REID LIFTING PGRS20 Installation instructions

Tel: [phone] www.reidlifting.com
ASSEMBLY VIDEO
www.reidlifting.com
Assembly & Operation

2
No. 1 in lightweight, portable, safe lifting solutions
CONTENTS
INTRODUCTION
CORRECT OPERATION
• Intended Use
• Inspection Prior to Initial Operation
• Inspection Before Starting Work
• Maximum Capacity
NOTES FOR CORRECT USAGE
• Warning
• Attaching the Load
• Temperature Range
• Regulations
INSPECTION/MAINTENANCE
• Regular Inspections
• Maintenance/Repair
• Storage and Transportation
• Marking
ATEX
• ATEX - Classification
• ATEX - Identification
• ATEX - Spark Formation
• ATEX - Static Electricity
• ATEX - Inspection, Maintenance & Repair
IRATA
LANGUAGE
ASSEMBLY INSTRUCTIONS
• Pre-Assembly
• Standard Assembly
• Master-link/Close-Coupled Trolley Installation
• Height Adjustment
• Foot Adjustment
• Pre-Assembly
• Confined Space Assembly
• Gantry Stowage
• Trolley Storing
• Winch Bracket Installation
• Winch Installation
• Sheave Trolley Installation
• Beam Width Adjustment
• Changing the Foot Option
• Adjustable Foot Option
DIMENSIONS
• P O R TA - GANTRY RAPIDE 250-500
• P O R TA -GANTRY RAPIDE 1000
QUALITY & SAFETY
• Accreditations
TESTING
PRODUCT IPR
INSPECTION RECORD

Tel: [phone] www.reidlifting.com
INTRODUCTION
All users must read these operating instructions
carefully prior to the initial operation. These
instructions are intended to acquaint the user with the
P O R TA -GANTRY RAPIDE and enable him/her to use it
to the full extent of its intended capabilities.
The operating instructions contain important
information on how to handle the
P O R TA -GANTRY
RAPIDE
in a safe, correct and economic way. Acting
in accordance with these instructions helps to avoid
dangers, reduce repair costs and down time and
to increase the reliability and lifetime of the
P O R TA -
GANTRY RAPIDE
.
Anyone involved in doing any of the following work with
the gantry must read the operation instructions and
act accordingly:
• Operation, including preparation, troubleshooting
during operation and cleaning
• Maintenance, inspection, repair
• Tr an sp or t
Apart from the operating guide, health & safety
and accident prevention act valid for the respective
country and area where the gantry frame is used,
the commonly accepted regulations for safe and
professional work must be adhered to.
It is incumbent on the user or instigator of work with
the equipment that all users have suitable medical and
physical capabilities. Likewise the competent person
should ensure there is a rescue plan in place in the
event of an emergency that could occur during
the work.
N.B. This document should form an element of the
overriding Risk Assessment and Method Statement
required for each lift.

4
No. 1 in lightweight, portable, safe lifting solutions
CORRECT OPERATION
Intended Use
The P O R TA -GANTRY RAPIDE is intended to be used
for the lifting of goods or the lifting of persons, or for
providing a safety anchor for the prevention of falls.
N.B. We recommend that the device is dedicated to
either goods or personnel use and where reasonably
practicable to avoid using the structure for both.
P O R TA -GANTRY RAPIDEsare suitable for Rope Access
and have been tested to 15KN static load as per test
requirements of IRATA International Code of Practice
(ICOP).
Inspection Prior to Initial Operation
Each P O R TA -GANTRY RAPIDE frame must be
inspected prior to initial operation by a competent
person. The inspection is visual and functional and shall
establish that the structure is safe and has not been
damaged by incorrect assembly, transport or storage.
Inspections are instigated by the user.
Inspection Before Starting Work
The inspection procedure requires that a valid
inspection/test certificate has been submitted to and
checked by the user.
Before starting work inspect the gantry frame
assembly and all load-bearing components for
visual defects. Check the integrity of all profiles for
denting and pin/bolt holes for wear and elongation.
Furthermore, test the trolley for free movement along
the beam and check the operation of the footing option.
Ensure that the overall WLL limit is adhered to –
following the necessary Risk Assessment and Method
Statement.
Maximum Capacity
The P O R TA -GANTRY RAPIDE is designed to lift and
lower loads up to its rated capacity. The capacity
indicated on the frame is the maximum Working Load
Limit (WLL) or Safe Working Load (SWL) which must
not be exceeded (definition is country dependent).
When being used as a personnel lifting anchor the user
must use a body harness and retractable device or
shock absorber to EN355 , ANSI Z359.6-09 or CSA
Z259.16-04 that limits the Maximum Allowed Force
(M.A.F.) to 6kN. Winches used with the P O R TA -GANTRY
RAPIDE should comply to EN1496:2017 or equivalent.
Only ONE person/load may be attached to ONE trolley
in accordance with the WLLs.
The P O R TA -GANTRY RAPIDE has different ratings
depending upon the application as detailed in the table
below .
The gantry has an up-rated capacity for personnel
positioning. This is when the structure is to be used
as an anchor for lifting persons that have a suitably
low chance of falling through a free distance and
only carried out following a comprehensive risk
assessment.
Model PGR1TS20, P GR1T S30, PGR1TS40, PGR1TM20, PG R1TM30,
PGR1TM40, P GR1T T20, P GR1T T30, P GR1TT40
Application WLL (kg) Capacity [Persons]
Fall Arrest* 150 3
Personnel
positioning
limit
500
Goods 1000 N /A
* N.B. only Applicable to P O R TA -GANTRY RAPIDE systems being used in accordance with PD CEN/TS
16415:2013. When being used in accordance with EN795:2012, the structure shall be limited to a maximum
of one user in fall arrest.
Model PGRS20 PGRS23, PGRM20,
PGRM23
PGRS40, PGRM40,
PGRT20, PGRT23,
PGRT40
Application WLL (kg) Capacity
[Persons] WLL (kg) Capacity
[Persons] WLL (kg) Capacity
[Persons]
Fall Arrest* 150 3150 2150 1
Personnel
positioning
limit
250 200 125
Goods 500 N/A 400 N /A 250 N/A

Tel: [phone] www.reidlifting.com
While the P O R TA -GANTRY RAPIDE has the capacities
stated below it is only one part of a fall arrest
system which is only as strong as its lowest rated
component. Each lift must be properly planned and
all weights clearly known along with the WLLs and
constraints of all fall arrest system devices.
The capabilities stated in the table below are only
applicable to the standard
P O R TA -GANTRY RAPIDE
configurations i.e. small, medium and tall. Bespoke
versions of the P O R TA -GANTRY RAPIDE are available
tailored to specific lifting needs. If unsure about your
system consult serial labels, information filled in on
page 23 or consult your supplier. A custom
P O R TA -GANTRY RAPIDE is designated by a product
number ending with a “C” found on the serial label
attached to each A-frame and the beam. For custom
designed P O R TA -GANTRY RAPIDE s please contact
your supplier for appropriate rating and capabilities.
In the event of simultaneous goods and personnel
combined lifting or when being used as a fall arrest
system in sub-zero AND wet conditions contact the
supplier as capacities may be reduced.
NOTES FOR CORRECT USAGE
• We recommend the use of load-sensing or overload
protection devices on all lifts
• The WLL (or SWL) rating must NOT be exceeded.
Risk Assessment & Method Statement must
consider additional loading in “wet lift” situations
• Ensure suitable winches and connection plates
are used for all applications – see Winch Bracket
Installation on pg 17
• Due care and attention should be practiced when
transporting and storing gantry to avoid damage
• Assemble only as instructed (ensure all pins and
bolts are present and fitted correctly as per
instructions)
• We recommend that gloves should be worn when
using this equipment
• We recommend single person assembly to avoid
conflicting actions
• Set up the gantry at a safe distance from the
hazard and subsequently move the structure into
place
• The beam must be horizontal prior to any lift and
A-frames vertical and parallel to each other
• Do not use the gantry frame if the trolley does not
run freely along the beam
• Trolleys have the ability to be locked into position on
the beam for certain applications. e.g. when gantry
is used as a restraint point
• Attach hoist only to the lifting point on the trolley
• Avoid side pull. Lowering and lifting should only
be carried out when the load chain/lifeline form
a straight and vertical line between the load and
lifting attachment point on the trolley
• Do not allow load to swing
• When lifting keep the load low to the ground
• NEVER walk away from structure whilst connected
to the equipment i.e. connected by a fall arrest
block or winch
• Only raise and lower loads when CASTOR BRAKES
are ENGAGED
• When using the gantry as a fall arrest anchor
the required clearance of the fall arrest device
should be considered - refer to device Assembly
& Operation manual and consider the height
adjustment on the gantry
• Before the gantry is used consideration must
be given to the potential effects of the lifelines
over sharp edges, chemical reagents, electrical
conductivity, cutting, abrasion, climatic exposure
and the effect of offset forces as a result of
pendulum falls
• The Gantry should NOT to be moved under load
except when a Competent Person or authority
approves a Risk Assessment and a Method
Statement for a particular reason
Warning
• The equipment shall not be used outside its
limitations, or for any purpose other than that for
which it is intended
• Only one lifeline should be used with each sheave
and they should never cross paths with each other
• Do not lift or transport loads while personnel are in
the danger zone

6
No. 1 in lightweight, portable, safe lifting solutions
• Do not allow personnel to pass under a suspended
load
• When gantry is used with multiple persons
attached working procedures should dictate that
individual lifelines do not cross and become tangled
• It is NOT recommended to mix the use of the gantry
with personnel and goods lifting concurrently
• Never leave a suspended load unattended
• Start moving the load along the beam only after it
has been attached correctly and all personnel are
clear of the danger zone
• Be aware of hazards when setting up/folding down,
eg. hands/fingers trapped in rotating parts
• It is essential for safety that the P O R TA -GANTRY
RAPIDE is withdrawn from use immediately should:
1. Any doubt arise about its condition for safe use
Or
2. It has been used to arrest a fall and not be used
again until confirmed in writing by a competent
person that it is acceptable to do so
• Be aware of adverse weather, high, gusty or
moderate/strong breeze conditions could impose
horizontal loads, potentially affecting the stability of
the structure. If weather conditions are impacting
lifting operations, work should be stopped and
gantry should be disassembled. If disassembling
is not possible, the gantry should be tied to a rigid
structure to avoid overturn
Attaching the Load
The operator must ensure that the hoist is attached
in a manner that does not expose him or other
personnel to danger by the hoist, chain(s) or the load.
Temperature Range
The P O R TA -GANTRY RAPIDE can be operated in ambient
dry temperatures between -20° and +55°C (-4°F to
131°F). Consult your supplier in case of extreme working
conditions. If used in sub-zero and wet conditions, fall
arrest appliances characteristics may change.
Regulations
The P O R TA -GANTRY RAPIDE complies with the following
regulations:
PPE Regulation (EU) 2016/425, Machinery Directive
2006/42/EC, The Provision and Use of Work Equipment
Regulations 1998 (S.I. 1998 No. 2306), The Lifting
Operations and Lifting Equipment Regulations 1998 (S.I.
1998 No. 2307). The safety regulations of the respective
country for using manual lifting equipment must be
strictly adhered to. EN79:2012, ANSI Z359.18-2017 and
CSA Z259.16-04 ce
rtified.
INSPECTION/MAINTENANCE
Regular Inspections
To ensure that the gantry frame remains in safe
working order it must be subjected to thorough periodic
inspections by a competent person. Inspections are to be
6 monthly for personnel lifting and 12 monthly for goods
only unless adverse working conditions or profile of use
dictate shorter periods. The components of the gantry
frame are to be inspected for damage, wear, corrosion
or other irregularities. To check for worn parts it may be
necessary to disassemble the gantry frame.
Repairs should only be carried out by an approved
specialist workshop that uses original spare parts.
It is recommended that once inspected the device is
marked with the date of next inspection.
Inspections are instigated by the user. If detailed
information is required on inspection and test criteria,
please refer to your supplier’s technical department.
Please refer to page 23 for the equipment
Inspection Record.
If using the Gantry in explosive atmospheres see
additional section titled ATEX.
Maintenance/Repair
In order to ensure correct operation not only the
operations instructions, but also the conditions for
inspection and maintenance must be complied with.
If defects are found stop using the P O R TA -GANTRY
RAPIDE immediately.
No alterations or additions to the equipment should be
made without the written consent of the manufacturer.
Any repair shall only be carried out in accordance with
the manufacturer’s procedures.

Tel: [phone] www.reidlifting.com
It is recommended to maintain the equipment in a
clean and dry manner. Cleaning is suggested using a
sponge or cloth with warm, soapy water (using diluted
domestic washing up liquid), rinsing and allowing to dry.
Storage and Transportation
When transporting the components the user must
take note of the manual handling considerations.
Do not throw the gantry or its components down or
stack items on top of it. Always place properly on the
ground avoiding damage to the equipment.
Marking
The serial labels indicate:
• The product identification number
• The products unique serial number
• The goods WLL of the device
• The year of manufacture
• The standards to which the device is approved.
• The ATEX rating of the product (if applicable) - see
ATEX section below
• CE 0088: Notified body number (currently LRQA)
who are responsible for approving REID Lifting’s
quality control system
Read
Assembly & Operation instructions
P O R TA - GANTRY RAPIDE
Assembly & Operation instructions
Equipment capacity warning label: refer to maximum
capacity section for rating explanations.
PORTA-GANTRY RAPIDE 250-500
PORTA-GANTRY RAPIDE 1000
ATEX:
This product has been designed for use in explosive
atmospheres. If the product is to be used in explosive
atmospheres then the following section must be
followed. Any different or exceeding use is considered
incorrect and REID Lifting Ltd will not accept any
responsibility for damages resulting from false
application. The risk is solely with the user. If the product
has been customised in any way then it may not comply
with standards and not be suitable for use in explosive
atmospheres. If this is the case then the product will not
have any of the below marking. If in doubt contact your
REID representative.
WARNING
This component is rated for a
working load limit of 1000kg
for goods; 500kg for personnel
positioning and150kg per user
for fall arrest. Retractable
devices or shock absorbers must
have a MAXIMUM ARRESTING
FORCE (M.A.F.) rating of 6kN or less.
System rating is that of the lowest
rated component.
WARNING
This component is rated for a
working load limit of 500kg for
goods; 250kg for personnel
positioning and150kg per user
for fall arrest. Retractable
devices or shock absorbers must
have a MAXIMUM ARRESTING
FORCE (M.A.F.) rating of 6kN or less.
System rating is that of the lowest
rated component.

8
No. 1 in lightweight, portable, safe lifting solutions
ATEX - Classification
As standard, the product meets the requirements
of Category 3 equipment for use in Zone 2 explosive
atmospheres, providing a normal level of protection
where mixtures of air and gases, vapours or mists or
by air/dusts mixtures are unlikely to occur or, if they
do occur, are likely to do so only infrequently and for a
short period only.
Or
Available as an upgrade the P O R TA -GANTRY RAPIDE
500 can be supplied to meet the requirements of
Category 2 equipment for use in Zone 1 explosive
atmospheres, providing a high level of protection
where mixtures of air and gases, vapours or mists or
by air/dusts mixtures are likely to occur.
ATEX - Identification
In addition to the previous marking section the product
will have the following identification on the serial label:
As Standard for Zone 2 Environments:
II 3 GD T6
Identification for protection against explosions
II: Unit group II – non-mining application
3: Category 3 – Normal safety for use in Zone 2
GD: For use in gas (G) & dust (D) atmospheres
T6:Temperature class – Max 85°C
Or
As an Upgrade for use in Zone 1
Environments (PGR500 only):
II 2 GD T6
Identification for protection against explosions
II: Unit group II – non-mining application
2: Category 2 – High safety for use in Zone 1
GD: For use in gas (G) & dust (D) atmospheres
T6:Temperature class – Max 85°C
ATEX - Spark Formation
Increased danger of ignition may emanate from
clashing of special material pairings. These are
non corrosion-resistant steel or cast iron against
aluminium, magnesium or pertinent alloys. This
applies especially in case of rust or surface rust.
When assembling the product and inserting fastening
components they must be clear of rust and debris of
any kind. Care must be taken to ensure the product
is handled in a suitable manner, is never thrown and
always placed onto the ground.
For Zone 1 and 2 applications, the height of the
P O R TA -GANTRY RAPIDE should NOT be adjusted using
the ratchet mechanism and/or geared wheel within
the said zone.
REID recommend the use of corrosion resistant tools
when assembling the P O R TA -GANTRY RAPIDE system
to prevent the possibility of any sparks.
For ATEX Zone 1 use, stainless steel castor brackets
are fitted to reduce the possibility of a spark.
ATEX - Static Electricity
For Zone 2 applications static electricity has been
identified as potential for build up leading to an
incendive spark. Although the risk of such ignition is
unlikely the gantry must be earthed during assembly
and use. This can be achieved by attaching a 4mm
earthing lead to a convenient location on metallic
parts of both the Gantry and Trolley.
In Zone 1 applications, for added explosion protection,
the gantry is fitted with anti-static trolley rollers,
stainless steel fasteners and therefore does not
need to be earthed. However, the effectiveness of
the conductivity during operation can be affected
by a dirty tread or other environmental influences
and therefore must be checked by the operator
periodically.

Tel: [phone] www.reidlifting.com
ATEX - Inspection, Maintenance
& Repair
If using the gantry in explosive atmospheres, in
addition to the Regular Inspection/Maintenance
information found on page 6, these additional
instructions should be followed.
Inspections shall be instigated by the user prior to
each use if used in a potentially explosive atmosphere.
Inspections and maintenance shall be carried out at a
safe distance away from an explosive atmosphere.
Special attention should be given to dust deposits on
the structure, especially in areas where the profiles
come into contact, and should be wiped clean and
care taken not to apply materials that could create
electrostatic charging. Additionally the bearings in
the trolley rollers and castors should be checked to
ensure they rotate freely.
The structure is predominantly constructed from
aluminium which will not rust. However there are
steel components used throughout. These are
the fasteners, castors, master-link, trolley rollers,
A-frame height adjustment gearing system (if fitted)
and the height adjustment ratchet (if fitted). Where
there is sign of any rust deposits on the aluminium
structure it should be wiped clean as above and where
there is sign of rust on a steel component then that
component should be removed from use and the
structure not used until a replacement is fitted.
IRATA
P O R TA -GANTRY RAPIDEsare suitable for Rope Access
and have been tested to 15KN static load as per test
requirements of IRATA International Code of Practice
(ICOP).
LANGUAGE
It is essential for the safety of the user that if this
product is re-sold outside the original country of
destination the reseller shall provide instructions
for use, maintenance, for periodic examination and
for repair in the language of the country in which the
product is to be used.

10
No. 1 in lightweight, portable, safe lifting solutions
ASSEMBLY INSTRUCTIONS
Gloves Hard hatProtective footwear
N.B. Appropriate PPE should be worn:
The P O R TA -GANTRY
RAPIDE and its constituent components are described in the image below.
Leg
Lockable Castors
‘Trap’ Plate
Cheek Plate
Sheaved
Trolley
Trolley
Upright
Beam

Tel: [phone] www.reidlifting.com
PRE-ASSEMBLY
•P O R TA -GANTRY RAPIDE system delivered
flat packed
• Ensure castors are locked
• Allow sufficient clearance for gantry frame
rotation. If sufficient space not available see steps
13 to 17 - Confined Space Set-up method
N.B. Trolley can be stored seperately, on the upper
Upright or the Leg
Pre set-up Checks
1. Rotate upper Upright to a vertical position. 2. While in this vertical position remove ball lock pin
from its stow hole on the Trap Plate.
Standard Assembly

12
No. 1 in lightweight, portable, safe lifting solutions
5. Repeat steps 1-4 for lower Upright. 6. Scissor upper Uprigtht until ball-lock pin is
adjacent to beam. Remove ball-lock pin and
continue scissor motion until stops engage beam
and holes are aligned.
Be careful not to trap hands between beam
and cheek plates!
3. Open leg and insert ball-lock pin into second hole
securing the leg in its open position. Repeat for
second leg on the same Upright.
4. Continue rotation of upper Upright until it comes
to rest on ground.

Tel: [phone] www.reidlifting.com
7. Re-insert ball-lock pin into hole ensuring the pin is
fully engaged through hole. A gentle rocking
motion can be used to induce alignment.
8. Repeat steps 6 and 7 for opposite Upright.
N.B. IF FITTED, ENSURE CASTOR BRAKES
APPLIED BEFORE LIFTING A LOAD.
10. Close Trolley plate encapsulating the beam and
re-insert ball-lock pin. Ensure pin is properly
engaged through holes.
If Trolleys are required to be locked into position
then an additional pin is available to provide
Trolley lock-off.
9. Remove pin. Open Trolley and present to beam
with plate rotated through 90°.
Be careful not to allow plate to swing open
uncontrolled.
Master-link/Close-Coupled Trolley Installation

14
No. 1 in lightweight, portable, safe lifting solutions
• Ensure all ball lock pins are fully engaged into
their respective holes
• Ensure all quick release knob/bolts on Trap
Plates and Beam are hand tight and secure
• Ensure Upright is bolted using top and
bottom fixing holes on Trap Plate.
• Ensure gantry is level
Pre-lift Checks
12. To increase height pull foot down until desired
position is achieved.
NB: Never adjust the height while the gantry
is under load.
Foot AdjustmentHeight Adjustment
11. Take weight of gantry Upright.
Remove bolts and adjust to the desired height.
Re-insert bolts and hand tighten quick release
knobs ensuring the gantry is secure.
NB: Ensure upright is bolted using top and
bottom fixing holes on Trap Plate.
NB: Never adjust the height while the gantry
is under load.

Tel: [phone] www.reidlifting.com
16. Rotate upper Upright around until ball-lock pin is
adjacent to beam. Remove pin and continue
motion until stops engage beam and holes are
aligned, as in steps 6 and 7.
Be careful not to trap hands between beam
and cheek plates!
15. Open leg and insert ball-lock pin into second hole
securing the leg in its open position. Repeat for
second leg.
13. Rotate upper Upright to vertical position.
Confined Space Assembly
14. While in this vertical position remove ball lock pin
from its stow hole.

16
No. 1 in lightweight, portable, safe lifting solutions
18. To fold the gantry reverse steps 10 to 1 for
Standard assembly or steps 17 to 13 for Confined
Space assembly.
When folding gantry ensure ball-lock pins are
stowed in cheek plate holes to avoid damage.
Gantry Stowage
Trolley can be stored seperately, on the upper
Upright or the Leg
Trolley Storing
17. Repeat steps 13 to 16 for lower Upright.
Be careful not to trap hands between beam
and cheek plates!
• Ensure all ball lock pins are fully engaged into
their respective holes
• Ensure all quick release knob/bolts on Trap
Plates and Beam are hand tight and secure
• Ensure Upright is bolted using top and
bottom fixing holes on Trap Plate.
• Ensure gantry is level
Pre-lift Checks

Tel: [phone] www.reidlifting.com
19. Remove existing bolt, A or C.
Present bracket to gantry as shown (with locating pin at bottom) and insert new, longer bolts securing the
winch with the quick release knobs provided.
Never install winch bracket while gantry is under load. Only install winches which are approved by REID for
use with the
PORTA -GANTRY RAPIDE and a suitable interface / mounting plate supplied.
Winch can be installed on both sides of gantry and on either bolts A and B or B and C (PGR250-500) OR A and
B, B and C or A and D (PGR1000). Ensure winch bracket and quick release knobs are hand tight.
Winch Bracket Installation
20. Place winch onto locating pin, D.
Rotate winch to align holes, E.
Place retaining pin into holes, F.
Observe pin is securely engaged.
N.B. Illustration shows one example of many
winches, fall arrests and interface brackets
available.
Winch Installation
21. Thread rope through Cheek Plates and capture
rope between Sheave and Beam.
Secure Sheave with ball-lock pin.
Observe pin is securely engaged.
Sheave Trolley Installation
A
D
B
C
PGR250-500 PGR1000

18
No. 1 in lightweight, portable, safe lifting solutions
24. Remove bolt and handle.
Store handle in safe place.
NB: Beam width adjustment can take place
during steps 4 or 5.
25. Move Upright assembly to required position.
Re-insert bolt and hand tighten quick release
knob. Complete assembly of gantry as steps 6-8.
Beam Width Adjustment
23. Insert second pin as shown
Observe both pins are fully engaged
22. Present Sheaved Trolley to underside of Beam.
Capture rope between Sheaved Trolley and Beam
and insert pin as shown.

Tel: [phone] www.reidlifting.com
26. The foot option can be changed by removing
the ball lock pin and withdrawing the foot
cartridge assembly.
2 7. For coarse adjustment in leg height set cartridge
at desired point (2x50mm increments).
• Ensure all ball lock pins are fully engaged into
their respective holes
• Ensure all quick release knob/bolts on Trap
Plates and Beam are hand tight and secure
• Ensure Upright is bolted using top and
bottom fixing holes on Trap Plate.
• Ensure gantry is level
28. For fine height adjustment depress lever and
push foot up to desired position.
Observe gantry is level.
NB: Never adjust the height while the gantry is
under load.
Changing the Foot Option Adjustable Foot Option
Pre-lift Checks

20
No. 1 in lightweight, portable, safe lifting solutions
DIMENSIONS
PORTA-GANTRY RAPIDE 250-500
*Ratings using European standards. Contact REID for other standards.
Dimensions (mm) WLL Unit
Weight
A
Beam
Length
B
C
Min
C
Max
D
Min
D
Max
E
Min
E
Max
F
Min
F
Max G
H
Min
H
Max J
Goods
Capacity
(kg)
Fall Arrest
Capaci t y*
(Persons)
Personnel
* (kg) (kg)
PGRS20 2000 2076 110 0 150 0
173 8 1938 1914 2114 2064 2264 1158 1850 2050
219 0 500 3250 33
PGRS23 2300 2376 1200 1800 2376 400 2200 35
PGRS40 4000 4076 2700 3500 4076 250 1125 40
PGRM20 2000 2076 110 0 1500
1642 2042 1818 2218 1968 2368 1215 1755 215 5
2076
400 2200
35
PGRM23 2300 2376 120 0 1800 2376 36
PGRM40 4000 4076 2700 3500 4076
250 1125
41
PGRT20 2000 2076 1100 150 0
1916 2816 2092 2992 2242 314 2 15 8 6 2028 2928
2631 39
PGRT23 2300 2376 1200 180 0 2631 40
PGR T40 4000 4076 2700 3500 4076 45
440
415
J
100
H D E F
80
G
