Inst r uc t ion
Manual
Model R3030/R3100
Digit al Manomet er
REED Inst r ument s
1 -8 7 7 -8 4 9 -2 1 2 7 | info@r eedinst r ument s.com | www.r eedinst r ument s.com

reedinstruments
www com
2
Table of Contents
Features......................................................................................... 3
Speci cations.............................................................................3-4
Instrument Controls & Indicators................................................4-5
Operating Instructions................................................................5-9
Auto Power-Off........................................................................... 5
Mode Options..........................................................................5-7
Calibration Mode .....................................................................7-8
Calibration Point Reference......................................................... 8
Manual Zero Setting.................................................................... 9
Troubleshooting........................................................................9-10
Battery Replacement................................................................... 10
Maintenance................................................................................ 11
REED Inst r ument s
1 -8 7 7 -8 4 9 -2 1 2 7 | info@r eedinst r um ent s.com | www.r eedinst r ument s.com

reedinstruments
www com
3
Features
• Portable, battery-operated pressure measuring device
• Measures gauge pressure (a measure of pressure in psi that is refer-
ence to ambient pressure) and differential pressure (a measure of the
difference between two pressures)
• 11 selectable pressure units: bar, mmHg, ozin2, kgcm2, psi, inH2O,
kPa, ftH2O, inHg, cmH2O, mbar
• Primary LCD readout displays currrent pressure reading while sec-
ondary readout displays real time clock
• Not suitable for absolute pressure measurement
Specifications
Range: R3030: 0~30 psi; 830 inH2O; 2068 mbar; 2.10 kg/cm2
R3100: 0~100 psi; 2768 inH2O; 6895 mbar; 7.03 kg/cm2
Accuracy: 0.3% of full scale at 25°C
Resolution:
Unit Range Model R3030 Model R3100
psi 1.000000 0.02 0.1
inH2O 27.680517 0.5 2
bar 0.068948 0.002 0.004
mbar 68.948253 2 4
mmHg 51.712016 1 3
ozin216.000844 0.3 1
kg/cm20.070309 0.002 0.004
kPa 6.894859 0.2 0.4
ftH2O 2.306719 0.04 0.2
cmH2O 70.309000 2 4
continued ...
REED Inst r ument s
1 -8 7 7 -8 4 9 -2 1 2 7 | info@r eedinst r um ent s.com | www.r eedinst r ument s.com

reedinstruments
www com
4
Response Time: 0.5 seconds
Format: Baud Rate: 2400 bit/sec; Data Bit: 8, Stop Bit: 1
Compensated Temp.
Range: 0~50°C
Operating Temperature: 0~50°C
Operating Humidity: ≤80% RH
Storage Temperature: -20~55°C
Power Supply: Single 9V battery
Dimensions: 72 x 182 x 30 mm
Weight: Approx. 220 g (with battery)
Includes: 2 x connection hose (4mm x 6mm (ID x OD)),
battery, hard carrying case, and user manual
Instrument Controls & Indicators
1. LCD screen displays pressure
value
2. “-” Negative pressure display
3. MAX/MIN presssure
4. REC internal recording
mode displays max./min.
pressure*
5. DC power input jack
6. Y/M/ D H/ M/S Real-time
clock 88:88:88 displays data
Year/Month/Day, Hour/Minute/
Second
7. Pressure unit indication
8. BAT Low battery indicator
9. DIF Differential pressure mode
continued ...
