Regency Fireplace Products GF950L-NG Quick start guide

WARNING:
If the information in these instructions are not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use petrol or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
919-840
Greenre®GF950L
Gas Fireplace
Owners &
Installation Manual
www.regency-re.com.au
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
MODELS: GF950L-NG
GF950L-LP
GF950L-ULPG
LISTINGS AND CODE APPROVALS
These gas appliances have been tested
in accordance with AS 5263.0, AS/NZS
5263.1.3 and have been certied by the
Australian Gas Association for installation and
operation as described in these Installation
and Operating Instructions.
Must be installed as per AS/NZS5601
Your unit should be serviced annually by
an authorised service person.
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance.
Do not touch any electrical switch.
Do not use any phone in your
building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the re department.
06 June 2018

2Regency GF950L Gas Fireplace
To the New Owner:
Congratulations!
You are the owner of a state-of-the-art Gas Fireplace by REGENCY®. The GF950L has been designed to provide you
with all the warmth and charm of a wood fireplace at the flick of a switch. The model GF950L has been approved
by AGA for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy,
comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with
these instructions and the many features of your Regency® Fireplace.
PAIRING THE REMOTE HANDSET AND CONTROL BOX ID CODE FOR GF950 GAS LOG FIRES
The Remote Control Handset has a set of unique ID codes that is pre-programmed into the memory. This set of ID codes helps to differentiate one Remote
Control Handset from another so that only the control box with a matching ID code will respond to the appropriate Remote Control Handset.
The control box will only learn the Remote ID codes during the first 30 seconds after power is applied and will ignore this special command from the
Remote after the first 30 seconds.
To match the control box to the remote, follow the steps below:
1. Remove a battery from the remote handset.
2. Turn off main power to the control box by turning off the isolation switch near the heater or at the switch on the GPO to the heater.
3. Wait 30 seconds (approximately).
4. Reconnect main power to the control box.
5. Immediately put the battery back in the remote & point the remote in the general direction of the heater.
6. Press and hold the PROG and FAN buttons simultaneously. The letters “LC” will appear on the display indicating the ID codes have been transmitted.
7. Release both the PROG and FAN buttons.
8. The display will revert back to the normal off mode display. The heater should start – fan on, spark, pilot light on, main burner on, even though the remote
screen says the heater is off.
9. Press the OFF button on the remote. The heater should turn off.
10. Wait approximately 30 seconds turn the unit on again & check all the functions work – fan speed can be adjusted, flame height can be adjusted, etc.
Note: The pairing up process can be carried out by anyone.
Note: In addition, please also go to: www.regency-fire.com.au to see the pairing up video.

Regency GF950L Gas Fireplace 3
table of
contents
Copy of Data Badge ......................................................4
Unit Dimensions ............................................................5
Important Message ......................................................6
General Safety Information ............................................6
Installation Checklist ......................................................7
Locating Your Gas Fireplace ..........................................7
Clearances ....................................................................8
Framing Dimensions ......................................................9
Combustible finishing ...........................................10
Unit assembly/ finishing/ mantel clearances + Mantel
leg clearances ......................................................10
Unit Assembly Prior To installation ..............................10
Nailing Strips-Combustible finishing ....................10
Installation Access panel .....................................10
Framing & Finishing (combustible) ..............................11
Combustible Requirements .........................................11
Clearances for combustible finishing with mantel ........12
Combustible Mantel Leg Clearances ...........................12
Unit assembly/ finishing/ mantel clearances
+ Mantel leg clearances .......................................13
Remove top Nailing Strips & standoffs ................13
Installation Access panel .....................................13
Clearances for non-combustible flushed finishing with
mantel ..........................................................................14
non combustible Mantel Leg Clearances .....................14
Flushed Finishing & Framing with Non-combustible
Material ........................................................................15
Non Combustible Requirements ..................................15
zero clearance box framing dimensions ......................16
Note: Fascia Part no. 468-911 must be used with optional
mock fireplace. .............................................................16
Zero clearance box framing and
combustible requirements............................................17
Zero Clearance box installation ..................................18
Installing a TV / ARTWORK flush with the unit ............19
Installing a TV / ARTWORK enclosed above the unit . . 20
Optional Framing kit .....................................................21
Non combustible facing installation .............................22
Framing & Finishing (clean finish installations only) ...23
Exterior Flue Termination Locations ............................24
Clearances ..................................................................25
Flue Restrictor Position ...............................................26
Flueing Introduction .....................................................27
Flueing Arrangement for Horizontal Terminations .......27
Flueing Arrangements ................................................28
Horizontal Termination (Flex) ...............................28
Horizontal terminations ................................................29
Rigid Pipe 4" x 6-5/8" (102mm x 175mm) ...................29
Horizontal Terminations ...............................................30
Rigid Pipe 4" x 6-5/8" (102mm x 175mm) ...................30
Vertical terminations ....................................................31
Rigid Pipe 4" x 6-5/8" (102mm x 175mm) ...................31
Flueing Arrangement for Vertical Terminations ............32
Direct flue zero Clearance top exit vertical flue Kit
Installation instructions GF950 ....................................33
Unit Installation with Horizontal Termination ...............34
102mm x 175mm Flueing ............................................34
Unit installation with Vertical Termination .....................36
102mm x 175mm Flueing ............................................36
High Elevation ..............................................................37
Gas Line Installation ....................................................37
Pilot Adjustment ...........................................................37
Gas Pipe Pressure Testing ..........................................37
Wiring Diagram ............................................................38
845 S.I.T. Valve Description .........................................39
Aeration Adjustment ....................................................39
Optional fan ducting kit installation ..............................40
Optional fan Kit installation .........................................41
Fan duct extension Kit installation ..............................42
Log set installation .......................................................43
Front trim removal / Installation ...................................45
Inner panel removal / Installation .................................45
Faceplate and deflector installation .............................46
Premium Black Glass Fascia Shown ..........................46
Screen & inner Door frame Installation ........................47
Optional finishing trim installation ................................48
Operating Instructions ................................................49
Lighting Instructions ....................................................49
Shutdown Instructions .................................................49
Remote Control ..........................................................49
Summary Of Controls .................................................49
Fan Operation ..............................................................49
Copy of Lighting Plate Instructions ..............................50
Normal Operating Sounds Of Gas Appliances ............50
Resetting the unit .........................................................50
Fan Service .................................................................51
Maintenance Instructions ............................................52
General flue Maintenance ...........................................52
Glass Gasket ...............................................................52
Glass Door ...................................................................52
Glass Replacement .............................................52
Troubleshooting ...........................................................53
Glass door Installation .................................................54
Valve Tray Replacement ..............................................55
Electronic components parts list ..................................56
Main Assembly ............................................................57
Accessories .................................................................59
Warranty ......................................................................61

4Regency GF950L Gas Fireplace
SAFETY LABEL
data badge
This is a copy of the data badge that accompanies each GF950L Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review.
NOTE: Regency® units are constantly being improved. Check the badge on the unit and if there is a difference, the badge on the unit is the correct one.
COPY OF DATA BADGE
Part #: 908-602c
Colour: Black on White, expect what is indicated in yellow.
Size: printed at 100%
July 18/17: Rev. C - Changed wording on Line 3 as per AGA -
removed Lines 4, 6 and 7 - updated caution
symbol size and font size to 10pt
May 7/14: Changed wording on Line 3 as per AGA
Dec 12/12: Removed redundant ‘do not’ from the last line
Mar. 3/09: Rev. A - added information
Nov. 6/06: no changes to artwork.
DO NOT OPERATE THIS APPLIANCE BEFORE READING THE
INSTRUCTIONS BOOKLET.
DO NOT PLACE ARTICLES ON OR AGAINST THIS
APPLIANCE
DO NOT STORE CHEMICALS OR FLAMMABLE MATERIALS
NEAR THIS APPLIANCE.
DO NOT OPERATE WITH PANELS, COVERS OR GUARDS
REMOVED FROM THIS APPLIANCE
.
908-602c
Part #: 919-841
Colour: Black on Grey
Size: 100% 7" W x 2.7" H
Dec.06/17 - draft for approval
Apr. 30/18 - Added Gas Consumption Low + Manifold Pressure Low Values
Serial
Number
Regency Gas Fireplace
463
Electrical: 240V 50 Hz
919-841
Gas Type NG LP ULPG
Model GF950L-NG GF950L-LP GF950L-ULPG
Gas Consumption High
Gas Consumption Low
35 MJ/hr 28 MJ/hr 28 MJ/hr
Manifold Pressure High
Manifold Pressure Low
0.87 kPa 2.49kPa 2.49 kPa
Injector Size 1 x #35 1 x #53 1 x #53
2.80mm 1.50mm 1.50mm
Model
Approval No. AGA 7908 G
AS/NZS 5263.0 & AS/NZS 5263.1.3
Distributed by:
Western Australia:
Air Group Australia
28 Division St
Welshpool, WA 6106
Eastern Australia
Fireplace Products
Australia Pty. Ltd.
1 Conquest Way
Hallam, VIC 3803
New Zealand:
Aber Holdings
17 Main Street Place
Te Rapa, HA 3200
To be installed by an authorised person in
accordance with installation instructions provided
with the appliance.
25 MJ/hr 23 MJ/hr 23 MJ/hr
0.4 kPa 1.6 kPa 1.6 kPa

Regency GF950L Gas Fireplace 5
1192mm
989mm
438mm
641mm
996mm
990mm
332mm
1000mm
480mm
1034mm
142mm
436mm
Black Premium Glass FasciaUnit with Finishing Trim - Flush Finish
Unit shown with Black Flat Fascia
DIMENSIONS
dimensions
UNIT DIMENSIONS
996mm
1091mm
113mm
540mm
890mm
332mm
159mm
726mm
796mm
933mm
14mm
523mm
560mm
258mm
500mm
74mm

6Regency GF950L Gas Fireplace
installation
11. Under no circumstances should this appliance
be modified. Parts that have to be removed
for servicing should be replaced prior to
operating this appliance.
12. Installation and any repairs to this appliance
should be done by an authorized service
person. A professional service person should
be called to inspect this appliance annually.
Make it a practice to have all of your gas
appliances checked annually.
13. Do not slam shut or strike the glass door.
14. Under no circumstances should any solid
fuels (wood, paper, cardboard, coal, etc.) be
used in this appliance.
15. The appliance area must be kept clear and
free of combustible materials, (gases and
other flammable vapours and liquids).
GENERAL SAFETY
INFORMATION
1. The appliance installation must conform with
local codes or, in the absence of local codes,
with the current Installation and Building
Codes.
2. The appliance when installed, must be elec-
trically grounded in accordance with local
codes.
3. See general construction and assembly
instructions. The appliance and vent should
be enclosed.
4. This appliance must be connected to the
specified vent and termination cap to the
outside of the building envelope. Never vent
to another room or inside a building. Make
sure that the vent is fitted as per Venting
instructions.
5. Inspect the flueing system annually for
blockage and any signs of deterioration.
6. Flueing terminals shall not be recessed into
a wall or siding.
7. Any safety glass removed for servicing must
be replaced prior to operating the appliance.
8. To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.
9. Wear gloves and safety glasses for protection
while doing required maintenance.
10. Be aware of electrical wiring locations in
walls and ceilings when cutting holes for
termination.
"THIS UNIT MUST ALWAYS
TERMINATE / FLUE
DIRECTLY TO THE OUTDOORS."
IMPORTANT MESSAGE
SAVE THESE
INSTRUCTIONS
The GF950L™ Direct Vent Fireplace must be installed
in accordance with these instructions. Carefully read all
the instructions in this manual first. Consult the "authority
having jurisdiction" to determine the need for a permit
prior to starting the installation. It is the responsibility
of the installer to ensure this fireplace is installed in
compliance with manufacturers instructions and all
applicable codes and complies with a AS/NZS 5601.
CLOTHING OR OTHER FLAMMABLE
MATERIALSHOULDNOTBEPLACED
ON OR NEAR THE APPLIANCE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURES, ESPECIALLY
THE FIREPLACE GLASS, AND SHOULD
STAY AWAY TO AVOID BURNS OR CLOTH-
ING IGNITION.
INSTALLATION AND REPAIR SHOULD
BE DONE BY AN AUTHORIZED SERVICE
PERSON. THE APPLIANCE SHOULD BE
INSPECTED BEFORE USE AND AT LEAST
ANNUALLY BY A PROFESSIONAL SERVICE
PERSON. MORE FREQUENT CLEANING
MAY BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL, ETC. IT IS IMPERATIVE THAT
CONTROL COMPARTMENTS, BURNERS
AND CIRCULATING AIR PASSAGEWAYS OF
THE APPLIANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED OUT
OFTRAFFIC AND AWAY FROM FURNITURE
AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLYWILLVOIDYOUR
WARRANTY AND MAY CAUSE A SERIOUS
HOUSE FIRE.
YOUNG CHILDREN SHOULD BE
CAREFULLY SUPERVISED WHEN
THEY ARE IN THE SAME AREA AS
THE APPLIANCE. TODDLERS,YOUNG
CHILDREN AND OTHERS MAY BE
SUSCEPTIBLE TO ACCIDENTAL
CONTACT BURNS. A PHYSICAL
BARRIERS IS RECOMMENDED IF
THERE ARE AT RISK INDIVIDUAL IN
THE HOUSE. TO RESTRICT ACCESS
TO A FIREPLACE OR STOVE,INSTALL
AN ADJUSTABLE SAFETY GATE TO
KEEPTODDLERS,YOUNG CHILDREN
AND OTHER AT RISK INDIVIDUALS
OUT OFTHE ROOM AND AWAY FROM
HOT SURFACES.

Regency GF950L Gas Fireplace 7
installation
This includes:
1) Clocking the appliance to ensure the correct
firing rate (rate noted on label) after burning
appliance for 15 minutes.
2) If required, adjusting the primary air to ensure
that the flame does not carbon. First allow
the unit to burn for 15-20 min. to stabilize.
CAUTION: Any alteration to the product that
causes sooting or carboning that results
in damage is not the responsibility of the
manufacturer.
LOCATING YOUR
GAS FIREPLACE
A) Flat on Wall
B) Flat on Wall Corner
C) Recessed into Wall/Alcove
D) Corner
Diagram 1
1. When selecting a location for your fireplace,
ensure that the clearances are met.
2. The appliance must be installed on a flat,
solid, continuous surface For example a
wood, metal or concrete floor. In a raised (on
the wall) application the appliance must be
installed on a metal or wood panel extending
the full width and depth of the appliance.
3. The GF950L Direct Vent Gas Fireplace can
be installed in a recessed position or framed
out into the room as in A, B, C and D. See
Diagram 1.
INSTALLATION CHECKLIST
1. Locate appliance:
a) Room location (Refer to "Locating Your
Gas fireplace" section)
b) Clearances to Combustibles (Refer to
"Clearances" section)
c) Mantle Clearances (Refer to "Mantel
Clearances" section)
d) Framing & Finishing Requirements (Refer
to "Framing & Finishing" section)
e) Flueing Requirements (Refer to "Flueing"
section)
2. Assemble the standoffs and nailing strips
(Refer to "Unit Assembly Prior to Installation).
3. Slide unit into place.
4. Install vent (Refer to "Flueing Arrangement"
sections).
5. Make gas connections (Refer to "Gas Line
Installation section).
6. Test the pilot (Refer to "Pilot Adjustment"
section).
7. Test Gas Pressure (Refer to "Gas Pipe Pres-
sure Testing" section).
8. Install standard and optional features. Refer
to the following sections:
a) Log Install
b) Faceplate / Door Frame Overlay
c) Remote Control
9. Final check.
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctly and operation fully explained to
customer.
4. The GF950L Direct Vent Gas Fireplace is
approved for alcove installations, see "Clear-
ances" section for details.
5. We recommend that you plan your instal-
lation on paper using exact measurements
for clearances and floor protection before
actually installing this appliance. Have an
authorized inspector, dealer, or installer
review your plans before installation.
Note: For ue terminations refer to "Exterior
Flue Termination Locations" section.

8Regency GF950L Gas Fireplace
Caution Requirements
The top, back and sides of the fireplace are defined by
standoffs. The metal ends of the standoff may NOT be
recessed into combustible construction.
WARNING
Fire hazard is an extreme risk
if these clearances (air space) to combustible materials are not
adhered to. It is of greatest importance that this replace and vent
system be installed only in accordance with these instructions.
CLEARANCES
The clearances listed below are Minimum distances unless otherwise stated:
A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance
that this fireplace and vent system be installed only in accordance with these instructions.
Clearance: Dimension Measured From:
A: Mantel Height (min.) 191mm Top of Fireplace Opening (Hot Air Outlet)
B: Sidewall (on one side) 146mm Side of Fireplace Opening
C: Ceiling
(room and/or alcove) 1003mm Top of Fireplace Opening
D: Mantel Depth (max.) 305mm 420mm Above Fireplace Opening
E: Alcove Width 1480mm Sidewall to Sidewall (Minimum)
F: Alcove Depth 787mm Front to Back Wall (Maximum)
G: From Floor 605mm Top of Fireplace Opening (Hot Air Outlet)
Note: 0 No hearth required
Installed close
to ceiling.
Flue Clearances to Combustibles
Horizontal - Top 76mm
Horizontal - Side 51mm
Horizontal - Bottom 51mm
Vertical 51mm
Alcove
E
F
F
E
D
A
B
Installed Close
to Floor
G
IMPORTANT: If installing a television above
this appliance, the television must be either
fully recessed into the wall above the
replace and or have a mantle below the
television. If the television is left unprotected,
the extreme heat being emitted from this
appliance will result in damage to the
television. See clearance requirements for
both mantle and or enclosing the top of the
appliance in this manual.
installation
NOTE: The unit can be installed onto a combustible base.

Regency GF950L Gas Fireplace 9
installation
FRAMING DIMENSIONS
Framing
Dimensions Description GF950
A Framing Height 940mm combustible nish
A¹Framing Height -Steel Stud 756mm non combustible steel stud
B Framing Width 1127mm
C Framing Depth 552mm
D Minimum Height to Combustibles 1156mm
E Corner Wall Depth 1273mm
F Corner Facing Wall Width 1800mm
G Vent Centerline Height 991mm
H* Non-combustible facing height *see non-combustible facing height in this manual
I Gas Connection Opening Height 38mm
J Gas Connection Height 67mm
K Gas Connection Inset 44mm
L Gas Connection Opening Width 89mm
NOTE: A minimum thickness of 12mm non-combustible facing board compliant with AS1530-1 and AS1530-3 is required when
using the non combustible flush finishing option.
A minimum thickness of 10mm-19mm combustible facing board is required when choosing the combustible flush finishing option.
Note: must maintain 13mm air gap all around the perimeter of the appliance when choosing this option.
D
G
H
Non-Combustible
Facing
Header
F
E
I
J
KL
Flex or Rigid Pipe
Drywall or
other facing
C
C
A
B
C
Timber
Studs
Finished Floor
A
B
C
Timber
Studs
Finished Floor
Non-combustible Flush Finishing Framing
A
1
Steel Stud
on edge
NOTE: Do not place timber
studs below the timber fram-
ing studs already in place.
Additional steel studs must
be added as shown when
choosing the non combus-
tible flush finishing option.
Note: Steel stud must be installed
after unit has been positioned in
place and prior to installation of
non- combustible finishing
Note: If raising the unit, then the
minimum framing height mea-
surement (A) must be adhered to.
For example: Unit raised 300mm
then A+ 300mm = 1240 mm.
Combustible flush finishing Framing

10 Regency GF950L Gas Fireplace
Nailing Strips
(DO NOT REMOVE NAILING STRIPS
WHEN USING COMBUSTIBLE FINISHING)
installation
UNIT ASSEMBLY PRIOR TO INSTALLATION
The nailing strips must be correctly positioned and attached before
unit is slid into position.
NAILING STRIPS-COMBUSTIBLE FINISHING
The nailing strips come attached to the unit. There is 1 plate on each side,
1 on the top.
The top and side nailing strips are secured to the framing.
IMPORTANT NOTE
Framing depth measurement is noted with the nailing strips
set as far forward on the rebox as possible. The nailing
strips can be adjusted back up to 38mm to allow for varying
thicknesses in non-combustible material & wall nishes.
INSTALLATION ACCESS PANEL
The unit is equipped with a removable access panel for pre-finish installation
of optional components - this panel is located on the lower front face.
1. Remove 4 screws to remove access panel.
2. Easier access to gas connection with panel removed.
3. Install any optional components with access panel removed.
4. Reinstall access panel, line up 2 upper tabs and secure in place with
4 screws.
Note: Access panel is no longer usable/accessible once facing material
installed.
Installation Access Panel
Tab locations on access panel
COMBUSTIBLE FINISHING
UNIT ASSEMBLY/ FINISHING/ MANTEL CLEARANCES + MANTEL LEG CLEARANCES

Regency GF950L Gas Fireplace 11
installation
COMBUSTIBLE REQUIREMENTS
FRAMING & FINISHING (COMBUSTIBLE)
Note:
Depending on the material used for finishing, the nailing strips must
be set accordingly so that the finished material is always be flush
with the edge of the flange.
If finishing with material with a combined thickness greater than
19mm, non-combustible material must be used.
Note:
*Finishing Trim or one of the fascias must be used with com-
bustible nishing.
10mm to 19mm combustible nishing can be used if the 13mm
air gap around the front facing of the unit is maintained. Finishing
material cannot be thicker than 19mm and must be ush with the
front edge of the ange.
Note:
• The siding nailing strips are factory set at 10mm. The top nailing
strip is xed during transit to the rear of the appliance.
• Do not place any reinforcement in front of header and behind
nishing material.
• The nailing strip must be used. It is xed during transit to the
rear of the unit.
NOTE:
The appliance must be installed on a flat,
solid, continuous surface For example a
wood, metal or concrete floor. In a raised
(on the wall) application the appliance
must be installed on a metal or wood
panel extending the full width and depth
of the appliance.
NOTE:
Do not remove the stando󰀨s which are
located around the perimeter o󰀨 this unit
These are in place and act as a guide for
the combustible material to be placed.
148mm
470mm
1021mm
618mm
Finished
Material
10mm-19mm thick-
ness using combus-
tible finishing
Note: must maintain
13mm air gap all
around
(see diagrams below
and on next page)
1st slot
Unit
13mm
gap
NOTE: Maintain a 13mm gap
all round.
A minimum of 10mm to
maximum 19mm material
thickness is required.

12 Regency GF950L Gas Fireplace
CLEARANCES FOR COMBUSTIBLE FINISHING WITH MANTEL
Due to the extreme heat this fireplace emits, the mantel clearances are critical.
Combustible finishing and mantel clearances are shown in the diagram
on the right. Finishing Trim must be used with combustible finishing.
Note: Maximum combustible finishing material thickness is 19mm
measured from the front of the fireplace opening. If total
finishing material is greater than 19mm, non-combustible
must be used.
Note: Ensure the paint that is used on the mantel and the facing is
"high quality" or the paint may discolour.
COMBUSTIBLE MANTEL LEG CLEARANCES
Mantel leg & combustible finishing clearances as per diagram:
Combustible Material
(152mm)
(305mm)
0
To Unit
Base
(618mm)
(254mm)
Top of
Fireplace
Opening
(508mm)
(305mm)
(407mm)
(178mm)
Combustible Stud
(On Edge)
Nailing Flange
Combustible facing
(min. 10mm- max. 19mm)
(234mm)
(200mm)
(100mm)
(309mm)
Allowable mantel
leg projection
181mm
254mm
330mm
38mm
MANTEL LEG
102mm
178mm
Allowable mantel
leg projection
181mm
254mm
330mm
38mm
MANTEL LEG
102mm
178mm
Allowable mantel
leg projection
181mm
254mm
330mm
38mm
MANTEL LEG
102mm
178mm
13mm Gap 13mm Gap
Combustible Combustible
installation
IMPORTANT:

Regency GF950L Gas Fireplace 13
installation
INSTALLATION ACCESS PANEL
The unit is equipped with a removable access panel for pre-finish installation
of optional components - this panel is located on the lower front face.
1. Remove 4 screws to remove access panel.
2. Easier access to gas connection with panel removed.
3. Install any optional components with access panel removed.
4. Reinstall access panel, line up 2 upper tabs and secure in place with
4 screws.
Note: Access panel is no longer usable/accessible once facing material
installed.
Installation Access Panel
Tab locations on access panel
Remove 7 standoffs
REMOVE TOP NAILING STRIPS & STANDOFFS
Remove the top nailing strip/standoff by removing 4 screws in locations
shown in Diagram to the right, then lift off and recycle.
NON COMBUSTIBLE FLUSHED FINISHING
UNIT ASSEMBLY/ FINISHING/ MANTEL CLEARANCES + MANTEL LEG CLEARANCES
Break off the 7 standoffs with a pair of pliers.

14 Regency GF950L Gas Fireplace
CLEARANCES FOR NON-COMBUSTIBLE FLUSHED FINISHING WITH MANTEL
Due to the extreme heat this fireplace emits, the mantel
clearances are critical.
Combustible mantel clearances from top of front facing are shown
in the diagram on the right.
Note: For a flushed finish using non-combustible finishing, seven
13mm stand-off tabs around the fireplace opening must be broken
off. The top nailing flange cannot be used and a non-combustible
steel stud must be installed to support the non-combustible facing.
Note: Ensure the paint that is used on the mantel and the
facing is "high quality" or the paint may discolour.
NON COMBUSTIBLE MANTEL LEG CLEARANCES
Mantel leg & Non-combustible finishing clearances as per diagram: (Flushed Finish)
Allowablemantel
leg projection
181mm
254mm
330mm
38mm
MANTELLEG
102mm
178mm
Allowablemantel
leg projection
181mm
254mm
330mm
38mm
MANTELLEG
102mm
178mm
Allowablemantel
leg projection
181mm
254mm
330mm
38mm
MANTELLEG
102mm
178mm
83mm
Non-combustible
83mm
Non-combustible
Combustible Material
(152mm)
(305mm)
0
To Uni
t
Base
(605mm)
(254mm)
Top of
Fireplace
Opening
(508mm)
(305mm)
(420mm)
(191mm)
Non-Combustible facing (min.12mm)
Non-Combustible steel stud
(152mm)
756mm to underside
of steel stud
(100mm)
(247mm)
(200mm)
(322mm)
installation

Regency GF950L Gas Fireplace 15
installation
NON COMBUSTIBLE REQUIREMENTS
FLUSHED FINISHING & FRAMING WITH NON-COMBUSTIBLE MATERIAL
Note: For flush finishing, the top nailing strip must be removed and a non-
combustible steel stud support added.
The seven fireplace opening standoffs which are located on this unit can
be removed when non combustible material is installed flush with the unit.
(see P. 13).
Non-combustible finishing material on the top and sides must also be used.
NOTE:
The appliance must be installed on
a flat, solid, continuous surface For
example a wood, metal or concrete
floor. In a raised (on the wall) ap-
plication the appliance must be
installed on a metal or wood panel
extending the full width and depth
of the appliance.
796mm
605mm
1165mm
Non-combustible
Combustible
Combustible
Steel Stud
on edge
T
imber Stud
Timber Stud
159mm
446mm
Non-Combustible
Material
Combustible
Material
Finished
Material
* diagrams shown below are
with top nailing strip removed.
12mm
25mm
38mm
Unit
Unit
Unit MINIMUM THICKNESS OF THE FINISH MATERIAL: 12MM
A minimum thickness of 12mm non-
combustible facing is required.

16 Regency GF950L Gas Fireplace
installation
ZERO CLEARANCE BOX FRAMING DIMENSIONS
Note: Fascia Part no. 468-911 must be used with optional mock fireplace.
A
B
C
D
F
E
H
I
J
G
Framing dimension Description GF950L
A Framing Height 1267mm
B Framing Width 1127mm
C Framing Depth 560mm
D Minimum Raised Height 100mm
E Corner Wall Depth 1564mm
F Corner Facing Wall Width 2212mm
G Gas Connection Opening Height 38mm
H Gas Connection Height 67mm
I Gas Connection Inset 44mm
J Gas Connection Opening Width 89mm
K Zero Clearance Box Height 1138mm
L Zero Clearance Box Width 560mm
NOTE: The unit and box must be raised a
minimum of 100mm for the Zero Clearance
fascia to fit.
NOTE: The zero clearance box must be
installed on a metal or wood base extending
the full width and depth of the box.

Regency GF950L Gas Fireplace 17
installation
ZERO CLEARANCE BOX FRAMING AND COMBUSTIBLE REQUIREMENTS
1073mm
941mm
841mm
Raise 100mm - Min.
Material
Thickness
Faceplate
Unit
Slots
1 2 3
The following material thicknesses may be accommodated by installing the Faceplate on slot 1, 2 or 3:
1= 10-12mm
2= 16-18mm
3 = 22-24mm

18 Regency GF950L Gas Fireplace
installation
ZERO CLEARANCE BOX INSTALLATION
1. Depending on which way the unit will be vented -- remove either the top
centre or back knockout.
tooltip
2. Slide the box into the framed opening.
3. Secure the box to the framing with 2 screws on each side
and the 2 holes on the base of the box.
4. Slide the unit into place while guiding the unit flue assembly back into
position on top of the unit and secure to the zero clearance box with 2
screws on each side.
5. Install flex venting through either top or back of zero clearance box.
Remove either top or back knockout
Slide Zero Clearance box into frame opening
Knockouts
tooltip

Regency GF950L Gas Fireplace 19
installation
INSTALLING A TV / ARTWORK FLUSH WITH THE UNIT
Note: All wiring should stay free and clear of the vent system to avoid damage due to heat, if located directly in front of the vent system.
Ensure wiring is secured without any sag.
Heat deflector must overhang front of TV by 51mm.
Follow mantel clearance chart for install height and heat deflector depth.
Note: The TV mounting bracket can not be secured directly to the appliance. It must be secured to framing. The TV depicted in the picture may need to be
higher depending on the style of TV mounting bracket used. The mounting bracket shown is a simple single strip TV secured to framing.
L
2"
51mm
DETAIL L
SCALE 1 : 6

20 Regency GF950L Gas Fireplace
installation
38.741in
984mm
M
5 3
4"
146mm
14 9
16
"
370mm
DETAIL M
SCALE 1 : 6
INSTALLING A TV / ARTWORK ENCLOSED ABOVE THE UNIT
Maximum recess is 146mm.”
Minimum height is 370mm from top lip.
Ensure framing does not interfere with venting
