Aluminium 4-Wheeled Rollator
Usage and Maintenance Instructions
Model :RG 4401

BEFORE USE
• Carefully remove all packaging. Avoid using any knives or other sharp
instruments as this may damage the surface of the product.
• Check the product for any visible damage. If you see any damage or suspect a
fault, do not use your product, but contact your supplier for support.
INTENDED USE
N.B. This equipment must be installed by a competent person.
Do not exceed the weight limit stated - doing so could put the user at risk.
120KGS WEIGHT LIMIT.
Your Rollator has been designed to assist you when walking and carrying small items
of shopping using the bag provided. The bag was designed specifically to fit your
rollator, please only use the bag supplied for your Rollator. Do not use or combine
bags and/ or baskets from other manufacturers.
When not in use, you can simply fold the Redgumbrand Rollator and store away until
you require it next. The range of rollators are designed to be used both inside and
outside the home.

7
ASSEMBLY INSTRUCTIONS
Carefully remove all packaging, including the cardboard tubes covering the knurled
tube part of the brake assembly. Check the product thoroughly for damage or
obvious faults.
Components of the rollator
Assembly procedure：
10
4
2
1
3
6
9
5
1、Handgrip
2、Adjustable tubing
handgrip
3、Brake lever
4、rotary knob
5、Backrest
6、Seat
7、Shopping basket
8、Front wheel quick
fold locking
9、Front wheel
10、Rear wheel
11、Cane holder
8
11
Step 1:
Unfolding front wheel: Rotate the front wheel downward
to 180 degrees until hearing the 'click' sound. The front
wheel is now unfolded.
Folding front wheel: Press the button and rotate the
front wheel upward to 180 degrees，The front wheel is
now folded.(Figure 1)
（图二）
Figure 1
If you suspect the unit to faulty, please do not use, but contact your
supplier immediately for service.
Figure 1.1
Front wheel safety lock: fold up the safety lock before
folding up the front wheel, (Figure 1.1)

Figure 2
）
Step 2:
Unfolding rear wheel: Press the button on both sides
and pull up，then move the rear wheel pole downward
until reset on the next button position. Repeat for the
second rear wheel.
Folding rear wheel: Press the button on both sides
and pull up，then move the rear wheel pole upward until
reset on the next button position. Repeat for the second
rear wheel.
Figure 3
Figure 4
Step 4:
Figure 5
Attach the bag to the hook of the seat frame.
(Figure 4)
Step 3:
Turn the rotary knob anti-clockwise, adjust the push
handle up and down to the desired height, then to
tighten the rotary knob clockwise, make sure the rotary
knob is securely fastened. The push handle is now
locked.(Figure 3)
Step 5：
Attach the cane holder on the base, the cane holder
base is located on the bottom left hand side of the
frame. ( Figure 5）

UNFOLD / FOLD
OPERATING THE BRAKES
Figure 6
Figure 7
Step 6:
Unfold the rollator by pressing down on both sides of
the seat frame. (Figure 6
Step 7:
To fold,pull seat upwards by the black handle on the
seat plate as show in (Figure 7) . The rollator can now
be folded completely.
Figure 8
Figure 9
1. To stop, gently apply a gripping pressure to both
brakes simultaneously ( figure 8), this will slow down
and stop your Rollator.
2. The brakes on your Rollator have a park option
(figure 9). To operate the park option, push
downwards on both brakes simultaneously. You will
feel
the brake make a very slight click. Your brakes are now
in the 'lock' position.
3. To unlock, simply pull up the brake again, you will
hear a slight click as the 'park' disengages.

REISSUE
If you reissue or are about to reissue this product, please thoroughly check all
components for their safety.
This includes:
• Bent or damaged tubes or cracks at the tube joints.
• Loose or worn horseshoe clips
• Elongated adjustment holes.
• Loose handles.
• Loose or worn Wheels and wheel fasteners (where fitted)
• Smooth, worn or split ferrules (rubber tips).
Replace all worn, missing or damaged parts where necessary. If in any
doubt, please do not issue or use, but immediately contact your
supplier for service support.
BRAKE ADJUSTMENT
Your Rollator brake system will
require periodic adjustment.
To adjust the brakes loosen Nut B and
then screw/unscrew Nut A. When
adjusted re-tighten Nut B. If further
adjustment is required then loosen the
Locking Screw and then using a pair of
pliers pull the cable down by
approximately a millimeter. Re-tighten
Locking Screw. The brakes can then be
adjusted further by loosening Nut B and
screwing/unscrewing Nut A as before
（Figure 9）
Figure 9

CARE AND MAINTENANCE & YOUR OBLIGATION
Withdraw your rollator immediately if any of the wheels become
difficult to turn or do not feel securely attached to the frame or if
you suspect damage or any other fault.
1. Only use your Rollator for the purpose for which it is intended, which is as an
aid to walking. It is intended your rollator is only used on standard pavements or at
home. It should not be used on rough terrain or pot-holed surfaces. The use of your
rollator on these surfaces can seriously compromise your safety and may damage
your rollator beyond repair.
2. Keep your Rollator clean by wiping down with a damp cloth with a mild
detergent. Do not under any circumstances use an abrasive or solvent based
cleaner, as this will seriously damage the rollator and void your warranty.
3. Wipe off all surfaces with a dry cloth and use a water dispersing agent such as
WD40 on all metal joints.
4. Regularly check that all wheels and the folding mechanism function correctly
and that all wheels move freely. Pay particular attention to the front wheels,
ensuring that they rotate freely and without obstruction and that they are
attached securely to the frame.
5. Monthly Checks - check that all locking pins are properly secure.
Check that no components are loose. Check the adjustment to your brakes.
Check castors.
6. Do not fit any parts or accessories to your rollator manufactured by another
company. To do so will annul your warranty and may seriously compromise your
safety.
7. We suggest that you check your rollator visually every day. However we
recommend that you should have your rollator serviced every three months or less if
used by, or issued to, various users.
CLEANING
Clean your rollator using a non-abrasive cleaner or mild detergent with a soft cloth.
Abrasive cleaners e.g. AJAX and/ or abrasive cleaning pads may seriously damage the
product beyond repair and should not be used. Always ensure that you wipe dry the
equipment after cleaning.
MAINTENANCE
Please make a safety check of the product at regular intervals or if you have any
concerns.
Manufacturers Warranty -12 months against manufacturing defects.
Our goods come with guarantees that cannot be excluded under the Australian
ConsumerLaw. You are entitled to a replacement part for a major failure and for
compensation for any other reasonably foreseeable loss or damage. You are entitled to
have the goods repaired or replaced if the goods fail to be of acceptable quality and failure
does not amount to major failure.
