Reiner jetStamp 990 User manual

PCset Help jetStamp 9902
ERNST REINER GmbH & Co. KG
Inhaltsverzeichnis
I Your jetStamp 5
................................................................................................................................... 61.1 Operating elements
................................................................................................................................... 81.2 Display and button function
................................................................................................................................... 91.3 Main menu
.......................................................................................................................................................... 10Cartridge change1.3.1
.......................................................................................................................................................... 10Device lock1.3.2
.......................................................................................................................................................... 10Bluetooth1.3.3
.......................................................................................................................................................... 10Date/time1.3.4
.......................................................................................................................................................... 11Numbering machine1.3.5
.......................................................................................................................................................... 11Settings1.3.6
.......................................................................................................................................................... 12Model version1.3.7
II Important notes 13
................................................................................................................................... 132.1 Rechargeable batteries
III Your safety 14
................................................................................................................................... 143.1 Safety, description
................................................................................................................................... 153.2 Safety noteson rechargeable batteries
................................................................................................................................... 163.3 Safety notes
................................................................................................................................... 163.4 Safe handling of print cartridges
IV Preparation and commissioning 17
................................................................................................................................... 174.1 Commissioning
.......................................................................................................................................................... 18Inserting rechargeable batteries4.1.1
.......................................................................................................................................................... 18Charge rechargeable batteries4.1.2................................................................................................................................... 194.2 Setting time and date
................................................................................................................................... 194.3 Setting summertime
................................................................................................................................... 204.4 Inserting the print cartridge
................................................................................................................................... 214.5 Saved print images
................................................................................................................................... 224.6 Activating Bluetooth
................................................................................................................................... 224.7 Selecting print image
................................................................................................................................... 224.8 Overview of stored print images
................................................................................................................................... 234.9 Printing the print image
................................................................................................................................... 244.10 Installing the REINER PCset software
.......................................................................................................................................................... 24System requirements4.10.1
.......................................................................................................................................................... 24Installing the software4.10.2
.......................................................................................................................................................... 24Firmware update4.10.3
V Software application 990 REINER PCset 26
................................................................................................................................... 265.1 Preparing jetStamp 990 for REINER PCset
................................................................................................................................... 265.2 Starting the REINER PCset software

3
3
ERNST REINER GmbH & Co. KG
................................................................................................................................... 275.3 Operating interface
.......................................................................................................................................................... 27Menu bar5.3.1 ......................................................................................................................................................... 28File
5.3.1.1 ......................................................................................................................................................... 28Edit
5.3.1.2 ......................................................................................................................................................... 28View
5.3.1.3 ......................................................................................................................................................... 28Presettings
5.3.1.4 ......................................................................................................................................................... 29Help
5.3.1.5 .......................................................................................................................................................... 29Toolbar5.3.2
.......................................................................................................................................................... 30Objects5.3.3................................................................................................................................... 315.4 Establishing Bluetooth connection
................................................................................................................................... 325.5 Example workflow: Generating the print image
.......................................................................................................................................................... 32Configuring the print image5.5.1
.......................................................................................................................................................... 32Transferring the print images5.5.2
.......................................................................................................................................................... 33Printing the print image5.5.3................................................................................................................................... 345.6 Objects settings
.......................................................................................................................................................... 34Text5.6.1 ......................................................................................................................................................... 34Presettings
5.6.1.1 ......................................................................................................................................................... 35Context menu text object
5.6.1.2 .......................................................................................................................................................... 36Date/Time5.6.2 ......................................................................................................................................................... 36Presettings
5.6.2.1 ......................................................................................................................................... 37Tab File - Settings Date / Clock time
5.6.2.1.1 ......................................................................................................................................................... 38Context menu date/time object
5.6.2.2 .......................................................................................................................................................... 39Numbering machine5.6.3 ......................................................................................................................................................... 39Presettings
5.6.3.1 ......................................................................................................................................... 40Tab File - Settings Date/time/numbering machine
5.6.3.1.1 ......................................................................................................................................................... 42Context menu numbering machine object
5.6.3.2
VI Maintenance 43
................................................................................................................................... 446.1 Changing the print cartridge
................................................................................................................................... 456.2 Cleaning the contacts of the print cartridge
................................................................................................................................... 466.3 Clean nozzles
.......................................................................................................................................................... 46Manual nozzle cleaning6.3.1................................................................................................................................... 466.4 Clean print carriage
................................................................................................................................... 476.5 Clean housing
VII Recognising and removing interferences 48
................................................................................................................................... 487.1 Operating modes and error messages
VIII Technical data and accessories 49
................................................................................................................................... 498.1 Type plate
................................................................................................................................... 508.2 Technical data
................................................................................................................................... 518.3 Transport and disposal
................................................................................................................................... 518.4 Accessories
IX Contact 52
X Operating instructions 53

PCset Help jetStamp 9904
ERNST REINER GmbH & Co. KG
Index 54

Your jetStamp 5
ERNST REINER GmbH & Co. KG Originalanleitung
1 Your jetStamp

PCset Help jetStamp 9906
ERNST REINER GmbH & Co. KG
Originalanleitung
1.1 Operating elements

Your jetStamp 7
ERNST REINER GmbH & Co. KG Originalanleitung

PCset Help jetStamp 9908
ERNST REINER GmbH & Co. KG
Originalanleitung
Trigger button
Flap for battery compartment
Display
Reset button
Key pad
Connection socket for mains adapter
Basis station
Charging indicator
Ink cleaning station
Micro USB socket
Print carriage
Jack socket for external triggering
Print cartridge
Grip strip print cartridge
Locking bracket
Nozzles print cartridge
Battery compartment
Print cartridge contacts
1.2 Display and button function
The display depends on the respective menu context. The start screen
of the main menu is shown.
The display is structured according to the following sections:

Your jetStamp 9
ERNST REINER GmbH & Co. KG Originalanleitung
A
Header
P01
Number of the set print image
51604A-B
Cartridge type used
USB
BT/BTC
USB active
Bluetooth active/Bluetooth connected
R01/01
Repeat switching of the numbering machine 1
Battery level
Battery is charging
B
Set print image
Text, date/time or numbering machine
C
Menu bar with menu items and commands
t u
Next page
Forward/back through print images or menu.
[MENU]
[SELECT]
Access to the main menu and
menu selection - Confirms entries and completes function settings.
[RETURN]
Back
Returns to the previous display (submenu / main menu / exit from main menu).
[OK]
Confirms entries and completes function settings.
D
Four push-buttons
Each button is always assigned to the menu item or command displayed in the
display menu bar above it.
1.3 Main menu
The menu selection of the device consists of main and submenus.
There are 7 main menus:
Cartridge change
Device Lock
Bluetooth
Date/Time
Numbering machine
Settings
Model/Version
For the button functions, see "Display and Button Functions"

PCset Help jetStamp 99010
ERNST REINER GmbH & Co. KG
Originalanleitung
1.3.1 Cartridge change
Select the button [MENU]. Use the buttons t u to browse until the display shows "Cartridge
change start".
Selecting [SELECT] moves the print carriage to the middle of the device so that the print
cartridge can be inserted/changed.
Selecting [SELECT] again moves the print carriage back to its basic position.
Selecting [RETURN] leaves the menu.
Also see "Inserting the Print Cartridge" and "Changing the Print Cartridge"
1.3.2 Device lock
Print images can be protected with a password.
When the print images are protected, the menu will show "Device Unlock". This means that a
password must be entered.
Select the button [MENU]. Use the buttons t u to browse until the display shows "Device
Lock".
Selecting [SELECT] enables or disables the device lock.
The symbol in the status indicator in the REINER PCset switches from to .
Selecting [RETURN] leaves the menu.
Also see "Settings - Password change".
1.3.3 Bluetooth
Only the 990-001 model is bluetooth-capable.
Bluetooth cannot be activated while an USB connection is active.
If Bluetooth is active the battery runtime reduces since Bluetooth is active in
standby mode as well.
Select the button [MENU]. Use the buttons t u to browse until the display shows
"Bluetooth".
Selecting [SELECT] enables or disables Bluetooth.
Selecting [RETURN] leaves the menu.
1.3.4 Date/time
Change clock
Select the button [MENU]. Use the buttons t u to browse until the display shows
"Date/Time".

Your jetStamp 11
ERNST REINER GmbH & Co. KG Originalanleitung
Setting the date and time at the jetStamp 990.
Select the button [SELECT]; the display shows "Change clock".
Push the button [SELECT] again and use the buttons t u and [OK] to set the date/time.
Select the button [OK] to accept the changes
Selecting [RETURN] leaves the menu.
See "Preparation and commissioning" under "Setting Date/Time".
Summertime
Selection between Europe/America/None
See "Preparation and commissioning" under "Setting summertime".
1.3.5 Numbering machine
Numb. machine 1 - 4 (numbering machine 1 - 4)
The numbering machine serves sequential numbering.
Up to 4 different numbering machines can be specified.
A numbering machine used in the selected print image is marked with an appended "*" here. The
specified "Numb. machine 1", for example, is displayed as "Numb. machine 1*".
See "Software application 990 PCset", "Settings Objects - Numbering Machine".
1.3.6 Settings
Cartridge type
Select the button [MENU]. Use the buttons t u to browse until the display shows "Settings"
and then "Cartridge type".
Select [SELECT] to choose the print cartridge.
Possible selections are:
51604A-B (P1-S-BK)
51605R-R (P1-S-RD)
P1-EF-AUB
P1-EF-RD
P1-MP2-BK
P1-MP3-BK
P1-MP4-BK
P1-MP6-YE
P1_AMI_EM
Also see "Technical data and accessories" under "Accessories".

PCset Help jetStamp 99012
ERNST REINER GmbH & Co. KG
Originalanleitung
Double print
Select the button [MENU]. Use the buttons t u to browse until the display shows "Settings"
and then "Double print".
Select [SELECT] to enable or disable the double print.
Password menu
Select the button [MENU]. Use the buttons t u to browse until the display shows "Settings"
and then "Password menu ON/OFF".
Selecting [SELECT] to choose between "ON" and "OFF".
"ON" means that the menu access is password-protected. You can only return to the menu
after entering the password.
The print images can, however, be selected and printed out on the device.
Password change
Select the button [MENU]. Use the buttons t u to browse until the display shows "Settings"
and then "Password change".
After selecting [SELECT], you will be asked to assign a new password.
Confirm your selection with [OK] or undo it with [RETURN].
Factory settings
Select [SELECT] to reset the jetStamp 990 to the delivery condition.
The print images at delivery are, however, not restored. A password set also cannot be reset
this way.
1.3.7 Model version
Model
Select [OK] to display the model and serial number.
Software version
Selecting [OK] to display the firmware status.
See "Software application 990 REINER PCset" under "Operating interface" "Menu bar help".

Important notes 13
ERNST REINER GmbH & Co. KG Originalanleitung
2 Important notes
Before commissioning of the jetStamp 990 always read the operating instructions and in particular
the safety notes with care. This prevents insecurities in handling of the marking devices and
connected safety risks to keep you safe and avoid damage to the device.
Rechargeable batteries
2.1 Rechargeable batteries
The charging of the batteries is electronically controlled. This ensures that the battery
cells are charged optimally and gently.
Recharging
Fully charge rechargeable batteries before first application. Duration approx. three hours.
After the first full charge, the batteries do not yet reach full capacity.
You must expect that the normal service times will be undercut.
Reaching full capacity
Full capacity is achieved when the batteries are completely discharged and charged several times.
Charging is possible via the enclosed plug-on mains adapter or the connection socket , as
well as via a micro USB socket .

PCset Help jetStamp 99014
ERNST REINER GmbH & Co. KG
Originalanleitung
3 Your safety
Safety, description
Safety notes on rechargeable batteries
Safety notes
Safe handling of print cartridges
3.1 Safety, description
Warnings of dangers that lead to death or severe injury directly if not observed.
Warnings of dangers that may lead to death or severe injury if not observed.
Warnings of dangers that may lead to injury if not observed.
Warnings of dangers that may lead to property damage if not observed.
Observe the operating instructions.
You are asked to perform actions here.
Notes and advice to make handling your jetStamp 990 even easier.
Notes on instruction videos.

Your safety 15
ERNST REINER GmbH & Co. KG Originalanleitung
3.2 Safety notes on rechargeable batteries
Rechargeable batteries are subject to wear. A longer service life than six months cannot be
warranted.
Possible explosion in contact with fire.
Do not forcefully open rechargeable batteries.
Do not expose rechargeable batteries to severe heat
Do not expose rechargeable batteries to extremely low barometric pressures.
Injuries resulting from destruction of the battery when using unsuitable rechargeable batteries or non-
rechargeable batteries.
Only use the batteries intended for the device.
Type usage
Use only the enclosed mains adapter to charge the rechargeable batteries.
Only use rechargeable batteries (two each) type nickel metal hydride (NiMH, REINER item number:
946 192 - 000) of build AA.
Always replace all flat rechargeable batteries at once.
Unauthorised batteries may cause damage or malfunction.
Use only prescribed rechargeable batteries.
Insertion
Observe polarity of rechargeable batteries when inserting (refer to the battery symbols in the battery
compartment)!

PCset Help jetStamp 99016
ERNST REINER GmbH & Co. KG
Originalanleitung
3.3 Safety notes
Possible tripping and damage to the device due to device lines lying freely in the room.
Place the device lines so that they do not pose any danger source!
Damage to the device at improper transport.
Only use packaging that provides protection from impact and shock for the device!
Damage to the device by dewing.
Before commissioning, wait until the device has reached room temperature and is completely
dry!
Only trained specialists should perform repairs.
3.4 Safe handling of print cartridges
Possible blindness due to eye contact with ink.
Do not point the jetStamp 990 nozzles against people's faces!
Damage to health caused by ingestion of ink.
Do not swallow!
Keep the print cartridge out of the reach of children!

Preparation and commissioning 17
ERNST REINER GmbH & Co. KG Originalanleitung
4 Preparation and commissioning
Commissioning jetStamp 990/990 BT
Setting Date/Clock Time
Inserting the print cartridge
Saved print images
Selecting print image
Overview of stored print images
Printing the print image
Installing the REINER PCset
4.1 Commissioning
Only connect the device to the PC after the REINER PCset software has been installed
(see "Installing the REINER PCset").
With the installation of the REINER PCset software, the required USB drivers are installed. If a
connection is established between the PC and the device, the USB drivers are automatically
detected and loaded. If the device is connected without installing the REINER PCset software,
the installation of the device drivers fails.
The batteries must be fully charged before first application.
The menu selection on the device is in English only.
Inserting rechargeable batteries
Charge rechargeable batteries

PCset Help jetStamp 99018
ERNST REINER GmbH & Co. KG
Originalanleitung
4.1.1 Inserting rechargeable batteries
The batteries must be fully charged before first application. The charging time is approx. three
hours. The batteries are charged when the green charging indicator is off .
Inserting rechargeable batteries Fig.
Always replace all flat rechargeable batteries at once.
When the batteries are removed, the date, time and counter reading of the numbering machines are
maintained.
Open the battery compartment flap at the rear of the marking device.
Ensure correct polarity and insert the batteries.
Close the battery compartment flap .
4.1.2 Charge rechargeable batteries
Connect the mains adapter of the device to the connection socket provided for the mains adapter
and connect it to the mains, or connect the device to a running PC by micro USB .
Green charging indicator lights up.
Charging is complete when the charging indicator is off.

Preparation and commissioning 19
ERNST REINER GmbH & Co. KG Originalanleitung
4.2 Setting time and date
Push [MENU] and browse t u
until the display shows "Date/Time".
Push [SELECT].
"Change clock" appears.
Push [SELECT].
Display: yyyy mm dd hh mm
The year "yyyy" flashes; push t u in order to set the year.
Push [OK].
The month "mm" flashes; push t u in order to set the month.
Push [OK].
The day "dd" flashes; push t u in order to set the day.
Push [OK].
The hours "hh" flash; push t u to set the hours.
Push [OK].
The minutes "mm" flash; push t u in order to set the minutes.
Push [OK].
"Change clock" appears again.
Push [RETURN].
[Date/Time] appears.
In order to get right to the next menu item, push t u .
– OR –
In order to save the settings and leave the menu,
Push [RETURN] twice.
The selected print image appears.
4.3 Setting summertime
Push [MENU] and browse t u
until the display shows "Date/Time".
Push [SELECT] and browse t u
until the display shows "Summertime".
Push [SELECT].
The display "Europe" is flashing. Push t u to get to the display "America" or "None" and
make your selection.
Push [OK] to save.
"Summertime" appears.
Push [RETURN].
"Date/Time" appears.
In order to get right to the next menu item, push t u .
– OR –
In order to save the settings and leave the menu,
Push [RETURN] twice.
The selected print image appears.

PCset Help jetStamp 99020
ERNST REINER GmbH & Co. KG
Originalanleitung
4.4 Inserting the print cartridge
When using special ink (MP), observe the notes in the operating instructions on the
print cartridge.
Damage to health caused by ingestion of ink.
Do not swallow!
Keep the print cartridge out of the reach of children!
Inserting the print cartridge Fig. + +
Take the jetStamp 990 from the basis station .
Push [MENU].
"Cartridge change Start" appears on the display.
Push [SELECT].
Print carriage moves to the device centre.
"Cartridge change end" appears on the display.
Push the locking bracket into the rear-most position.
Unpack the new print cartridge and remove the protective film or clip.
(see operating instructions for the print cartridge P1).
