Reichert Longlife Project-O-Chart Quick start guide

12084
Longlife™
Project-O-Chart®
Parts and Service Manual

CLAIMS FOR SHORTAGES
We use extreme care in selection, checking,
rechecking and packing to eliminate the possibility
of error. If any shipping discrepancies are
discovered:
1 . Carefully go through the packing materials to be
sure nothing was inadvertently
overlooked when the unit was unpacked.
2. Call the distributor you purchased the product
from and report the shortage. The contents of
the shipping container are packed at the
factory and none should be missing if the box
has never been opened.
3. Claims should be filed within 30 days.
PRODUCT CHANGES
Reichertreservestherighttomakechangesin
design or to make additions to or improvements in
its products without obligation to add such to
products previouslymanufactured.
REICHERTBRAND
NAME/TRADEMARKS/TRADENAMES
ReichertOphthalmic Instruments aremanufactured
and/ordistributed by Reichert Inc. The following are
trademarksof Reichert Inc.
Ful-Vue Keratometer Lenschek
Lensometer Longlife MarkIV
NCT Non-Contact Phoroptor
P-O-C Prelude Premier
Project-O-Chart Radiuscope RxMaster
Selectra Ultramatic Vertometer
XPERT XCEL
CLAIMS FOR DAMAGE IN TRANSIT
Our shipping responsibility ceases with the safe
delivery in good condition to the transportation
company. Claims for loss or damage in transit
should be made promptly and directly to the
transportationcompany.
If, upon delivery, the outside of the packing case
shows evidence of rough handling or damage, the
transportation company’s agent should be
requested to make a “Received in Bad Order”
notation on the delivery receipt. If within 48 hours
of delivery, concealed damage is noted upon
unpacking the shipment and no exterior evidence
of rough handling is apparent the transportation
company should be requested to make out a “Bad
Order” report. This procedure is necessary in
order for the dealer to maintain the right of
recovery from the carrier.
WARRANTY
ThisReichertproduct is warranted by Reichert Inc.
againstdefective materialandworkmanship under
normaluseforaperiodof one year from the date of
invoiceto the original purchaser. (Anauthorized
distributor shall not be considered an original
purchaser.)Under this warranty,Reichert's sole
obligationisto repair or replace the defective part or
productatReichert's discretion.
Thiswarrantyappliestonewproductsanddoesnot
apply to a product which has been tampered with,
altered in any way, misused, damaged by
accident or negligence, or which has the serial
numberremoved, altered or effaced. Nor shallthis
warrantyextendtoaproductinstalledoroperatedin
amannernotinaccordancewiththeapplicable
Reichert instruction manual, nor to a product which
hasbeen sold, serviced, installed or repaired other
than by a Reichert factory, Technical Service Center
orauthorized Reichert Ophthalmic Instruments
Dealer.
Lamps,bulbs,charts,cardsandotherexpendable
items are not covered by this warranty.
All claims under this warranty must be in writing
directed to the Reichert factory, Technical Service
Center, orauthorized Instrument distributor making
the original sale and must be accompanied by a
copyof the purchaser’s invoice.
This warranty is in lieu of all other warranties
implied or expressed. All implied warranties of
merchantabilityorfitnessforaparticularuseare
herebydisclaimed. No representative or other
person is authorized or allowed to make any other
obligationsfor Leica.
Reichert shall not be liable for any special,
incidental,or consequential damages for any
negligence, breach of warranty, strict liability or any
other damages resulting from or or relating to the
design, manufacture, sales, uses or handling of the
product.
PATENT WARRANTY
Ifnotifiedpromptly in writting of any action brought
against the Purchaser based on claims that the
instrument infringes a U.S. Patent, Reichert will
defend such action at its expense and will pay
costs and damages in any such action, provided
thatReichertshall have sole control of the defence
of any such action with information and assistance
(atReicher''s expence) for such defence, and of all
negotiationfor the settlement and compromise
thereof.
12084-102 Rev B Page 2

TABLE OF CONTENTS
SERVICE Page 4
1. TROUBLESHOOTING CHART Page 5
2.DISASSEMBLY, REASSEMBLY AND ADJUSTMENT Page 6
2.1 Rearcoverremovalandreplacement.................................................................... Page 6
2.2 Frontcoverremovalandreplacement................................................................... Page 6
2.3 Projectiontubedisassemblyandreassembly...................................................... Page 6
2.4 Lampsocketreplacement...................................................................................... Page 6
2.5 Electronicbracketassemblyreplacement............................................................ Page 7
2.6 Switchreplacement................................................................................................. Page 7
2.7 Lampadjustment...................................................................................................... Page 7
2.8 Cross-slidedetentadjustment................................................................................ Page 7
2.9 Verticalslidesprocketadjustment.......................................................................... Page 7
3. SETTING LINE VOLTAGE SELECTOR Page 8
4. ADJUSTING LAMP INTENSITY FOR DIFFERENT LINE VOLTAGES Page 8
4.1 Highline voltages(120-130or240-260volts)....................................................... Page 8
4.2 Lowlinevoltages(100-110or200-220volts)....................................................... Page 8
PARTS LISTING AND SCHEMATIC DRAWINGS Page 9
12084-102 Rev B Page 3

SERVICE
Thismanual contains serviceinformationincluding
schematic drawings and a complete listing of parts
forthe 12084LongLife
TM
Project-O-Chart® and
relatedmounts.
Theservice information providedin this manualhas
beenprepared as an instructionalguidefor
performingtroubleshooting, fieldrepair androutine
maintenanceof the 12084 LongLifeP-O-C
TM
.The
instructionsaredesignedto assist authorized repair
andservice technicians andrequire prior knowledge
andexperiencewith precision mechanical, optical
andelectronic test instruments. Therefore, for
safetyand continued high performance of this
instrument, it is suggested that any repairs or
servicebe performed bythoseauthorized.
Instructions for setup and use, in addition to
directionson the care of this instrument,are given
inthe Instruction Manual 12084-101 which is
packagedwiththe instrument or can be ordered
throughReichert Ophthalmic Instruments
3374WaldenAve.Depew,New York, 14043.
12084-102 Rev B Page 4

1. TROUBLESHOOTING CHART
SYMPTOM
Correct size image cannot be obtained
Image cannot be focused
Dim image or uneven illumination
No light when turned on
Slide will not hold position or does
not move smoothly
Lamp flickers
POSSIBLE CAUSE
1. P-O-C not positioned correctly - see
instructions for proper positioning
1. Lenses in projection tube improperly
installed
2. May require auxiliary lens to be installed
3. If a mirror is used, the mirror is not an
optical quality first surface mirror
1. Lamp not positioned correctly
(See Section 2.7)
1. Lamp burned out
2. Fuse blown
3. Check wall outlet - Is outlet on a wall
switch?
4. Defective switch
(See Section 2.6)
5. Defective lamp socket
(See Section 2.4)
6. Defective electrical assembly
(See Section 2.5)
1. Adjust vertical slide sprocket
(See Section 2.9)
1. Defective lamp socket
(See Section 2.4)
2. Poor connection at one of the electric
plugs
12084-102 RevB Page 5

2.3 PROJECTIONTUBEDISASSEMBLY AND
REASSEMBLY -Referto Figure2.
It is not normally necessary to disassemble the
projectiontube. After prolonged use (several
years),depending on the environment,afilm
may form on the inside surfaces of the lenses.
THETUBE SHOULD ONLY BE
DISASSEMBLEDFOR CLEANINGWHEN
ABSOLUTELY NECESSARY.
2.3.1 Removethe projection tubefromthe
projectorby loosening the guide tube
lock screw (20).
2.3.2 Removethe inner tube by looseningthe
outer tube lock screw (20).
2.3.3 Removethe two retainingrings(38).
2.3.4 Standthetube upright on the end from
whichthe retainingringswere removed
and slowly lift the tube from the stack of
lenses and spacers. NOTE: It is now
advisable to mark the edges of the lenses
using a soft pencil so that they can be
replacedin the same order and with the
samesideup as in Figure 2.(32-37)
2.3.5 After the lenses are cleaned, place in a
"stack”andslipthetube(32)downover
the stack. Push the bottom spacer up
andinstallretainingrings.
2.3.6 Usethesame technique when
disassembling the lens assembly in the
largetube(24-27).
2.4LAMP SOCKET REPLACEMENT -Referto
Figure 3.
2.4.1 Removetherearcover
2.4.2 Unplug the lamp socket assembly (92)
fromthe PC board.
2.4.3 Removethe two screws (94)which
secure the lamp socket.
2.4.4 Pullthewiresandconnectorthroughthe
hole in the bracket.
2.4.5 Feedtheconnectorand wires of the new
socket through the hole in the bracket
andpluginto PC board.
2.4.6 Attach the socket using the two screws.
2. DISASSEMBLY, REASSEMBLY AND
ADJUSTMENT
2.1 REARCOVERREMOVALAND
REPLACEMENT- Refer toFigure3.
2.1.1 Unplug the powercord from the
Project-O-Chart.
2.1.2 Using a tool, rotate the cam-lock (78)
1/4turn counter-clockwise andremove
therear cover. Therearcover is replaced
byplacing the cover into position and
rotating the cam-lock 1/4 turn clockwise.
2.2 FRONTCOVERREMOVAL AND
REPLACEMENT- RefertoFigures 2 and 3.
2.2.1 Remove therearcover.
2.2.2 Remove the two mountingknobs(23).
2.2.3 Loosen thesprocket and spacer
setscrew (18). This is accessible through
a small hole in the rear plate near the
electrical bracket.
2.2.4 Remove the two slide adjustment knobs.
(1).
2.2.5 Remove the shaft (2) from clip (3) side.
Sprocket(17) and friction springs, washer
and spacer (14, 15, 16) remain in place.
2.2.6 Remove the fourscrews(22) which
securethe front cover.The cover may
nowbe spread apart to clear mounting
bosses on slide adjustment casting. Pull
coverforward andremove. Dothis
carefully toavoid marking projection
tube.
2.2.7 The cover is replacedbyreversing the
aboveprocedure. Check the operationof
the sprocket mechanism using a slide.
Adjustper 2.9 if needed.
12084-102 Rev B Page 6

2.5 ELECTRICALASSEMBLY REMOVALAND
REPLACEMENT- Referto Figure 3.
2.5.1 Remove the rear cover.
2.5.2 Removethe screws (87) securingthe
bracketand remove the bracket.
2.5.3 Unplug the lamp socket assembly (92)
fromthe PC board.
2.5.4 Removethelampsocketplate(89)by
turningthe three adjusting screws (90)
counter clockwise.
2.5.5 The electrical bracket assembly is
replacedby reversing the above.
2.5.6 Reattach the lamp socket plate. The
screwsare self-tapping and may be
difficult to start. USE CARE.
2.5.7 Lamp adjustment per 2.7 will be
necessary.
2.6 SWITCH REPLACEMENT - RefertoFigure 3.
2.6.1 Remove the rear cover
2.6.2 Disconnect the wires from the switch (73)
and remove the switch from the
electrical bracket (86) by pressing firmly
onthe retaining wings on either side of
the switch.
2.6.3 Replacethe switch in reverseorder.
Make sure the switch is oriented
correctlybefore seating.
2.7 LAMP ADJUSTMENT -RefertoFigure 3.
2.7.1 Remove the rear cover.
2.7.2 Re-connectpower cord to projectorand
walloutlet.
2.7.3 Mark projection tubes to identify their
positions.
2.7.4 Loosenlock screws (20,figure 2) and
slide both tubes into unit as far as
possible.
2.7.5 Turnontheprojector and hold a card or
piece of paper 1" (25mm) in front of the
objectivetube.
2.7.6 Adjust the three adjusting screws (90) so
that the image of the filament is centered
and in best focus.
2.7.7 Re-positionprojection tubes to their
previousposition and tighten lock
screws.
2.7.8 Checkfor even fill of screen with no
noticeabledarkening in any corner of the
screen. Readjust the three adjustment
screws to correct any darkening.
2.8 CROSSSLIDEDETENT ADJUSTMENT -
Referto Figure 3.
2.8.1 Removetherearcover.
2.8.2 Loosenthescrew(54) and adjust pin (50)
forproper loading. Tighten the screw for
amore positive index.
2.9 VERTICALSLIDESPROCKET
ADJUSTMENT
2.9.1 Removerearcover.
2.9.2 Removeelectrical bracket ifneeded
(see2.5above).
2.9.3 Using a small hex wrench loosen the set
screw (18) on the vertical slide sprocket
(17) thru the sprocket adjusting hole in
therear plate.
2.9.4 Move sprocket until teeth line up with
center of holes in vertical slide.
2.9.5 Tightenset screw.
2.9.6 Insert slide and check for smooth
verticalmotion of slide.
2.9.7 Repeat2.9.3- 2.9.6 as needed.
2.9.8 Insure that set screw is securely
tightenedandreattach electrical bracket
ifneeded.
2.9.9 Checkfor proper lamp alignmentand
readjustper 2.7 if needed.
12084-102 Rev B Page 7

12084-102 Rev B Page 8
4.1 HIGH LINE VOLTAGES (120-130 OR 240-260
VOLTS)
If the local line voltage is at least 10 volts
greaterthan the nominalvoltages mentioned
inSection 3 (115 volts or230 volts), referto
Figure 1 and locate the PC board trace on the
backsideof the PC board labeled “Cut for
120-130or 240-260VoltOperation.”The trace
can be cut with a small utility knife. This
process inserts an additional resistor in series
with the lamp, lowering its intensity. Make
sure to completely cut the trace between the
two half circles.
4.2 LOW LINE VOLTAGES (100-110 OR 200-220
VOLTS)
Adjusting the POC for low line voltages is a
little more difficult. Refer to Figure 1 and
locatethe two holes marked “Short for
100-110 or 200-220VoltOperation”on the PC
board. A small piece of wire must be soldered
betweenthese two holes.
The wire should be at least 24 AWG. It can
be soldered thru the holes in the PC board or
“tacksoldered” on the bottom of the board.
Use a low to moderate wattage “pencil” type
solderingiron and solderintendedfor
electrical use only.
This process shorts the second resistor in
serieswith the lamp and delivers the full
voltageof the transformer to the lamp.
Check that all the work is clean and secure
andreplace therearcover.
Figure 1
3. SETTlNGLINE VOLTAGESELECTOR
Theline voltage can be set for either 115 volt
nominaloperation or230volt nominal
operation. The unit is shipped in the 115 volt
position.
To select230volt operation remove therear
cover and slide the selector switch (71) to the
230 volt position. Replace the fuse (74) with
a .25A/250V fuse. The fuse holder will accept
either 3AG type fuses or 5 x 2mm fuses.
Make sure that a plug which meets applicable
standardsand codes for your area is attached
to the cord, or replace the cord with an
appropriate one.
4. ADJUSTINGLAMP INTENSITY FOR
DIFFERENTLINE VOLTAGES
The POC can be set to maintain optimum
lampintensityandlife with different line
voltagesusing two resistors (70) on the PC
board. These resistors adjust the lamp
voltageupor down by approximately 5%. The
unit is shipped from the factory with one
resistor bypassed and one in circuit. The life
ofthelampdecreases rapidly with higher than
nominal input voltages, and its intensity may
belower than desired with lower input
voltages. Itis therefore advantageousto
optimizethelampintensityfordifferentline
voltages.

12084-102 Rev B Page
9
PARTS LISTING AND SCHEMATICDRAWINGS
Theschematic drawings provide an easymeansof
identifying and locating parts and are keyed to the
parts list by the use of index numbers. To order a
part, identify and locate the part by referring to
thesedrawingsand note the index number for the
part. Refer to the parts Iist and locate the
appropriateindex number. Thepart number,
descriptionand quantity required will befound
oppositethe index number.
Partsshould be ordered directly from an authorized
ReichertOphthalmicInstruments distributor. When
ordering parts, be sure to include a complete
description,partnumber and correct quantity.

Figure 2
12084-102 Rev B Page 10

12084 LONGLIFE PROJECT-O-CHART FRONT ASSEMBLY
INDEX# PART # DESCRIPTION QUAN.
1 12084-012-001 SlideAdjustingKnob 2
2 11083-058 Slide Adjusting Shaft 1
3 X50368 RetainingRing.250Shaft,Slide Adjust 1
4 X20606 Stop Screw 6-32 x 1/4 Horiz. Mask 2
5 11085-258 Horizontal Slide Mask 1
6 X34062 Rivet Dch 120 x 343, Horiz. Mask 3
7 12084-014 Slide Housing 1
8 11083-031 Roller, Horiz. Mask 3
9 11083-032 Spacer, Horiz. Mask 3
10 12084-008 Lever, Horiz. Mask 1
11 11085-071 Friction Spring, Horiz. Mask 1
12 11085-265 Spacer, Horiz. Mask 1
13 12084-004 FrontCover 1
14 11083-054 Spacer 1
15 01037-001 Washer, Flat 1
16 X50584 Spring,Slide Sprocket 2
17 11083-041 Slide Sprocket 1
18 X20642 Set Screw, 6-32 x 1/8, Slide Sprocket 2
19 11083-015 ObjectiveGuideTube 1
20 11082-009 Lock Screw,Guide Tube 2
21 11082-010 Screw Insert,GuideTube 2
22 X30744 FrontCoverMtg-Screw 4
23 12084-011-001 Mounting Knob 2
24 11082-868 Objective Assembly Complete (Includes Items 24thru40) 1
24 11082-013 Rear Retaining Ring, Back Obj. 1
25 11082-603 Back ObjectiveLens Negative 1
26 11082-604 Back Objective Lens Positive 1
27 11082-001 Back Cell 1
28 11082-002 Back Objective Lens Barrel 1
29 X76000 Screw Flat Head 2-56 x 3/1 6 1
30 11082-003 Threaded Insert, Bact, Obj. Lens 1
31 11082-017 Diaphragm, Front Obj. Lens 1
32 11082-004 Front ObjectiveLensBarrel 1
33 11082-605 Front Objective BackCrownLens 1
34 11082-005 Rear Spacer,Front Obj. 2
35 11082-606 Front Objective Middle Flint Lens 1
36 11082-006 Front Spacer,FrontObj. 1
37 11082-607 Front ObjectiveFrontCrown Lens 1
38 11082-008 RetainingRing 2
12084-102 Rev B Page 11

Figure 3
12084-102 RevB Page 12

12084 LONGLIFE PROJECT-O-CHART REAR ASSEMBLY
INDEX# PART # DESCRIPTION QUAN.
40 12084-851 Cross Slide Assy Complete (includes items 40 thru 46, see sheet 14) 1
47 12084-017 SlideHousing Cover 1
48 11083-051 RelampLabel 1
49 12084-007 ID Plate 1
50 11083-039 Cross Slide Spring Adjusting Rod 1
51 11083-034 Cross Slide Detent Spring 1
52 11083-052 Cross Slide Ball 1
53 12084-021 CondenserHolder 1
54 X20590 Set Screw, 4-40 x 1/8, Cross Slide 1
55 11082-602 Condenser Film Lens 1
56 11082-014 CondenserSpacer 1
57 11082-601 Condenser LampLens 1
58 11082-015 Condenser RetainingRing 1
59 12084-024 CaptiveScrew 1
60 12084-025 ReflectorSupport 1
61 11122-604 Reflector 1
62 12084-922 Electrical Assembly (Includes Items 66 thru 75 & 78 thru 86) 1
70 WFAG10018 Fuse3AG .5Amp 250V (I15VOperation) 1
70 Fuse2mm x 5mm .25Amp 250V (230VOperation)
75 WCBL10018 PowerCord 1
76 11083-033 Light Shield 1
77 12084-002 RearCover 1
78 11083-432-001 RearCoverFastener Stud 1
87 X76104 Elec. Assy. Mtg. Screw 6-32 x 3/8 4
88 11083-038 Lamp Adjusting Spring 3
89 12084-026 Lamp MountingPlate 1
90 X76099 InsulatorMountingScrew 2
91 X76109 LampAdjusting Screw Pan Head 3
92 12084-921 Lamp Socket Assembly 1
93 X76085 Lamp Socket Mtg. Screw #4 x 3/8 2
94 11143-001 ProjectorLamp 1
95 12084-019 Bushing 2
12084-102 Rev B Page 13

12084-102 Rev B Page14
12084 LONGLIFE PROJECT-O-CHART CROSS SLIDE ASSEMBLY
INDEX# PART # DESCRIPTION QUAN.
40 12084-851 Cross Slide Assembly Complete (includes items 40 thru 46) 1
40 11085-041 Cross Slide Knob 2
41 12084-005 CrossSlide Frame 1
42 X76192 Machine Screw, CrossSlide 3
43 11083-062 Filter Cover 1
44 11085-604 Green Filter 1
45 11085-603 Red Filter 1
46 11085-039 Cross Slide Filter Spring 1
- 11085-064 DustCover 1

12084-102 Rev B Page 15

12084-102 Rev B Page 16

12084-102 Rev
12090 TABLE MOUNT
INDEX# PART # DESCRIPTION QUAN.
1 11090-016 PivotPin 1
2 12090-001 Base 1
3 11090-019 Weight Plate 1
4 X9560 Screw,Self-Tapping 6-20 x 3/4 4
5 X20078 Screw,Cap 10-32 x 5/8 4
6 3330-047B RubberFoot 4
12091 WALL MOUNT
INDEX# PART# DESCRIPTION QUAN.
1 11091-018 PivotPin 1
2 12091-005 BaseCover 1
3 12091-006 Wall Mount, Cast 1
12092 INSTRUMENT STAND
INDEX# PART # DESCRIPTION QUAN.
1 12092-027 Clamp 1
2 11091-018 PivotPin 1
3 12091-030 BaseCover 1
4 12092-029 Base,InstrumentArm 1
5 X38715 Screw, Bracket to Adapter Plate 2
6 12092-028 AdapterPlate 1
7 X54079 Screw,Clamp to Adapter Plate 4
12096 FLOOR STAND
INDEX# PART # DESCRIPTION QUAN.
1 11090-016 PivotPin 1
2 11093-002 Floor Stand Post 1
3 12096-002 FloorStand BaseCover 1
4 X25268 Post Screw, 1/4-20 x 1/2 2
5 11093-006 FloorStandWeight 1
6 3330-047B RubberFoot 4
7 X20078 Screw,Cap 10-32x5/8 4
8 X53984 Screw,Self Tapping #8 4
12094 YOKE
INDEX# PART # DESCRIPTION QUAN.
1 12094-001 Mounting Fork 1
2 11090-013 ForkInsert 1
3 X20162 Fork Adjusting Screw 1/4-28 x 7/8 2

Printed in U.S.A
3374 Walden Ave.
Depew, NY 14043
Tel: [phone]
FAX: [phone]
12084-102 Rev B
6/03
