can remain on seat walker when folded if empty.
If not empty remove from walker prior to folding.
6.
2kg Max.
bag load

redgumbrand.com.au
7.
OPERATION - HANDLE ADJUSTMENT
The All Terrain Compact Seat Walker has adjustable height handles.
Please follow these steps to adjust the handle height correctly:
1. Depress the push buon located on the outside of the upright.
2. Move the handle to the required height.
(You will need to depress the push buon
for every height seng change)
3. Check to ensure press buon has fully engaged
with hole prior to use.
Press
Buon
Press buon
MUST protrude
3mm out from upright
when properly
located in place

redgumbrand.com.au
OPERATION - HAND BRAKES
The All Terrain Compact Seat Walker has
closed loop hand brakes on both handles.
IMPORTANT NOTE
Both hand brakes should be used
simultaneously to ensure your
seat walker stops as required and
you are in control.
To STOP, gently pull upwards
on both brakes simultaneously.
This will slow down and stop
the seat walker.
Release both brakes to
allow the seat walker
to become mobile again.
The brakes on your seat walker
also have a park brake opon.
To engage the park brake:
Push downwards on both brakes
simultaneously. Push the brakes
down unl you hear
To unlock, simply pull the brakes up.
You will hear a click as the ‘park lock’
disengages.
8.
Pull both levers up
to brake
Push both levers down
to engage park brake

redgumbrand.com.au
9.
OPERATION - BRAKE ADJUSTMENT
The All Terrain Compact Seat Walker
brake system will require periodic adjustment.
Adjustment is required when either the brake
or park brake no longer stops the rear wheel
from spinning.
To adjust the brake:
1. Carefully release the locking screw using
a suitable allen key (not supplied).
2. Adjust the brake arms unl it clear the wheel
by approx. 3 mm.
3. Re-posion the locking boss to be hard up
against the brake body.
4. Reghten the locking screw.
5. Check the brake to ensure the wheel
stops spinning when the brake is on.
6. Repeat the brake adjustment
procedure if required unl
brakes work as required.
When adjusted the brakes should
work in both normal braking and
in parking mode.
Locking
Boss
Locking
Screw
3mm GAP

redgumbrand.com.au
USAGE GUIDELINES - DO’s + DON’TS
Please follow these guidelines to get the opmal benet from the All Terrain Compact
Seat Walker. Failure to follow these guidelines may result in damage to the seat walker
and put the user at risk.
The All Terrain Compact Seat Walker is designed to take 136kg Maximum Load.
Do not overload the seat walker!
Do not overload the bag - 2kg max loading.
Pinch points do exist on this product - Please keep hands and any other body parts away
from moving parts when adjusng the seat walker.
Always adjust the handle heights to suit the user.
Always engage the park brakes when user is geng on or o the seat walker.
When in use always engage the park brakes on the seat walker when staonary.
Please take extra care when taking the seat walker oroad.
Go up or down inclines directly. Do not try to cross on an angle as this will cause
instability and the seat walker may p over.
All four wheels should always
remain on the ground.
The seat walker is not intended
to be self propelled while seated.
IMPORTANT NOTE
Do not t any parts or accessories to
the All Terrain Compact Seat Walker
that are manufactured by another
company. To do so will void your
warranty and may seriously
compromise your safety.
If you have any issues
or quesons about the
All Terrain Compact Seat Walker
please contact your supplier or
REDGUM Brand direct.
10.

redgumbrand.com.au
11.
PRODUCT CARE - INSPECTIONS / CLEANING
INSPECTIONS
We suggest that the All Terrain Compact Seat Walker is visually checked periodically
for signs of damage or wear prior to use. Overall check that no components are loose
or worn.
Check the tyre pressure periodically: 35 P.S.I (240 kPa / 2.5 Bar)
Withdraw the seat walker immediately if you suspect damage or any
other fault. If in any doubt, please do not issue or use, but immediately
contact your supplier for service support.
CLEANING
Clean the All Terrain Compact Seat Walker
using a non-abrasive cleaner or
mild detergent with a so cloth.
Abrasive cleaners or abrasive cleaning
pads could damage the seat walker
and should not be used.
Bag can be removed and
machined washed if required:
Cold water wash - gentle cycle
with mild detergent.
Tumble dry on lowest temperature.
Spot clean any small marks with
mild soap and water then allow
to air dry.
If you have any issues or quesons
about the All Terrain Compact
Seat Walker please contact your
supplier or REDGUM Brand direct.

redgumbrand.com.au
12.
WARRANTY
The REDGUM Brand:
RG4412 - All Terrain Compact Seat Walker
is covered by a 12 Month Warranty from the date of purchase.
If the product has any manufacturing faults during this period contact the place of
purchase for assessment. Failures as a result of ACCIDENTAL MISUSE, MODIFICATION
OR WEAR AND TEAR ARE NOT COVERED BY THIS WARRANTY.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entled to a replacement part for a major failure and for
compensaon for any other reasonably foreseeable loss or damage. You are entled
to have the goods repaired or replaced if the goods fail to be of acceptable quality
and failure does not amount to major failure.
If you have any issues or quesons about the All Terrain Compact Seat Walker
please contact your supplier or REDGUM Brand direct on:
T: [phone]
F: [phone]
E: [e-mail]
A: 1 Business Way, Malaga
Western Australia 6090
Please keep this
User Manual
in a safe place
for future reference.
