Reely HT-6 User manual

(Remote Control „HT-6“ 2,4 GHz
Item no. 1310037
Version 04/15
7

2
Table of Contents
Page
1. Introduction..........................................................................................................................................................4
2. Explanation of Symbols .......................................................................................................................................4
3. Intended Use .......................................................................................................................................................5
4. Product Description .............................................................................................................................................5
5. Scope of Delivery.................................................................................................................................................6
6. Safety Information................................................................................................................................................6
a) General Information.......................................................................................................................................6
b) Operation.......................................................................................................................................................7
7. Notes on Batteries and Rechargeable Batteries..................................................................................................8
8. Charging Rechargeable Batteries........................................................................................................................8
9. Transmitter Controls ............................................................................................................................................9
10. Setting Up the Transmitter.................................................................................................................................10
a) Inserting the Batteries..................................................................................................................................10
b) Switching on the Transmitter ....................................................................................................................... 11
c) Modifying the Throttle Function ...................................................................................................................13
d) Setting the Control Stick Length..................................................................................................................14
11. Setting up the Receiver .....................................................................................................................................15
a) Connecting the Receiver .............................................................................................................................15
b) LED Display.................................................................................................................................................16
c) Mounting the Receiver.................................................................................................................................17
d) Installing the Servos ....................................................................................................................................18
e) Checking the Servo Function ......................................................................................................................18
12. Programming the Remote Control.....................................................................................................................19
13. The System Setting Menu „System Setup“........................................................................................................20
a) Model Memory Selection „Model Select“.....................................................................................................21
b) Model Name Setting „Model Name“ ............................................................................................................22
c) Model Type Selection „Type Select“............................................................................................................23
d) Copying Model Memory „Model Copy“........................................................................................................24
e) Deleting Model Memory „Model Reset“.......................................................................................................25
f) Receiver Programming „RX Setup“.............................................................................................................26
Digital Coding „AFHDS 2A“ .........................................................................................................................27
Receiver Voltage „RX Battery“.....................................................................................................................28
Failsafe Setting „Failsafe“............................................................................................................................29
Sensor List „“Sensor List“............................................................................................................................30
Servo Control Frequency „Servos Freq“......................................................................................................31
(

3
Page
g) Operation as Trainer Transmitter „Trainer Mode“........................................................................................32
h) Operation as Student Transmitter „Student Mode“......................................................................................33
i) Control Stick Assignment „Sticks Mode“......................................................................................................34
j) Display Brightness „LCD Brightness“ ..........................................................................................................35
k) Transmitter Software Version „Firmware Ver.“.............................................................................................36
l) Transmitter Software Update „Firmware Update“........................................................................................37
m) Reset to Factory Settings „Factory Reset“ ..................................................................................................38
14. The Function Setting Menu „Functions Setup“ ..................................................................................................39
a) Servo Direction Setting „Reverse“...............................................................................................................40
 b) ServoEndDeectionSetting„EndPoints“..................................................................................................41
c) Servo Control/Test „Display“........................................................................................................................42
d) Encoder Assignment „Aux. Channels“.........................................................................................................43
e) Basic Trim „Subtrim“....................................................................................................................................44
f) Dual Rate/Exponential Setting „Dual Rate/Exp.“.........................................................................................45
g) Throttle Curve Setting „Throttle Curve“ .......................................................................................................47
h) Pitch Curve Setting „Pitch Curve“................................................................................................................49
i) Swash Plate Servo Setting „Swash AFR“....................................................................................................51
j) Mixer Programming „Mix“ ............................................................................................................................53
k) Delta Mixer „Elevon“....................................................................................................................................56
l) V-Tail Mixer „V Tail“......................................................................................................................................58
m) Gyro Sensitivity Setting „Gyroscope“...........................................................................................................60
n) Switch Assignment „Switches Assign“.........................................................................................................62
o) Throttle switch „Throttle Hold“ .....................................................................................................................63
15. Remote Control Operation.................................................................................................................................64
16. Binding Function................................................................................................................................................65
17. Maintenance and Care ......................................................................................................................................66
18. Declaration of Conformity (DOC).......................................................................................................................66
19. Disposal.............................................................................................................................................................66
a) General Information.....................................................................................................................................66
b) Batteries and Rechargeable Batteries.........................................................................................................66
20. Troubleshooting .................................................................................................................................................67
21. Technical Data ...................................................................................................................................................68
a) Transmitter...................................................................................................................................................68
b) Receiver ......................................................................................................................................................68

4
1. Introduction
Dear Customer,
thank you for purchasing this product.
This product complies with the statutory national and European requirements.
To maintain this status and to ensure safe operation, you as the user must observe these operating instructions!
These operating instructions are part of this product. They contain important notes on commissioning and
handling. Also consider this if you pass on the product to any third party.
Therefore, retain these operating instructions for reference!
All company names and product names are trademarks of their respective owners. All rights reserved.
If there are any technical questions, please contact:
International: www.conrad.com/contact
United Kingdom: www.conrad-electronic.co.uk/contact
2. Explanation of Symbols
The symbol with the exclamation mark points out particular dangers associated with handling, function or
operation.
The „arrow“ symbol indicates special advice and operating information.

5
3. Intended Use
The6-channelremotecontrol„HT-6“issolelydesignedfor private use in the eld of model constructionandthe
operating times associated with it. This system is not suitable for industrial use, such as controlling machines or
equipment.
Any use other than that described above can damage the product and involves additional risks such as short circuit,
re,electricshock,etc.Theproductmustnotbetechnicallychangedorconverted!Thesafetyinformationmustbe
observed at all times!
Observe all safety information in these operating instructions. They contain important information on hand-
ling of the product.
You are solely responsible for the safe operation of your remote control and your model!
4. Product Description
The „HT-6“ remote control system is a radio remote control system ideally suited for model planes or helicopters.
The 6 proportional channels allow you to use the steering function and control function independently from each other.
The remote control also features several mixing and memory functions needed for the different models. The settings
of up to 20 different models can be saved in the remote control system.
Inadditiontheremote controlunitofferstheoption ofcallingdifferentightmodes andthussetindividualrudder
deectionsforspecicightphasessuchastake-offorlanding.
Thanks to pioneering 2.4 GHz radio transmission with return channel, you can read current values, such as the recei-
ver voltage or the quality of the radio control, comfortably at the display of your remote control transmitter. In connec-
tion with a receiver with I-BUS system and the corresponding sensor modules (each not enclosed), further measured
values such as temperature, rotating speed or speed can be recorded and transmitted to the transmitter.
The LC display is easily readable and the easy-to-use buttons permit simple, quick and safe data input. Thanks to
electronic trimming, the rudders are always in the correct position. The last set position is assumed automatically
when the remote control is switched on!
The ergonomic casing can be held and operated comfortably and allows you to safely control the model.
The 2.4 GHz-receiver warrants best reception for secure signal transmission.
For operation, 4 AA/mignon batteries (e.g. Conrad item no.: 652507, pack of 4, order 1x) are required for the trans-
mitter.WherenoightcontrollerwithBECswitchisused,youalsoneed4AA/mignonbatteriesforthereceiver(e.g.
Conrad item no. 652507, order once) or 4 AA/mignon rechargeable batteries with the corresponding battery holder.
Alternatively, 4- or 5-cell NiMH receiver batteries can also be used with the switch cable.

6
5. Scope of Delivery
• Remotecontroltransmitter
• Remotecontrolreceiver
• Bindingplug
• Operatinginstructions
6. Safety Information
In case of damage caused by non-compliance with these operating instructions, the warranty/gua-
rantee will expire. We do not assume any liability for consequential damage!
We do not assume any liability for property damage and personal injury caused by improper use or
non-compliance with the safety instructions! In such cases the warranty/guarantee is voided.
Normal wear and tear in operation and damage due to accidents (like the receiver aerial being torn off, the
receiver casing broken etc.) are excluded from the warranty.
Dear customer, these safety instructions are not only for the protection of the product but also for your own
safety and that of other people. Therefore, read this chapter very carefully before taking the product into
operation!
a) General Information
• Theunauthorisedconversionand/ormodicationoftheproductisprohibitedforsafetyandapprovalreasons(CE).
• Thisproductisnotatoyandnotsuitableforchildrenunder14yearsofage.
• Theproductmustnotgetdamporwet.
• Takingoutprivateliabilityinsuranceisrecommended.Ifyoualreadyhaveone,getsomeinformationonwhetheror
not the operation of a radio-operated model is covered by your insurance.
•Donotconnectthedrivemotortoelectricmodelsbeforethereceiversystemhasbeeninstalledcompletely.This
ensures that the drive motor does not start unintentionally.
•Donotleavepackagingmaterialunattended.Itmaybecomeadangeroustoyforchildren.
•Pleasecheckthefunctionalsafetyofyourmodelandoftheremotecontrolsystemeachtimebeforeyouusethe
model. Watch out for visible damage such as defective plug connections or damaged cables. All movable parts on
the model have to be running smoothly. However, there must be no tolerance or ‚play‘ in the bearing.
•TheoperationandhandlingofRCmodelsmustbelearned!Ifyouhavenevercontrolledsuchamodel,startespe-
cially carefully to get used to how it responds to the remote commands. Do be patient!
• Shouldquestionsarisethatarenotansweredwiththehelpofthisoperatingmanual,contactus(contactinformation,
see chapter 1) or another expert.

7
b) Operation
• Ifyoudonotyethavesufcientknowledgeonhowtodealwithremote-controlledmodels,pleasecontactanexpe-
rienced model sportsman or a model construction club.
• Whenputtingthedeviceintooperation,alwaysturnonthetransmitterrst.Thenswitchonthereceiverinthemodel.
Otherwise, the model might show unpredictable responses!
• Beforeoperatingthemodel,checkwhetherthestationarymodelreactsasexpectedtothecommandsoftheremote
control.
• Whenyouoperatethemodel,alwaysmakesurethatnopartsofyourbody,otherpeopleorobjectscomewithinthe
dangerous range of the motors or any other rotating drive parts.
• Improperoperationcancauseseriousdamagetopeopleandproperty!Alwaysmakesurethatthemodelisinyour
line of sight and do not operate it at night.
• Onlyoperateyourmodelifyourabilitytorespondisunrestricted.Fatigueortheinuenceofalcoholormedication
can lead to wrong responses.
• Operateyourmodelinanareawhereyoudonotendangeranypersons,animalsorobjects.Onlyoperateiton
privatesitesorinplaceswhicharespecicallydesignatedforthispurpose.
• Incaseofafaultstopoperatingyourmodelstraightawayandremovethecauseofmalfunctionbeforeyoucontinue
to use the model.
• DonotoperateyourRCsystemduringthunderstorms,beneathhigh-voltagepowerlinesorintheproximityofradio
masts.
• Neverswitchofftheremotecontrol(transmitter)whilethemodelisinuse.Toswitchoffthemodel,alwaysswitchoff
themotorrst,thenswitchoffthereceiver.Onlythenmaytheremotecontrolbeswitchedoff.
• Protecttheremotecontrolfromdampnessandheavydirt.
• Donotexposetheremotecontroltodirectsunlightorexcessiveheatforalongperiodoftime.
• Ifthebatteriesintheremotecontrolarelow,therangedecreases.Ifthereceiverbatteriesorrechargeablebattery
in the receiver are low, the model will not respond correctly to the remote control.
 Ifthisisthecase,stopyingimmediately.Replacethebatterieswithnewonesorrechargetherechargeablebatte-
ries.
• Donottakeanyriskswhenoperatingtheproduct!Yourownsafetyandthatofyourenvironmentdependscompletely
on your responsible use of the model.

8
7. Notes on Batteries and Rechargeable Batteries
• Keepbatteries/rechargeablebatteriesoutofthereachofchildren.
• Donotleaveanybatteries/rechargeablebatterieslyingaroundopenly.Thereisariskofbatteriesbeingswallowed
by children or pets. If swallowed, consult a doctor immediately!
• Batteries/rechargeablebatteriesmustneverbeshort-circuited,disassembledorthrownintore.Thereisadanger
of explosion!
• Leakingordamagedbatteries/rechargeablebatteriescancausechemicalburnstoskinoncontact;therefore,use
suitable protective gloves.
• Donotrechargenormalbatteries.Thereisariskofreandexplosion!Chargeonlyrechargeablebatteriesintended
forthis;usesuitablechargers.
• Alwaysobservecorrectpolarity(positive/+andnegative/-)wheninsertingthebatteries/rechargeablebatteries.
• Ifthedeviceisnotusedforanextendedperiodoftime(e.g.storage),removetheinsertedbatteries/rechargeable
batteries from the remote control and the car to avoid damage from leaking batteries/rechargeable batteries.
• Rechargetherechargeablebatteriesaboutevery3months.Otherwise,so-calleddeepdischargemayresult,ren-
dering the rechargeable batteries useless.
• Alwaysreplacetheentiresetofbatteriesorrechargeablebatteries.Nevermixfullychargedbatteries/rechargeable
batteries with partially discharged ones. Always use batteries or rechargeable batteries of the same type and manu-
facturer.
• Nevermixbatteriesandrechargeablebatteries!
• Forreasonsofoperationalsafety,onlyusebatteriesandrechargeablebatteriesfortheremotecontroltransmitter.
8. Charging Rechargeable Batteries
If you use rechargeable batteries for power supply of the receiver, they are usually at at delivery and must be
charged.
Note:
Before a rechargeable battery reaches maximum capacity, several complete discharge and charge cycles
are necessary.
Always discharge the rechargeable battery at regular intervals, since charging a „half-full“ rechargeable bat-
tery several times can cause a so-called lazy battery effect. This means that the rechargeable battery loses
capacity. It no longer provides all of its stored energy, and the operating time of the model is reduced.
If you use several rechargeable batteries, purchasing a high-quality charger may be worthwhile. Such a
charger usually has a quick-charging feature.

9
9. Transmitter Controls
Front:
Figure 1
1 Transmitter aerial
2 Carry handle with integrated second transmitter aerial
3 Rotary encoder „VRB“
4 Toggle switch „SWC“
5 Toggle switch „SWD“
6 Trim button for elevator/nod function (in mode II)*
7 Control stick for elevator/nod and aileron/roll function
(in mode II)*
8 Trim button for aileron/roll function (in mode II)*
9 „OK“ button
10 „CANCEL“ button
11 On/off switch
12 LC display
13 Binding button
14 „DOWN“ button
15 „UP“ button
16 Trim button for rudder/tail function (in mode II)*
17 Control stick for rudder/tail and throttle/pitch function
(in mode II)*
18 Trim button for throttle/pitch function
(in mode II)*
19 Toggle switch „SWA“
20 Toggle switch „SWB“
21 Eyelet for shoulder belt
22 Rotary encoder „VRA“
* Further information for mode setting can be found in the system setting menu in the menu item „Sticks mode“.

10
Rear:
23 Trainer/student socket
24 Battery compartment lid
10. Setting Up the Transmitter
 Inthefurthercourseoftheseinstructions,guresinthetextalwaysrefertotheadjacentgureorthegures
withinthesection.Referencestootherguresareindicatedwiththecorrespondinggurenumber.
a) Inserting the Batteries
For the power supply of the transmitter you will need 4 alkaline
batteries (e.g. Conrad item no. 652507, pack of 4, order 1) of
the size AA/mignon.
Proceed as follows to insert the batteries:
The battery compartment lid (1) is located on the back of the
transmitter. Press the corrugated area (2) and push off the lid
downwards.
Ensure that the polarity is correct when inserting the 4 batteries.
A corresponding note (3) is located on the bottom of the battery
compartment.
Then slide the lid of the battery compartment back on from the
bottom until the locking mechanism engages.
Figure 2
Figure 3

11
b) Switching on the Transmitter
After you have inserted four new batteries, check the position of the toggle switches. All switches must be in the front
position.
Thecontrolstickfortheelevator/nodandaileron/rollfunction(seegure1,item7)mustbeinthemiddleposition.The
controlstickfortherudder/tailandthrottle/pitchfunctions(seegure1,item17)mustbeinthemiddlepositionaswell
or must be pushed into the bottom-most position (motor off).
Nowswitchonthetransmitterusingtheon/offswitch(seeg.1,item11).
First, you will hear three signal sounds in increasing pitch and the operating display with the currently set model
appears in the backlit display.
The backlighting is deactivated automatically about 20 seconds after activation or the last button operation. If no ope-
rating element ids operated within 60 s with the plant on, the plant will emit short signal sounds as warning note.
The operating display consists of the following elements:
1 Manufacturer logo
2 Digital encoding
3 Memory display
4 Model name display
5 Throttle/pitch trimming display (in Mode II)*
6 Rudder/tail trimming display (in Mode II)*
7 Aileron/roll trimming display (in Mode II)*
8 Elevator/nod trimming display (in Mode II)*
9 Battery symbol for transmitter voltage supply
10 Battery symbol for receiver voltage supply
11 Modeltypegure
12 Display of the receiver voltage
13 Display of the transmitter voltage
14 Display of the defectively transmitted transmitter data
* Further information for mode setting can be found in the system setting menu in the menu item „Sticks mode“.
 Theoperatinginstructionsingure4appearcompletelyonlyifthereceiversystemisinoperation.Otherwi-
se, e.g. the values for receiver voltage or signal quality are not displayed.
Figure 4

12
 Ifoneofthefourtoggleswitches(seegure1,items
4, 5, 19 and 20) is not in the front position, and if the
control stick for the throttle/pitch function is not in the
bottom position, warning sounds are emitted at activa-
tion and the corresponding note is displayed.
In this case, the affected switches and the control stick
must be put in the required position. The display then
switches to the operating display and the warning
sounds go out.
Important!
 Ifthepowersupplyisnotsufcientforcorrecttransmitteroperationanymore,thebatteryiconwillashata
voltage of less than 4.2 V and the transmitter emits acoustic warning sounds at regular intervals. The model
should then no longer be operated.
When the voltage drops below 4.0 V, the transmitter emits alarm sounds without interrupting. In this case,
operation of the model must be ceased as quickly as possible, since the model may otherwise be lost!
Insert new batteries for further operation of the transmitter.
Figure 5

13
c) Modifying the Throttle Function
Exworks,yourremotecontrol„HT-6“isconguredsothatthecontrolleverforthethrottle/pitchfunctionisonthe
left.ThisisthemostcommoncongurationinEurope.Ifyouprefertohavethethrottle/pitchfunctionontherightas
opposed to the left stick, you have the option of swapping the two stick units with each other.
To make the necessary changes, some experience with remote control transmitters is required. Therefore you should
consult an experienced model maker or a model construction club if you do not feel capable of undertaking the pro-
cedures described in the following.
• Removethetransmitterbatteries.
• UnscrewthefourscrewsbymeansofaPhillips-tipscrewdriverfromtherearpanelofthetransmitterandlifttherear
panel carefully towards the left.
• Ondemand,youcandisconnectthesupplylinesofthebatteryboxandtheteacher/studentsocket(1)atthemain
PCB.
• Forthis,loosenthefourscrewsatthecontrolstickunitsandswapthetwounits(g.6A,item2).Youneedtoturn
the control stick units by 180° each so that the connections of the control stick potentiometers (3) are aligned to the
insideagain(seeg.6B).
• Screwonthecontrolstickunitsagainandcheckthemechanicalfunctionofthecontrolsticks.
• Connectthebatteryboxandtheteacher/studentboxtothemainPCB.
• Attachthetransmitterbackwallagainandturninthefourattachmentscrewsagain.
Figure 6
 TheelectronicmodicationofthethrottlefunctionisdonelaterintheSystemsettingmenuunder„Sticks
mode“.

14
d) Setting the Control Stick Length
You can adjust the length of the control sticks, depending on
your steering habits.
To do so simply hold the bottom part of the grip (1) and turn the
upper part (2) up anti-clockwise.
You can now set the length of the control stick by turning the
bottom part of the grip.
Finally, tighten the upper part of the grip back up.
Figure 7

15
11. Setting up the Receiver
a) Receiver Connection
Onitsrighthandside,thereceiver(seegure8,item1)offerstheoptionofconnectingupto6servoswithJRor
Futaba plug connectors.
The receiver battery or a battery box is connected to a switch cable either on a free slot or at the top-most slot
(B/VCC).
Figure 8
When connecting servos and speed controllers, always make sure of correct polarity of the plug connectors.
The impulse line of the servos (depending on manufacturer yellow, white or orange) must be connected to
the left (inner) one of the three adjacent plug-in contacts. The plug contact for the negative line (black or
brown, depending on the manufacturer) must be connected to the right (outer) pin contact.
The receiver outputs are assigned as follows:
Channel Output Helicopter Motor model plane
1 CH1 Roll servo Aileron servo
2 CH2 Pitch servo Elevator servo
3 CH3 Throttleservoorightcontroller Throttleservoorightcontroller
4 CH4 Tail servo/gyro Rudder servo
5 CH5 Gyro sensitivity Additional channel 5
6 CH6 Pitch servo Additional channel 6
- B/VCC Battery connection* Battery connection*

16
* Electricmodelswithanelectronic ight controller only requireaseparaterechargeablereceiverbatteryifthe
ightcontrolleruseddoesnothaveaBECcircuit.Forfurtherinformation,refertothetechnicaldocumentsofthe
controller.
Channels 5 and 6 can be assigned differently depending on
model. There also is the option of operating two servos via a
V-cable at a receiver output.
For a possible setup or distribution of the control channel, see
theadjacentsketchesingure9.
If a model is equipped, e.g. with two aileron servos, the second
servo can be connected to a receiver output that has not been
assigned yet. The control is then performed via one of the three
freely programming mixers.
For more information on the servo connection and the mixing
functions, see the following chapters (programing of the remote
control transmitter) in the respective function.
Important!
It is recommended to use a pair of tweezers or long-nosed pliers to disconnect the connection. To prevent
cable breaks, you should always pull on the plastic casing of the plug to disconnect the connection. Never
pull on the cables.
b) LED Display
ThereceiverhasanLEDdisplaythatservesmainlyasanindicatorforthereceiverconditionononeside(seegure
8, item 2).
The LED is lit only when the transmitter is on and bound to the receiver in operation of the receiver. If the transmitter
doesnotrecogniseanyvalidtransmittersignal,theLEDashes.Moreinformationonthetransmitterbindingcanbe
taken from chapter: Binding Function.
Figure 9

17
c) Installing the Receiver
Installation of the receiver depends on the model. For this reason, you should always follow the recommendations
of the model manufacturer regarding the installation. Regardless of the model, you should always try to install the
receiver so that it is protected from dust, dirt, moisture, heat and vibration in the best possible way.
Keepenoughdistancefrommotorsandelectronicightorspeedcontrollers.Metalorcarbonpartshaveashielding
effect and thus may considerably impair reception. In this case, it is sensible to relocate the aerial outwards through
bores in the fuselage.
Two-sided adhesive foam (servo tape) or rubber rings that hold the foam-wrapped receiver securely in place are
suitable for fastening.
Caution, important!
The receiver has two separate HF-receiver parts that
are equipped with a receiver aerial (1 and 2) each.
To achieve the maximum possible reception line, the
two aerials must be placed at a 90°-angle to each
other.
It is not relevant if one aerial is placed to the right and
the other up or one to the left and the other down. It is
only important that the two aerials are at a 90° angle
to each other.
Attention!
The aerial wire lengths are determined precisely.
For this reason, you must not roll up the aerial wires,
place them in a loop or cut them off. This would decre-
asetherangesignicantlyandthusposeaconsidera-
ble safety risk.
Route the aerial wires out of the mode through an opening in the fuselage if possible. For models with a carbon fuse-
lage, the aerial must be placed to the outside.
Figure 10
Figure 11

18
d) Mounting the Servos
The installation of a servo (1) always depends on the particular
model used. Detailed information on this can be found in the
construction documents of the model.
Generally, however, try screwing in the servos in a vibration-
dampened manner. This is why rubber bushings (2) with metal
sleeves (3) are usually included with the servos.
When servos are obstructed, the servos cannot assume the re-
quired positions. This causes higher power consumption and the
model cannot be controlled properly.
The linkages therefore must work as smoothly as possible wit-
houthavinganyplayinthebearingsordeections.
Before installing the servo lever, take the transmitter and then
the receiver into operation and check the trim at the remote
control transmitter for correct middle position (see following
chapter).
Then always mount the servo stick at a 90° angle to the linkage
rods(seegure9,sketchA).
Theservoleverisatanangletothelinkagerod(seegure9,
sketch B), the control paths of the two control directions will be
unequal.
A slight mechanical inclination due to interlock of the servo le-
vers may be corrected with the trim later.
e) Checking the Servo Function
To run a test, connect the servos used to the receiver. Pay attention to the assignment of the receiver outputs as
described above.
Take the remote control into operation, then the receiver. If attached correctly, the servos should react to movement
of the control sticks at outputs 1 - 4. The servos at the outlets 5 and 6 react depending on the models programmed to
the transmitter and/or the activated switches and controllers. Further information on transmitter programming can be
taken from the following chapter: Programming the Remote Control.
Caution, important!
 Alwaysswitchonthetransmitterrst,thenthereceiver.Whenyouswitchoffthedevices,alwaysswitchoff
thereceiverrst,thenthetransmitter.
Never switch off the remote control as long as the receiver is in operation. This can lead to unexpected
reactions by the model!
Figure 12
Figure 13

19
12. Programming the Remote Control
Your remote control offers a „System setup“ menu for best ad-
justment to your model and a „Functions setup“ menu with diffe-
rent menu items that have many subordinated settings as well.
Depending on the model type (helicopter or plane model) set in
the system menu, the function menu setting options will differ.
The changes of the respective settings are made with the four
programming buttons (also see gure 1, items 9, 10, 14 and
15).
The settings are permanently saved and are retained even when
changing the batteries.
The functions of the operating elements:
• „OK“button
 Tocalltheprogrammingmenus,brieypushthebutton„OK“withthetransmitteron.Thedisplayedoperatingdisplay
switches to the menu display and the transmitter switches to programming mode. This button can also activate
selected settings. If the button is pushed or longer, the factory settings stored in the menu item are called.
• „CANCEL“button
This button allows you to leave the currently selected menu or submenu again. Every brief push of this button takes
you a step back until you reach the operational display. If the button is kept pushed for a while, the changed set
values are stored.
• „UP“and„DOWN“buttons
The two buttons can be used to select the desired menu/submenu or change set values.
The transmitter emits a short signal sound for each permissible push of a button.
Figure 14

20
13. The System Setting Menu „System Setup“
Thebasicsettingsoftheremotecontroltransmitteraremadeinthesystemsetupmenurst.Thesesettingsarenot
referredtoindividualmodels.Thespecicsettingsoftheindividualmodelsareonlymadeafterwardsinthefunction
setting menu (see chapter 14).
To get to the system settings menu, push the button „OK“ with
the transmitter switched on. The operating display in the display
switches to the menu display. The selection window around the
remote control icon shows that you can call the „System Setup“
menu in this setting.
Brieypushthebutton„OK“againtogettothesystemsettings
menu.
Therst6menuitemsofthesystemsettingmenuarenowdis-
played.
The following setting functions are available for you in the system setting menu:
Function Display
Model memory selection „Model select“
Model name settings „Model name“
Model type selection „Type select“
Copying model memory „Model copy“
Deleting model memory „Model reset“
Receiver programming „RX Setup“
Operation as a trainer transmitter „Trainer mode“
Operation as a student transmitter „Student mode“
Control stick assignment „Sticks mode“
Display brightness „LCD brightness“
Transmitter software version „Firmware ver.“
Transmitter software update „Firmware update“
Factory reset „Factory reset“
Figure 15
